14. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex key in a secure place; the large hex key is
used to adjust the walking belt (see page 23).
If you purchase the optional chest pulse sensor (see page 19), follow the steps below to install the receiver
included with the chest pulse sensor.
1. Remove the key from the console and unplug
the power cord.
Remove the 3/4" Screw (23) and the Access Door
(100) from the back of the Console Base (98).
2. Connect the wire on the receiver (A) to the indi-
cated wire extending from the Console Base (98).
Hold the receiver so the small cylinder is ori-
ented as shown and is facing the Console
Base. Attach the receiver to the plastic posts on
the Access Door (100) with the two included
small screws.
3. Make sure that no wires are pinched. Reattach
the Access Door (100) with the 3/4" Screw (23).
Discard the other wires included with the re-
ceiver.
98
100
23
11
Wire
Small
Screws
Small
A
Cylinder
