Clean Air Optima CA-803 User Manual

Airwasher 2in1: air purifying & air humidifying
Hide thumbs

Advertisement

Quick Links

Download this manual
Airwasher
2in1: Air purifying &
Air humidifying
User's Manual
CA-803

Advertisement

loading
Need help?

Need help?

Do you have a question about the Optima CA-803 and is the answer not in the manual?

Questions and answers

Related Manuals for Clean Air Optima CA-803

Summary of Contents for Clean Air Optima CA-803

  • Page 1 Airwasher 2in1: Air purifying & Air humidifying User’s Manual CA-803...
  • Page 2 Clean Air Optima CA-803 Product Name - 230 35W (natural humidifaction) 250ml/h 4 Liter Suitable for rooms up to 35m² / 90m³ / 375ft² 6,4 Kg 380(width)X207(length)X396(height)
  • Page 4 - 230...
  • Page 5 airwasher...
  • Page 7 Chlorine, acid type and others...
  • Page 8 It can cause the sensor not to work properly. Dry the water drop Dry the water drop inside completely. inside completely.
  • Page 9 Completely dry!

  • Page 10: Water Tank

    Outlet •• I t is the place where humidified and purified air will evaporative Operation Part Water tank cover • Refer to the explanation on • Place the water tank operation part on page 11) and close it. • It is a part that displays Water tank current surrounding humidity and function)
  • Page 11 Mode Manual Level Lamp Timer Power It is a button to turn ON/OFF the Mood lamp. It is executed automatically for aircleaning when the device power is ON.
  • Page 13 Do not put flammable substances inside the water tank. It may ignite. Open the watertank cover and pull Open the watertank lid and fill in the the water bottle out. First pull out the water tank when disassembling the water tank part. Close the watertank lid.
  • Page 14 Evaporative humidifying system Operation of Sensor Display of Indoor Humidity It displays that the air will be purified...
  • Page 15 Mode Manual Level Lamp Timer Power Put the watertank inside the body. It requires 20 seconds for the water to be filled in the water tank after the water tank is put inside the body. Plug in the power and operate when “Empty” display is disappeared.
  • Page 16 ' (Level) ▪ If the humidification level button is pressed, it is displayed in sequence of Low ->High->Turbo repeatedly. Manual Mode Manual Remove the remaining water in the water bassin, supply water in the water tank and put it back. When the water is supplied completely, start the operation.
  • Page 17 ▪ When the power is ON, clean air is emitted automatically.
  • Page 18 If the desired humidity is lower than the current indoor humidity, it will not be humidified any more. Press the Manual button to set it higher than the current indoor humidity. When the current humidity exceeds the desired humidity, the humidification stops and the current humidity and desired humidity are displayed alternately.
  • Page 19 Before cleaning you MUST Watertank (Daily) tank Body (When it gets dirty) ECO-Air Plus Filter Remove dust on the surface of ECO-Air Plus Filter using a cleaner or a soft brush. Do not clean the ECO-Air Plus filter with water. If it is cleaned with water, it may lead to bad performance.
  • Page 20 Clean the waterbassin twice per week Pull out the water tank cover and water tank. Pull out the waterbassin. The water tank should be taken out first Refer to the method on disassembling the before you can remove the waterbassin. water tank on page 12.
  • Page 21 Use a soft sponge to clean the water bassin. When the water level sensor is fallen out, assemble it as follow Put in the humidification filter (Rotor) and Put the water tank and water tank cover install the water bassin in the body. in the body.
  • Page 22 Clean the humidification filter (Rotor) 2 - 3 per week To remove the humidification filter (Rotor) of water tank part, refer to page 20. Soak the humidification filter (Rotor) in the Disassemble the humidification filter (Rotor). water and clean it using a soft sponge. If the stain cannot be removed, it should be soaked in warm water ( under 40°C) with dissolved neutral detergent for about 3 hours and rinse away with...
  • Page 23 Tel: +49(0)5921 878-121 E-mail: info@optima-luftreiniger.de by yourself Can't t Staining (powder) when A ow...

  • Page 24: Warranty

    Take in this case, your supplier or, if that is not possible with Clean Air Optima contact. If the defect in the device to something other than material and / or workmanship be due, processing or repair costs will be billed.
