coaxLAN CL64WLAN Manual

Hide thumbs Also See for CL64WLAN:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
coaxLAN Modem CL64WLAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL64WLAN and is the answer not in the manual?

Questions and answers

Related Manuals for coaxLAN CL64WLAN

Summary of Contents for coaxLAN CL64WLAN

  • Page 1 Modem CL64WLAN...

  • Page 2: Table Of Contents

    2.3. Position Your CL64WLAN ..................................7 2.4. Cable Your CL64WLAN ..................................8 3. Getting Starting ........................9 3.1. Prepare for login the CL64WLAN web management ........................9 3.2. Login the Web Management Interface ............................9 4. Knowing WEB Management Interface ................ 10 4.1.
  • Page 3 CL64WLAN User Manual V001 9.4. DMZ Setting ......................................31 9.5. Port Forward ......................................31 9.6. IGMP Setting ......................................32 10. System ..........................33 10.1. System and Kernel Log ..................................33 10.2. Log Server ......................................33 10.3. Device Reboot ....................................34 10.4.

  • Page 4: Introduction

    10/100M Ethernet interface. Hardware Setup: Getting to know your CL64WLAN. The Wi-Fi CL64WLAN provides you with an easy and secure way to set up a wireless home network with fast access to the Internet over a coaxial cable network. The CL64WLAN has a built-in CL64WLAN to work with the CLM253 of the Internet service providers.

  • Page 5: Unpack Your Cl64Wlan

    CL64WLAN User Manual V001 2.1. Unpack Your CL64WLAN If you unpack your CL64WLAN box, you will find a IPC-S unit, a router Ethernet cable and a power adapter. CL64WLAN Router Ethernet cable Power If any parts are incorrect, missing, or damaged, contact your dealer. Keep the carton and original packing materials in case you need to return the product for repair.

  • Page 6: Front Panel

    V001 CL64WLAN User Manual Interface Qty. Description Cable Connect to uplink CATV network Connect to STB or TV by cable Ethernet LANn ports for connecting to PC. They can work on Router Mode. WAN connection can get the IP address from upper-layer device.

  • Page 7: Position Your Cl64Wlan

    • CLM253 by coaxial cable network. If it is blinking green, data are being transmitted or received. • If it is off, the CL64WLAN is off or no link is detected in the CABLE • port. LAN1-2 If it is solid green, the related LAN port has detected an Ethernet •...

  • Page 8: Getting Starting

    Step 1: Configuring the IP address of your PC to 192.168.1.X (2~254) subnet mask is • 255.255.255.0, gateway is 192.168.1.1. Step 2: Ping the IP address of the CL64WLAN (Default address is 192.168.1.1). If the • PC can get right reply from the ping command, it means that the connection between the PC and the CL64WLAN is correct.

  • Page 9: Login The Web Management Interface

    CL64WLAN User Manual V001 3.2. Login the Web Management Interface Open the WEB browser (recommend IE), enter http://192.168.1.1 in the address bar, and then press enter to display the login interface, as shown in Picture. Please input user name and password: For general subscribers, •...

  • Page 10: Knowing Web Management Interface

    V001 CL64WLAN User Manual Picture Note: You can modify the password after entering the WEB management interface. Please refer to the section for related operation. Knowing WEB Management Interface The WEB management interface can rapidly complete required function configurations. This chapter will lead you to understand and become familiar with the WEB management interface.

  • Page 11: Main Menu Introduction

    CL64WLAN User Manual V001 The sub-menu area: on the left, where you will have different options depending on • the menu selected in the main menu area. The content area: below the main menu area and next to sub-menu area.

  • Page 12: Running

    V001 CL64WLAN User Manual Main Menu Sub-menu Running Device information. • Network Status. • Wireless Status. • Configuration Wizard. • Network Network Status. • Static Routing. • WAN Setting. • LAN Setting. • QoS. • Wireless Wireless Status. • Basic Setting.

  • Page 13: Device Information

    CL64WLAN User Manual V001 Running The Running screen includes the following sub-menus: Device information. • Network Status. • Wireless Status. • Configuration Wizard. • 5.1. Device information If the Device Information sub-menu is selected the screen shown in Picture is displayed.

  • Page 14: Wireless Status

    V001 CL64WLAN User Manual Picture This page will show the WAN connection status and the LAN status. WAN Status: It shows a table with the following information for each available • interface: Interface Name: to identify uniquely this WAN network interface.
  • Page 15 ◦ Noise: level of noise received in dBm. ◦ Transmission power: power used by the CL64WLAN to transmit in dBm. Device connected: it shows a table of the devices connected to the WiFi network • with the following information of each device: ◦...

  • Page 16: Configuration Wizard

    V001 CL64WLAN User Manual 5.4. Configuration Wizard If the Wireless Status sub-menu is selected the screen shown in Picture is displayed. Picture The Configuration Wizard screen provides a rapid configuration of the slave. The first screen asks about the kind of the WAN access mode to be used; you will select one of the following...

  • Page 17: Network

    CL64WLAN User Manual V001 Network The Network screen includes the following sub-menus: Network status • Static Routing • WAN Setting • LAN Setting • Network status is the same sub-menu as in Running → Network Status as it is shown in Picture Picture 6.1.

  • Page 18: Wan Settings

    V001 CL64WLAN User Manual Picture This page allows to create static IPv4 routes. The parameters to configure are: IP address: the network destination of the route. • Subnet mask: the netmask associated with the network destination. • Gateway: Specifies the forwarding or next hop IP address over which the set of •...

  • Page 19: Wan Connection Named Rule

    CL64WLAN User Manual V001 6.2.1. WAN Connection Named Rule The WAN Connection has the following rule for the Network Name parameter: <Numerical order>_<Keywords>_<Bridge_or_Router>_<VLAN> The following table explains the parameters to build the Network Name: Content Definition Description Numerical order Sequence number...

  • Page 20: Default Wan Connection And Router Mode

    V001 CL64WLAN User Manual 6.2.2. Default WAN Connection and Router Mode Picture There is a default WAN connection, named 1_INTERNET_R_VID_. This WAN connection works on Router mode, with DHCP and VLAN Disable as it is shown in Picture. The WAN Set page allows to set the parameters described in the following table:...
  • Page 21 CL64WLAN User Manual V001 ITEM DESCRIPTION Network Name Name of the WAN connection, you can add a new WAN connection or edit an existing WAN connection. Mode The available modes are: Bridge and Route. Enable or disable NAT function. This parameter is only available when the Route mode is selected.

  • Page 22: Lan Setting

    LAN clients on TCP/IP automatically. By default, the CL64WLAN device acts as a DHCP server. It assigns IP, DNS server, and default gateway addresses to all computers connected to the LAN. The assigned default IP address of the device 192.168.1.1 is also the gateway address.

  • Page 23: Wireless

    CL64WLAN User Manual V001 Item Description DHCP enable The DHCP function will be enabled if the enable option is selected in this combo box. Lease time It is the period of time during which the DHCP server allows the assigned IP addresses to be used by the clients.

  • Page 24: Base Settings

    V001 CL64WLANUser Manual Picture The Wireless screen lets you view or configure the wireless network setup. 7.1. Base Settings If the Base Settings sub-menu is selected the screen shown in Picture is displayed. This page is organized in two areas: Basic Settings: where you can enable or disable WiFi, set wireless channel, set the •...
  • Page 25 V001 Item Description WIFI There are two options in this combo box: Enable: to enable WiFi interface of the CL64WLAN. • Disable: to disable WiFi interface of the CL64WLAN • Channel Selection This combo box allows to set the operating channel...
  • Page 26 V001 CL64WLAN User Manual Picture SSID<n> Area: where you can configure the parameters of the related access point. • Up to 4 different areas can appear depending on the value configured in the parameter Set SSID number in the Basic Set Area. The following table explains all the...
  • Page 27 CL64WLAN User Manual V001 Item Description SSID It is the Service Set Identifier (SSID) of the access point. It is a 32 alphanumeric unique identifier which is used to identify uniquely the access point and it is also known as the wireless network name. This field is case-sensitive.

  • Page 28: Mac Filter

    V001 CL64WLAN ser Manual 7.2. MAC Filter If the MAC Filter sub-menu is selected the screen shown in Picture is displayed. This page allows to enable or disable the MAC filtering function for the SSID selected in the combo box. The MAC Filter combo box has the following options: Disable: the MAC filtering function is disabled.

  • Page 29: Url Filter

    CL64WLAN User Manual V001 (acknowledged) packet to confirm that the server's SYN/ACK packet was received, and communications would then commence. However, in a SYN flood, the ACK packet is never sent back by the hostile client. Instead, the client program sends repeated SYN requests to all the server's ports.

  • Page 30: Ip Filter

    V001 CL64WLAN User Manual Item Description Filter Name The name of the filter. Filter Mode The working mode of the filter. Two options are available in this combo box: Whitelist: only the MACs added to the list will • be authorized for connection.

  • Page 31: Application

    CL64WLAN User Manual V001 Item Description Filter Mode It is the mode of the filter. The combo box provides two options: Whitelist(WAN → LAN ingoing filter): only • the source IP addresses included in the white list will be accepted.

  • Page 32: Alg Setting

    V001 CL64WLAN User Manual IGMP Setting • These menus allow to configure some items related with applications running in the network managed by the slave unit. 9.1. ALG Setting If the ALG Setting sub-menu is selected the screen shown in Picture is displayed. This page allows to enable or disable the following protocols: H.323: it is a protocol designed for the setup, management and termination of a...

  • Page 33: Dynamic Dns

    This page allows to configure a dynamic DNS (Domain Name System). DDNS is a method of automatically updating a name server in the domain name system, often in real time. This is specially useful when the IP address provided by your CL64WLAN changes each time you reconnect to the Internet.

  • Page 34: Dmz Setting

    V001 CL64WLAN User Manual Picture This page allows to enable or disable the UPnP (Universal Plug and Play) service. UPnP is a set of networking protocols that permits networked devices, such as personal computers, printers, Internet gateways, Wi-Fi access points and mobile devices to seamlessly discover each other's presence on the network and establish functional network services for data sharing, communications, and entertainment.

  • Page 35: Igmp Setting

    CL64WLAN User Manual V001 Picture This page allows to create rules of port forwarding or port mapping. Port forwarding is an application of the network address translation (NAT) that redirects a communication request from one address and port number combination (internal) network available to hosts on the opposite side of the gateway (external network), by remapping the destination IP address and port number of the communication to an internal host.

  • Page 36: System

    V001 CL64WLAN User Manual Picture routers. By listening to these conversations the switch maintains a map of which links need which IP multicast streams. The Apply button confirms the changes. The Refresh button updates the information shown in this page.

  • Page 37: Device Reboot

    CL64WLAN User Manual V001 Item Description Hostname Name used to identify the logs generated by this slave unit Remote Log Server IP IP address of the server which receives the log messages. Remote Log Server Port Port used to send the log messages to the log server.

  • Page 38: System Upgrade

    V001 CL64WLAN User Manual Picture This page allows to reboot the slave unit clicking on the Reboot button. The Refresh button updates the information shown on this page. 10.4. System Upgrade If the Device Reboot sub-menu is selected the screen shown in Picture is displayed.

  • Page 39: Restore Factory

    CL64WLANUser Manual V001 Once the upgrading file is selected, the user has to click the Upload button to upload the file to the slave unit. A pop-up window will be shown to confirm the upload, as it is shown in Picture.

  • Page 40: Management

    V001 CL64WLAN User Manual Picture This page allows the following operations: Restore factory settings: if the Restore button is clicked, the system will restore all the • setting to the factory default values. Backup current configuration: if the Backup button is clicked, the current •...

  • Page 41: Tr069 Management

    CL64WLAN User Manual V001 10.7. TR069 Management If the TR069 Management sub-menu is selected the screen shown in Picture is displayed. TR069 is a technical specification that defines an application layer protocol for remote management of end-user devices. It was entitled CPE WAN Management Protocol (CWMP).
  • Page 42 V001 CL64WLAN User Manual Item Description TR-069 They are two radio buttons to enable or disable the TR-069 protocol. Inform They are two radio buttons to enable or disable the informs sent from the slave unit to the auto configuration server (ACS).

  • Page 43: Diagnosis

    CL64WLAN User Manual V001 Picture Diagnosis The Diagnosis screen includes the following sub-menus: Ping Test • Tracert Test • 11.1. Ping Test If the Management sub-menu is selected the screen shown in Picture is displayed. Picture This page allows to select a network interface and configure an IP address or a Host Name to do a “ping”...

  • Page 44: Tracert Test

    V001 CL64WLAN User Manual 11.2. Tracert Test If the Management sub-menu is selected the screen shown in Picture is displayed. Picture This page allows to select a network interface and configure an IP address or a Host Name to do a “trace route” test of that IP address or host.
