Manuale di servizio GD6
Service manual GD6
Conservare per futura
consultazione.
To be kept for future advice.
MA_H006_GD6_Service Manual rev.01
04/03/2011 - 999999000267

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GD6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for grandimpianti GD6

  • Page 1 Manuale di servizio GD6 Service manual GD6 Conservare per futura consultazione. To be kept for future advice. MA_H006_GD6_Service Manual rev.01 04/03/2011 - 999999000267...
  • Page 2 GD6 Con ventilatore GD6 Vented version...
  • Page 3 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannellatura esterna Outer casing Code Descrizione Description Qty. GR37ASK8061817-81 COPERCHIO SUPERIORE GRIGIO TOP COVER GREY METALLIC 1 Pc’s 101-a GR37ASK8900338 VITE Vedi GR36ASK8902362 SCREW Repl.by 8902362 3 Pc’s 101-b GR37ASK8901413 RONDELLA AZ 4,3 ZINCATA LOCK WASHER AZ 4,3 GALV 2 Pc’s GUIDA PER PANNELLO FRONTALE/ GR37ASK8061763...
  • Page 4 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannellatura esterna Outer casing...
  • Page 5 www.groupdynamics-laundry.com sales@groupdynamics.lv Parte superiore Upper session Code Descrizione Description GR37ASK8076029 STAFFA FRONTALE FRONTBEAM 1 Pc’s 501-a GR37ASK8900338 VITE vedi GR36ASK8902362 SCREW Repl.by 8902362 2 Pc’s 501-b GR37ASK8901413 RONDELLA AZ 4,3 ZINCATA LOCK WASHER AZ 4,3 GALV 2 Pc’s GR37ASK8076202 FILTRO EMC CON INDUTTORE EMC-FILTER WITH INDUCTOR 1 Pc’s 527-a GR37ASK8901155 DADO M6M8 BH8 ZINCATO...
  • Page 6 www.groupdynamics-laundry.com sales@groupdynamics.lv Parte inferiore Lower session Code Descrizione Description GR37ASK8061824 MOTORE COMPLETO TD20 MOTOR COMPL. TD20 1 Pc’s 206-a GR37ASK8901969 VITE MRT-TT 5x12 FZB T20 SCREW MRT-TT 5x12 FZB T20 4 Pc’s 206-b GR37ASK8080119 CONDENSATORE 8UF 450V P2 CLASS CAPACITOR 8UF 450V P2 CLASS 1 Pc’s GR37ASK8065797 VENTOLA 120MM UL4...
  • Page 7 www.groupdynamics-laundry.com sales@groupdynamics.lv Vasca e parti correlate Cylinder and related parts Code Descrizione Description GR37ASK8801322 TELAIO COMPLETO TD60 FRONT FRAME COMPL. TD60 1 Pc’s GR37ASK8083949-49 TELAIO COMPLETO FRONT FRAME COMPL. 1 Pc’s GR37ASK8061932-49 COPERCHIO GRIGIO SEDE LAMPADA UL4 LAMP HOUSING LID GREY UL4 1 Pc’s GR37ASK8061887 SUPPORTO PER LAMPADA ULTEM TD20 UL4...
  • Page 8 www.groupdynamics-laundry.com sales@groupdynamics.lv Vasca e parti correlate Cylinder and related parts...
  • Page 9 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannello di controllo Control panel Pos Code Descrizione Description 401 GR37ASK8080887-69 PANNELLO WMD60.2 MECCANICA PANEL WMD60.2 MECH. 1 Pc’s 402 GR37ASK8079749 CAVO O-RING IN GOMMA O-RING CORD CELLULAR RUBBER 1 Pc’s 411 GR37ASK8081749-69 PULSANTE START/STOP STAMPATO TD PUSHBUT. START/STOP PRINTED TD 1 Pc’s 413 GR37ASK8081710-69 PULSANTE PRINCIPALE WMD60.2 PUSHBUTTON MAIN SWITCH WMD60.2 1 Pc’s...
  • Page 10 www.groupdynamics-laundry.com sales@groupdynamics.lv Schema elettrico Circuit diagram...
  • Page 11 GD6 Con condensatore GD6 Condensed version...
  • Page 12 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannellatura esterna Outer casing Code Descrizione Description GR37ASK8061817-81 COPERCHIO SUPERIORE GRIGIO TOP COVER GREY METALLIC 1 Pc’s 101-a GR37ASK8900338 VITE Vedi GR36ASK8902362 SCREW Repl.by 8902362 3 Pc’s 101-b GR37ASK8901413 RONDELLA AZ 4,3 ZINCATA LOCK WASHER AZ 4,3 GALV 2 Pc’s PANNELLO LATERALE COMPL.
  • Page 13 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannellatura esterna Outer casing...
  • Page 14 www.groupdynamics-laundry.com sales@groupdynamics.lv Parte superiore Upper session Code Descrizione Description GR37ASK8076029 PONTE FRONTALE FRONT BEAM 1 Pc's 501-a GR37ASK8900338 VITE vedi GR36ASK8902362 SCREW Repl.by 8902362 2 Pc's 501-b GR37ASK8901413 VITE vedi GR36ASK8902362 LOCK WASHER AZ 4,3 GALV 2 Pc's GR37ASK8077502-49 SEDE TANICA RECUPERO CONDENSA HOUSING WATER TANK 1 Pc's 503-a GR37ASK8902087...
  • Page 15 www.groupdynamics-laundry.com sales@groupdynamics.lv Parte inferiore Lower session Code Descrizione Description GR37ASK8061940 TRONCONE DI CANALE ESTERNO UL4 STUB AIRCANAL EXTERNAL AIR UL4 1 Pc's INVOLUCRO VENTOLA LATO INGRES- EXT.AIR FAN CASING INLET SIDE GR37ASK8052637 1 Pc's SO UL4 GR37ASK8061960 VENTOLA DIAM. 108 FAN IMPELLER DIA.
  • Page 16 www.groupdynamics-laundry.com sales@groupdynamics.lv Parte inferiore Lower session...
  • Page 17 www.groupdynamics-laundry.com sales@groupdynamics.lv Vasca e parti correlate Cylinder and related parts Code Descrizione Description GR37ASK8801322 TELAIO COMPLETO TD60 FRONT FRAME COMPL. TD60 1 Pc's GR37ASK8083949-49 TELAIO COMPLETO FRONT FRAME COMPL. 1 Pc's COPERCHIO GRIGIO SEDE LAMPADA GR37ASK8061932-49 LAMP HOUSING LID GREY UL4 1 Pc's SUPPORTO PER LAMPADA ULTEM TD20 GR37ASK8061887...
  • Page 18 www.groupdynamics-laundry.com sales@groupdynamics.lv Vasca e parti correlate Cylinder and related parts...
  • Page 19 www.groupdynamics-laundry.com sales@groupdynamics.lv Pannello di controllo Control panel Code Descrizione Description GR37ASK8080887-69 PANNELLO WMD60.2 MECCANICA PANEL WMD60.2 MECH. 1 Pc’s GR37ASK8079749 CAVO O-RING IN GOMMA O-RING CORD CELLULAR RUBBER 1 Pc’s GR37ASK8077503 VASCHETTA RECUPERO CONDENSA WATERTANK 1 Pc’s MANOPOLA VASCHETTA RECUPERO GR37ASK8077501-81 HANDLE WATER TANK 1 Pc’s...
  • Page 20 www.groupdynamics-laundry.com sales@groupdynamics.lv Schema elettrico Circuit diagram...
  • Page 21 www.groupdynamics-laundry.com sales@groupdynamics.lv Type: TD60.C Contents Updates ..................................................4 Introduction .................................................5 General product information ........................................6 Troubleshooting strategy ..........................................7 Product overview ..........................................8 Programme table ..............................................9 Programme descriptions ........................................... 10 Settings................................................. 11 Service menu ..............................................12 Service menu content ..........................................13 Fault indicators ..............................................15 Components and measurement values ....................................
  • Page 22 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Updates Revi- Date Description Initials sion 2009-08-12 Conference version 2010-04-29 Supplemented with information 2010-07-19 Added information about automatic lint filter detection...
  • Page 23 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Introduction You are holding the service manual for TD60 tumble dryers. It should be easy to service a tumble dryer. It is important that you, as a service technician, are provided the necessary conditions to work in an efficient and satisfactory manner. Our hope is that this service manual will prove a useful tool in your daily work.
  • Page 24 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C General product information Lint filter sensor A lint filter sensor was introduced in August 2010. If the lint filter is not fully seated or inserted incorrectly in the lint filter holder, the machine will not start. Moreover, an error message is dis- played: “Insert filter”.
  • Page 25: Troubleshooting Strategy

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Troubleshooting strategy At Asko, we believe in always remaining focused on the customer, and as an ASKO service techni- cian, you are one of the most important ambassadors of our brand. As such, it is important that the customer finds the service callout a pleasant experience.
  • Page 26: Product Overview

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Product overview TD60.C Programmes: A total of 7 programmes. Settings: 4 settings (Language, Child-safe, Buzzer, Heater 2) Knob and button descriptions Programme selector (J1) Turn clockwise or anti-clockwise to cycle through the different programmes and options in the various menus.
  • Page 27: Programme Table

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Programme table Programme Material Tempe- Max. Energy consump- Programme time rature load tion (approx. kWh) (kg) 1600 1600 Auto extra dry Cotton, linen Auto 2:25 1:55 normal dry Auto dry Cotton, linen Auto 2:15 1:45 normal dry *Auto normal dry Cotton, linen...
  • Page 28: Programme Descriptions

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Programme descriptions Programme designation Description Auto extra dry This programme is for items that are particularly difficult to dry, e.g. jeans with very thick seams. Auto dry These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto dry programme shuts off the heat slightly later than Auto normal dry.
  • Page 29 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Settings Opening the settings menu Is the machine on? First turn off the power at the main På/Av power switch (S1). Start Stop Press the Stop button (S3) while simultaneously pressing the main power switch (S1). ×...
  • Page 30 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Service menu Opening the service menu På/Av If the machine is on: First turn off the power at the main Start Stop power switch (S1). Press and hold the Start button (S2) while simultaneously pressing the main power switch (S1).
  • Page 31: Service Menu Content

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Service menu content Date the software was programmed (Year_Week) Date of manufacture of the control unit (Year_Week) Software version NCP0: Total number of cycles run NCP1: Number of cycles for Programme 1 NCP2 Number of cycles for Programme 2 NCP3: Number of cycles for Programme 3 NCP4:...
  • Page 32 www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Filter interval Sets the display interval for “Clean Lint Filter”. 0 = no display, 1 = display every programme etc. Condenser inter- Sets the display interval for “Clean condenser”. 0 = no display, 1 = display every 100 programmes etc. Total Reset Resets all settings to factory defaults.
  • Page 33: Fault Indicators

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Fault indicators Error message Cause Action Over Flow • A micro switch is opened when a full conden- • Check that the customer has emptied the tank and sed water tank is detected. Detection begins 30 restarted the machine.
  • Page 34: Components And Measurement Values

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Components and measurement values Item Component Measurement value Comment number Primary winding: 23.8 Ω 80 618 24 Motor 50 Hz, Auxiliary winding: 28.1 Ω 220/240 V Current: 1.1 A; 270 W; 2850 80 618 95 Motor 60 Hz, Winding resistance: The motor is a 2-pin motor and is directly connec-...
  • Page 35: Technical Data

    www.groupdynamics-laundry.com sales@groupdynamics.lv Service Manual TD60.C Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight: 39 kg (vented) 47 kg (condenser) Cylinder volume: 111 l Max. load capacity: EU 7.0 kg US/AU 6.0 kg Speed: 52 rpm Rated power: 1950 W = 10 A 2500 W = 16 A 3000 W = 16 A...
