- Page 1 PS Model INSTALLATION AND OPERATION MANUAL FOR WOOD-BURNING SAUNA STOVES EN 15821:2011...
- Page 2 Resellers as well as the representative of our factory will be happy to assist you in choosing the appropriate sauna stove. For more information, visit our website at www.skamet.ee Dear Client You have purchased a high quality sauna stove, which will guarantee you sauna pleasures for many years.
- Page 3 The risk of damage and expenses caused due to the non- purposeful application shall be covered by the person, who made unau- thorised changes in the device. SKAMET Safe distance from flammable materials/surfaces (cm) PS-110 series models Distance from the side wall Distance from the back wall...
-
Page 4: General Information
General information Optimal sauna climate is achieved only when there is natural ventilation in the steam room: the inlet of fresh air has to be under the sauna stove near the fl oor (marked by letter A in Figure 1), and the outlet has to be by the ceiling (marked by letter B in Figure 1) as far as possible from the stone hearth. -
Page 5: Important Information
Important information Incorrect installation of the sauna stove may cause fi re hazard. Please read through the installation and the user’s manual carefully before the installation and use of the sauna stove. During installation it is very important to apply safe distances from the sauna stove and follow the instructions as follows: The sauna stove is installed in a room especially built for the purpose. - Page 6 6. Smoke channel 7. Maintenance port 8. End of the smoke channel 9. Opening of the smoke fl ue Figure 2. Cross section of the stove Table 3. Specifi cations of PS-series models PS-110 PS-110 5-12 5-12 70,5 70,5 PS-210...
- Page 7 Description of the sauna stove The sauna stove is covered by a metal housing. The sauna stove has three (on sides and at the back) double walls, which enable to decrease the safe distances. The stove con- sists of a furnace with an ash compartment under it and a compartment for stoves for the sauna hearth on top of it with a trapeze-shaped outlet fl...
- Page 8 Protection of walls When wooden walls (wooden boards, planks, logs, etc.) are closer to the stove than al- lowed according to safe distances, the walls have to be protected by installing required materials (heat barrier). Single-layer heat barrier is made of at least 7-mm thick fi bre- reinforced non-fl...
-
Page 9: Warranty Conditions
Hearth stones Stones of the hearth must not block the air circu- lation between the centre of the hearth and the housing. Some natural stones may contain improper sub- stances such as sulphur compounds, which make them unsuitable for the use as hearth stones. Clean the stones from dust before you pile them on the hearth. - Page 10 Hytte og Bolig AS Tlf. 22439000 www.hytteogbolig.no...
