Peakeep MHP3132 Plus Instruction Manual

Instruction Manual
MHP3132 Plus

Getting Started

1. Remove the battery compartment cover from the bottom of the unit, properly align and insert 2 AAA alkaline batteries,
replace cover.
2. Uncoil the antenna and extend to its full length.
3. Plug the unit into an AC power outlet. The time display will blink and the unit is in the time set mode.
Note:
Backup batteries maintain time, alarm, and radio station pre-sets; however they do not power the display, nor trigger the alarm
during power interruptions. For best results, replace batteries every 6 months.
Set Time
1. With the radio off and the time display blinking, set the unit to the current time using the T-/Hr and the T+/Min buttons.
2. When the current time is displayed, press the M+/Set button. The display will stop blinking.
Reset Time When Need
1. With the radio off, press and hold the M+/Set button until the time display starts to blink.
2. Set the unit to the current time using the T-/Hr and the T+/Min buttons.
3. When the desired time is displayed, press the M+/Set button. The display will stop blinking.
Note:
When the time display starts to blink, the seconds' timer re-sets to zero. If no buttons are pushed within 30 seconds, the unit
will revert to previous settings. When setting current time, be careful to select AM or PM, as appropriate, by monitoring the
PM indicator light.
Set Alarm
1. With the radio off, press V-/AL1 to toggle between Buzzer and Radio alarm modes, as indicated by the buzzer alarm indicator
or radio alarm indicator lights. In either mode, the alarm time display will blink.
2. Set Alarm 1 time using the T-/Hr and the T+/Min buttons while alarm time is blinking.
3. When the desired Alarm 1 time is displayed, press the M+/Set button.
4. For Alarm 2, press V+/AL2 and repeat the remainder of steps 1, 2, and 3.
Note:
When setting alarm times, the factory default is 12:00 AM, be careful to select AM or PM, as appropriate, by monitoring the PM
indicator light. If no buttons are pushed within 30 seconds, the unit will revert to previous settings.
Turn Alarm On
With the radio off, press AL1 repeatedly to select Buzzer or Radio alarm modes, as indicated by the buzzer alarm indicator or
radio alarm indicator lights. Same procedure applies for alarm 2 with AL 2 button.
Completely Shut Alarm Off
With the radio off, press V-/AL1 or V+/AL2 buttons repeatedly, , as appropriate, until both the buzzer and radio alarm
indicators are off.
Wake to Alarm
When the alarm sounds, the appropriate alarm indicator blinks. The buzzer alarm starts low and increases in volume. The
radio alarm plays the most recently tuned station at the selected volume. Both alarm options sound for up to 1 hour.
Suspend Alarm (Snooze Function)
When alarm goes off, press the SNOOZE button to temporarily suspend the alarm for 5 minutes.
Reset the Alarm for the Next Day
When alarm goes off, press any button except the SNOOZE button. This re-sets the alarm for the next day at the same time.
