Summary of Contents for Genaray ESDS-25
-
Page 1: User Manual
Escort ™ LED LIGHTS USER MANUAL... - Page 2 The Escort fixtures are designed with an integrated 2.4 GHz receiver with 99 channels. The lights can be controlled individually or globally with the Genaray MB-WRT remote. Advanced features include an adjustable dimmer from 10% to full brightness and built-in barndoors with a hammered reflective silver finish.
- Page 3 TABLE OF CONTENTS Precautions .............4 Contents Include ..........6 Product Overview ...........8 Mounting the Light ........12 Powering the Light ........15 Operating the Escort ........17 Storing the Light ...........21 FCC Declaration of Conformity ....21 Product Specifications .........22 Escort LED Lights - USER MANUAL...
-
Page 4: Precautions
· Do not attempt to disassemble or instructions, and keep this repair the equipment—doing so will manual in a safe place. void the warranty, and Genaray will not be responsible for any damage. · Keep this unit away from water and any flammable gases or liquids. - Page 5 · Keep this unit away from children. · Use only parts provided by the manufacturer. · Make sure the item is intact and that there are no missing parts. · All images are for illustrative purposes only. Escort LED Lights - USER MANUAL...
-
Page 6: Contents Include
CONTENTS INCLUDE ESDS-25 ESDF-75 · Genaray ESDS-25 Escort · Genaray ESDF-75 Escort Daylight LED Spot Light Daylight LED Flood Light · Diffusion filter · Diffusion filter · Tungsten filter · Tungsten filter · Stand mount · Stand mount · Handle mount ·... -
Page 7: Esdf
ESDFS-KIT ESBF-75 · ESDS-25 · Genaray ESBF-75 Escort Bi-Color LED Flood Light · ESDF-75 (×2) · Diffusion filter · Diffusion filters (×3) · Stand mount · Tungsten filters (×3) · Handle mount · Stand mounts (×3) · AC adapter · Handle mounts (×3) ·... -
Page 8: Product Overview
Diffuser/filter slot LED array PRODUCT OVERVIEW Barndoors 1/4˝-20 mounting socket Escort LED Lights - USER MANUAL... - Page 9 Battery contacts LED display Battery compartment Power switch Battery release buttons Power socket 1/4˝-20 mounting 1/4˝-20 mounting socket socket Battery indicator Mounting slot Escort LED Lights - USER MANUAL...
- Page 10 Handle mount Stand mount Mounting plate Mounting plate Release button Release button 1/4˝-20 threaded mount Umbrella mount Tilt adjustment PRODUCT Guide pin knob OVERVIEW Locking wheel Locking knob 5/8˝ socket Tungsten filter (Daylight models only) Diffuser Escort LED Lights - USER MANUAL...
- Page 11 Color temperature Channel number Dimmer number Plus button Minus button Mode button Set button Escort LED Lights - USER MANUAL...
-
Page 12: Mounting The Light
MOUNTING THE LIGHT MOUNTING THE ESCORT TO A LIGHT STAND 1. Slide the stand mount’s mounting plate into the mounting slot of the fixture until it clicks into place. Note: Make sure the tilt adjustment knob is locked before you mount the fixture onto a light stand. - Page 13 ALTERNATE METHOD (WITHOUT To mount the fixture horizontally: THE STAND MOUNT) 1. Detach the mounting plate from the handle mount by To mount the fixture vertically: loosening the locking wheel. · Attach a ball or photo head to your tripod, 2.
- Page 14 MOUNTING THE ESCORT TO THE HANDLE MOUNT 1. Align the 1/4˝ threaded mount and guide pin with the socket on the mounting plate. Turn the locking wheel until the mounting plate is securely flush with the top of the handle mount. 2.
-
Page 15: Powering The Light
POWERING THE LIGHT The Escort can be powered directly from USING THE FIXTURE WITH an AC outlet or the two included batteries. BATTERY POWER Important Important The Escort is a multi-voltage fixture The Escort will work only when capable of running on 100–240 V, both batteries are installed. - Page 16 Charging the batteries: Using the cigarette lighter cable: The four battery indicator lights each 1. Attach the battery to the charger as represent 25% charge. When the described in the previous section. remaining charge is less than 25%, the 2. Plug the cigarette lighter adapter cable bottom light will blink to indicate that into your car’s cigarette lighter, and you need to recharge the battery.
-
Page 17: Operating The Escort
The Escort and the remote must be set to lights and preventing interference from the same channel. To set the channel on the other remote devices in your area. remote, refer to the user manual included with the Genaray MB-WRT wireless remote. Escort LED Lights - USER MANUAL... - Page 18 100 K increments, or press and hold to change rapidly. Since the ESDS-25 and ESDF-75 are daylight balanced, the color temperature 3. The color temperature setting will stop stays at a constant 5600 K.
- Page 19 The dimmer value can be adjusted, but the refer to the user manual included with color temperature cannot be changed. the Genaray MB-WRT wireless remote. To return to adjustable temperature mode, tap the Set ( ) button twice. The color temperature reading will return to the previously set temperature.
- Page 20 SHAPING AND DIFFUSING THE LIGHT TUNGSTEN FILTER (ESDF-75 AND ESDS-25 ONLY) Barndoors and the included diffuser can shape or modify the light. The orange tungsten filter changes the color temperature of your light from 5600 K BARNDOORS (daylight) to 3200 K (warm tungsten light).
-
Page 21: Storing The Light
STORING FCC DECLARATION OF THE LIGHT CONFORMITY When you're finished using the light, push This device complies with Part 15 of the power switch to the Off position. the FCC rules. Operation is subject to the following two conditions: Remove the power cord or the batteries from the fixture, and close the barndoors 1. -
Page 22: Product Specifications
PRODUCT SPECIFICATIONS All Models LED count: 680 DC cable length: 12.6´ (3.8 m) Dimming: 10% to full brightness Car charger cable length: 3.9´ (1.2 m) Electrical consumption: 40 W Dimensions (W × H × D): 10.35˝ × 7.2˝ × 2˝ (26.3 ×... - Page 23 ESDS-25 (Daylight Spot Light) ESDF-75 (Daylight Flood Light) Color temperature: 5600 K Color temperature: 5600 K (3200 K with tungsten filter) (3200 K with tungsten filter) Luminance: 6790 lx @ 1 m Luminance: 3330 lx @ 1 m Coverage: 25°...
- Page 24 ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
