SYSTEM REQuIREMENTS

• ADSL/VDSL Internet service
• Computer with:
• Microsoft Windows
• Internet Explorer 9, Firefox 23, Safari 7, or Chrome 28 or higher version with Java installed
and enabled

PRODuCT SETuP

HARDWARE SETUP

PC
DSL-124 Phone
PC
DSL-124 Phone
Power
PC
DSL-124
PC
PC
Power
DSL-124
DSL-124
®
10/8/7/Vista/XP SP3 or Mac with OS X 10.3 or higher
Step 1
Position your DSL-124 near your PC and a telephone wall jack
which provides DSL service. Keep the modem router in an open
area for better wireless coverage.
Step 2
Plug one end of the supplied DSL phone cable into the DSL port on
the back of the modem router, and the other end into the telephone
wall jack.
Step 3
Connect the supplied power adapter to the modem router and a
power outlet, and press the power button. The device LEDs will light
up. Wait approximately one minute before proceeding to step 4.
Step 4
Plug one end of the supplied Ethernet cable into the port labeled
1 on the back of the modem router, and the other end into the
Ethernet port on your computer.
If you are setting up the DSL-124 using a laptop or mobile
device, connect using the default Wi-Fi network name D-Link.
