coaxLAN CL64WLAN User Manual

Internet over coaxial slave unit
Hide thumbs Also See for CL64WLAN:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
Internet over coaxial
Slave unit
CL64WLAN
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL64WLAN and is the answer not in the manual?

Questions and answers

Related Manuals for coaxLAN CL64WLAN

Summary of Contents for coaxLAN CL64WLAN

  • Page 1 Internet over coaxial Slave unit CL64WLAN User’s manual...

  • Page 2: Hardware Setup

    1. Hardware Setup Getting to know your CL64WLAN The Wi-Fi CL64WLAN provides you with an easy and secure way to set up a wireless home network with fast access to the Internet over a coaxial cable network. The CL64WLAN has a built-in CL64WLAN to work with the CLM6/CLM253 of the Internet service providers.

  • Page 3: Front Panel

    Front Panel The router front panel has the status LEDs shown in the following figure. Description POWER Solid green. Power is supplied to the CL64WLAN. Solid green. System has started. Blinking green. The CL64WLAN is starting up. LOOP If the loop happened the LOOP led will on •Solid green.

  • Page 4: Position Your Cl64Wlan

    1.3 Position Your CL64WLAN The CL64WLAN lets you access your network from virtually anywhere within the operating range of your wireless network. However, the operating distance or range of your wireless connection can vary significantly depending on the physical placement of your slave. For example, the thickness and number of walls the wireless signal passes through can limit the range.

  • Page 5: Getting Start

    255.255.255.0, gateway is 192.168.1.1. Step 2 Ping IP address of the CL64WLAN (Default address is 192.168.1.1). If the PC can get right reply from Ping command, it is mean the connecting between the PC and CPE is normal.

  • Page 6: Web Management Interface Introduction

    [Hier eingeben] Login to the WEB management interface Note: You can modify the password after entering WEB management interface. Please refer to system maintenance “Management” for related operation. 3 Know WEB Management Interface WEB management interface can rapidly complete required function configurations. This chapter will lead you to understand and become familiar with WEB management interface.

  • Page 7: Main Menu Introduction

    [Hier eingeben] 3.2 Main Menu Introduction M ain M enu Sub-M enu Device inform ation. Network Status. W ireless Status. Running Configuration W izard. Network Network Status. Static Routing. W AN Setting. LAN Setting. Q oS. W ireless W ireless Status. Basic Setting. M AC Filter. Security Basic Setting.

  • Page 8: Network Status

    [Hier eingeben] 4.2 Network Status Click Network Status to display the following screen: The page will show WAN connection status and LAN status. WAN Status shows current system WAN Connection Name, Connect Type, Connect Status, Default Gateway, IP Address that has been obtained, subnet Mask, preferred dns1, LAN Status will show client ID, IP address, MAC Address and Hostname.

  • Page 9: Configuration Wizard

    [Hier eingeben] 4.4 Configuration Wizard Click Configuration Wizard to display the following screen: The Configuration Wizard screen provide rapid configuration, you can choose in DHCP Mode, Static Mode and PPPoE Mode based on your network. 5 Network Network screen includes Network status, Static Routing, WAN Setting, LAN Setting, Qos.
  • Page 10 [Hier eingeben] Content Definition Description Numerical order Sequence number To identify the WAN Connection, following the next rule: based the sequence of the WAN Connection created, number in sequence increasing, no reuse the number have been used Keywords TR069 The connection is used for TR069 INTERNET The connection is used for INTERNET, not support the TR069...
  • Page 11 [Hier eingeben]...
  • Page 12 [Hier eingeben] LABEL DESCRIPTION Network Name Name of the WAN connection, you can add a new WAN connection or edit a exist WAN connection Mode Bridge or Route mode. Enable or disable NAT function Connect Type You can use DHCP, Static and PPPoE mode. maximum transmission unit (MTU in bytes) VLAN ID If you enable VLAN then enter the VLAN ID here.
  • Page 13 [Hier eingeben] Below is the page as you choose the PPPoE IP. You should configure the PPPoE user name and password here. If you choose DHCP, the router willl obtain an IP address automatically from the up-layer device. Bridge Mode: If you use bridge mode the PC or other terminal after connecting will get IP address from up-layer device.

  • Page 14: Lan Setting

    [Hier eingeben] Click SAVE-->Apply button , then we get the ‘2_INTERNET_B_VID_’ Connection. You can set up serval WAN Connection to carry out different service to subscriber. 5.2 LAN Setting The LAN Setup screen allows configuration of LAN IP services such as Dynamic Host Configura- tion Protocol (DHCP).
  • Page 15 [Hier eingeben] These addresses are part of the designated private address range for use in private networks and are suitable for most applications. If your network requires a different IP addressing scheme, you can change these settings in the LAN Setup screen. Note: If you change the LAN IP address of the router while connected through the browser, you are disconnected.

  • Page 16: Base Setting

    [Hier eingeben] 1. DHCP Server: The DHCP function will go into effect if you select “Enable” as the figure beside. 2. IP Pool Starting Address: The starting IP address which DHCP Server automatically starts. 3. IP Pool Ending Address: The ending IP address which DHCP Server automatically ends. The IP address that DHCP Server assigns to the requested client should be within the IP Pool.

  • Page 17: Mac Filter

    [Hier eingeben] Basic Set Area LABEL DESCRIPTION WIFI Enable or disable W LAN Channel Set the operating channel manually by selecting a channel from Selection the Channel Selection list or use Auto Channel Select to have it automatically configured. Model The default 11NGHT40PLUS in Mode setting, and you can also manually change it into other modes.

  • Page 18: Basic Setting

    [Hier eingeben] If you enable the MAC Filter, Can choose two rules, MAC White list and MAC Black list. In MAC address table, you can add the corresponding MAC address. 7 Security 7.1 Basic setting In Basic Setting screen, you can set relevant parameters, such as SYN-flood recovery, Invalid pac- kets, Forward, Web Remote Management.

  • Page 19: Url Filter

    [Hier eingeben] 7.2 URL Filter In URL Filter screen, Provide URL Filter table, Click add button to add corresponding rules. 7.3 IP Filter In IP Filter screen, Provide enable/disable IP Filter, you can choose whitelist or blacklist, Click Apply button to add corresponding rules. 8 System System Maintenance includes User Manager, System Update, Reboot, Reset Default, System Log;...

  • Page 20: System Upgrade

    [Hier eingeben] 8.2 System Upgrade Device Software Upgrading can update device software version. Click ‘Choose File’ button, and choose corresponding upgrading file. Click upload button, and then system will pop-up a windows to confirm uploading file. [Hier eingeben]...
  • Page 21 [Hier eingeben] After that ,you can click to upgrade.

  • Page 22: Device Reboot

    [Hier eingeben] In upgrade. 8.3 Device Reboot Click Reboot button to reboot the current home gateway devices, as displayed below. 8.4 Restore Factory Reset Default Setting, click submit button to restore the factory setting of the home gateway into default status. All parameters configurations made in system which includes WAN port parameter settings, wifi settings and other parameters will be cleared.

  • Page 23: System Log

    [Hier eingeben] 8.5 System Log Log basic setting can be chosen to enable or disable log. Log pri includes Emergency, Alert, Cri- tical, Error, Warning, Notice, Information, Debugging, a total of eight categories. It can be chosen into different log pri according to different operation situation. Click submit button to finish rele- vant setting.
