- Page 1 ALIEN TECHNOLOGY ALR-9930-ADEV ALR-9932-ADEV 8101943-000 Revision C QUICK START GUIDE...
- Page 2 CKNOWLEDGEMENTS OPYRIGHT CKNOWLEDGEMENTS The contents of this document are the property of Alien Technology™ Corporation and are copyrighted. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited. For additional copies if this document please contact: Alien Technology Corporation 18220 Butterfield Blvd.
- Page 3 CHAPTER 4 POWERING UNIT ......................... 13 CHAPTER 5 OEM INTERFACE BOARD....................14 CHAPTER 6 ALR-9930 JUMPER SETTINGS ................... 16 CHAPTER 7 ALR-9932 JUMPER SETTINGS ................... 17 • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™...
-
Page 4: Chapter 1 Part Identification
0500125-001 Circular Antenna 1300011- Software CD 0010 6 Volt Power 6800012-001 Supply 0800028-001 RS-232 Cable Variety of 0500111-001 1 Bag Sample Tags • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™... - Page 5 ALR-9930-A Part Identification Table • Identify and locate all components before proceeding to the reader hookup section. • If any parts are missing or damaged please contact Alien Technology Alien Technology Corporation 18220 Butterfield Blvd. Morgan Hill, CA 95037 www.alientechnology.com •...
-
Page 6: Chapter 2 Reader Hook Up
STEP 2: Plug the Circular Antenna into the OEM Reader Engine and the RS-232 Cable into the OEM Interface Board as shown in figure 2. RS-232 Cable 0800028-001 Circular Antenna cable with adaptors. 0500116-001 Figure 2. • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™... - Page 7 See FCC OET Bulletin 56 “Hazards of radio frequency and electromagnetic fields” and Bulletin 65 “Human exposure to radio frequency electromagnetic fields • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™...
-
Page 8: Chapter 3 Software Installation
Color settings can be found under: My Computer / Control Panel / Display / Display Properties / Settings / Color Palette STEP 3. Place the Alien CD in your CD drive. It will auto-run and present you with the following screen. - Page 9 STEP 5. Click on the “Next” button. This will popup a dialog box asking where to install the software. The default location is set to C:\Program Files\Alien RFID Gateway. This can be changed but it is recommended to keep this setting. Click the “Next” button to move to the next screen.
- Page 10 STEP 7. Click “Next” to move on to the Desktop Icon screen. This screen asks whether or not to create a shortcut icon to the Alien RFID Gateway and to place this shortcut on the desktop. The default setting it to go ahead and create the shortcut. Click “Next” to move to the next screen.
- Page 11 Click the “Install” button if all options are acceptable. STEP 9. The software will now proceed with the installation. Progress is shown by the window below. • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™...
- Page 12 STEP 10. When the Alien RFID Gateway installation has finished the following screen will appear. Click “Finish” to dismiss the window and exit the installation procedure. The software installation process is complete. Remove the software CD from the CD drive and store it for future use.
-
Page 13: Chapter 4 Powering Unit
Plug the Power Supply into the OEM Interface Board as shown in figure 3. Power Supply 6800012-001 Figure 4. Your OEM Reader Engine is now ready for use. Please refer to the Alien RFID Reader Engine Integration guide for instructions on the use of the unit. • D ARL-9930/32-ADEV D ’... -
Page 14: Chapter 5 Oem Interface Board
1 and 2. TP13 TP14 TP10 TP11 Pin 6 Pin 5 Pin 4 Pin 3 Pin 2 Pin 1 Figure 5. • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™... - Page 15 Serial Receive (from host to module)(TTL or RS-232)(PC TP13 connecting RS-232 to DB-9 – pin 3 or to DB25 – pin 2) • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™...
-
Page 16: Chapter 6 Alr-9930 Jumper Settings
6. JUMPER SHUNTS ARE INSTALLED FROM PIN 2 TO PIN 3 ON JP1-JP4. Figure 6. Figure 6. • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™... - Page 17 For use with the RS_232 Version of the OEM reader engine the jumper shunts should be installed as shown in figure 7. JUMPER SHUNTS ARE INSTALLED FROM PIN 1 TO PIN 2 ON JP1-JP4. Figure 7. • D ARL-9930/32-ADEV D ’ # 8101943-000 Rev C UICK TART EVELOPER UIDE © 2002, 2003 Alien Technology™...
