- Page 1 Installation Instructions Care and firing instructions...
-
Page 2: Table Of Contents
CONTENTS EXPLODED DIAGRAM ......................2 GENERAL INFORMATION......................3 IMPORTANT POINTS......................3 PRECONDITIONS........................4 PREPARATIONS........................5-6 INSTALLATION INSTRUCTIONS ..................6-9 CARE-FIRING INSTRUCTIONS ..................10-11 TECHNICAL INFORMATION/DIMENSIONS ................12 EXPLODED DIAGRAM - 2 -... -
Page 3: General Information
Important! These installation instructions and the associated firing instructions must be saved! Quality approval Keddy's masonry stoves are tested by a certified testing institute and comply with the requirements in the Swedish Building Regulations and for CE Marking. Manufacturer's Declaration Keddy's masonry stoves have been manufactured in accordance with the documents that form the basis for the respective certificates and their associated requirements for production inspections. -
Page 4: Preconditions
FLUE The distance from the sides of the stove to flamma- The K20 may be connected to a flue approved for a ble material must be 500 mm ventilated space. The minimum of 350ºC. As the area, length and material... -
Page 5: Preparations
PREPARATIONS 1. FLOOR PLATE AND OUTDOOR AIR CONNEC- TION Arrange the floor plate according to the instructions on page 4 under the heading Floor plate. If you choose to make your own floor plate, the minimum dimensions stated in the above-mentioned point must be followed at all times. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Before starting on the installation of the stove, the following steps need to be fully completed: The chimney: Alternative 1 An existing chimney prepared for rear connection. Alternative 2 A newly installed chimney prepared for rear connection. Alternative 3 Preparation for a new top connection chimney. - Page 7 INSTALLATION INSTRUCTIONS 5. It is now time to place the hearth on to element 2. If outdoor air is to be connected, the outdoor air sleeve must be installed on the hearth (see the instructions in the accessory box for the outdoor air kit.) To facilitate the installation of the hearth, you can choose to unscrew and separate the body from the front/door.
- Page 8 10. Install a further three elements no 5 and one ele- ment no 6 in mortar. Install pipe 390 mm. K20 Rear connection 11. For rear connection. Cut the 500 mm pipe to a suitable length. Hang the pipe in the hole prepared in the chimney breast.
- Page 9 The cleaning cover and the hot air grilles are perma- nently installed after the stove has been rendered and painted. K20 Top connection cont. Insulation 13. Assemble elements 7 and 8 in mortar. Secure the connection sleeve with insulation in the hole on the front.
-
Page 10: Care-Firing Instructions
CARE & FIRING INSTRUCTIONS The Keddy K20 has been tested by a certified testing institute. It has extremely good envi- ronmental values and a useful efficiency exceeding 80%. For the stove to work optimally, it is of key importance that you follow the care and firing instructions below. Non-compliance will invalidate the warranty. -
Page 11: Care-Firing Instructions
PACKAGING The K20 is equipped with an innovative self-clos- The stove is delivered on an untreated wooden pal- ing and self-locking door. When putting firewood let, which can be sorted as combustible material or in or removing ash, carefully place the door at burned in the insert. -
Page 12: Technical Information/Dimensions
K20 TECHNICAL SPECIFICATION DIMENSIONS AND PERFORMANCE Height 2170 mm Width 920/1020 mm Depth 570 mm Weight K20 850 Kg Height, centre rear connection 1905 mm Height, top connection 2170 mm Outer dimensions, connection ∅150 mm Efficiency 83 % Nominal output...
