Erie water treatment Eco Technical Manual

Hide thumbs Also See for Eco:
Table of Contents

Advertisement

Quick Links

Technical Manual
WATER SOFTENER
© 2016 erie water treatment
TM-EN-ULTRA-Rev2016.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco and is the answer not in the manual?

Questions and answers

Related Manuals for Erie water treatment Eco

Summary of Contents for Erie water treatment Eco

  • Page 1 Technical Manual WATER SOFTENER © 2016 erie water treatment TM-EN-ULTRA-Rev2016.01...
  • Page 2 Exploded view - Ultra 20L, 27L, 34L - System ................Page 24 Exploded view - Ultra 20L, 27L, 34L - Cover assembly ............Page 26 Exploded view - Valve body assembly - Eco ................Page 28 Exploded view - Valve body assembly - Eco .................Page 30...

  • Page 3: Warning & Safety Instructions

    WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the appliance, we advise you read  and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in this Technical Manual.
  • Page 4 OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE MIN-MAX: 1,4-8,3 bar / 20-120 psi   this appliance is configured to perform optimally at an operating pressure of 3 bar (45 psi) ±½ bar (7 psi); in case of a lower or higher operating pressure the performance may be affected negatively! ...
  • Page 5 INSTALLATION WITH 3-VALVE BYPASS SYSTEM (not included) Picture 1 To facilitate the installation, you may want to remove the Picture 4 main cover from the appliance (Ultra Mini only).  = mains water supply (untreated water)  = inlet of appliance (untreated water) BLUE CAP OF COVER ...

  • Page 6: Start-Up

    START-UP ELECTRICAL PERFORM REGENERATION 13. Manually initiate a regeneration, by pressing the scroll Picture 6 button repeatedly until the display shows: 1. Plug the transformers output lead into the socket on the appliances power cord; secure it by means of the Regen in 10 sec TwistLock clamp.

  • Page 7: Electronic Control Panel

    ELECTRONIC CONTROL PANEL Picture 8 SERVICE MODE In service mode the display shows: symbol button function on 1 line: the time of day and the remaining capacity;  to advance to the next SCROLL on 2 line: the total volume of water used since start-up. ...
  • Page 8 ELECTRONIC CONTROL PANEL SALT LEVEL ALARM PROGRAMMING INSTRUCTIONS - BASIC SETTINGS The electronic control panel is equipped with a salt level alarm, that will periodically remind the user to check the salt  Before entering the programming mode, make sure that level inside the brine cabinet and to refill it with water the appliance is in service mode.
  • Page 9 ELECTRONIC CONTROL PANEL Press the up or down button to set the volume  PROGRAMMING INSTRUCTIONS - of resin. CONFIGURATION PARAMETERS 7. Press the scroll button again; the display will show:  All configuration parameters on this appliance have been pre-programmed in the factory, to offer optimal Override: 7 days performance in a wide range of applications and situations.

  • Page 10: Maintenance

    ELECTRONIC CONTROL PANEL 12. Press the scroll button again; the display will show: DIAGNOSTICS MODE Salt alarm: ON  In the Diagnostics mode several operating parameters can be consulted; particularly during a service intervention, these parameters can be helpful to identify the cause of a Press the up or down button to activate or...
  • Page 11 MAINTENANCE ROUTINE CHECKS WATER CONDITIONER SALT Regularly the user should perform a basic check to verify if the Picture 11 appliance is functioning correctly, on the basis of the The appliance needs 'brine' for its periodic regenerations. This following control points: brine solution is made from water, that is automatically dosed 1.

  • Page 12: Hydraulic Flow Diagrams - Eco

    HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREP. BRINE DRAW SLOW RINSE SERVICE REFILL BRINE PREPARATION BRINE DRAW / SLOW RINSE Page 12...

  • Page 13: Hydraulic Flow Diagrams - Eco

    HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREP. BACKWASH BRINE DRAW SLOW RINSE FAST RINSE SERVICE REFILL BRINE PREPARATION BACKWASH BRINE DRAW / SLOW RINSE FAST RINSE Page 13...

  • Page 14: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION Hard (untreated) water Open or defective bypass Close or replace bypass to service Appliance in regeneration Wait until regeneration finishes or manually advance regeneration to end No salt in brine cabinet Add salt and initiate regeneration manually Salt bridging Break salt bridge(s) and initiate regeneration manually...
  • Page 15 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Control valve fails to Low operating pressure Check operating pressure; must be higher than 1,4 draw brine Drain flow adjuster closed too much Open drain flow adjuster slowly until unit draws brine Plugged injector and/or brine restrictor Clean injector and/or brine restrictor Plugged injector filter Clean injector filter...

  • Page 16: Electrical Wiring Diagrams

    ELECTRICAL WIRING DIAGRAMS     = flow meter    = power lead  = auxilliary contact (24 VAC, max. 500mA)  = refill solenoid (white)  = drain solenoid  = key pad    ...

  • Page 17: Default Configuration Parameter Settings

    DEFAULT CONFIGURATION PARAMETER SETTINGS Model Resin Units Metric Metric Metric Metric MaintInt (mths) Exchange capacity per liter resin (°f M (1) (2) Age correction (%) Resin (liters) Override (days) Cycle 1: REFILL (sec) Cycle 2: BRINE PREPARATION (min) Cycle 3: BRINE DRAW/SLOW RINSE (min) SNAP SNAP SNAP...

  • Page 18: Exploded View - Ultra 14L - System

    EXPLODED VIEW - ULTRA 14L - SYSTEM Page 18...
  • Page 19 38117 Bolt (2x) 38532 Overflow assembly DIM84/M6X20/P + Bolt&nut, brine well DIM934/M6/POL 39004 Dome label ‘erie water treatment’ 38522 Drain hose to be ordered per meter 38521 Clamp, drain hose (4x) 74163 Air gap with double hose barb Recommended Spare Part...

  • Page 20: Exploded View - Ultra 14L - Control Valve Assembly

    EXPLODED VIEW - ULTRA 14L - CONTROL VALVE ASSEMBLY Page 20...
  • Page 21 EXPLODED VIEW - ULTRA 14L - CONTROL VALVE ASSEMBLY Item Description Remark 541NCX9B/J80 Valve body assembly   541NCX4B/J8J Valve body assembly 72682 Timer mounting bracket 74101 Extension post (2x) 74100 Timer housing 74107 Bolt, timer housing (2x) 15/102 Screw, PCB (2x) ...

  • Page 22: Exploded View - Ultra 20L, 27L, 34L - System

    EXPLODED VIEW - ULTRA 20L, 27L, 34L - SYSTEM Page 22...
  • Page 23 38505 + 38515 Cabinet body, maxi 38400 Tank cover 19098 Ratchet fastener (2x) 38532 Overflow assembly DIM84/M6X20/P + Bolt&nut, brine well DIM934/M6/POL 39004 Dome label ‘erie water treatment’ 74163 Air gap with double hose barb Recommended Spare Part Page 23...

  • Page 24: Exploded View - Ultra 20L, 27L, 34L - Cover Assembly

    EXPLODED VIEW - ULTRA 20L, 27L, 34L - COVER ASSEMBLY Page 24...
  • Page 25 EXPLODED VIEW - ULTRA 20L, 27L, 34L - COVER ASSEMBLY Item Description Remark 38501 Cover, maxi 74164 Front panel assembly 72738 Printed Circuit Board  72737 Printed Circuit Board  15/102 Screw, PCB (2x) 72596 Timer housing 38200 Thumb screw (2x) 72263 Twist lock clamp, power cord ...

  • Page 26: Exploded View - Valve Body Assembly - Eco

    EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 26...
  • Page 27 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid retainer (4x) 413/134/24 Solenoid  541/229 Retainer, solenoid 413/58 Guide, solenoid 413/62 Spring, solenoid plunger   74099 Plunger, solenoid  74098 Diaphragm, solenoid 15/222 Screw, back cap (4x)

  • Page 28: Exploded View - Valve Body Assembly - Eco

    EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 28...
  • Page 29 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid (6x) 413/134/24 Solenoid (2x)  541/229 Retainer, solenoid 413/58 Guide, solenoid (2x) 413/62 Spring, solenoid plunger (2x)   74099 Plunger, solenoid (2x)  74098 Diaphragm, solenoid (2x)

  • Page 30: Exploded View - Valve Body Assembly

    EXPLODED VIEW - VALVE BODY ASSEMBLY Item Description Remark 15/87 Screw, valve head 72216 Valve head 541/300/G Drain flow control 2,0 gpm 11L, Eco 15L, Eco 541/300/J Drain flow control 2,6 gpm 185/115/1 O-ring, drain line adaptor 74018 Nut, drain solenoid 74016 Drain line adaptor...
  • Page 31 Page 31...

  • Page 32: Technical Data - Eco

    TECHNICAL DATA - ECO Technical specifications: Model Ultra Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure...

  • Page 33: Technical Data - Eco

    TECHNICAL DATA - ECO Technical specifications: Model Ultra Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure...
  • Page 34 Page 34...
  • Page 35 Page 35...
  • Page 36 Manufactured & Assembled by erie water treatment a division of Aquion, Inc. www.eriewatertreatment.com...
