Summary of Contents for SonicWALL Email Security 200
-
Page 1: Email Security
® SonicWALL Email Security Getting Started Guide Version SonicWALL, Inc. 1143 Borregas Avenue Sunnyvale, CA 94089-1306 Phone: +1.408.745.9600 Fax: +1.408.745.9300 E-mail: info@sonicwall.com PN: 232-001700-00 Rev. A... -
Page 2: Limited Warranty
SonicWALL, Inc. warrants that commencing from the delivery date to Customer (but in any case commencing not more than ninety (90) days after the original shipment by SonicWALL), and continuing for a period of twelve (12) months, that the product will be free from defects in materials and workmanship under normal use. -
Page 3: Getting Started Guide 7
SonicWALL Email Security 200 SonicWALL Email Security 300, SonicWALL Email Security 400 SonicWALL Email Security 500 SonicWALL Email Security 6000 appliance. Note: An updated version of this guide may exist. Refer to SonicWALL’s Documentation Web site for complete, updated documentation at: <http://www.sonicwall.com/Support.html>... - Page 4 “Using Quick Configuration to Set Up Email Management” on page 14 “Verification and Further Configuration” on page 16 “Routing Mail to Your SonicWALL Email Security” on page 16 “Verifying Mail from the Internet Through Your SonicWALL Email Security” on page 16 “Configuring Outbound Mail Filtering” on page 16...
-
Page 5: Before You Begin
*Das eingeschlossene Netzkabel ist für Gebrauch in Nordamerikas nur vorgehabt. Für Europaïsche Union (EU) Kunden, ist ein Netzkabel nicht eingeschlossen. What You Need to Begin A computer to use as a management station for initial configuration of SonicWALL Email Security software Internet Explorer 5.0 or higher... - Page 6 Email Security appliance. Authentication Code: Record the authentication code found (xxx-xxx) on the top right access panel of your SonicWALL Email Security appliance. Networking Information Select a free static IP address for your Email Security IP Address: SonicWALL Email Security appliance that is within the range of your local subnet.
- Page 7 Cooling Fan Serial Port LAN Port Power Supply * Pressing the reset button for several seconds will result in a reboot of the SonicWALL Email Security appliance. Alert: Do not plug devices into any ports (other than those indicated) unless explicitly instructed to do so by a SonicWALL technical support representative.
-
Page 8: Creating A Mysonicwall.com Account" On
Note: You must enter a valid email address. 4. Follow the prompts to finish creating your account. SonicWALL will email a subscription code to the email address you entered in the personal information. 5. When you return to the login screen, log in with your new username and password. - Page 9 Getting Started Guide 7.1 Registering Your SonicWALL Email Security Appliance 1. Locate your SonicWALL Email Security Software serial number. It should be printed on the label on the right-side of your SonicWALL Email Security appliance. 2. If you are not already logged into mysonicwall.com, go to <https://www.mysonicwall.com/...
-
Page 10: Connect Directly To The Sonicwall Email Security Appliance" On
“Activating the Email Security License Subscriptions” on page 10 Apply Power to the SonicWALL Email Security 1. Plug the power cord into the back of the SonicWALL Email Security appliance and into an appropriate power outlet. 2. Turn on the power switch on the front, top, right corner of the appliance. - Page 11 3. Log into SonicWALL Email Security appliance using “admin” as the user name and “password” as the password. Initial System Configuration 1. The first time you log in to the SonicWALL Email Security appliance, you are directed to the system configuration page. Configure your settings as follows: Monitoring Email address of the The email address of the mail server administrator.
-
Page 12: Date And Time
SonicWALL Email Security appliance in the next steps. Activating the Email Security License Subscriptions SonicWALL Email Security provides dynamic licensing, which allows you to activate your licenses by simply logging into your mysonicwall.com account. The mysonicwall.com server automatically uses... - Page 13 4. Click the Register button. The product is added to the list of your registered products. You can then click on it to add or activate services. 5. You can check that the registration is correct by logging in to your SonicWALL Email Security administration site and clicking System/License Management. All your license information should be available.
-
Page 14: The Sonicwall Email Security Interface" On
SonicWALL Email Security. Before and After 1. Plug one end of the provided Ethernet cable into the LAN port on the back of your SonicWALL Email Security appliance. 2. Plug the other end of the cable into an open port on your network hub or switch. - Page 15 Change the default password for security reasons. To change the default password: 1. Login to the SonicWALL Email Security appliance using the IP address you entered in “Hostname and Networking” on page 10. 2. Navigate to the System > Administration page.
- Page 16 The Quick Configuration page will walk you step-by-step through the configuration of your SonicWALL Email Security appliance. Use this window the first time you configure SonicWALL Email Security if you are installing SonicWALL Email Security as an All-In-One server and have only one downstream server.
- Page 17 15. Type the URL where users can view their email junk boxes in the URL for user view field. Click Test this Link to verify connectivity. 16. Under Updates, click Test Connectivity to SonicWALL to test your connection to mysonicwall.com for automated software updates.
-
Page 18: Verifying Mail From The Internet Through Your Sonicwall Email Security" On
Security appliance. You may have to work with your ISP to change this record. Create a rule in your firewall or router to route all port 25 (SMTP mail) traffic to your SonicWALL Email Security appliance. Refer to your firewall or router documentation for instructions on creating rules to route traffic. - Page 19 3. Browse to the Delivery tab, and click the Advanced button. 4. In the Smart Host field, enter the FQDN on your SonicWALL Email Security appliance (such as, esa.example.com). Note: The Exchange Server must be able to resolve this host name.
- Page 20 MX-lookup on the domain in the TO field. Messages that arrive at the SonicWALL Email Security appliance from any other IP address will be treated as an Inbound message, and delivered directly to the Exchange server. The SonicWALL Email Security appliance always gives preference to specific matches (for example an exact IP address match takes precedence over “Any”).
-
Page 21: Troubleshooting
Getting Started Guide 7.1 Troubleshooting This section contains the following subsection: Configuring a Static IP Address Configuring a Static IP Address Complete the following section based on your operating system in order to configure your management computer with a static IP address: Windows XP 1. - Page 22 Getting Started Guide 7.1 Rack Mounting the SonicWALL Email Security 200 / 300 / 400 / 500 / 6000 Appliance The above SonicWALL appliances are designed to be mounted in a standard 19-inch rack mount cabinet. The following conditions are required for proper installation: Use the mounting hardware recommended by the rack manufacturer and ensure that the rack is adequate for the application.
- Page 23 Notice About Modifying Equipment Alert: Modifying this equipment or using this equipment for purposes not shown in this manual without the written consent of SonicWALL, Inc. could void the user’s authority to operate this equipment.
-
Page 24: Vcci Statement
Getting Started Guide 7.1 BMSI Statement VCCI Statement Canadian Radio Frequency Emissions Statement This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à toutes la norme NMB-003 du Canada. CISPR 22 (EN 55022) Class A Complies with EN 55022 Class A and CISPR22 Class A. - Page 25 All certificates held by NetSonic, Inc. Lithium Battery Warning The Lithium Battery used in the SonicWALL Internet security appliance may not be replaced by the user. The SonicWALL must be returned to a SonicWALL authorized service center for replacement with the same or equivalent type recommended by the manufacturer. If, for any reason, the battery or SonicWALL Internet security appliance must be disposed of, do so following the battery manufacturer's instructions.
- Page 26 SonicWALL will provide a machine-readable copy of the GPL open source on a CD. To obtain a complete machine-readable copy, please send your written request, along with a certified check or money order in the amount of US $25.00 payable to “SonicWALL, Inc.” to: General Public License Source Code Request SonicWALL, Inc.
