Getting started with FortiGate-7000
Interface
Local VLAN ID
FIM02 local VLAN IDs
Interface
Local VLAN ID
[T]: Set remote TFTP server IP address: The IP address of the TFTP server.
[F]: Set firmware image file name: The name of the firmware file to be installed.
12. Press Q to quit this menu.
13. Press R to review the configuration.
If you need to make any corrections, press C and make the changes as required. When the configuration is correct
proceed to the next step.
14. Press T to start the TFTP transfer.
The firmware image is uploaded from the TFTP server and installed on the FPM module which then reboots.
When it starts up the module's configuration is reset to factory defaults. The module's configuration is
synchronized to match the configuration of the primary module. The new module reboots again and can start
processing traffic.
15. Verify that the configuration has been synchronized.
The following command output shows the sync status of the FIM modules in a FortiGate-7000 chassis. The field
in_sync=1 indicates that the configurations of the modules are synchronized.
diagnose sys confsync
status | grep in_sy
FIM04E3E16000080, Slave, uptime=177426.45, priority=2,
slot_id=1:2, idx=0, flag=0x0, in_sync=1
FIM10E3E16000063, Master, uptime=177415.38, priority=1,
slot_id=1:1, idx=1, flag=0x0, in_sync=1
If in_sync is not equal to 1 or if a module is missing in the command output you can try restarting the
modules in the chassis by entering execute reboot from any module CLI. If this does not solve the problem,
contact Fortinet support.
FortiGate-7000
Fortinet Technologies Inc.
Installing firmware on an FIM or FPM module from the BIOS using a TFTP server
MGMT1
11
MGMT1
21
MGMT2
MGMT3
12
13
MGMT2
MGMT3
22
23
MGMT4
14
MGMT4
24
44
