- Page 1 DAB & FM Radio with Bluetooth , AUX & 2.1 Audio ® MODEL NUMBER: 80923 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
- Page 2 Contents Welcome Section Bluetooth • Bluetooth Mode 2-3. Information & Safety Instructions • Pairing • Bluetooth Menu Contents & Features Controls & Layout • AUX Mode Setup • AUX Menu • Out Of The Box 17-24. System Control Method • System Menu •...
-
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality REKA product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. -
Page 4: General Information
General information & Safety Instructions Please read the following safety information before use. C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN • To avoid risk of electric shock do not attempt to open this appliance. •... - Page 5 General information & Safety Instructions Please read the following safety information before use. To prevent possible hearing damage, do not use at high volume levels for long periods. Adaptor Care To get the best out of your adaptor please observe the following: •...
- Page 6 Contents & Features Contents 1 x DAB & FM Radio 1 x 5V/2A Mains adaptor Features • DAB receiver (174MHz - 240MHz) • FM receiver (87.5MHz - 108.00MHz) • Stores 10 FM presets • Stores 10 DAB presets • 5V/2A mains adapter (included) •...
- Page 7 Controls & Layout Preset Info Menu Alarm Tune+ / Mode Skip Back Scan / Scan Play/Pause Tune- / Dimmer Skip Forward On/Off / Speaker Display Volume Headphone DC5V In Port AUX In Aerial After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE:...
- Page 8 Setup Out Of The Box Once you have removed the radio from the packaging, connect the 5V/2A mains adaptor (supplied) to a suitable mains outlet. Fully extend the aerial and press the dial to turn the radio on. A welcome splash will show followed by the radio first scan for the available DAB stations in your area.
- Page 9 Control Method Using The Buttons All the button actions are just a quick press unless otherwise stated in the required action. This includes the button function of the dial. Using The Dial (On/Off/Vol) The dial on this radio is dual action. This means you can use it to scroll through available options and press it for required button actions.
-
Page 10: Dab Mode
DAB Mode The radio, when turned on, is usually in DAB mode. If is not, repeatedly press the ‘Mode’ button until DAB shows on the display. Tune In A Station All the available stations are saved by the radio in alphabetical order. To select a station press the ‘Tune+’... - Page 11 Preset Store To save a preset, connect the radio to the required station so it is playing (Tune In A Station - Page 8). Press and hold the ‘Preset’ button for 3 seconds. You will see ‘Preset Store’, press the tune +/- buttons to cycle through the available preset slots.
-
Page 12: Dab Menu
DAB Menu Press the ‘Menu’ button to enter the DAB menu. The first option on the screen will be ‘Full Scan’. Using the tune +/- buttons, you can cycle through the DAB menu options and press ‘Select’ to select your option. Options: Full Scan >... - Page 13 Prune You can remove any station from the station list that is marked with a ‘?’ in front of the name listing. To delete a station, connect the radio to the required ‘?’ listed station so it is active (Tune In A Station - Page 8). Press the ‘Menu’...
-
Page 14: Manual Tune
Manual Tune Press the ‘Menu’ button to enter the DAB menu. The first option will be ‘Full Scan’, press the tune +/- buttons to cycle through the menu to ‘Manual Tune’, then press ‘Select’ to access the manual tune options. Press the tune +/- buttons to find a channel to tune and press ‘Select’... -
Page 15: Audio Settings
Scan Settings Scan settings will allow you to change how the radio auto scans. As default the scan setting is set to strong stations. Press the ‘Menu’ button to enter the FM menu. The first option will be ‘Scan Setting’, press ‘Select’ to access this feature. Use the tune +/- buttons to cycle through the two options and then press ‘Select’... - Page 16 Preset Store To save a preset, connect the radio to the required station so it is playing (Tune In A Station - Page 12). Press and hold the ‘Preset’ button for 3 seconds. You will see ‘Preset Store’, press the tune +/- buttons to cycle through the available preset slots.
-
Page 17: Bluetooth Mode
Pairing The radio is automatically in pairing mode. Go to the Bluetooth menu on your device and search ‘REKA BT’ under available devices. Select it from the list to instantly pair with your device Your device will automatically re-pair to the radio if the radio is in bluetooth mode, available and is still in your connected device list. -
Page 18: Aux Mode
AUX Mode This radio will allow you to play music from a compatible device such as a smart phone, tablet, laptop, etc through a 3.5mm AUX cable (not supplied) connected to the radio’s AUX in port and the AUX out or headphone port of the device you wish to connect. -
Page 19: System Menu
System System Menu It is possible to access the system menu through both modes. Press ‘menu’ button, then press the ‘Tune-’ to cycle the menu to ‘System’ and press ‘Select’ to access it. Using the tune +/- buttons, you can cycle through the system menu options available. -
Page 20: Factory Reset
System SW Version This option displays the radio’s firmware version installed on the chipset. Once in the system menu list, press the tune +/- buttons repeatedly until you get to ‘SW Version’ and then press ‘Select’ to display this information. Press ‘Menu’... -
Page 21: Inactive Standby
System Language It is possible to change the menu language for the menu systems. Once in the system menu list, press the tune +/- buttons repeatedly until you get to ‘Language’ and then press ‘Select’ to select this feature. Select the update source by using the tune +/- to cycle through the available options and press ‘Select’... - Page 22 System Time From here you can set the date and time manually, update it from different sources, change the time format and the date format. Once in the system menu list, press the tune +/- buttons repeatedly until you get to ‘Time’ and then press ‘Select’ to select this feature. In this sub menu you can choose from the following: •...
- Page 23 System Time - Auto Update With this option you can auto update the time and date information from a DAB or FM signal. Once in the Time sub menu list, press the ‘Tune+’ button repeatedly until you get to ‘Auto Update’ and then press the ‘Select’ to set this feature.
- Page 24 System Time - Set Date Format With this option you can change the displayed format of the date. Once in the Time sub menu list, press the tune +/- buttons repeatedly until you get to ‘Set Date Format’ and then press ‘Select’ to set this feature.
-
Page 25: Setting The Alarm
System Setting The Alarm There are 2 alarms that can be set on this radio. You can either just press ‘Alarm’ button or go through the system menu. Once in the system menu list, press the tune +/- buttons repeatedly until you get to ‘Alarm’... - Page 26 System Turning The Alarm On/Off The alarm can be set or disabled with the last option when setting the alarm (See page 23, Setting The Alarm). To check which alarm(s) have been set press the button to put the radio into standby mode and check the display. The bell icon and number indicate alarm 1 or 2 is active and the double bell icon indicates that both alarms are active.
-
Page 27: Backlight Options
Dimmer Backlight Options There are 4 levels of brightness the screen can be displayed at. Press the ‘Dimmer’ button to cycle through all the modes. The modes available are: Full > Medium > Low > Off Info Information Details When listening in DAB or FM mode you can cycle through the available information from the broadcasting service and the radio by pressing the ‘Info’... - Page 28 FAQ’s No Sound, just The Date And Time • The radio is in standby. Give the dial a quick press to bring it out of standby. Buttons Are Not Working, But The Screen Is Active • The radio is in standby. Give the dial a quick press to bring it out of standby.
- Page 29 Specification DAB & FM Radio with Bluetooth , AUX & 2.1 Audio ® General Chipset/Solution: Frontier Approx Weight: 1.2Kg Approx Dimensions: 208mm x 125mm x 107mm Headphone Port Size: 3.5mm AUX In Port Size 3.5mm Mains Adaptor: 5V/2A (1.35m length) Speaker Speaker Size: 2 x 35mm, 1 x 70mm...
- Page 30 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 31 Warranty Card DAB & FM Radio with Bluetooth , AUX & 2.1 Audio ® Model Number: 80923 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: Office Use: Repaired...
