- Page 1 Technical Manual WATER SOFTENER Models: SOF-CS- SOF-BBS © 2017 erie water treatment TM-EN-SOF-CS_BBS-Rev2017.03...
-
Page 2: Table Of Contents
TABLE OF CONTENT Table of content ........................Page 2 Warning & Safety instructions ....................Page 3 Operating conditions & Requirements ..................Page 4 Installation ..........................Page 5 Commissioning ......................... Page 6 Electronic control panel ......................Page 7 Maintenance ..........................Page 11 Hydraulic flow diagrams - Eco .................... -
Page 3: Warning & Safety Instructions
WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the appliance, we advise you read and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in this Technical Manual. -
Page 4: Operating Conditions & Requirements
OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE MIN-MAX: 1,4-8,3 bar / 20-120 psi this appliance is configured to perform optimally at an operating pressure of 3 bar (45 psi) ±½ bar (7 psi); in case of a lower or higher operating pressure the performance may be affected negatively! ... -
Page 5: Installation
INSTALLATION 5. Connect the house/application to the outlet of the 3-valve PREPARATION BRINE CABINET bypass system. (only for SOF-CS-) DRAIN Picture 1&11.a To facilitate the installation, you may want to remove the salt We recommend the use of a stand pipe with P-trap. lid and main cover from the brine cabinet. -
Page 6: Commissioning
COMMISSIONING to reduce the residual hardness: turn the screw ELECTRICAL clockwise. 8. Measure the residual water hardness with a water Picture 6 hardness test kit; readjust if necessary. 1. Plug the transformers output lead into the socket on the appliances power cord;... -
Page 7: Electronic Control Panel
ELECTRONIC CONTROL PANEL To reset the maintenance reminder, simply access the Picture 8 configuration parameters programming mode. symbol button function SERVICE MODE to advance to the next SCROLL parameter to increase the value of the In service mode the display shows: ... - Page 8 ELECTRONIC CONTROL PANEL Press the scroll button again; the display will show: If the control panel is left in this position, a delayed regeneration will be started at the indicated Exit preprogrammed time of regeneration. To cancel this mode, press the scroll button repeatedly;...
- Page 9 ELECTRONIC CONTROL PANEL Press the up or down button to set the volume Press the up or down button to set the reserve of resin. capacity: Variable: the reserve capacity is calculated 6. Press the scroll button again; the display will show: automatically, based on the registered daily water usage.
- Page 10 ELECTRONIC CONTROL PANEL DIAGNOSTICS MODE In the Diagnostics mode several operating parameters can be consulted; particularly during a service intervention, these parameters can be helpful to identify the cause of a problem or malfunction. Before entering the Diagnostics mode, make sure that the appliance is in service mode.
-
Page 11: Maintenance
MAINTENANCE WITH 3-VALVE BYPASS SYSTEM (not included) RECOMMENDATION Picture 10.a Notwithstanding the reliability of the appliance, we strongly recommend to have it serviced and maintained on a regular SERVICE POSITION basis by a competent and duly trained technician. He will be ... - Page 12 MAINTENANCE SANITIZING THE APPLIANCE This appliance is manufactured from premium quality material and assembled in safe conditions to assure it is clean and sanitary. If installed and serviced correctly, this appliance will not infect or contaminate your water supply. However, as in any 'device' plumbed-in in your water distribution system, a proliferation of bacteria is possible, especially in case of 'stagnant water'.
-
Page 13: Hydraulic Flow Diagrams - Eco
HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREP. BRINE DRW SLOW RINSE SERVICE REFILL BRINE PREPARATION BRINE DRAW / SLOW RINSE Page 13... -
Page 14: Hydraulic Flow Diagrams - Eco
HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREP. BACKWASH BRINE DRAW SLOW RINSE FAST RINSE SERVICE REFILL BRINE PREPARATION BACKWASH BRINE DRAW / SLOW RINSE FAST RINSE Page 14... -
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Hard (untreated) water Open or defective bypass Close or replace bypass to service Appliance in regeneration Wait until regeneration finishes or manually advance regeneration to end No salt in brine cabinet Add salt and initiate regeneration manually Salt bridging Break salt bridge(s) and initiate regeneration manually... - Page 16 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Improper brine draw Low operating pressure Check operating pressure; must be higher than 1,4 Plugged injector and/or brine draw restrictor Clean injector and/or brine draw restrictor Plugged injector filter Clean injector filter Restricted drain line Verify drain line for kinks or restrictions Restricted brine line Verify brine line for kinks or restrictions Leak in brine line...
-
Page 17: Electrical Wiring Diagrams
ELECTRICAL WIRING DIAGRAMS = flow meter = power lead = auxilliary contacts (24 VAC, max. 500mA) = refill solenoid (white) = drain solenoid = key pad = flow meter ... -
Page 18: Default Configuration Parameter Settings - Sof-Cs
DEFAULT CONFIGURATION PARAMETER SETTINGS - SOF-CS Model SOF-CS-Eco- Resin Metric Metric Metric Metric Units Metric MaintInt (mths) (1) (2) Exchange capacity per liter resin (°f M Resin (liters) Override (days) Cycle 1: REFILL (sec) Cycle 2: BRINE PREPARATION (min) Cycle 3: BRINE DRAW/SLOW RINSE (min) Regen Dlyd/Immd Dlyd/Immd... -
Page 19: Default Configuration Parameter Settings - Sof-Bbs
DEFAULT CONFIGURATION PARAMETER SETTINGS - SOF-BBS Model SOF-BBS-Eco- Resin Metric Units Metric MaintInt (mths) (1) (2) Exchange capacity per liter resin (°f M Resin (liters) Override (days) Cycle 1: REFILL (sec) Cycle 2: BRINE PREPARATION (min) Cycle 3: BRINE DRAW/SLOW RINSE (min) Regen Dlyd/Immd Dlyd/Immd... -
Page 20: Exploded View - Sof-Cs - System
EXPLODED VIEW - SOF-CS - SYSTEM Page 20... - Page 21 Eco 15L, Eco 20L, Eco 39091 Cabinet body, maxi Eco 26L, Eco 32L, Eco 20L, Eco 38532 Overflow assembly 39004 Dome label ‘erie water treatment’ 39099 Label ‘Softena’ (mini) Eco 11L, Eco 39100 Label ‘Softena’ (midi) Eco 15L, Eco 20L, Eco 39101 Label ‘Softena’...
-
Page 22: Exploded View - Sof-Cs - Cover Assembly
EXPLODED VIEW - SOF-CS - COVER ASSEMBLY Page 22... - Page 23 EXPLODED VIEW - SOF-CS - COVER ASSEMBLY Item Description Remark 38511 Thumb screw, PCB cover 38545 PCB cover 15/102 Screw, PCB 74280 Printed Circuit Board 74279 Printed Circuit Board 38551 Cover assembly 72685 Backwash solenoid cable (black) ...
-
Page 24: Exploded View - Sof-Bbs - System
EXPLODED VIEW - SOF-BBS - SYSTEM Page 24... - Page 25 Eco 11L, Eco PT/1035/BA Pressure tank 10x35 Eco 32L, Eco E8000 Softening resin 39004 Dome label ‘erie water treatment’ 39099 Label ‘Softena’ (mini) Eco 11L, Eco 39100 Label ‘Softena’ (midi) Eco 32L, Eco J/0918(W) Tank jacket, mini Eco 11L, Eco...
-
Page 26: Exploded View - Valve Body Assembly - Eco
EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 26... - Page 27 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid retainer (4x) 413/134/24 Solenoid 541/229 Retainer, solenoid 413/58 Guide, solenoid 413/62 Spring, solenoid plunger 74099 Plunger, solenoid 74098 Diaphragm, solenoid 15/222 Screw, back cap (4x) 541/286/3 Back cap 74258...
-
Page 28: Exploded View - Valve Body Assembly - Eco
EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 28... - Page 29 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid (6x) 413/134/24 Solenoid (2x) 541/229 Retainer, solenoid 413/58 Guide, solenoid (2x) 413/62 Spring, solenoid plunger (2x) 74099 Plunger, solenoid (2x) 74098 Diaphragm, solenoid (2x) 15/222 Screw, back cap (4x) 541/274/3...
-
Page 30: Exploded View - Sof-Cs - Valve Head Assembly
EXPLODED VIEW - SOF-CS - VALVE HEAD ASSEMBLY Item Description Remark 15/87 Screw, valve head 72216 Valve head 541/300/G Drain flow control 2,0 gpm 11L, Eco 15L, Eco 541/300/J Drain flow control 2,6 gpm 185/115/1 O-ring, drain line adaptor 74018 Nut, drain solenoid 74016 Drain line adaptor... -
Page 31: Exploded View - Sof-Bbs - Valve Head & Timer Assembly
EXPLODED VIEW - SOF-BBS - VALVE HEAD & TIMER ASSEMBLY Item Description Remark 72263 Twist lock clamp, power cord 70971 Power cord 72519 Flow meter cable 71681 Backwash solenoid cable (black) 71682 Refill solenoid cable (white) ... -
Page 32: Technical Data - Sof-Cs-Eco
TECHNICAL DATA - SOF-CS-ECO Technical specifications: Model SOF-CS-Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure Model SOF-CS-Eco Resin (Ltr) -
Page 33: Technical Data - Sof-Cs-Eco
TECHNICAL DATA - SOF-CS-ECO Technical specifications: Model SOF-CS-Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure Model SOF-CS-Eco Resin (Ltr) -
Page 34: Technical Data - Sof-Bbs-Eco
TECHNICAL DATA - SOF-BBS-ECO Technical specifications: Model SOF-BBS-Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure Model SOF-BBS-Eco Resin (Ltr) -
Page 35: Technical Data - Sof-Bbs-Eco
TECHNICAL DATA - SOF-BBS-ECO Technical specifications: Model SOF-BBS-Eco Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure Model SOF-BBS-Eco Resin (Ltr) - Page 36 Page 36...
- Page 37 Page 37...
- Page 38 Page 38...
- Page 39 Page 39...
- Page 40 Manufactured & Assembled by erie water treatment a division of Aquion, Inc. www.eriewatertreatment.com...
