LED Status
Green steady
ADSL Green blinking (slow)
Green blinking (fast)
Off
Internet
Green steady
Green blinking
Red
Off
LAN x
Green steady
(1 to 4)
Green blinking
Off
USB
Green
Off
WLAN Green steady
Green blinking
Off
Green steady
WPS
Green blinking (slow)
Green blinking (fast)
F@ST 5302
Meaning
ADSL/VDSL Up
ADSL/VDSL Synchronisation in progress or down
ADSL/VDSL training and analysis phases
• Power Off or
• The Internet account must be configured or
• Bridge mode
The Internet account is configured
Tx/Rx traffic
Invalid or unauthorised Internet account
No link detected on the Ethernet port
Ethernet port has detected a link with device
Tx/Rx traffic at 100 Mbps
No USB connection
USB connection available
Wi-Fi deactivated
Wi-Fi activated
Wi-Fi Tx/Rx traffic
WPS deactivated
WPS activated
WPS Tx/Rx traffic in progress
WPS pairing in progress
