Model No. PFSY92080
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
Serial
Number
Decal
USERÕS MANUAL
PATENT PENDING
¨
Advertisement
Table of Contents
Related Manuals for ProForm PFSY92080
Summary of Contents for ProForm PFSY92080
- Page 1 Model No. PFSY92080 Serial No. The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
3. If you feel pain or dizziness at any time while exercising, stop immediately and begin cool- ing down. 4. Use the home gym system only on a level surface. Cover the floor or carpet beneath the home gym system for protection. -
Page 3: Before You Begin
Mountain Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is PFSY92080. The serial number can be found on a decal attached to the PROFORM System (see the front cover of this manual). -
Page 4: Assembly
Assembly Note: This introduction will save you more time than it takes to read it! Making Things Easier for Yourself Everything in this manual is designed to ensure that the assembly of our products can be complet- ed successfully by anyone. However, it is impor- tant to recognize that your new equipment is a sophisticated product with many small parts. -
Page 5: Frame Assembly
Frame Assembly 1. Before beginning, make sure that you have read and understood the information on page 4. Locate and open the parts bag labeled ÒFRAME ASSEMBLY.Ó Press a 2Ó Square Inner Cap (24) into each end of the Stabilizer (5). Insert two 3/8Ó x 2 3/4Ó Carriage Bolts (20) up through the holes in the Stabilizer and place it flat on the floor. - Page 6 5. Slide the Press Upright (3) onto the indicated 5/16Ó x 2 1/2Ó Carriage Bolts (22) in the Press Base (4). Tighten a 5/16Ó Nylon Locknut (68) onto each Carriage Bolt. Note: The Press Upright (3) must be leaning towards the center of the unit with the two brackets oriented as shown.
- Page 7 7. Position two Weight Bumpers (19) over the indicated holes in the Stabilizer (5). Insert both Weight Guides (23) through the Weight Bumpers (19) and the holes in the Stabilizer (5). See the inset drawing. Press two Round Weight Inserts (76) into the indicated holes in each Weight (26).
-
Page 8: Arm Assembly
10. Attach the upper ends of the Weight Guides (23) to the welded bushing underneath the Top Frame (1) with a 5/16Ó x 6 1/2Ó Bolt (89) and a 5/16Ó Nylon Locknut (68). Tighten the Nylon Locknut fully. 11. Slide the Press Seat Upright (37) onto the 5/16Ó x 2 1/2Ó... - Page 9 14. Press a 2Ó Square Inner Cap (24) into the lower end of each Press Arm (46 and 47). Press a 1Ó Round Inner Cap (88) into the side of each Press Arm. Identify the Right Press Arm (47). It has a Locking Pin (98) mounted on the upper end.
-
Page 10: Cable Assembly
17. Lubricate both axles on the Top Frame (1). Identify the Right Arm (80) and the Left Arm (81) by noting the position of the welded bracket (A) on each Arm. Arm identification is very important for this step. Place a Weld Cover (63) on top of the Right Butterfly Arm (80) in the location shown. - Page 11 19. Wrap the High Cable (73) around a 3 1/2Ó Pulley (35) in the direction shown. Slide the 3 1/2Ó Pulley (35) onto a 3/8Ó x 5Ó Bolt (42). Slide a Cable Trap (44) onto the Bolt. Slide the Bolt into the indicated hole in the Top Frame (1).
- Page 12 23. Remove the 3/8Ó Nylon Locknut (50) attached to the 3/8Ó x 5Ó Bolt (42) in step 19. Wrap the High Cable (73) around a 3 1/2Ó Pulley (35) in the direction shown. Slide the 3 1/2Ó Pulley (35) and a Cable Trap (44) onto the 3/8Ó...
- Page 13 27. Locate the Butterfly Cable (97). It is approximately 58Ó long and it has a closed loop on both ends. Attach one end of the Butterfly Cable (97) to the indi- cated bracket on the Left Butterfly Arm (81) with a 5/16Ó...
- Page 14 31. Wrap the Low Cable (72) around a 3 1/2Ó Pulley (35) in the direction shown. Slide the Pulley and a Cable Trap (44) onto a 3/8Ó x 4 3/4Ó Bolt (65). Slide the Bolt into the indicated hole in the bracket on the Butterfly Upright (2).
-
Page 15: Seat Assembly
35. Attach the closed loop at the end of the Low Cable (72) to the Support Bracket (27) on the Butterfly Upright (2) with a 5/16Ó x 1Ó Bolt (48) and a 5/16Ó Nylon Locknut (68). Note: On the closed loop, the Cable is attached on one side, while the other side is flat (see the inset drawing). - Page 16 38. Attach one Backrest (41) to the Butterfly Backrest Frame (15) with two 1/4Ó x 3/4Ó Screws (17). Unscrew the handle on the Adjustment Knob (99) until it is loose. Pull out the handle as far as it will go and slide the Butterfly Backrest Frame (15) into the slot in the Butterfly Upright (2).
-
Page 17: Miscellaneous Assembly
41. Press two 3/4Ó Round Inner Caps (34) into each Pad Tube (28). Insert one Pad Tube (28) into the Butterfly Seat Frame (11). Slide a Foam Roller (30) onto each end of the Pad Tube. Insert the other Pad Tube (28) into the Leg Lever (29). - Page 18 44. The decal shown below has been attached to the home gym system in the two locations shown. If a decal is missing or illegible, please call our customer hotline at the number on the front cover to order a replacement decal.
-
Page 19: Cable Diagram
Cable Diagram The Cable Diagrams below show the proper routing of the Butterfly Cable (97), the High Cable (73) and the Low Cable (72). The numbers show the correct route for each cable. Make sure the Cables are routed correctly, that the Pulleys move smoothly and that the Cable Traps do not touch or bind the Cables. -
Page 20: Adjustment
The instructions below describe how each part of the home gym system can be adjusted. Refer to the exercise chart mounted on the shroud to see how the home gym system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct start- ing position for the exercise to be performed. - Page 21 Attaching the Lat Bar, Row Bar or Ankle Strap to the Low Pulley Station Attach the Lat Bar (61) to the Low Cable (72) with a Cable Clip (69). For some exercises, the Chain (67) should be attached between the Lat Bar and the Low Cable with two Cable Clips.
-
Page 22: Weight Resistance Chart
Adjusting the Weight System for Row Exercises To set up the weight system for row exercises, pull down on the Press Arm Locking Pin (98). Push the Press Arms (46, 47) towards the weight stack and release the Locking Pin so it snaps into one of the holes in the Cable Frame (57). -
Page 23: Trouble-Shooting And Maintenance
This warranty gives you specific legal rights. You may also have other rights which vary from state to state. ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813 PROFORM is a registered trademark of ICON Health & Fitness, Inc. Part No. 151251 H03915-AC R1298A ¨... - Page 24 Trouble-shooting and Maintenance Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents.
- Page 25 1" Round Inner Cap (88) 3/4Ó Retaining Ring (86) 3/4Ó Dome Cap (75)Ñ2 3/4" Round Inner Cap (34) 5/8Ó x 1/2Ó Bushing (32) 1 3/4Ó Square Inner Cap (21) Cable Clip (69) 1" x 2Ó Inner Cap (43) 2" Square Inner Cap (24)
- Page 26 Part Identification Chart - Model No. PFSY92080 1 1/2" Flat Washer (100) 1/2" Plain Nut (40) 1/2" Nylon Locknut (51) 5/16" Nylon Locknut (68) 5/16" Nylon Jamnut (25) #8 x 1Ó Black Screw (7) #10 x 3/4Ó Black Screw (91) #8 x 3/4Ó...
- Page 27 Part List - Model No. PFSY92080 Key No. Qty. Description Top Frame Butterfly Upright Press Upright Press Base Stabilizer Leg Lever Bumper #8 x 1Ó Black Screw Butterfly Base Locking Knob Ankle Strap Butterfly Seat Frame Press Frame Seat Plastic Sleeve...
