Avet Reels Fishing Reel JX 6.0 Parts List

Models JX 6.0 Parts List
66 1
65
68 69
71
73
72
67 70
74
24 25
1 - Main Housing JX 6.0-001
15 - Spool Spring Washer (2 req.)
2 - Gear cover JX6.0-002
16 - Spool Spring
3 - Cover Screw (2 req.) JX6.0-003
17 - Brake Bearing
4 - Spool Shaft JX6.0-004
18 - Brake Disk
4A-Shaft Shoulder JX6.0-004A
20 - Antireverse Gear
4B-Shaft Pin JX6.0-004B
21 - Disk Ring
5 - Belleville Washers (4 req.) JX6.0-005
22 - Pinion Gear
6 - Pusher Bushing JX6.0-006
23 - Pinion Bearing
7 - Spool Bearing JX6.0-007
24 - Drive Shaft
8 - Spool Tube JX6.0-008
25 - Connection Arm
9 - Clicker Gear Retainer Ring JX6.0-009
26 - Friction Ring
10- Clicker Gear JX6.0-010
27 - Friction Washer
11- Spool JX6.0-0 11
28 - Drive Gear
12- Brake Pad JX6.0-012
29 - Drive Shaft Bearing (2 req.)
14- Spool Bearing JX6.0-014
30 - End Housing
(rev. 5-08)
4A
4B 4
3
32 31
2
33 20 22 23
21
26 27 28 29
31 - Dog
JX6.0-015
32 - Dog Cover Screw (2 req.)
JX6.0-016
33 - Dog Cover
JX6.0-017
34 - Stop Pin (2 req.)
JX6.0-018
35 - Pin Screw (2 req.)
JX6.0-020
36 - Handle Knob
JX6.0-021
37 - Knob Screw
JX6.0-022
38 - End Housing Screw (3 req.)
JX6.0-023
39 - Drive Shaft Tube
JX6.0-024
40 - Drive Shaft Washer
JX6.0-025
41 - Male Cam
JX6.0-026
42 - Male Cam Pin (2 req.)
JX6.0-027
43 - Female Cam
JX6.0-028
44 - Lever Arm
JX6.0-029
45 - Teflon Washer (2 req.)
JX6.0-030
10
5 6 7 8 9
34 35 36 37
55A
42
41 43 44 45 46 47 48 49
49A
30
38 39 29 40
JX6.0-031 46- Drive Washer
JX6.0-032 47- Preset Washer
JX6.0-033 48- Preset Sprin
JX6.0-034 49A- Preset Knob Detent
JX6.0-035 49- Preset Knob
JX6.0-036 50- Crank Arm
JX6.0-037 51- Crank Arm Washer
JX6.0-038 52- Acorn Nut
JX6.0-039 53- Locking Plate
JX6.0-040 54- Locking Plate Screws (2 req.)
JX6.0-041 55A- Handle Shaft Washer
JX6.0-042 55- Handle Knob Shaft
JX6.0-043 56- Handle Shaft Bearing
JX6.0-044 57- Handle Knob
JX6.0-045 58- Knob Bearing
18
11 12
15 16
14 17
56
55
57
58 59
60
62
50 54
53
51 52
JX6.0-04 6 59- Knob Washer (optional) JX6.0-059
60- Spring Washer JX6.0-060
JX6.0-047
61- Lock Washer JX6.0-061
JX6.0-048
62- Nut JX6.0-062
JX6.0-049A
63- Knob Cap JX6.0-063
JX6.0-049
JX6.0- 050 64- Knob Cap Screws (2 req.) JX6.0-064
JX6.0-051 65- Clicker Pin JX6.0-065
66- Pin Support JX6.0-066
JX6.0-052
67- Pin Washer JX6.0-067
JX6.0-053
68- Clicker Spring (2 req.) JX6.0 -068
JX6.0-054
JX6.0-055 A 69- Clicker Arm JX6.0-069
JX6.0-055 70- Pin E Clip JX6.0-070
71- Reel Foot JX6.0-071
JX6.0 . -056
72- Reel Foot Screw JX6.0-072
JX6.0-057
73- Clamp JX6.0-073
JX6.0-058
74- Clamp Screws (2 req.) JX6.0-074
61
63
64
