V4055A,B,D,E ON-OFF FLUID POWER GAS VALVE ACTUATOR

SPECIFICATIONS

Models:
V4055A Actuator, with V5055, V5097 or VE5000 Gas Valves,
provides on-off control of fuel. With proper adapter (see
Accessories), it replaces the V4034 Actuator on a V5034
Gas Valve.
V4055B Actuator is a high pressure version of V4055A.
V4055D Actuator is identical to V4055A, except has a
Proof-of-Closure Switch. Used with V5055C/V5097C
(double seal) for valve seal overtravel interlock.
V4055E Actuator is identical to V4055B, except has a
Proof-of-Closure Switch. Used with V5055E/V5097E
(double seal) for valve seal overtravel interlock.
NEMA 4 weatherproof models available.
Nominal Opening Time: See Table 1.
Valve
V5055/V5097A,C: 3/4 to 3 in.
V5055A,C: 4 in.
V5055/V5097B: 3/4 to 3 in.
V5055B: 4 in.
V5055/V5097D,E: 3/4, 1-1/4, 1-1/2 in. 5
V5055/V5097D,e: 2, 2-1/2, 3 in.
a
Use a V4055D or V4055E (with Proof-of-Closure Switch) with a V5055/V5097C or V5055/V5097E (with double seal) for valve
seal overtravel interlock.
b
Maximum operating pressure differential.
c
Maximum closeoff pressure without seat leakage. This is the maximum valve pressure drop allowed while fully closed, and is
independent of the valve body rating.
Electrical Ratings: See Tables 3 and 4.

ORDERING INFORMATION

When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number.
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Relations
Honeywell, 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Honeywell Limited/Honeywell Limitée, 35 Dynamic Drive, Scarborough, Ontario M1V 4Z9.
International Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France,
Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
60-2309—10
Table 2. Pressure Ratings of Valve-Actuator Combinations.
V4055A,D
b
Differential
psi
mbar
5
340
3
200
5
340
3
200
340
5
340
Table 1. Nominal Opening Time (seconds).
Model
Standard
Fast-opening
Maximum Closing Time: One second when de-energized.
Ambient Operating Temperature Ratings:
60 Hz Models: -40°F to +150°F (-40°C to +66°C).
50 Hz, 50/60 Hz Models: -10°F to +158°F (-23°C to +70°C).
Mounting: V4055 Actuator attaches directly to V5055/V5097
Valve with two sets of screws positioned 90 degrees apart.
Combination is multipoise.
NOTE: 220 to 240 Vac, 50/60 Hz models are vertical mount
only.
Pressure Ratings: See Table 2.
Actuator
a
c
Closeoff
psi
bar
15
1
15
15
1
5
15
1
15
15
1
5
75
5
25
45
3
15
2
50 Hz
32
26
16
13
a
V4055B,E
b
Differential
Closeoff
psi
mbar
psi
1000
15
340
15
1000
15
340
15
1700
75
1000
45
60 Hz
c
bar
1
1
1
1
5
3
