Summary of Contents for Dodge Journey 2017

  • Page 1 2017 J O U R N E Y USER GUIDE...
  • Page 2 I M P O R T A N T T hi s User Gu id e is intende d to famili arize yo u with the imp orta n t fe atu res o f yo u r veh icle. Yo ur Owne r’s Manual, Nav ig atio n/Uco nn ec t Ma n ua ls , Warra nty B ooklets and Tire Warranty can be fo und o n yo ur DV D (if a ppl i ca ble) or b y visi ting the we bs ite o n the back co ve r of you r Use r Gu id e.

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S INTRODUCTION/WELCOME POWER INVERTER ... . . 109 POWER OUTLETS ... . . 110 WELCOME FROM FCA US LLC .

  • Page 4: Introduction/Welcome

    I N T R O D U C T I O N / W E L C O M E WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. Your new FCA US vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 5 I N T R O D U C T I O N / W E L C O M E VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc.

  • Page 6: Controls At A Glance

    C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Instrument Cluster Display Controls pg. 104 2. Turn Signal/Light Lever pg. 61 3. Instrument Cluster pg. 6 4. Instrument Cluster Display pg. 6 5.
  • Page 7 C O N T R O L S A T A G L A N C E 9. Switch Panel • Hazard Switch • Rear Defroster pg. 68 • Electronic Stability Control (ESC) OFF Indicator Light pg. 119 • Air Recirculation pg. 69 10.

  • Page 8: Instrument Cluster

    C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Temperature Gauge 2. Tachometer 3. Instrument Cluster Display (See page 114 for Instrument Cluster Warning Light information.)

  • Page 9: Speedometer

    C O N T R O L S A T A G L A N C E 4. Fuel Gauge 5. Speedometer 6. Fuel Filler Door Location (See page 119 for Instrument Cluster Indicator Lights information.)

  • Page 10: Getting Started

    G E T T I N G S T A R T E D KEY FOB Locking And Unlocking The Doors And Liftgate Lock The Doors And Liftgate Push and release the lock button on the key fob to lock all doors and liftgate. The turn signal lights will flash, and the horn will chirp to acknowledge the signal.

  • Page 11: Remote Start

    G E T T I N G S T A R T E D Emergency Key Should the battery in the vehicle or the key fob go dead, there is an emergency key located in the key fob. To remove the emergency key, slide the button at the back of the key fob sideways with your thumb and then pull the key out with your other hand.
  • Page 12 G E T T I N G S T A R T E D To Unlock From The Driver Or Passenger Side: With a valid Keyless Enter-N-Go key fob located outside the vehicle and within 5 ft (1.5 m) of the driver or passenger side door handle, grab either front door handle to unlock the door automatically.
  • Page 13 G E T T I N G S T A R T E D NOTE: • If “Unlock All Doors 1st Press” is programmed, all doors will unlock when you grab hold of the front driver's door handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press,”...

  • Page 14: Keyless Enter-N-Go - Ignition

    G E T T I N G S T A R T E D KEYLESS ENTER-N-GO — IGNITION Engine Starting/Stopping Starting Normal starting of the vehicle can only happen with a valid Keyless Enter-N-Go key fob inside the vehicle. 1. Place the gear selector in PARK or NEU- TRAL.

  • Page 15: Vehicle Security Alarm

    G E T T I N G S T A R T E D 2. Push the ENGINE START/STOP button a second time to change the ignition switch to the ON/RUN position. 3. Push the ENGINE START/STOP button a third time to return the ignition switch to the OFF position.

  • Page 16: Occupant Restraint Systems

    G E T T I N G S T A R T E D OCCUPANT RESTRAINT SYSTEMS Some of the most important safety features in your vehicle are the restraint systems. Occupant Restraint Systems Features • Seat Belt Systems • Supplemental Restraint Systems (SRS) Air Bags •...
  • Page 17 G E T T I N G S T A R T E D WARNING! • Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.
  • Page 18 G E T T I N G S T A R T E D Change Of Status If the driver or outboard front seat passenger (if equipped with outboard front passenger seat BeltAlert) unbuckles their seat belt while the vehicle is traveling, the BeltAlert warning sequence will begin until the seat belts are buckled again.
  • Page 19 G E T T I N G S T A R T E D WARNING! • Wearing your seat belt incorrectly could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of the seat belt. Follow these instructions to wear your seat belt safely and to keep your passengers safe, too.
  • Page 20 G E T T I N G S T A R T E D Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, and next to your arm in the rear seat (for vehicles equipped with a rear seat).
  • Page 21 G E T T I N G S T A R T E D Adjustable Upper Shoulder Belt Anchorage In the driver and front passenger seats, the top of the shoulder belt can be adjusted upward or downward to position the seat belt away from your neck. Push or squeeze the anchorage button to release the anchorage, and move it up or down to the position that serves you best.
  • Page 22 G E T T I N G S T A R T E D WARNING! • ONLY use a Seat Belt Extender if it is physically required in order to properly fit the original seat belt system. DO NOT USE the Seat Belt Extender if, when worn, the distance between the front edge of the Seat Belt Extender buckle and the center of the occupant’s body is LESS than 6 inches.
  • Page 23 G E T T I N G S T A R T E D Energy Management Feature — If Equipped This vehicle has a seat belt system with an Energy Management feature in the outboard front seating positions and in the outboard rear seating positions (if equipped with outboard rear seat Energy Management feature) that may help further reduce the risk of injury in the event of a collision.
  • Page 24 G E T T I N G S T A R T E D How To Engage The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire seat belt is extracted. 3.
  • Page 25 G E T T I N G S T A R T E D Active Head Restraint (AHR) Components: Active Head Restraint (AHR) Components 1 — Head Restraint Front Half (Soft Foam and Trim) 2 — Seatback 3 — Head Restraint Back Half (Decora- tive Plastic Rear Cover) 4 —...
  • Page 26 G E T T I N G S T A R T E D Resetting Active Head Restraints (AHR) If the Active Head Restraints are triggered during a collision, the front half of the head restraint will be extended forward and separated from the rear half of the head restraint (See Image).
  • Page 27 G E T T I N G S T A R T E D Air Bag Warning Light The ORC monitors the readiness of the electronic parts of the air bag system whenever the ignition switch is in the START or ON/RUN position. If the ignition switch is in the OFF position or in the ACC position, the air bag system is not on and the air bags will not inflate.
  • Page 28 G E T T I N G S T A R T E D Front Air Bags This vehicle has front air bags and lap/shoulder belts for both the driver and front passenger. The front air bags are a supplement to the seat belt restraint systems. The driver front air bag is mounted in the center of the steering wheel.
  • Page 29 G E T T I N G S T A R T E D The first stage inflator is triggered immediately during an impact that requires air bag deployment. A low energy output is used in less severe collisions. A higher energy output is used for more severe collisions.
  • Page 30 G E T T I N G S T A R T E D The steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as the air bags inflate to their full size. The front air bags fully inflate in less time than it takes to blink your eyes.
  • Page 31 G E T T I N G S T A R T E D WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury.
  • Page 32 G E T T I N G S T A R T E D WARNING! Occupants, including children, who are up against or very close to Side Air Bags can • be seriously injured or killed. Occupants, including children, should never lean on or sleep against the door, side windows, or area where the side air bags inflate, even if they are in an infant or child restraint.
  • Page 33 G E T T I N G S T A R T E D Rollover Events Side Air Bags are designed to activate in certain rollover events. The ORC determines whether the deployment of the Side Air Bags in a particular rollover event is appropriate, based on the severity and type of collision.
  • Page 34 G E T T I N G S T A R T E D If A Deployment Occurs The front air bags are designed to deflate immediately after deployment. NOTE: Front and/or side air bags will not deploy in all collisions. This does not mean something is wrong with the air bag system.
  • Page 35 G E T T I N G S T A R T E D Enhanced Accident Response System Reset Procedure In order to reset the Enhanced Accident Response System functions after an event, the ignition switch must be changed from ignition START or ON/RUN to ignition OFF. Carefully check the vehicle for fuel leaks in the engine compartment and on the ground near the engine compartment and fuel tank before resetting the system and starting the engine.
  • Page 36 G E T T I N G S T A R T E D • These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded.
  • Page 37 G E T T I N G S T A R T E D Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Recommended Type Of Child Restraint Children who are two years Either an Infant Carrier or a old or younger and who have Convertible Child Restraint, Infants and Toddlers...
  • Page 38 G E T T I N G S T A R T E D WARNING! Do not install a rear-facing car seat using a rear support leg in this vehicle. The floor of this vehicle is not designed to manage the crash forces of this type of car seat. In a crash, the support leg may not function as it was designed by the car seat manufac- turer, and your child may be more severely injured as a result.
  • Page 39 G E T T I N G S T A R T E D WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child re- straint.
  • Page 40 G E T T I N G S T A R T E D 2. Pull the release loop forward to release the latch and seat cushion. Release Loop 3. Lift the seat cushion up and push back to lock it in the booster seat position. 4.
  • Page 41 G E T T I N G S T A R T E D WARNING! In a severe collision, the booster seat may be damaged and should be inspected by an authorized dealer and possibly replaced before it is used again. The integrated booster seat must be replaced following a collision that meets any of the following criteria: •...
  • Page 42 G E T T I N G S T A R T E D Recommendations For Attaching Child Restraints Restraint Combined Use any attachment method shown with an “X” Below Type Weight of the LATCH – Seat Belt LATCH – Seat Belt + Child + Child Lower An-...
  • Page 43 G E T T I N G S T A R T E D LATCH Positions For Installing Child Restraints In This Vehicle Lower Anchor / Top Tether Locations (Third Row Shown – If Equipped) Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage sys- tem until the combined weight of What is the weight limit (child’s...
  • Page 44 G E T T I N G S T A R T E D Frequently Asked Questions About Installing Child Restraints With LATCH 5 Passenger Vehicle: All second row head restraints are Can the head restraints be removable. removed? 7 Passenger Vehicle: All second and third row head restraints are removable.
  • Page 45 G E T T I N G S T A R T E D Locating The Upper Tether Anchorages There are tether strap anchorages behind each second row seating position, located on the back of the seat, near the floor. LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side.
  • Page 46 G E T T I N G S T A R T E D WARNING! • Use anchorages B and C to install a LATCH-compatible child restraint in the center seating position (2). Do not install a LATCH-compatible child restraint using anchorages C and D.
  • Page 47 G E T T I N G S T A R T E D How To Stow An Unused Switchable-ALR (ALR) Seat Belt When using the LATCH attaching system to install a child restraint, stow all ALR seat belts that are not being used by other occupants or being used to secure child restraints. An unused belt could injure a child if they play with it and accidentally lock the seat belt retractor.
  • Page 48 G E T T I N G S T A R T E D Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Third Row Shown – If Equipped Automatic Locking Retractor (ALR) Locations Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit Always use the tether anchor (child’s weight + weight of...
  • Page 49 G E T T I N G S T A R T E D Installing A Child Restraint With A Switchable Automatic Locking Retractor (ALR) Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder belt.
  • Page 50 G E T T I N G S T A R T E D Installing A Child Restraint With A Cinching Latch Plate (CINCH) — If Equipped: Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder belt.
  • Page 51 G E T T I N G S T A R T E D Installing Child Restraints Using The Top Tether Anchorage WARNING! Do not attach a tether strap for a rear-facing car seat to any location in front of the car seat, including the seat frame or a tether anchorage.

  • Page 52: Head Restraints

    G E T T I N G S T A R T E D 4. Remove slack in the tether strap according to the child restraint manufacturer’s instructions. Rear Seat Tether Strap Mounting WARNING! • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
  • Page 53 G E T T I N G S T A R T E D When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts.
  • Page 54 G E T T I N G S T A R T E D Head Restraints — Second Row Seats The second row seats are equipped with adjustable and removable head restraints. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button located on the base of the head restraint, and push downward on the head restraint.

  • Page 55: Front Seats

    G E T T I N G S T A R T E D FRONT SEATS Power Seats The power seat switch, located on the out- board side of the seat near the floor, con- trols forward/back, up/down, and tilt adjust- ment.
  • Page 56 G E T T I N G S T A R T E D Manual Seat Adjustment Forward/Rearward Lift up on the adjusting bar located at the front of the seat near the floor and release it when the seat is at the desired position. Then, using body pressure, move forward and backward on the seat to be sure that the seat adjusters have latched.
  • Page 57 G E T T I N G S T A R T E D Flip 'n Stow Front Passenger Seat Storage The seat latch release-loop is located in the center of the seat cushion between the seat cushion and the seatback. Pull the loop upward to release the latch and then for- ward to open the seat to the detent position.

  • Page 58: Rear Seats

    G E T T I N G S T A R T E D REAR SEATS 60/40 SPLIT SECOND-ROW PASSENGER SEATS To Lower The Seatback 1. Locate the seatback release lever on the lower outboard side of the seat. 2. Place one hand on the seatback and apply a gentle pressure.
  • Page 59 G E T T I N G S T A R T E D STADIUM Tip ’n Slide (EASY ENTRY/EXIT SEAT) — SEVEN PASSENGER MODELS To Move The Second-Row Passenger Seat Forward NOTE: Raise the 20% seatback/armrest before moving the 60% seat, to allow for full seat travel. To allow passengers to easily enter or exit the third-row passenger seats move the Tip ’n Slide control lever on the upper outboard side of the seatback forward, and in one fluid motion, the seat cushion flips upward and the seat moves forward on its tracks.

  • Page 60: Heated Seats

    G E T T I N G S T A R T E D To lock the seatback in a reclined position, pull the latch release-loop located at the top of the seatback upward, allow the seatback to recline, then release the release-loop. WARNING! •...

  • Page 61: Heated Steering Wheel

    G E T T I N G S T A R T E D WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions must exercise care when using the seat heater.

  • Page 62: Tilt/Telescoping Steering Column

    G E T T I N G S T A R T E D TILT/TELESCOPING STEERING COLUMN The tilt/telescoping control handle is lo- cated below the steering wheel at the end of the steering column. Push down on the handle to unlock the steering column.

  • Page 63: Operating Your Vehicle

    O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km).
  • Page 64 O P E R A T I N G Y O U R V E H I C L E Front Wipers Intermittent, Low And High Operation Rotate the end of the lever to the first detent position for one of five intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

  • Page 65: Headlight Switch

    O P E R A T I N G Y O U R V E H I C L E HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights and to the second detent for head-...

  • Page 66: Electronic Speed Control

    O P E R A T I N G Y O U R V E H I C L E ELECTRONIC SPEED CONTROL The Electronic Speed Control switches are located on the steering wheel. Cruise ON/OFF Push the ON/OFF button to activate the Speed Control.
  • Page 67 O P E R A T I N G Y O U R V E H I C L E The drivers preferred units can be selected through the instrument panel settings if equipped. The speed decrement shown is dependant on the chosen speed unit of U.S. (MPH) or Metric (km/h): U.S.

  • Page 68: Climate Control

    O P E R A T I N G Y O U R V E H I C L E CLIMATE CONTROL Radio 4.3 Manual Climate Controls Radio 4.3 Manual Climate Controls 1 — Temperature Control Button 6 — Rear Defrost Button 2 —...
  • Page 69 O P E R A T I N G Y O U R V E H I C L E Radio 8.4 Automatic Climate Controls Radio 8.4 Automatic Climate Controls 1 — A/C Button 8 — SYNC Button 2 — Air Recirculation Button 9 —...
  • Page 70 O P E R A T I N G Y O U R V E H I C L E Climate Control Knobs Climate Control Knobs 1 — A/C Button 6 — Rotate Blower Control Knob 2 — Air Recirculation Button 7 —...

  • Page 71: Parkview Rear Back-Up Camera

    O P E R A T I N G Y O U R V E H I C L E SYNC Temperature Button — If Equipped Press the SYNC button on the touchscreen once to control driver and passenger temperatures simultaneously. Press the SYNC button on the touchscreen a second time to control the temperatures individually.

  • Page 72: Power Sunroof

    O P E R A T I N G Y O U R V E H I C L E POWER SUNROOF The power sunroof switch is located on the overhead console. Opening Sunroof Express Open Push the switch rearward and release it within one-half second.

  • Page 73: Wind Buffeting

    O P E R A T I N G Y O U R V E H I C L E WARNING! • Do not let children play with the sunroof. Never leave children unattended in a vehicle, or with access to an unlocked vehicle. Do not leave the key fob in or near the vehicle, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode.

  • Page 74: Electronics

    E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Voice Command Button pg. 100 2. Uconnect Phone Button pg. 93 3. Steering Wheel Audio control (Left – Behind Steering Wheel) pg. 104 4.
  • Page 75 E L E C T R O N I C S 7. Uconnect Radio pg. 75 8. Tune/Scroll Knob/Browse/Enter Button 9. SD Card Slot (push in to insert/eject) pg. 93 10. CD Slot 11. Front Power Outlet pg. 110 12. Aux Jack (located in the storage bin in the front center stack) pg. 92 13.

  • Page 76: Cybersecurity

    E L E C T R O N I C S CYBERSECURITY Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks. These networks allow your vehicle to send and receive information. This information allows systems and features in your vehicle to function properly. Your vehicle may be equipped with certain security features to reduce the risk of unauthorized and unlawful access to vehicle systems and wireless communications.

  • Page 77: Identifying Your Radio

    E L E C T R O N I C S IDENTIFYING YOUR RADIO Radio 4.3 & 4.3S • Models 4.3 and 4.3S have a 4.3 inch touchscreen with buttons on the face- plate on each side of it. • Model 4.3S has all Model 4.3 features, plus SiriusXM Satellite Radio (1-year trial subscription included).

  • Page 78: Radio 4.3 & 4.3S At A Glance

    E L E C T R O N I C S Radio 4.3 & 4.3S AT A GLANCE Radio 4.3 & 4.3S 1 — Radio: AM/FM/SIRIUS Satellite Radio (If Equipped) 2 — Status Bar 3 — Settings: Clock, Display, etc. 4 —...
  • Page 79 E L E C T R O N I C S • The Audio Menu shows the following options for you to customize your audio settings. • Equalizer • Balance/Fade • Speed Adjust Volume • Press the “Exit” button on the touchscreen to exit from the Audio Menu. Equalizer •...

  • Page 80: Radio 8.4/8.4 Nav At A Glance

    E L E C T R O N I C S RADIO 8.4/8.4 NAV AT A GLANCE Radio 8.4 NAV 1 — Status Bar (8.4 NAV) 2 — Small Navigation Map (8.4 NAV) 6 — Climate Control Button 3 — More Settings Button 7 —...
  • Page 81 E L E C T R O N I C S • If the time is not displayed at the top of the screen, press “More” button on the touchscreen and then “Settings” button on the touchscreen. In the Settings screen, press the “Clock”...

  • Page 82: Radio

    E L E C T R O N I C S RADIO Models 4.3 & 4.3S Models 4.3 & 4.3S 1 — Radio Station Presets 5 — Audio Settings 2 — View All Presets 6 — Direct Tune Radio Station 3 —...
  • Page 83 E L E C T R O N I C S Models 8.4 & 8.4 NAV Radio 8.4 Radio 1 — Radio Station Presets 5 — Seek Down Button 2 — Toggle Presets 1–6 and 7–12 6 — Direct Tune To A Radio Station 3 —...

  • Page 84: Siriusxm Satellite Radio

    E L E C T R O N I C S Direct Tune • Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number. Store Radio Presets Manually Your radio can store 12 total preset stations. They are shown at the top of your screen. To see all 12 stations, Press the “All”...
  • Page 85 E L E C T R O N I C S More... (4.3S Only) • Access more menus: Audio, Favorites, Game Zone, and Replay. Traffic & Weather (U.S. Residents/8.4 & 8.4 NAV Only) • Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel.
  • Page 86 E L E C T R O N I C S Browse Sub-Menu Description Sub-Menu Traffic/ Lets you browse Traffic & Weather information by city. Weather (4.3S only) Jump (8.4 & Lets you select your favorite cities for Traffic & Weather information, by 8.4 NAV selecting Traffic, then Jump feature on the main satellite radio screen.

  • Page 87: Ipod/Cd/Aux Controls

    E L E C T R O N I C S IPOD/CD/AUX CONTROLS Models 4.3 & 4.3S Models 4.3 & 4.3S 1 — Music Source 2 — More: Audio Settings and Shuffle 3 — Current Track Information 4 — Play/Pause 5 —...
  • Page 88 E L E C T R O N I C S Models 8.4 & 8.4 NAV Models 8.4 & 8.4 NAV 1 — Music Source: Disc, iPod, SD Card, AUX Or Bluetooth 2 — Repeat Track 3 — Shuffle Music Tracks 4 —...

  • Page 89: Garmin Navigation

    E L E C T R O N I C S GARMIN NAVIGATION Garmin Navigation (8.4 NAV Only) Radio 8.4 NAV integrates Garmin’s consumer-friendly navigation into your vehicle. Garmin Navigation includes Lane Assist and Junction View, Speed Limit information, and a database with over six million points of interest.
  • Page 90 E L E C T R O N I C S Main Navigation Menu Main Navigation Menu Touchscreen 1 — Where To? Button 4 — Tools Button 2 — View Map Button 5 — Detour Button 3 — Settings Button 6 —...
  • Page 91 E L E C T R O N I C S Finding A Place By Spelling The Name • From the Main Navigation Menu press “Where to?” press “Points of Interest” and then press “Spell Name.” • Enter the name of your destination. •...
  • Page 92 E L E C T R O N I C S Following Your Route Following Your Route 1 — Distance To Next Turn 6 — Press And Drag Map 2 — Current Location 7 — Your Location On The Map 3 —...

  • Page 93: Siriusxm Travel Link

    E L E C T R O N I C S Taking A Detour • To take a detour you must be navigating a route. • Press “Detour.” NOTE: If the route you are currently taking is the only reasonable option, the device might not calculate a detour.

  • Page 94: Playing Ipod/Usb/Mp3 Devices

    E L E C T R O N I C S 2 – Movie Listings View information on movies that are playing at theaters near your current location. 3 – Sports Scores View scores and upcoming events for all major sports. 4 –...

  • Page 95: Uconnect Phone

    E L E C T R O N I C S • The USB port supports certain Mini, Classic, Nano, Touch, and iPhone devices. The USB port also supports playing music from compatible external USB Mass Storage Class memory devices. Some iPod software versions may not fully support the USB port features.
  • Page 96 E L E C T R O N I C S Start Pairing Procedure On The Radio • Models 4.3, 4.3S: Push the MORE button on the faceplate, then press the “Phone” button on the touchscreen. Next, press the “Settings” button on the touchscreen and then “Add Device.”...
  • Page 97 E L E C T R O N I C S Start Pairing Procedure On Mobile Phone • Search for available devices on your Bluetooth enabled mobile phone. This is usually within Settings or Options under “Bluetooth.” See your mobile phone’s manual for details.
  • Page 98 E L E C T R O N I C S Select The Mobile Phone's Priority Level • When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite phone. Selecting “Yes” will make this phone the highest priority.
  • Page 99 E L E C T R O N I C S Phone Menu Screen — Models 8.4 & 8.4 NAV 1 — Favorite Phonebook Entries 9 — SMS (text messaging) 2 — Phone Battery Level 10 — Direct Dial 3 — Current Phone 11 —...
  • Page 100 E L E C T R O N I C S Mute (Or Unmute) Microphone During Call • During a call, press the “mute” button on the touchscreen to mute and unmute the call. Transfer Ongoing Call Between Handset And Vehicle During an on-going call, press the “Transfer”...
  • Page 101 E L E C T R O N I C S Changing The Volume • Start a dialogue by pressing the Phone button , then say a command for example - "Help." • Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Uconnect system is speaking.

  • Page 102: Uconnect Voice Command (8.4 & 8.4 Nav Only)

    E L E C T R O N I C S UCONNECT VOICE COMMAND (8.4 & 8.4 NAV ONLY) • If the Uconnect Voice Command button exists on your steering wheel, then you have the Voice Command feature. • The Voice Command feature lets you keep your hands on the steering wheel, and your eyes on the road.
  • Page 103 E L E C T R O N I C S SiriusXM Travel Link “Show fuel prices” “Show movie listings” “Show current weather” “Show extended weather” “Show Travel Link favorites” “Show NFL headlines” “Show NBA rankings” “Show NFL schedules” “Show NBA scores” Navigation “Navigate to (Address)”...
  • Page 104 E L E C T R O N I C S • When the Voice Command system is ready to be given a command, the green indicator is visible in the right corner of the touchscreen. The following chart lists the navigation voice commands that may be available.

  • Page 105: Video Entertainment System (Ves)

    E L E C T R O N I C S VIDEO ENTERTAINMENT SYSTEM (VES) System Operation • The screen is located on the headliner behind the front seat. To lower the screen, press the release button located in the rear of the overhead console. •...

  • Page 106: Steering Wheel Audio Controls

    E L E C T R O N I C S STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to increase or decrease the volume.

  • Page 107: Programmable Features

    E L E C T R O N I C S Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic, and the instrument cluster display will display “CAL”...

  • Page 108: Universal Garage Door Opener (Homelink)

    E L E C T R O N I C S Radio 8.4 Customer Programmable Features • The Radio 8.4 system allows you to access Customer Programmable feature settings such as Display, Clock, Safety/Assistance, Lights, Doors & Locks, Heated Seats, Engine Off Operation, Compass Settings, Audio, Phone/Bluetooth and SIRIUS Setup through buttons on the touchscreen.
  • Page 109 E L E C T R O N I C S To erase the channels, place the ignition switch into the ON/RUN position, then push and hold the two outside HomeLink buttons (I and III) for up to 20 seconds or until the red indicator flashes.
  • Page 110 E L E C T R O N I C S Programming A Non-Rolling Code NOTE: For programming Garage Door Openers manufactured before 1995. 1. Place the ignition switch to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light in view.

  • Page 111: Power Inverter

    E L E C T R O N I C S POWER INVERTER • There is a 115 Volt, 150 Watt power inverter outlet located on the back of the center console. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts.

  • Page 112: Power Outlets

    E L E C T R O N I C S POWER OUTLETS • There is a 12 Volt power outlet located in the front storage bin below the radio. This outlet has power available when the ignition switch is in the ON position. •...
  • Page 113 E L E C T R O N I C S • Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your New Vehicle Limited Warranty.

  • Page 114: Utility

    U T I L I T Y TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) GCWR (Gross Max. GTW Engine/ Max. Tongue Combined Wt. Frontal Area (Gross Trailer Transmission Rating) Wt.) 1,000 lbs (454 kg) which 6,000 lbs 22 sq ft 2.4L/Automatic includes up to 100 lbs (45 kg)

  • Page 115: Recreational Towing (Behind Motorhome, Etc.)

    U T I L I T Y RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Wheel OFF the Towing Condition FWD Models AWD Models Ground NOT ALLOWED NOT ALLOWED Flat Tow NONE Front NOT ALLOWED Dolly Tow NOT ALLOWED NOT ALLOWED Rear...

  • Page 116: What To Do In Emergencies

    W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
  • Page 117 W H A T T O D O I N E M E R G E N C I E S – Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON/RUN position and may stay on for as long as four seconds.
  • Page 118 W H A T T O D O I N E M E R G E N C I E S As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) which display in the instrument cluster display when one or more of your tires is significantly under-inflated.
  • Page 119 W H A T T O D O I N E M E R G E N C I E S CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
  • Page 120 W H A T T O D O I N E M E R G E N C I E S The dual brake system provides a reserve braking capacity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.
  • Page 121 W H A T T O D O I N E M E R G E N C I E S CAUTION! Prolonged driving with the Malfunction Indicator Light (MIL) on could cause damage to the engine control system. It also could affect fuel economy and driveability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur.

  • Page 122: If Your Engine Overheats

    W H A T T O D O I N E M E R G E N C I E S Oil Change Due Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Due” message will display for 5 seconds along with a single chime to indicate the next scheduled oil change interval.

  • Page 123: Jacking And Tire Changing

    W H A T T O D O I N E M E R G E N C I E S JACKING AND TIRE CHANGING Jack Location The jack and jack-handle are stowed underneath a cover in the rear storage bin in the cargo area.
  • Page 124 W H A T T O D O I N E M E R G E N C I E S 6. Block both the front and rear of the wheel diagonally opposite of the jacking position. For example, if changing the right front tire, block the left rear wheel. NOTE: Passengers should not remain in the vehicle when the vehicle is being jacked.
  • Page 125 W H A T T O D O I N E M E R G E N C I E S Spare Tire Stowage NOTE: Refer to “Spare Tire Removal” for information on assembling the winch tools. 1. Place the spare tire near to the winch cable. Hold the spare upright so that the tire's tread is on the ground and the valve stem is at the top of the wheel facing away from the rear of the vehicle.
  • Page 126 W H A T T O D O I N E M E R G E N C I E S 3. Place the jack underneath the lift area that is closest to the flat tire. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange.
  • Page 127 W H A T T O D O I N E M E R G E N C I E S 6. Install the spare tire. NOTE: For vehicles so equipped, do not attempt to install a center cap or wheel cover on the compact spare.
  • Page 128 W H A T T O D O I N E M E R G E N C I E S Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle. 2. To ease the installation process for steel wheels with wheel covers, install two lug nuts on the mounting studs which are on each side of the valve stem.
  • Page 129 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 130: Jump-Starting

    W H A T T O D O I N E M E R G E N C I E S CAUTION! • The winch mechanism is designed for use with the jack-handle only. Use of an air wrench or other power tools is not recommended and they can damage the winch. •...
  • Page 131 W H A T T O D O I N E M E R G E N C I E S Jump-Starting Procedure 1. Connect the positive (+) end of the jumper cable to the remote positive (+) post of the vehicle with discharged battery.

  • Page 132: Gear Selector Override

    W H A T T O D O I N E M E R G E N C I E S WARNING! • When temperatures are below the freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump-starting because the battery could rupture or explode and cause personal injury.

  • Page 133: Towing A Disabled Vehicle

    W H A T T O D O I N E M E R G E N C I E S 5. Move the gear selector into the NEUTRAL position. 6. The vehicle may then be started in NEUTRAL. 7. Reinstall the override cover. TOWING A DISABLED VEHICLE Wheel OFF The Towing Condition...

  • Page 134: Enhanced Accident Response System (Ears)

    W H A T T O D O I N E M E R G E N C I E S CAUTION! • When “rocking” a stuck vehicle by shifting between REVERSE and DRIVE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. •...

  • Page 135: Maintaining Your Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E OPENING THE HOOD 1. Pull the hood release lever located un- der the left side of the instrument panel. 2.

  • Page 136: Engine Compartment - 2.4L

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 2.4L 1. Engine Coolant Reservoir Cap 2. Power Steering Fluid Reservoir 3. Engine Oil Dipstick 4.
  • Page 137 M A I N T A I N I N G Y O U R V E H I C L E 6. Transmission Dipstick (4 speed only) 7. Brake Fluid Reservoir 8. Remote Jump Start Positive Terminal 9. Power Distribution Center (Fuses) 10.

  • Page 138: Engine Compartment - 3.6L

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 3.6L 1. Engine Coolant Pressure Cap 2. Power Steering Reservoir 3. Engine Oil Filter Access 4.
  • Page 139 M A I N T A I N I N G Y O U R V E H I C L E 6. Brake Fluid Reservoir 7. Remote Jump Start Positive Terminal 8. Power Distribution Center (Fuses) 9. Air Cleaner Filter 10.

  • Page 140: Fluid Capacities

    M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES U.S. Metric Fuel (Approximate) Front Wheel Drive (FWD) Models 20.5 Gallons 77.6 Liters All-Wheel Drive Models 21 Gallons 79.8 Liters Engine Oil With Filter...
  • Page 141 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technol- ogy (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.

  • Page 142: Adding Fuel

    M A I N T A I N I N G Y O U R V E H I C L E ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap has been designed for use with this vehicle.

  • Page 143: Flexible Fuel (3.6L Engine Only) - If Equipped

    M A I N T A I N I N G Y O U R V E H I C L E Materials Added To Fuel Designated TOP TIER Detergent Gasoline contains a higher level of detergents to further aide in minimizing engine and fuel system deposits.
  • Page 144 M A I N T A I N I N G Y O U R V E H I C L E Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to the steps described under “Instrument Cluster Warning Lights”...
  • Page 145 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 146 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 147 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 148: Fuses

    M A I N T A I N I N G Y O U R V E H I C L E FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating.
  • Page 149 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description F125 – 10 Amp Red Steering Column Control Module F126 – 25 Amp Clear Audio Amplifier F127 –...
  • Page 150 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description Brake/Electronic Stability Control F156 – 10 Amp Red Module Power Transfer Unit Module – If F157 –...

  • Page 151: Tire Safety Information

    M A I N T A I N I N G Y O U R V E H I C L E TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P”...
  • Page 152 M A I N T A I N I N G Y O U R V E H I C L E Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/ 80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S.
  • Page 153 M A I N T A I N I N G Y O U R V E H I C L E Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side.
  • Page 154 M A I N T A I N I N G Y O U R V E H I C L E Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door.
  • Page 155 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recom- mended load capacity for your vehicle.
  • Page 156 M A I N T A I N I N G Y O U R V E H I C L E Steps For Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.

  • Page 157: Tires - General Information

    M A I N T A I N I N G Y O U R V E H I C L E WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle.
  • Page 158 M A I N T A I N I N G Y O U R V E H I C L E Compact Spare Tire — If Equipped The compact spare is for temporary emergency use only. You can identify if your vehicle is equipped with a compact spare by looking at the spare tire description on the Tire and Loading Information Placard located on the driver’s side door opening or on the sidewall of the tire.
  • Page 159 M A I N T A I N I N G Y O U R V E H I C L E WARNING! Limited use spares are for emergency use only. Installation of this limited use spare tire affects vehicle handling. With this tire, do not drive more than the speed listed on the limit use spare wheel.
  • Page 160 M A I N T A I N I N G Y O U R V E H I C L E When cleaning extremely dirty wheels including excessive brake dust, care must be taken in the selection of tire and wheel cleaning chemicals and equipment to prevent damage to the wheels.

  • Page 161: Department Of Transportation Uniform Tire Quality Grades

    M A I N T A I N I N G Y O U R V E H I C L E DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration.

  • Page 162: Replacement Bulbs

    M A I N T A I N I N G Y O U R V E H I C L E REPLACEMENT BULBS Interior Bulbs Bulb Number Courtesy/Reading Lamps (Incandescent) Courtesy/Reading Lamps (Optional LED) LED (Serviced at authorized dealer) Glove Compartment Lamp Cargo Lamp Optional Door Map Pocket/Cupholder...

  • Page 163: Consumer Assistance

    Booklet. United States customers may visit the Dodge Contact Us page at www.dodge.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Compartment Material” from the left menu. You may also obtain a complimentary copy by calling 1-800-423-6343 (U.S.) or...

  • Page 164: Reporting Safety Defects In The United States

    • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep ® , Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.

  • Page 165: Mopar® Accessories

    • For the full line of Authentic Dodge Accessories by Mopar, visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.

  • Page 166: Frequently Asked Questions

    • How do I configure my Universal Garage Door Opener (HomeLink)? pg. 106 UTILITY • How do I know how much I can tow with my Dodge Journey? pg. 112 WHAT TO DO IN EMERGENCIES • What do I do if my TPMS warning light is blinking? pg. 115 •...

  • Page 167: Index

    I N D E X Accessories ....163 B-Pillar Location ... .152 Mopar ....163 Brake Fluid .
  • Page 168 I N D E X Electronic Speed Control SET Emergency, In Case Of Indicator ....119 Freeing Vehicle When Stuck . . .131 Front Fog Light Indicator ..119 Jacking .
  • Page 169 I N D E X Fuel Aftermarket Electronics ..3 Canada ....3 Adding ....140 Inverter Outlet (115V) .
  • Page 170 I N D E X Malfunction Indicator Light (Check Pretensioners Engine) ....118 Seat Belts ....20 Master Cylinder (Brakes).
  • Page 171 I N D E X Extender ....19 Tire Markings ....149 Front Seat ..15, 16, 18 Tires .
  • Page 172 I N D E X Wheel And Wheel Trim Care. . .141, 157 Windshield Wipers ... .62 Wind Buffeting....71 Wiper Blade Replacement .
  • Page 173 N O T E S...
  • Page 174 N O T E S...
  • Page 175 N O T E S...
  • Page 176 N O T E S...
  • Page 177 N O T E S...
  • Page 178 N O T E S...
  • Page 179 D O D G E . C A ( C A N A D A ) This guide has been prepared to help you get quickly acquainted with your new Dodge brand vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual.
  • Page 180 Dodge brand vehicle. Simply download the app, select your make and model and enjoy the ride. To get this app, go directly to the App Store or Google Play and enter the search keyword “Dodge”...

Table of Contents
