Standard Configuration - Avital Keyless Entry System. 2101L Owner's Manual

➜

standard configuration

Button
The locking/arming function is controlled by pressing this
button for one second. Pressing
seconds) after arming will honk the horn.
Button
The unlocking/disarming function is controlled by pressing this
button for one second. Pressing
seconds) after disarming will honk the horn.
Button
An optional auxiliary function are controlled by this button. (An
optional auxiliary function, such as trunk release, can be
controlled by pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
Button
The panic feature is controlled by pressing this button for one
second.
and
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
© 2008 directed electronics, inc.
Buttons
a 2nd time (within 5
a 2nd time (within 5
7
