Windsor Spirit series Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING MACHINE
WARNING
Connect machine to a properly grounded outlet only. See grounding instructions.
Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
Use indoors only. Do not use outdoors or expose to rain.
Do not allow to be used as a toy. Close attention is necessary when used by or near children.
Use only as described in this manual. Use only manufacturer's recommended attachments.
Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
0
damaged, left outdoors, or dropped into water, return it to an authorized service center.
Do not pull or carry by cord, use cord as a handle, close adoor
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Do not handle plug or appliance with wet hands.
Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
Do not pick up anything that is burning or smoking, such as cigarettes, matches,
Do not use without filter screens in place (Located in dome and in lower tank).
Turn off all controls before unplugging.
Use extra care when cleaning on stairs.
Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where
they may be present.
INDUSTRIES, INC.,
98141
To reduce the risk of fire, electric shock, or injury:

SAVE THESE INSTRUCTIONS

1351 W. Stanford
Ave., Englewood CO 80110 USA *303-762-18OO'FAX 303-762-0817
Rev
1
on
a cord, or pull cord around sharp
or
hot ashes.
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spirit series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Windsor Spirit series

Summary of Contents for Windsor Spirit series

  • Page 1: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING MACHINE WARNING To reduce the risk of fire, electric shock, or injury: Connect machine to a properly grounded outlet only. See grounding instructions. Do not leave appliance when plugged in.
  • Page 2 Brush Drive Assembly Wiring Diagrams Record the model and serial number on the blue data label located at the rear of the machine These numbers are used when calling upon the Windsor dealer for parts and service. MODEL SERIAL NO.
  • Page 3 WARN I NG THIS FOR COMMERCIAL USE PRODUCT ONLY. grounding conductor can result In a risk of ELECTRICAL: electric shock. Check wlth a qualified elec- In the USA this vacuum operates on a standard 15 amp 11 5 volt A.C. power circuit (1 nomi- trician service person If you are in doubt...
  • Page 4 Equipment Set 1.) Connect hoses to dome. Loop power cord through strain relief as shown. Become familiar with the machine. ONIOFF CONTROLS; I .) Brush storage/Height adjustment. Brush On/Off switch. 3.) Brush circuit breaker. (6amp) switch. 5.) Vac/Pump circuit breaker. Handle release bar.
  • Page 5 Lower brush housing to the floor. Turn the control knob until the pin lines 1.) Set dome and recovery tank to the side. up with the slot in the bracket and the housing comes down. Use a clean bucket to fill the solution tank with hot water.
  • Page 6 11.) Release the solution lever about 6 Fill the solution tank. inches (1 cm) before the end of each pass to ensure all solution is Move machine to the cleaning area. picked up. 3.) Lower the brush housing to the floor. 12.) Allow each cleaning pass to overlap the previous pass about 1 inch Adjust the brush to the desired height.
  • Page 7 15.) Ventilate the room when cleaning has t Insl>ection: been completed. Keep all traffic off the Determine precisely what areas you are go- carpet until it is thoroughly dry. ing to clean. Note problem areas in the car- pet or tack strip. Look for loose carpet, 16.) When done cleaning for the day bring heavily damaged areas, discolored stains, the machine to a utility sink and floor...
  • Page 8 8 liters) of clean hot water. With machine over floor CAUTION: drain turn on vac/pump switch until Using non-Windsor parts to repair this solution tank is empty. machine will void the 6-3-1 warranty. Inspect spray pattern of jets. Remove jets and rinse if clogged.
  • Page 9 CAUTION: These procedures are performed by a Do not allow this machine to remain in a trained service technician. The regularity of vehicle or area where the temperature these procedures may depend on the ma- will be below 40°F (4OC). Allowing this chine’s use.

  • Page 10: Troubleshooting Chart

    Troubleshooting Chart Condition Corrective Action Power Dead electrical circuit breaker in fuse box Check building circuit breaker. Faulty power cord Replace Test switch for continuitymeplace if necessaaty. Faulty circuit breaker Test circuit breaker for continuity/Relace Internal wiring problem With the machine unplugged, check for, and correct, any loose wire connections inside the machine at the switches terminal block.
  • Page 11 Troubleshootina Chart Condition Corrective Action c o - Clean with steel wool. Corrosion on fitting Remove and soak in acetic acid (white vinegar). Lubricate lightly with silicone base lubricant. Make several passes at right angles to each other. Severe soil conditions Use a prespray.

  • Page 12: Servicing The Vac Motor

    Servicing the Vac Motor To access the vac motor first remove the solution tank. There are (2) screws which attach the the motor assembly it will be necessary to remove the screws which attach the motor to the END CAP If armature commutator is not concentric, extremely pitted, or grooved the motor will need to be replaced or sent to a qualified...
  • Page 13 Brush Assembly Rev.
  • Page 14 Tanks Each tank has a filter screen which protects the machine’s internal parts from damage. Ensure that these screens are in place and clean before operating machine. SPIRIT...
  • Page 15 Pump Repair Manifold Valve The SPIRIT is equipped with quick change jet nozzles which are easy to clean or re- place. PUMP ASSEMBLY 65115 1.) With tanks empty, tilt machine MOTOR 230V back. Press in and turn nozzle remove. HOUSING manifold ensure slot in tip runs parallel to manifold.
  • Page 16 Chassis Switc hes Handle PART NO. DESCRIPTION PART DESCRIPTION 34229 Frame, Main Chasis Awning 70088 Scr, 10-32 x 1/2 PHMS 57104 Nut, 10-32 w/Star Washer 73169 Strain Relief Scr, 8-32 x 7/8 PHMS 70449 23572 Cord Asm, 11 5V SJTW/-A 5 0 89081 Wheel, 1 0 Non-Marking Grey 23574...
  • Page 17 Brush Drive Assembly Periodically check the drive belt for wear. Replace worn or frayed belts before they break, when possible. To access the belt remove the belt cover. To replace the belt it is necessary to loosen the motor and remove the brush. The "preset"...
  • Page 18 POWER IN CIRCUIT BREAKER CIRCUIT BREAKER CHASSIS PUMP MOTOR BRUSH MOTOR 230V SPR-I Wiring Diagram 886 1 1...
