Before you power your Cricket up for the first
time, verify that you have connected the motors
and battery as shown below.
9-Right Servo
NOTE: The Servo yellow wire faces toward middle of the PC board.
SPK-speaker wire
10-Left Servo
71 – Cricket Robot Documentation
12-Sonar Servo
11-Center Servo
No Connect
Black Battery
Red Battery
