OPERATOR MANUAL
FB 7100 PLUS
H0402EN00
10.2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB 7100 PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wittenborg FB 7100 PLUS

Summary of Contents for Wittenborg FB 7100 PLUS

  • Page 1 OPERATOR MANUAL FB 7100 PLUS H0402EN00 10.2011...
  • Page 2 The symbol indicates that the machine may not be disposed of as ordinary waste; it must be disposed of in accordance with the provisions of the European directive 2002/96/CE (Waste Electrical and Electronics Equipments - WEEE) and of any resulting national laws, for preventing any possible adverse effects on the environment and on human health.

  • Page 3: Table Of Contents

    Cleaning the instant ingredient canisters........50 Removing the solid waste container..........31 Cleaning the single chamber coffee canister....... 52 Cleaning the cup carrier ............... 32 Cleaning the dual chamber coffee canister ......... 53 Unlocking the drip tray..............33 10.2011 FB 7100 PLUS...
  • Page 4 Setting of free vend and key discount .......... 70 Time Discount ................71 Setting time discount..............73 Energy saving periods..............74 Setting energy saving periods............75 Display messages and trouble shooting Display messages ................ 77 Trouble shooting ................79 FB 7100 PLUS 10.2011...

  • Page 5: Introduction

    All communication transfer of ownership. with the machine, such as drink selection, rinsing functions, data retrieval and settings, is carried out by using the direct selection buttons. 10.2011 FB 7100 PLUS...

  • Page 6: Safety

    We recommend to install a fault current required prior to reconnecting the safety switch. The connections must be vending machine and he should made using an earthed safety plug socket additionally carry out a functional test. complying with valid regulations. FB 7100 PLUS 10.2011...
  • Page 7 There is danger of injuries! The door can be closed only after removing the key from the door switch. If power is turned on, be careful not to touch moving parts and electrical components. 10.2011 FB 7100 PLUS...

  • Page 8: Technical Data

    (min. inner diameter 6 mm.). It is recommended to apply a water tap on the water network outside the machine in an accessible position. FB 7100 PLUS 10.2011...
  • Page 9 Standard Instant ingredient canister: Approximately 2.6 l Further system require- Ambient temperature. Min. 4°C - max. 36°C (-2/+0) at 80% RH ments Acoustic emission: The A-weighted sound pressure level is below 70 dB. Subject to changes. 10.2011 FB 7100 PLUS...

  • Page 10: Product Presentation

    3 Freshbrew ingredient canister 4 Advertising poster 5 Operating panel 6 Door lock 7 Cup carrier 8 Pot platform Operating panel (fig.2): 1 Display 2 Payment panel 3 Selection panel 4 Pot panel/Discount key 5 Optical interface FB 7100 PLUS 10.2011...

  • Page 11: Machine Cabinet

    Dispense head Solid waste container 10 Cover for boiler 11 Door switch 12 Base tray 13 Cash box 14 Drip tray 15 Lock for drip tray 16 Retaining pin for cup carrier 10.2011 FB 7100 PLUS...

  • Page 12: Operation

    (See also diagram “SOverview of Operator ----SALES AUDIT---- *Total number and Technicians functions” on page 13.) Total turnover • jump to the top of a row, e.g. from “Turnover per drink” to “Total turnover”. FB 7100 PLUS 10.2011...
  • Page 13 Reset cash audit Continue? resetting of counters. *Reset counters ‘Esc’ button Press this button to exit a function without activating Reset cash audit Continue? it, e.g. avoid resetting a *Reset counters counter. 10.2011 FB 7100 PLUS...

  • Page 14: Navigation Buttons

    Press this button to continue to the next digit, Price: [Drink] e.g. in price setting *Set price: xx.xx functions. -> ‘OK’ button Press this button to save changes to settings in the Price: [Drink] *Set price: xx.xx system. -> FB 7100 PLUS 10.2011...

  • Page 15: Pot Panel (Multibrew)

    The display steps back one number each time a portion is dispensed, or if ‘optimised multibrew’ is active a progressive bar is shown. • Remove the pot when the drinks have been dispensed. 10.2011 FB 7100 PLUS...

  • Page 16: Discount Lock

    • After dispensing, remove the pot. • After dispensing, remove the cup. If you want one or more drinks at a dis- count: • • Press the multibrew button and insert the password needed to avoid free drink dispensing. FB 7100 PLUS 10.2011...

  • Page 17: Overview Of Operator And Technicians Functions

    No. per group, nres No. per group, res (See explanation on previous pages). Turn. p. group,nres Turn. p. group,res Card audit No. per drink, nres No. per drink, res Turn. p. drink,nres Turn. p. drink,res Continued on next page 10.2011 FB 7100 PLUS...
  • Page 18 MB. number, res MB. turnover, res Discount key audit D.Key number ,nres D.Key turnov. ,nres D.Key number ,res D.Key turnov. ,res Time Discount audit T.Disc number ,nres T.Disc turnov.,nres T.Disc number ,res T.Disc turnov.,res Continued on next page FB 7100 PLUS 10.2011...
  • Page 19 Printing Not Resetable Resetable Cash action Cash collected Dispense coins Manual filling Reset tube contents Basic operations Change prices Global price Price per drink Step prices Change quantities Drink On/Off Change group Continued on next page 10.2011 FB 7100 PLUS...
  • Page 20 Show Install. Date Set Install. Date Energy saving Save Energy On/Off Set Day(s) Set Time Set Temperature Set Doorlight Set counters on/off Selfcheck setting Gr. counters on/off 100% discount mode Use EVA-DTS events Continued on next page FB 7100 PLUS 10.2011...
  • Page 21 Softener counter Ex.WaterCirculation Set Rinse Timeout Brewer assembly chk Clogged filter chk Global dr. scaling Reset relationship Change Comm. route Closed door Serial XModem Serial EDDCMP IR XModem IR EDDCMP Back to terminal Continued on next page 10.2011 FB 7100 PLUS...
  • Page 22 Zero vend mode Zero vend index Revalue Immediate change Currency code(auto) Currency code(man) Coin validator Decimal point pos. Freevend count.mode Delayed Paymentmode Set Cash Sale Sess. Complete Mode Autom Cashaudit Res Pricelist Start Nr. Continued on next page FB 7100 PLUS 10.2011...
  • Page 23 Diagnostics/Test Overall functions Wittlink test Full dispense test Test vend Cup handling Sensor test User interface Button/Key test Display test Pre. sel. led test Door light toggle Test Init.text Coin return motor Continued on next page 10.2011 FB 7100 PLUS...
  • Page 24 Brewer positions Move piston forward Move piston back Change password GSM settings GSM On/Off PIN Code Pre-Alarms Set GSM Thresholds Reset Pre-Al. cnt Bank ID's Reset GSM relations DaylightSaving UP KEY Utility Setup files Statistics files FB 7100 PLUS 10.2011...

  • Page 25: Shortcuts

    .. Perform a rinse function Step 5 Perform a test vend Step 7 Read the counters Step 8 Proceed to the menu functions Step 9 1. This short cut is not present in all machines. 10.2011 FB 7100 PLUS...
  • Page 26 Press “3” ----SALES AUDIT--- *Total number, nres Total turnover,nres and, if open, close the door to go directly to reading the counters. From here you can select one of the available counters. FB 7100 PLUS 10.2011...
  • Page 27 Operation Step Action Display Press “4” --MENU SELECTION-- *Operator Technician and, if open, close the door to go directly to the menu selections. From here you can select one of the menus 10.2011 FB 7100 PLUS...

  • Page 28: Additional Features

    • The machine can be set to enable selection of several drinks, one after the other, from only one payment action by coins or card. Single-vend • The machine can be set to return coins / release payment card after each drink selection. FB 7100 PLUS 10.2011...

  • Page 29: Cleaning And Maintenance

    - nylon coffee filter has a neutral Make sure that all components are white seal. installed correctly after the clean- ing procedure. Clean the inside and outside of the vending machine by using a clean damp cloth, and do not splash it. 10.2011 FB 7100 PLUS...

  • Page 30: Maintenance Routines

    Soft clean cloths or paper towels Removing and emptying the solid waste container Ingredients Cleaning the cup carrier Cleaning the drip tray Cleaning the machine interior and exterior Mounting the cleaned parts Rinsing machine Last check FB 7100 PLUS 10.2011...

  • Page 31: Schedule For Deep And Occasional Maintenance Routines

    Cleaning machine interior and exterior (max. 30 minutes at 60°C, max. 30 seconds at 80°C). Mounting cleaned parts Rinsing and last check 10.2011 FB 7100 PLUS...
  • Page 32 Cleaning and maintenance Interval Type of work / Check Exchange kit (hygiene kit) Occasional Cleaning the instant ingredient canisters Once a month Cleaning the freshbrew ingredient canister Replacing the filter roll Rinsing / descaling the brewer FB 7100 PLUS 10.2011...

  • Page 33: Regular Cleaning

    If power is turned on, be careful not isters. to touch moving parts and electri- • Push the outlet tube upwards to close the cal components! outlet spout of the wanted canister (fig. 10). 10.2011 FB 7100 PLUS...

  • Page 34: Filling The Freshbrew Ingredient Canister

    • Push base tray back in place. pull forwards over the end stops in guiding rail. Place canister on a plain, clean surface. • Fill the canister with instant ingredient, press lid slightly down and push back canister in place. FB 7100 PLUS 10.2011...

  • Page 35: Removing The Solid Waste Container

    • Close the lid. • Take out the solid waste container • Remove plastic bag from container, and insert a new liner. • Push base tray back in place. • Wipe clean the area behind the solid waste container. 10.2011 FB 7100 PLUS...

  • Page 36: Cleaning The Cup Carrier

    (fig. 16). The complete cup carrier is dish- washer-proof. FB 7100 PLUS 10.2011...

  • Page 37: Unlocking The Drip Tray

    • Remove the lid and empty the tray. cup station. (fig. 19) • Clean drip grid (a), lid and tray in hot water with cleaning agent and wipe parts dry (fig. 20). Wipe sensor (fig. 20,a) in lid dry. 10.2011 FB 7100 PLUS...

  • Page 38: Cleaning Inside And Outside

    Regular cleaning Cleaning inside and outside Mounting of cleaned parts • Clean the door and the housing inside • Remount all parts. and outside, and finally the bottom with a clean, damp cloth (fig. 21). FB 7100 PLUS 10.2011...

  • Page 39: Rinsing Machine

    FB 7100 Rinsing machine Down Right Left/Top • Have an empty pot (min.1,5 l) ready to place on the pot platform (fig. 22) • Turn to the display and follow the diagram to perform a machine rinse. 10.2011 FB 7100 PLUS...

  • Page 40: Last Check

    (see diagram above). In this case the drink will not be included in the Sales Audit counter ( See “Calling and resetting counters” on page 56.). There is a risk of scalding from hot water. FB 7100 PLUS 10.2011...

  • Page 41: Deep Cleaning

    - whipper wheel for coffee mixer (option) - dispense head with outlets and hoses - brewer cylinder with mixing funnel, mixing funnel hood and valve - filter and support for filter - scraper - cup carrier. 10.2011 FB 7100 PLUS...

  • Page 42: Filling The Instant Ingredient Canisters

    (fig. canisters one by one as described in 26). regular cleaning • Pull forwards the base tray (fig. 25). (fig. 27). • Leave the outlet spouts closed, and push canisters back in place. FB 7100 PLUS 10.2011...

  • Page 43: Filling The Freshbrew Ingredient Canister

    30 mm (fig. 28). place. Check to ensure that the canister is locked in place. Do not use pressure to force more coffee / tea into the canister as this could damage the dosing system. 10.2011 FB 7100 PLUS...

  • Page 44: Cleaning The Ingredient Waste Tray

    • Repeat procedure until all mixing funnels • Relocate the ingredient waste tray. • Loosen locking rings of mixing funnels by have been removed. pressing release lever anti-clockwise and pull out mixing funnel leaving hose back on (fig. 32). FB 7100 PLUS 10.2011...

  • Page 45: Cleaning The Powder Trap

    • Pull off the whipper wheel (fig. 36) and the relocate items in reverse order. lower sealing ring. The machine is fitted with a diffus- • Soak all removed parts in hot water with er or a coffee mixer. cleaning agent. 10.2011 FB 7100 PLUS...

  • Page 46: Removing The Dispense Head

    Lift off and remove the coffee waste chute (fig. 39). (fig. 39). FB 7100 PLUS 10.2011...

  • Page 47: Cleaning The Freshbrew Unit

    1 - Mixing funnel hood 2 - Mixing funnel 3 - Upper valve 4 - Air cylinder 5 - Brewer cylinder 6 - Cylinder grip 7 - Filter 8 - Filter gasket 9 - Filter support spring 10 - Scraper 10.2011 FB 7100 PLUS...

  • Page 48: Disassembling The Freshbrew Unit

    Deep cleaning Disassembling the freshbrew unit The parts to be cleaned are disassembled in the sequence indicated below: The illustrations to be read row by row 1) from left to right, 2) from top to bot- tom. FB 7100 PLUS 10.2011...

  • Page 49: Reassembling The Freshbrew Unit

    Reassembling the freshbrew unit The parts of the freshbrew unit are reassembled in the sequence indicated below: The illustrations to be read row by row 1) from left to right, and 2) from top to bottom. 10.2011 FB 7100 PLUS...

  • Page 50: Emptying The Solid Waste Container

    Emptying the solid waste container Cleaning the base tray • Take out the solid waste container, empty • Remove and clean the base tray from it and insert a new liner (fig. 40). machine (fig. 41). FB 7100 PLUS 10.2011...

  • Page 51: Cleaning The Cup Carrier

    • Remove the cup carrier (fig. 42) (see • Take out and clean the drip tray and its (fig.44). regular cleaning). parts (fig. 43 and 44). (see regular cleaning). • Clean the drip grid and tray (see regular cleaning). 10.2011 FB 7100 PLUS...

  • Page 52: Cleaning Inside And Outside

    45 thoroughly with clean and warm water. • Remount all canisters and push the outlet • Dry all parts with a dry cloth. tubes downwards to open the outlet spouts of the canisters (fig. 46). FB 7100 PLUS 10.2011...

  • Page 53: Rinsing And Last Check

    • Turn on machine with the main switch. • Rinse machine twice (see regular cleaning). • Clean outside of machine with a clean damp cloth (fig. 46). • Perform a test dispensing by pressing a selection button e.g. coffee with milk and sugar. 10.2011 FB 7100 PLUS...

  • Page 54: Occasional Routines

    • Take the canister by the handle and pull it canister and remove the dosing system. forwards (fig. 48) until end stops in guiding rail. Lift the canister upwards and pull forwards over the end stops. The lid is automatically triggered open. FB 7100 PLUS 10.2011...
  • Page 55 • Let components dry completely The canisters must always be re- • Reassemble instant ingredient canister in turned to their original position. reverse order. 10.2011 FB 7100 PLUS...

  • Page 56: Cleaning The Single Chamber Coffee Canister

    • Place the canister upside down on a • Wipe the inside of the canister with a soft, table. clean and dry brush. Take care not to damage the mixing wire. The canister and canister parts are not dishwasher-proof. FB 7100 PLUS 10.2011...

  • Page 57: Cleaning The Dual Chamber Coffee Canister

    Do not use a brush. one coffee chamber and one dosing system. • Clean the canister in hot water. 10.2011 FB 7100 PLUS...

  • Page 58: Replacing Brewer Filter And Gasket

    - Nylon filter for coffee: every 25.000 dispensings - Gasket for metal filter: every 50.000 dispensings. FB 7100 PLUS 10.2011...

  • Page 59: Rinsing / Descaling The Brewer

    • Open the door, remove the coffee canister, brewer must either be disassembled and rinsed manually turn to the display and follow the diagram or a new rinse procedure must be to perform a rinse of the brewer. performed. 10.2011 FB 7100 PLUS...

  • Page 60: Additional Routines

    Total: 00000.00 No. per drink, nres Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 No. per drink, res Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 Turn. p. drink,nres Cash audit Continued on next page FB 7100 PLUS 10.2011...
  • Page 61 MB per drink, nres Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 MB per drink, res Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 No. per group, nres Cash audit Continued on next page 10.2011 FB 7100 PLUS...
  • Page 62 Total: xxxxxx Group 2 Total: 000.00 Turn. p. group,nres Group 1 Total: xxxxxx Group 2 Total: 000.00 Turn. p. group,res Group 1 Total: xxxxxx Group 2 Total: 000.00 Card audit Cash audit Continued on next page FB 7100 PLUS 10.2011...
  • Page 63 Coffee Total: 0000000 Coffee with milk Total: 0000000 Turn. p. drink,nres Coffee Total: 0000000.00 Coffee with milk Total: 0000000.00 Turn. p. drink,res Coffee Total: 0000000.00 Coffee with milk Total: 000.00 Cash audit Continued on next page 10.2011 FB 7100 PLUS...
  • Page 64 Collected money Amount: 00000.00 Manually filled Amount: 00000.00 Manually delivered Amount: 00000.00 Value overpay Amount: 00000.00 Cashless audit Dispensed change Amount: 00000.00 * Applicable only to BDV and MDB/ ICP coin mechanisms. Continued on next page FB 7100 PLUS 10.2011...
  • Page 65 No. per drink, nres Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 No. per drink, res Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 MB. discount audit No. per group, res Continued on next page 10.2011 FB 7100 PLUS...
  • Page 66 Number: xxxxx MB. turnover, res Amount: 00000.00 Discount key audit D.Key number, nres Number: xxxxx D.Key turnover, nres Amount: 00000.00 D.Key number res Number: xxxxx D.Key turnover, res Amount: 00000.00 Time Discount audit Continued on next page FB 7100 PLUS 10.2011...
  • Page 67 Additional routines Discount key audit Diagram continued Time Discount audit T.Disc number ,nres Number xxxxxxx T.Disc turnov., nres Number xxxxxxx T.Disc number ,res Number xxxxxxx T.Disc turnov., res Number xxxxxxx Step price audit Continued on next page 10.2011 FB 7100 PLUS...
  • Page 68 [Group] Total: 0000000 Reset of sales Reset counters Reset sales audit Continue ? audit finished Reset of cash Reset cash audit Continue ? audit finished Reset of test Reset test audit Continue ? audit finished Printing FB 7100 PLUS 10.2011...
  • Page 69 Printing Errors Continue? in progress Please wait Printing audit Cash Audit Printing Continue? in progress Please wait Printing audit Printing Test Audit Continue? in progress Please wait Printing audit Group Counters Printing Continue? in progress Resettable 10.2011 FB 7100 PLUS...
  • Page 70 Printing audit Printing Errors Continue? in progress Please wait Printing audit Printing Cash Audit Continue? in progress Please wait Printing audit Printing Test Audit Continue? in progress Please wait Printing audit Printing Group Counters Continue? in progress FB 7100 PLUS 10.2011...

  • Page 71: Emptying The Cash Box

    • Pull out the cash box and empty it. (fig. 58) • Turn to the display and follow the diagram to register the removed amount electronically. The amount is registered under “Collected money” (See “Calling and resetting counters” on page 56). 10.2011 FB 7100 PLUS...

  • Page 72: Adding Change Manually

    “Manually filled” (See “Calling Dispense coins and resetting counters” on page 56) Press < OK> to Cash audit is Manual filling adjust audit now adjusted * Applicable only to BDV and MDB/ ICP coin mechanisms. FB 7100 PLUS 10.2011...

  • Page 73: Changing Prices

    Set step price Set step price(s) Select drink Preselection 1(+) Value : 00.00 -> Preselection 1(-) Global price (+) Global stepprice(+) Set value : 00.00 -> Global price (-) Global stepprice(-) Set value : 00.00 -> 10.2011 FB 7100 PLUS...

  • Page 74: Setting Of Free Vend And Key Discount

    • turn free vend on or off Technician Counter • set or change key discount rates FB 7100 Cash action Basic operations Service information Machine settings Set freevend, global (Off = 0, On = 1):1 Key discount Set percentage: 000 FB 7100 PLUS 10.2011...

  • Page 75: Time Discount

    • A period cannot have a ‘start time’ later than the ‘end time’, see Non Example next page. • The same time period cannot include days from different weeks, i.e. a period cannot be set from Monday to Monday. 10.2011 FB 7100 PLUS...
  • Page 76 Set end time 14:00 Period 2 Set start day Su=6 Set start time 10:00 Set end day Su=6 Set end time 14:00 Result: Time discount is given on Saturdays and Sundays between 10:00 a.m. and 2:00 p.m. FB 7100 PLUS 10.2011...

  • Page 77: Setting Time Discount

    Set Time discount (0-100) :20 -> Set start day: Set end day: Set day(s) Period 1 (Mo=0, Su=6, All=7):7 (Mo=0, Su=6, All=7):7 Set start time: Set end time: Set time Period 1 Time: 22:00 Time: 23:59 -> 10.2011 FB 7100 PLUS...

  • Page 78: Energy Saving Periods

    The temperature during the energy saving period is set in ‘set Result: The machine is not ‘shut down’ as the end time must not be earlier than temperature’ the start time for the same day or the setting ‘ALL’. FB 7100 PLUS 10.2011...

  • Page 79: Setting Energy Saving Periods

    When the selection buttons have been left untouched for more than 10 minutes after the last drinks dispensing, and an energy saving period is still in force, the machine returns to the energy saving mode. 10.2011 FB 7100 PLUS...
  • Page 80 Set end day: (Mo=0, Su=6, All=7):1 Set start time: Set time Period 1 Time: 00:00 -> Set end time: Time: 00:00 Set temperature -> Set temperature Temp.: 000 -> Set doorlight Set doorlight 1=On / 0=Off:1 -> FB 7100 PLUS 10.2011...

  • Page 81: Display Messages And Trouble Shooting

    • Remove impurities from water supply connection. • Empty and clean base tray. Wipe it dry. Base tray full • Empty and clean drip tray. Wipe sensor dry. Drip tray full • Remove cup from cup carrier. Please remove cup 10.2011 FB 7100 PLUS...
  • Page 82 • Remove pot from pot platform. Please remove pot • Remove blocking object from upper valve of brewing cylinder. No SB1 (or 2) cyl. Pressure • Clean the brewer unit. SB Piston error • Clean the brewer unit. SB Scraper error FB 7100 PLUS 10.2011...

  • Page 83: Trouble Shooting

    Ingredients are moist and become lumpy in canisters cleaner from outside or take out fan and clean box from the inside of the machine. • Check for blockage around mixing funnels. Remove and rein- stall components as necessary. 10.2011 FB 7100 PLUS...
  • Page 84 • Check if sensor for drip tray is soiled. Clean as necessary. • Check if mixing funnels are blocked, and clean as necessary. No drinks are delivered • Check the coffee/tea filter, and clean as necessary. • Reassemble freshbrewer unit correctly. Freshbrewer unit is malfunctioning FB 7100 PLUS 10.2011...
