MUL-1.2M-KU Satellite Dish Manual
2.5.2 Assemble LNBF Feed Support Arm
1. Assemble top and bottom LNBF holder/mount/clamp (12 and 13) with 2 screws (1)
2. Attach bottom LNBF holder (12) to LNBF feed arm (11) with screw (2)
3. Insert plastic plug (14) into top of LNBF feed arm
www.multicominc.com
All Rights Reserved © 2017 Multicom, Inc.
(800) 423-2594
(407) 331-7779
10
