I have a speaker cabinet connected to the Att output
I have a speaker cabinet connected to the Thru output
I have a speaker cabinet connected to both the Thru and
Att output
And if you are hesitating about which Torpedo Captor to get:
My situation
I have a combo amplifier
I have an amplifier with fixed impedance
I have an amplifier with selectable impedance
I have an amplifier with selectable impedance and
a speaker cabinet
I have one or several amplifiers and one or
several speaker cabinets, and they all have (or
can be set to) the same impedance
I have one or several amplifiers and one or
several speaker cabinets, but they don't all have
the same impedance
6 Specifications
6.1 List of Power Amplifiers (available through Wall of
Sound)
Designation
SE 6L6 Configuration Single Ended - Class A with 6L6
SE EL34 Configuration Single Ended - Class A with EL34
SE EL84 Configuration Single Ended - Class A with EL84
SE KT88 Configuration Single Ended - Class A with KT88
PP 6L6 Configuration Push-Pull - Class AB with 6L6
PP EL34 Configuration Push-Pull - Class AB with EL34
PP EL84 Configuration Push-Pull - Class AB with EL84
PP KT88 Configuration Push-Pull - Class AB with KT88
6.2 List of Cabinets (available through Wall of Sound)
Designation
GUITAR cabinets
PinnacleHG Dr. Z ® "Z-Best®" Thiele Ported 2×12 with v30's
Voice30Blue Vox® AC30® loaded by the famous Celestion® Blue AlNiCo®
http://wiki.two-notes.com/
Characteristics
Impedance of the Captor
Impedance of the speaker cabinet
Impedance of the speaker cabinet
connected to the Thru output
Which version of Captor to get
Impedance of the combo's speaker cabinet
Impedance of the amp
All version will work. We recommand the 8 ohms
version, because it's the most common
impedance out there.
Impedance of the speaker cabinet
This same impedance
The impedance of the amp (or amps) you want to
play silently. You can use the Captor with the
others with the matching speaker cabinet in the
Thru output
Inspired by
