Specifications

General Specifications
Display
Meter Power
Auto Power OFF
Current output capability
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Dimensions
Weight
Accessories Supplied
Range Specifications
Mode Function
Measure Current
Percent (%)
Source Current
Percent (%)
Power Loop Power

Battery Replacement

When the battery symbol appears on the LCD, replace the 9V battery as soon as possible.
1. Open the calibrator's lid as far as possible.
2. With a coin or wide blade screwdriver, open the battery compartment moving in the direction
of the arrow embossed on the compartment cover (location of compartment is identified in
the meter description section).
3. Replace the battery and close the battery compartment cover.
You, as the end user, are legally bound (Battery ordinance) to return all used batteries
and accumulators; disposal in the household garbage is prohibited!
You can hand over your used batteries / accumulators at collection points in your
community or wherever batteries / accumulators are sold!
Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the
end of its lifecycle
actoolsupply.com
9999 count LCD
9 volt battery or AC adaptor
Meter automatically powers off after 10 minutes of inactivity
24mADC at 1000 ohms
5ºC to 40ºC (41ºF to 104ºF)
o o
-20 C to 60 C (- 4
Max 80% up to 31ºC (87ºF) decreasing linearly to 50% at 40ºC
(104ºF)
<80%
2000meters (7000ft.) maximum
96 x 118 x 45mm (3.8 x 4.7 x 1.8") folded
340g (12 oz.)
9V battery, AC Adaptor and calibration cable with spade lugs
Range (Resolution)
0 to 50mA (0.01mA)
-25% to +230% (0.1%)
0 to 24mA (0.01mA)
-25% to +125% (0.1%)
24VDC, <50mA
6
actoolsupply.com
o o
F to 140 F)
Accuracy (% of reading
± (0.075% + 1 digit) or ± 3 digits
(whichever is greater)
412300A-EU-EN v3.4 07/13
