1. Hardware Setup

Getting to know your CL64WLAN
The Wi-Fi CL64WLAN provides you with an easy and secure way to set up a wireless home
network with fast access to the Internet over a coaxial cable network. The CL64WLAN has a
built-in CL64WLAN to work with the CLM6/CLM253 of the Internet service providers. With your
CL64WLAN, you can block unsafe Inter- net content and applications, and protects the devices
(computers, gaming consoles, and so on) that you connect to your home network.
This chapter explains how to set up your hardware. If you have already set up your CL64WLAN,
you can skip this chapter. Chapter 2 explains how to set up.
This chapter contains the following sections:

•Unpack Your CL64WLAN

•Hardware Features

•Position Your CL64WLAN
•Cable Your CL64WLAN
1.1 Unpack Your CL64WLAN
Open the box and remove the CL64WLAN, cables, Power adapter and installation guide.
CL64WLAN RouterEthernet cable cablePower adapter
If any parts are incorrect, missing, or damaged, contact your On Networks dealer. Keep the carton
and original packing materials in case you need to return the product for repair.
1.2 Hardware Features
Before you cable your CL64WLAN, take a moment to become familiar with the front, side, and
back pa- nels and the label. Pay particular attention to the LEDs on the front panel.
Back Panel
2
