TRK-MPC5604P EVB User Manual
• 3.3V from on-board LDO
• 3.3V from Motor Control Port
• Jumper to select BAM source:
• From internal memory
• From CAN
• From LIN Flex
• RESET Push Button and LED indicator w/ enable
• User Features:
• 4 User Push Buttons w/ enable and pull-up & pull-down options
• 4 DIL switches w/ enable and pull-up & pull-down options
• 10K Ohm POT connected to an ADC input channel w/ enable
• 1 photocell w/ enable
• 4 User LED's w/ enable
• 1 RS232 interface w/ enable (DB9 and transceiver footprint only)
• 1 CAN interface w/ enable to high-speed CAN transceiver with
DB9 CAN connector
• 2 LIN channels w/ enable sharing one LIN transceiver with two
standard LIN connectors
• 4 distinct GND test points
• Specifications:
• Board Size 4.7" x 4.3"
• Power Input:
• USB Cable: 5VDC, 500mA max
• DC Power Jack: 2.1/5.5mm barrel connector, 9VDC to
12VDC Center Positive
3
