- Page 2 C O P Y R I G H T © 2003 by AVerMedia TECHNOLOGIES, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by...
-
Page 3: Table Of Contents
Contents Introduction ...1 What’s in the Package ... 1 The AVerMedia TVBox™ 5 Unit ... 2 Touch Button Control Panel... 2 Infrared Sensor... 2 Connection Ports... 3 Installation and Setup ... 4 Connecting the VGA monitor or LCD Projector ... 6 Connecting the Computer... -
Page 4: Introduction
Introduction Thank you for purchasing the AVerMedia TVBox™ 5! With the AVerMedia TVBox 5, you can turn your VGA monitor or LCD projector into a TV/multimedia center with or without turning on your PC. It is true plug-n-play and there is no software driver required. You can easily switch between TV/Video source and PC display at anytime. -
Page 5: The Avermedia Tvbox™ 5 Unit
AVerMedia TVBox™ 5 The AVerMedia TVBox™ 5 Unit Touch Button Control Panel The Touch Button Panel found on the top side of the AVerMedia TVBox 5 provides quick access to commonly used functions. Infrared Sensor When using the remote control, aim it at the Infrared Sensor which is located at the front panel of the AVerMedia TVBox 5. -
Page 6: Connection Ports
User Manual Connection Ports The port connectors allow connection of your TV antenna, PC, VGA monitor or LCD projector, speakers, video, or s-video source etc. AVerMedia TVBox 5 Back Panel AVerMedia TVBox 5 Front Panel The Installation and Setup section provides more information on cable connections. -
Page 7: Installation And Setup
AVerMedia TVBox™ 5... - Page 8 User Manual...
-
Page 9: Connecting The Vga Monitor Or Lcd Projector
AVerMedia TVBox™ 5 Connecting the VGA monitor or LCD Projector Connect the VGA monitor or LCD Projector cable to the AVerMedia TVBox 5 VGA OUT port. Connecting the Computer You can use AVerMedia TVBox 5 with or without turning on your PC. To switch to PC anytime, connect the VGA cable to the AVerMedia TVBox 5 VGA IN port and to your PC VGA card (the terminal where your monitor... -
Page 10: Connecting The Antenna
Connecting the Antenna Attach the antenna or cable TV to the ANT IN port of the AVerMedia TVBox 5 . Connecting an Audio Cable Plug one end of the supplied audio cable to your sound Connecting an External Amplified Speaker Connect your external amplified speaker to the AVerMedia TVBox 5... -
Page 11: Connecting The Audio/Video Equipment
Connecting the Audio/ Video Equipment RCA (Composite) Video connection: Connect the video cable (not included) to the VIDEO OUT of the video device and to the AVerMedia TVBox 5 A/V IN yellow port. S-Video connection: Connect the s-video cable (not included) to the S- VIDEO OUT of the video device and to the AVerMedia TVBox 5 S-IN port. -
Page 12: Using The Avermedia Tvbox 5
Using the AVerMedia TVBox 5 Different countries have different TV systems, for example, PAL-BG, PAL-DK, NTSC-J, NTSC-M…etc. AVerMedia TVBox 5 functions only with the TV system of the country it is manufactured for and originally distributed in. Each column in the table below corresponds to a different type of TV system. Only one of these TV systems (only one column) will appear as your SET AREA. -
Page 13: Calling Up A Menu Display
AVerMedia TVBox™ 5 Note: Teletext buttons only present in European model. Calling Up a Menu Display Press MENU button remote control to call up and exit the main menu or sub-menu display. Then, you can use the CH▲ or CH▼ buttons to select the items in the menu list;... -
Page 14: Tv Source
Main Menu On Screen Display TV SOURCE CH FINETUNE CH SCAN Usage Use the CH▲ or CH▼ buttons to select between antenna TV or cable TV source, then press Vol► button to make the selection. If the TV reception is not clear, choose CH FINETUNE then press Vol◄... -
Page 15: More
Main Menu On Screen Display MORE.. DEFAULT FAVORITE CH Usage Press Vol► button to call up MORE.. menu list. Use the CH▲ or CH▼ buttons to select YES to clear all the preset channels and to restore the original factory default picture setting or NO to exit. -
Page 16: Set Area
On Screen Display Main Menu SET AREA OSD POSITION RESOLUTION LANGUAGE Customizing the Picture Setting If you want to adjust the picture quality, press the PICTURE button on the remote. Then, you can use the CH▲ or CH▼ buttons to select the items in the PICTURE menu;... -
Page 17: Supported Display Setting In Pip Mode
Supported Display Setting in PIP Mode The reference table below lists the monitor display resolution and refresh rate settings that TVBox 5 supports when viewing in PIP mode: Resolution Refresh Rate (Hz) 640 x 480 60, 72, 75, 85 800 x 600 60, 72, 75, 85 1024 x 768 60, 70, 75, 85... - Page 18 User Manual do not relate to a Product defect. The Warranty Period of any repaired or replaced Product shall be the longer of (a) the original Warranty Period or (b) thirty (30) days from the date of delivery of the repaired or replaced Product. 2.
-
Page 19: Contact Information
AVerMedia TVBox™ 5 SUCH DAMAGES. AVERMEDIA’S TOTAL, AGGREGATE LIABILITY FOR DAMAGES OF ANY NATURE, REGARDLESS OF FORM OF ACTION, SHALL IN NO EVENT EXCEED THE AMOUNT PAID BY YOU TO AVERMEDIA FOR THE SPECIFIC PRODUCT UPON WHICH LIABILITY IS BASED. 5.
