3000 DAN DRYER Hand dryer.
UK
1 of 12
Maintenance and service manual
3000 DAN DRYER Hand dryer
Maintenance and service manual
Version history
Version:
Description of changes:
Page(s):
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk
Advertisement
Table of Contents
Related Manuals for DAN DRYER 3000
Summary of Contents for DAN DRYER 3000
- Page 1 3000 DAN DRYER Hand dryer. 1 of 12 Maintenance and service manual 3000 DAN DRYER Hand dryer Maintenance and service manual Version history Version: Description of changes: Page(s): DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
- Page 2 DAN DRYER A/S accepts no responsibility if the machine is installed, used, modified or composed otherwise than specified in this manual. Note !!! The machine is designed for indoor use only. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
-
Page 3: Installation And Connection
Hole for hidden wiring Hole for wall Hole for wall mounting mounting Cut-out screw screw for wiring through the bottom DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk... - Page 4 Turn clockwise to increase air speed and anti-clockwise to reduce air speed. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
-
Page 5: Regular Maintenance
If the problem is not resolved by the above actions the entire hand dryer guide: unit must be sent for repair to DAN DRYER or replaced with a new one. IMPORTANT: If the unit is returned to DAN DRYER it must be accompanied by a detailed description of the problem. -
Page 6: Cleaning The Inside Of The Machine
If so, disassemble by removing the screws and by disconnecting wires from carbon brush terminals. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk... - Page 7 (appearance depends on the timer type). air (max. 8 bar). Blow from both sides, and be Please be careful not to damage wires. careful not to damage the heating element. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
- Page 8 15. Assemble the top of the fan housing onto the bottom part by tightening the four screws. Be ca- reful not to overtighten. Fix angle bracket to base plate of the motor. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
-
Page 9: Spare Parts
10. Rubber gasket for fan housing (small) 21. Fan housing, bottom part 11. Heating element, 900 W 22. Housing screw (2 pcs.) 23. Allen key for housing screws DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk... - Page 10 8. Assemble new carbon brushes and reassemble screws and wires 9. Reassemble all components and test run the hand dryer. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
-
Page 11: Heating Element Replacement
3. Disconnect wires from timer unit. 4. Disassemble sensor bracket and timer unit from fan housing. 9. Reassemble all components and test run the hand dryer. DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk... -
Page 12: Technical Specifications
Expected lifetime of hand dryer (after replacing the brushes): 108.000 hand dryings. • Expected total lifetime of hand dryer before disposal: 324.000 hand dryings. Dimensions: Wiring chart: DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • info@dandryer.dk...
