- Page 1 K800 Installation instructions...
- Page 2 CONTENTS GENERAL INFORMATION....................3 IMPORTANT POINTS......................3 PREREQUISITES........................4 Floor plate Outdoor air supply Flue PREPARATIONS........................5-8 Flue connections for rear and top installation Floor plate and outdoor air connection INSTALLATION INSTRUCTIONS..................9-11 CARE & FIRING INSTRUCTIONS .................12-14 TECHNICAL SPECIFICATION...................15 CERTIFICATES........................16 - 2 -...
-
Page 3: General Information
GENERAL INFORMATION * Turned hot plate (for rear installation) * Outdoor air unit * Glasshatch (816-36) Important! Keep these installation instructions and the associated firing instructions! Manufacturer's declaration IMPORTANT POINTS * NOTE! Read through all of the installation instructions before beginning the installation. 12-14. -
Page 4: Prerequisites
PREREQUISITES BUILDING NOTICE FLOOR PLATE DISTANCE TO FLAMMABLE STRUCTURAL steel plate. UNITS in the desired place. OUTDOOR AIR SUPPLY FLUE Min 630 CHIMNEY CONNECTIONS The illustration on page 5 shows the K800 from LOAD-BEARING SURFACE - 4 -... -
Page 5: Preparations
Floor Plate 2. FLUE CONNECTION Min 595 mm Note! If you install Keddy's floor glass, the di- mensions above must be extended by 6 mm, i.e. they become 926/1012 and 1066/1151 mm. this at the end of the Installation instructions on p. 11. - Page 6 EXAMPLE A Rear connection directly into a chimneybreast or a masonry chimney, e.g. a Heda Chimney. Mark installed. NOTE! Bricking the pipe into the chimney is not allowed. EXAMPLE B Rear connection through a flammable wall 3. UNPACKING / DISMANTLING The stove can be moved in as delivered - 6 -...
- Page 7 NOTE! To close the door, push it closed without lifting the lock hasp. - 7 -...
- Page 8 Keep a hand on the panels during this op- eration, to prevent them from falling on the floor. NOTE! Model 816-36 with whole sidepanel should not be removed as it also holds the glass- panels in place. Concrete panel guide You have now removed all of the necessary parts and can unscrew the stove and move it into the house.
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS In most cases the installation is identical on all K800 stoves. When it differs we will describe it in the text. Before starting on the installation of the stove, the following steps need to be fully completed: The chimney: Outdoor air supply Floor plate Several operations have to be carried out before the stove is put into place. - Page 10 We are now ready to place the stove in its intended position. NOTE! Because the stove is heavy and is also equipped with adjustment screws under the base, it can be a good idea to take a piece of the pack- aging to stand the stove on, in order to protect the floor while manoeuvring it into position.
- Page 11 NOTE! Always leave at least 5 mm of ven- tilated space between the top of the stove and the chimney's insulation/outer steel jacket. (See the illustration.) You have now made your stove ready for use. In order for the sealant to harden properly, you must leave the stove for at least three days before firing it for the first time.
-
Page 12: Care & Firing Instructions
CARE & FIRING INSTRUCTIONS The K800 has been tested by the Swedish National Testing and Research Institute. It has met the strictest environmental requirements on the market and has useful efficiency of not less than 80%. For the K800 to work optimally, it is of key importance that you follow the care and firing instructions below. - Page 13 FIRING AND FILLING WITH WOOD Automatic mode tal results. FIRING IN MANUAL MODE (If the chim- ney is cold or if there are unfavourable weather conditions, you may need to keep the door ajar during the first five minutes in order to establish a satisfactory chimney draught.) Manual Mode (If the chimney is cold or if there are unfavourable...
- Page 14 GOOD TO KNOW REMOVAL OF SOOT AND MAINTENANCE paper. paper. Pay attention to the risk of fire when you throw out the ash, as the ash may con- tain live embers for a very long time! In order to be able to close the damper in automatic mode, you must disconnect the plug from the wall.
-
Page 15: Technical Specification
K800 TECHNICAL SPECIFICATION DIMENSIONS AND PERFORMANCE Output 3 - 9 kW - 15 -... - Page 16 License number: 378 016...
