S&P ECOROOM Installation Manual And Commissioning page 9

Mounting with sleeve (non delivered):
Cut the mounting sleeve of inner diameter (B) to the length of the wall passage (X). Seal the mounting
sleeve using the expanding foam. Mount the exchanger in the mounting sleeve and secure the body
using the 3 screws.
4. CONNECTIONS AND ELECTRICAL CHARACTERISTICS
IPX4 - 230V – 50/60Hz – 25W – 0,2A
INDOOR USE.
A
Inside diameter of 100 or 150 mm as a
B
C Diameter 107 or 158 mm as a minimum
X
Expanding foam
Mounting Sleeve
-4-b
-5-
Put the Halo in the outside wall
99 or 149 mm
minimum
Wall thickness
L N
Power supply
type H05VV-F-3G0,5
