  • Page 1 ESL8530RO Dishwasher User Manual...
  • Page 2 15. WARRANTY ....................24 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3 ENGLISH responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •...

  • Page 4: Safety Instructions

    Do not leave the appliance with the door open, to • avoid a tripping hazard. Before any maintenance operation, deactivate the • appliance and disconnect the mains plug from the socket. Do not use high pressure water sprays and/or steam •...

  • Page 5: Water Connection

    ENGLISH • Do not pull the mains cable to • Do not drink and play with the water in disconnect the appliance. Always pull the appliance. the mains plug. • Do not remove the dishes from the appliance until the programme is 2.3 Water connection complete.

  • Page 6: Product Description

    3. PRODUCT DESCRIPTION Top spray arm Rinse aid dispenser Upper spray arm Detergent dispenser Lower spray arm Lower basket Filters Upper basket Rating plate Cutlery drawer Air vent 3.1 Beam-on-Floor The Beam-on-Floor is off when the appliance is The Beam-on-Floor is a light that is deactivated.

  • Page 7: Control Panel

    ENGLISH 4. CONTROL PANEL On/off button TimeManager button Display XtraDry button Delay button Reset button Program button Indicators MyFavourite button 4.1 Indicators Indicator Description Rinse aid indicator. It is always off while the programme operates. 5. PROGRAMMES Programme Degree of soil Programme phases Options Type of load •...

  • Page 8: Consumption Values

    Programme Degree of soil Programme phases Options Type of load • Normal or light • Wash 45 °C • XtraDry soil • Rinse • Delicate crock‐ • Dry ery and glass‐ ware • Fresh soil • Wash 60 °C •...

  • Page 9: Settings

    ENGLISH Water Energy Duration Programme (kWh) (min) 0.01 1) The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of dishes can change the values. 5.2 Information for test info.test@dishwasher-production.com institutes Write down the product number (PNC) that is on the rating plate.
  • Page 10 1. Press activate it. • The indicators off. How to activate the acoustic • The indicator still flashes. signal for the end of • The display shows the current programme setting. –...

  • Page 11: Options

    ENGLISH – = AirDry is deactivated. CAUTION! Do not try to close the – = AirDry is activated. appliance door within 2 2. Press to change the setting. minutes after automatic 3. Press on/off to confirm the setting. opening. This can cause damage to the appliance.

  • Page 12: Before First Use

    In the other programmes the setting of How to activate TimeManager XtraDry is permanent and it is automatically used in next cycles. This Press TimeManager, the related configuration can be changed at any indicator comes on. time. If the option is not applicable to the...

  • Page 13: Daily Use

    ENGLISH 9. DAILY USE 1. Open the water tap. automatically the appliance when it is not 2. Press the on/off button to activate the operating. appliance. The function comes into operation: Make sure that the appliance is in • 5 minutes after the completion of the programme selection mode.

  • Page 14: Hints And Tips

    Opening the door while the Cancelling the programme appliance operates Press and hold Reset until the appliance is in programme selection mode. Opening the door while a programme is Make sure that there is detergent in the running stops the appliance. It may affect...

  • Page 15: Care And Cleaning

    ENGLISH • Do not put in the appliance items • The spray arms are not clogged. made of wood, horn, aluminium, • There is dishwasher rinse aid (unless pewter and copper. you use multi- tablets). • Do not put in the appliance items that •...

  • Page 16: Cleaning The Upper Spray

    7. Reassemble the filters (B) and (C). 8. Put back the filter (B) in the flat filter (A). Turn it clockwise until it locks. 2. Remove the filter (C) out of filter (B). 3. Remove the flat filter (A).

  • Page 17: Troubleshooting

    ENGLISH 11.3 External cleaning • Clean the appliance with a moist soft cloth. • Only use neutral detergents. • Do not use abrasive products, abrasive cleaning pads or solvents. 11.4 Internal cleaning • Carefully clean the appliance, including the rubber gasket of the door, with a soft damp cloth.
  • Page 18 With some problems, the display WARNING! shows an alarm code. Repairs not properly done The majority of problems that can may result in serious risk to occur can be solved without the need the safety of the user. Any...
  • Page 19 ENGLISH Problem and alarm code Possible solution Small leak from the appli‐ • The appliance is not levelled. Loosen or tighten the ance door. adjustable feet (if applicable). • The appliance door is not centred on the tub. Adjust the rear foot (if applicable). The appliance door is diffi‐...
  • Page 20 Problem Possible cause and solution There are whitish streaks or • The release quantity of rinse aid is too much. Ad‐ bluish layers on glasses and just the rinse aid level to a lower level. dishes. • The quantity of detergent is too much.

  • Page 21: Technical Information

    ENGLISH Problem Possible cause and solution Dull, discoloured or chipped • Make sure that only dishwasher-safe items are tableware. washed in the appliance. • Load and unload the basket carefully. Refer to bas‐ ket loading leaflet. • Place delicate items in the upper basket. Refer to "Before first use", "Daily use"...

  • Page 22: Installation

    14. INSTALLATION Remove entire plastic There should be a minimum The hose should not be membrane from sink trap 2mm gap between the top of extended by more than spigot & fit drain hose to spigot the dishwasher and...

  • Page 23: Water Drain Hose

    The highest point of the drain hose must entire be no more than 600 mm from the floor internal and must have a continuous fall to the membrane plumbing connection. The drain hose can be lengthened using additional lengths and connectors. These must be purchased from Electrolux...

  • Page 24: Warranty

    6. Proof of purchase is required before you can make a claim under this warranty. 11. C onfidentiality: You accept that if you make a warranty claim, Electrolux and its agents including ASC may exchange information in relation to you 7.

  • Page 25: Environmental Concerns

    16. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste. Return the Put the packaging in relevant containers product to your local recycling facility or to recycle it. Help protect the contact your municipal office.
