- Page 2 Dear Customer, Congratulations on your purchase of a HEXAGONE robotic pool cleaner we trust you will enjoy the benefits of your new state of the art robotic cleaner. The cleaner range has been designed, manufactured and checked with the upmost care so that you will be completely satisfied with it.
- Page 3 Safety • Keep the robot out of the reach of children • Place the trolley so that the cleaner can reach the furthest corner of the pool. • Never let anybody enter the swimming pool during cleaning • Never put the trolley into the water, Only the robot has to go into the water •...
- Page 4 Index 1. How to set up your cleaner ? A – Unpacking B – Battery connection 2. How to use your Quick Vac ? A – Pool entry B – Start up D – Pool exit 3. Cleaning and maintenance A –...
- Page 5 1. How to set up your cleaner ? A – Unpacking Unpack the unit by taking the necessary precautions. Do not use sharp tools (cutter, knife ...) Check all items for damage from delivery. If damage is caused from the delivery please make a note on the delivery slip. Only the recipient can file a claim with the carrier, you have 48 hours to do so by registered letter with acknowledgment of receipt.
- Page 6 2. How to use your Quick Vac ? A – Pool entry • The trolley and the Battery box should be placed so that the robot can reach all corners of the pool; • Be sure to place the entire cable in the pool, removing any cable loops before entering the unit in water. •...
- Page 7 3. Cleaning and maintenance A - Cleaning of filter The filter bag must be cleaned after each use. IMPORTANT : Remove the filter from the Quick Vac. Put the bag upside down to empty theany largest debris Wash the filter under a tap or use a hose to spray.
- Page 8 Your vacuum cleaner has been manufactured in accordance with the highest standards. To use your equipment safely, observe the following: Keep the power supply unit far from the pool so as to prevent any falls. In order to avoid any risk of electric shock, never open the electronic control box. Call a qualified technician. ...
- Page 9 5 – Your warrantee These conditions correspond to the French laws in force at the date of printing. Manufacturers Conditions A - Conditions We guarantee that all materials are technically sound and free of defects of materials and manufacture and that they are consistent with the state of the art and techniques at the time of marketing.
- Page 10 6 – Exploded view and spare parts list ITEM REFERENCE DESIGNATION ZPVJD002 Pump/debris sealing flap ZPV005-D Cable ZPVBB001 Float ZPVQS002 Telescopic fixing point ZPVQS001 Mount for Telescopic fixing point ZPV026-D 360° multi direction wheels ZPV011-D Cable Plug ZPVQP001 Side Handle ZPV020-D-2100 Filter standard ZPV022-D-2100...
