Lectrotab MLC-1 Installation & Operation Manual page 9

Enter, Adjust and Exit Program Mode:
•
Before entering program mode, 12vdc or 24vdc must be applied to MLC
terminals 1, 2 and 7 (see wiring)
•
Press and hold Bow Down (top) button and Bow Up (bottom) button for 4
seconds to enter program mode
•
LED L1 (top left LED) will begin flashing and LED R1 (top right LED) will be lit
constantly
•
Press and release the Port Side Down (left) button to cycle through the three
settings under "Setting"
•
Press and release the Starboard Side Down (right) button to change the "Setting
Value"
•
Press and hold Bow Down (top) button and Bow Up (bottom) button for 4
seconds to exit and save new value
Setting Enter
(1L) Auto
Press Bow
Retract
Down and Bow
Last
Up 4 sec.
Setting
(2L)
Press Bow
Actuator
Down and Bow
Stroke
Up 4 sec.
Time
(3L) Swap Press Bow
LED Down and Bow
tracking Up 4 sec.
Program Mode Sequence
Change Setting
Change Setting
Press/Release Press/Release
Port Bow Side
Down
Press/Release Press/Release
Port Bow Side
Down
Press/Release Press/Release
Port Bow Side
Down
Setting Value Default
Value
R1 = Standard
Stbd Bow R2 = Last Tab
Down Set
R1=4sec,
R2=5sec.,
Stbd Bow
R3=6s, R4=7s,
Down
R5=8s
R1 = LEDs
track tab
position
Stbd Bow
R2 = LEDs
Down
track button
press
9
Program Details
R1=Standard Auto Retract
R1 R2=Return to last tab position
before key switch off
Change setting value to match
R5 actuator stroke time to fully
deploy
R1==LEDs track angle of tab
position
R1
R2=LEDs track same side as
button being pressed
