AGT1 GOLD & PLATINUM TESTER
EASY OPERATION GUIDE: STEPS 1 & 2
The AGT1
easy steps and recommendations to get accurate test results.
STEP 1:
AGT1 POWER UP
After the batteries are installed and the pen probe is fully plugged into the unit, turn on the AGT1 by
pushing the switch to BAT if batteries are installed or AC if the AC adaptor is installed, depending on
which power option you wish to use. The AGT1 will then go through its self-check boot up sequence
(flashing LED bar graph and indicators). Once the lights stop flashing the READY light and NA light at the
far right of the bar graph will remain on.
STEP 2:
CHECK PEN PROBE & ELECTRICALLY CHARGE IT FOR USE
Remove the pen probe cap, then dab the pen probe's felt tip on a clean, dry paper towel to clean it and
absorb any excess pen probe solution, leaving the pen probe's felt tip the consistency of a normal felt tip
pen or marker. Note that if the solution drips from the pen probe's felt tip and simultaneously touches
both the gold or platinum and the testing plate it will not work. File a small area on the surface of the 14K
yellow gold calibration piece
the pen probe is working by holding it upright at an approximate 90° angle and gently touching the very
A
B
AuRACLE
MUST
be used while following the below
and rest it on the testing plate with the filed area facing up. Check that
A
end of the pen probe's felt tip to the filed area of the 14K
yellow gold calibration piece
and wait for the reading to settle each time. By repeatedly
touching the 14K yellow gold calibration piece it is electrically
charging the pen probe for use, which is a vital part of the
start up process. The LEDs on the bar graph will react by
climbing upward or downward. At this point the pen probe is
charging and note that it is not important where the LED
indicator settles
graph will be found only in the very center of the 14K range in
the calibration process as outlined in STEP 3 below.
. Repeat this process 3 times
B
C
. A distinct calibration point on the LED bar
C
™
