Light4Me COB PIXEL BAR 10 RGB User Manual

Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
This pixel COB Par can make very nice and bright effect as an architectural wall wash or for performance stages
where traditional stage lighting emit a lot of heat onto performers. Please read the manual before operation.

A. SPECIFICATION

1.
Voltage: AC 100V-240V, 50Hz/60Hz
2.
Power consumption: 105W
3.
LED: COB 10*Tri-9W RGB
4.
Beam angle: 55 degree
5.
DMX channels: 3, 5, 30 CH
6.
Operation mode: LCD display
7.
Working temperature: -10~40℃
8.
Dimension: 900*182.5*111mm
9.
Net weight: 7kgs
10. Power linking: 4pcs@110V, 8pcs@240V
11. Lumen:
R
227lux@2m
G
303lux@2m
B
296lux@2m
Full on
767lux@2m

B. OPERATION

This fixture has six working modes; press the "MODE" button can switch the modes.
 Built-in programs
 Auto running
 DMX mode
 Master/slave
 Sound-active
 Static color
LIGHT4ME COB PIXEL BAR 10 RGB
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COB PIXEL BAR 10 RGB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Light4Me COB PIXEL BAR 10 RGB

Summary of Contents for Light4Me COB PIXEL BAR 10 RGB

  • Page 1 LIGHT4ME COB PIXEL BAR 10 RGB User Manual This pixel COB Par can make very nice and bright effect as an architectural wall wash or for performance stages where traditional stage lighting emit a lot of heat onto performers. Please read the manual before operation.
  • Page 2 1. Built-in Programs Mode 1) Press “MODE” button enter built-in programs mode “Program Mode”, Press “SETUP” button enter into programs effect “Program：01”, press “UP” or “ DOWN” button to select “Program：01- Program：19”. 2) When select the programs effect “Program：01” a. Press “SETUP” button could set the static color effect “1.R Flash000”, could set the static color “1.R”, “2.RG”, “3.G”, “4.GB”, “5.B”...
  • Page 3 78—90 PROGRAM08 91—103 PROGRAM09 104—116 PROGRAM10 117—129 PROGRAM11 130—142 PROGRAM12 143—155 PROGRAM13 156—168 PROGRAM14 SPEED FLASH 169—181 PROGRAM15 0--255 0--255 182—194 PROGRAM16 195—207 PROGRAM17 208—220 PROGRAM18 221—233 PROGRAM19 234—255 SOUND Sensitivity NO USE 0--255 DMX Mode 2：“Chan：05”, Red 0-255 Green 0-255 Blue 0-255 Dim 0-255 Flash 0-255...
  • Page 4 value “Red 000 -Red 255” via “UP” or “DOWN” button. 3) Press “SETUP” button enter green brightness setting menu “Red 255 Green255”, could set the brightness value “Green000 - Green255” via “UP” or “DOWN” button. 4) Press “SETUP” button enter blue brightness setting menu “Blue 255”, could set the brightness value “Blue 000 - Blue 255”...
