- Page 1 ASSEMBLY INSTRUCTIONS CW343 FLAT PANEL AUDIO/VIDEO SYSTEM...
- Page 2 FOR YOUR SAFETY, PLEASE FOLLOW THESE PRECAUTIONS: ! DO NOT PLACE ITEMS ON THE SHELVES WHICH EXCEED THE MAXIMUM WEIGHT LIMITS OF 125 LBS. FOR TOP SHELF, 50 LBS. FOR THE MIDDLE SHELF, AND 75 LBS. FOR THE BOTTOM SHELF. ALWAYS PLACE THE HEAVIEST COMPONENTS ON THE BOTTOM SHELF.
- Page 3 Parts List Quantity Quantity Part Part DSYF1 DSYF13 10 mm DSYF2 DSYF14 15 mm DSYF3 DSYF15 28 mm DSYF4 DSYF16 70 mm DSYF5 DSYF17 35 mm DSYF6 DSYF18 DSYF7 DSYF19 DSYF8 DSYF20 DSYF9 DSYF21 DSYF10 DSYF22 12 mm DSYF11 DSYF23 DSYF12 DSYF24...
- Page 4 assEMBLY iNstrUCtiONs NOTE: 2 PEOPLE ARE RECOMMENDED TO ASSEMBLE THIS FURNITURE. TO AVOID DAMAGE DURING ASSEMBLY, IT SHOULD BE ASSEMBLED ON A SOFT SURFACE. 1. On a very SOFT and flat surface, CAREFULLY LAY the two curved Wood Sides (DSYF17, DSYF18) face down and approximately 52 inches apart from one another.
- Page 5 Fig. 2 DSYF18 DSYF19 DSYF16 DSYF17 DSYF2 4. With the help of an assistant to support the curved Wood Sides (DSYF17, DSYF18), carefully ATTACH the Bot- tom Shelf Support Frame (DSYF19) to the back side of the Bottom Wood Frame (DSYF16) as shown using eight 15 mm Screws (DSYF2).
- Page 6 Fig. 3 DSYF3 DSYF14 DSYF20 DSYF19 DSYF3 5. With the Bottom Shelf Support Frame (DSYF19) laying flat on the floor, ATTACH the CMS ® (Cable Management System) Post (DSYF20) to the Top Shelf Rear Support Bar (DSYF14) using two 28 mm Screws (DSYF3). Do not yet tighten fully. 6.
- Page 7 DSYF1 Fig. 4 7. Carefully SLIDE the Left and Right Side Poles (DSYF12, DSYF13) into the holes in the curved Wood Sides (DSYF17, DSYF18). DSYF12 Note (!): Pay close attention to the position of each Side Pole in re- gards to its Part Number, and posi- tion as shown above.
- Page 8 10. SCREW two Shelf Support Posts (DSYF11) into the DSYF14 prethreaded holes in the DSYF6 sides of the curved Wood Sides (DSYF17, DSYF18). 11. ATTACH two sets of Shelf Support Clips (DSYF8) to the DSYF8 DSYF20 holes in the CMS ®...
- Page 9 Fig. 6 DSYF14 DSYF23 DSYF5 DSYF13 DSYF12 DSYF10 15. With the help of an assistant, CAREFULLY PLACE the Top Glass Shelf (DSYF23) onto the stand assembly as shown. SE- CURE the Top Shelf using two 35 mm Screws (DSYF5) as shown from beneath the Top Shelf Rear Support Bar (DSYF14) and into the Shelf Discs on the underside of the Shelf.
- Page 10 Shelf Support Clips DSYF17 DSYF22 (DSYF8) as shown. Be careful not to overtighten. NOTE (!): Make sure the CW343 is on a flat and level surface, and that all Glass Shelves are secure and level before attempting to...
