AV Stumpfl UHD Player Manual

Professional solid state media player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UHD Player
Manual
Version 2017|10|10
Based on Firmware Version: 1.1.x
AV Stumpfl GmbH | Austria | www.AVstumpfl.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHD Player and is the answer not in the manual?

Questions and answers

Related Manuals for AV Stumpfl UHD Player

Summary of Contents for AV Stumpfl UHD Player

  • Page 1 UHD Player Manual Version 2017|10|10 Based on Firmware Version: 1.1.x AV Stumpfl GmbH | Austria | www.AVstumpfl.com...

  • Page 2: Table Of Contents

    5.2. CONNECTING OUTPUT DEVICES ..................10 5.2.1. VIDEO ........................10 5.2.2. AUDIO ........................10 5.3. CONNECTING THE PLAYER TO THE NETWORK .............. 11 5.4. POWERING THE PLAYER ....................12 5.5. PLAYBACK MEDIA FILES ....................12 6. UHD PLAYER CONFIGURATION ...............14 6.1. WEB INTERFACE ......................15...
  • Page 3 6.1.1. WEB INTERFACE OVERVIEW ................... 16 6.1.2. CONFIGURING THE WEB INTERFACE ..............18 6.2. INITIALIZATION FILE ....................... 19 6.2.1. OVERVIEW INITIALIZATION FILE ................19 6.2.2. CONFIGURING THE INITIALIZATION FILE ..............21 7. NETWORK SETTINGS ..................22 8. DISPLAY CONFIGURATION ................24 9. CONTENT ......................27 9.1.
  • Page 4 14.4. GPIOS - REMOTE IN ..................... 76 14.5. AVIO ..........................77 15. SYSTEM SETTINGS ..................79 15.1. DATE & TIME ....................... 79 15.2. CHANGE UHD PLAYER NAME ..................80 15.3. UNDO LAST CHANGES ....................80 15.4. SAVE & LOAD CONFIGURATION .................. 81 15.5. REBOOT ........................81 15.6.

  • Page 5: Usage Notice

    LED lights up in green → device is ready for operation.) → The UHD Player will only play supported file formats. Media files with a size of up to 30 GB have been tested. → After enabling the write protection of the SD...

  • Page 6: Technical Data

    2.1. SUPPORTED FILE FORMATS Here is a list of all file formats that are supported by the UHD Player. For additional information and tips on how to create content that works best with the UHD Player, please see the content chapter.

  • Page 7: Audio

    2.1.3. AUDIO The UHD Player supports the following audio formats: Audio Codec: AAC and MP3 up to 320 KB/s, PCM via WAV, FLAC Sample Rates: 32 kHz, 44.1 kHz and 48 kHz are supported 2.2. DATA CARRIER SD / SDHC Cards (Class 10), USB Sticks or USB Drives with a read capability of at least 30 MB/s 2.3.

  • Page 8: Scope Of Delivery

    3. SCOPE OF DELIVERY Fig. 1: UHD Player and accessories 1x UHD Player 1x Power adapter 12V / 2A 1x 8 GB SDHC Card 1x UHD Player Manual 1x Retaining clip for SD Card slot FILES ON THE SD CARD UPON DELIVERY The following files will be on the SD Card upon delivery: Sample media file (AVS Story.mkv)

  • Page 9: Hardware Overview

    4. HARDWARE OVERVIEW Here is an overview of the ports of the UHD player’s front and rear panels: 4.1. FRONT PANEL VIEW AND PORTS Fig. 2: UHD Player front panel LEDS SD CARD SLOT USB DATA PORT (1) LEDS The LEDs indicate from left to right:...
  • Page 10 SD Cards with up to 16 GB of memory are tested. SD Cards with a read speed of minimum 30 MByte/s are recommended. To prevent the SD Card from being ejected by mistake, you can use the enclosed retaining clip. Place it over the SD Card and attach it to the player using the two enclosed screws.

  • Page 11: Rear Panel View And Ports

    (7) LAN PORT The UHD Player’s LAN Port is a standard RJ-45 connector for 1000 Base-T Ethernet communications. Connect the UHD Player to your network if you want to use its web interface, to sync several players or to control e.g.

  • Page 12: Left Side Panel View And Ports

    (9) POWER CONNECTOR Please use the provided power supply (12V / 2 A) to power the UHD player. 4.1.2. LEFT SIDE PANEL VIEW AND PORTS Fig. 4: UHD Player left side panel REMOTE IN REMOTE OUT (10) REMOTE IN The UHD Player provides 16 GPIOs (General-purpose input/output) that can be used with a default key assignment but may also be customized to perform special actions.

  • Page 13: Right Side Panel View And Ports

    4.1.3. RIGHT SIDE PANEL VIEW AND PORTS Fig. 5: UHD Player right side panel (12) USB PERIPHERAL PORTS The two USB 3.0 ports on the right side are USB ports for PERIPHERAL DEVICES only. Insert your USB peripheral device here, e.g. a keyboard / presenter.

  • Page 14: First Steps

    5. FIRST STEPS 5.1. INSTALLATION Remove the UHD player and its accessories from the packaging. Place the player on a flat surface or mount it on a wall. Use the brackets on both sides. Make sure there is sufficient ventilation and, to avoid overheating, do not place several players on top of one another.

  • Page 15: Connecting The Player To The Network

    100 meters. Distance may be extended with a repeater. STEP 2: IP ADDRESS The UHD Player and your computer must be in the same IP range, otherwise they will not be able to communicate. Proceed with one of the following possibilities: (A) CHANGE THE COMPUTER’S IP ADDRESS:...

  • Page 16: Powering The Player

    HDMI output device and display information about the network and video settings, sync mode, current firmware, serial number, etc. Fig. 7: The UHD Player’s Web Interface Info Screen is displayed when there is no data carrier inserted. 5.5. PLAYBACK MEDIA FILES The simplest way of playing back media files with a UHD Player in Standalone Mode is as follows: •...
  • Page 17 The player is set to Play Mode “Repeat All” by default, and it will play your media files successively in alphanumeric order. The UHD Player is designed for 24/7 operation. If you want to stop playback, just interrupt the power supply or remove the data carrier.

  • Page 18: Uhd Player Configuration

    6. UHD PLAYER CONFIGURATION The UHD Player can be configured in two different ways: 1. Via the player’s Interface 2. Via the Initialization File that you can find on the delivered SD Card Web Interface vs. Initialization File: Which to choose? This depends on your situation and personal preference.

  • Page 19: Web Interface

    6.1. WEB INTERFACE Using the Web Interface is a fast and intuitive way of configuring the UHD Player. You need a network connection to access the UHD Player via its web interface. Refer to the Connecting the Player to the Network Network Settings chapters for network details.

  • Page 20: Web Interface Overview

    Open your web browser and enter the UHD Player’s IP address into the address bar. The main page of the Web Interface will then be displayed in the web browser. Fig. 9: Main page of the UHD Player’s Web Interface with IP address in the web browser’s address line Info: Compared to the illustrations in this manual, the Web Interface may be displayed in a slightly different way, depending on the web browser used.
  • Page 21 Fig. 11: Sitemap of the Web Interface [INFO] gives a quick overview of the player’s basic settings. [BASIC SETTINGS] and [ADVANCED SETTINGS] allow access to all settings that refer to the playback. [SYSTEM] enables all system-relevant settings to be modified. [REMOTE ACCESS] gives information about the player’s current state and lets you control the playback.

  • Page 22: Configuring The Web Interface

    6.1.2. CONFIGURING THE WEB INTERFACE After having edited one or several settings in the [Basic Settings] or [Advanced Settings] tab, these changes need to be applied. To do this, press [Apply Settings] at the bottom of the Web Interface. To restore the previous configuration, press [UNDO].

  • Page 23: Initialization File

    Data transfer is usually faster via an SD Card than via a USB data carrier. When using a USB data carrier, please ensure that the read speed is minimum 30 MByte/s. The UHD Player will only read from the USB data carrier (use the USB data slot) if the SD Card has been removed.
  • Page 24 Options: Group01, Group02, Group03, Group04, Group05, Group06, Group07, Group08, Group09, Group10 [DHCP] On Options: On, Off [IP Address] 192.168.3.177 Options: IP Address of UHD Player [Subnet] 255.255.255.0 Options: Subnet of UHD Player [Gateway] 192.168.3.1 Options: Gateway of UHD Player [DNS] 192.168.3.1...

  • Page 25: Configuring The Initialization File

    The function “Auto EDID” is enabled. To disable Auto EDID, change the option from “On” to “Off”: [Auto EDID] Off Options: On, Off After all changes are made, save the file under the same name, and then eject the SD Card / USB data carrier and insert it into the UHD Player again.

  • Page 26: Network Settings

    How to determine the IP address of a UHD Player on the local network: A) Remove the data carrier from the UHD Player and it will display its Web Interface Info Screen, including the current network configuration on the local display.
  • Page 27 DHCP needs to be turned off first. [Subnet] Upon delivery, the subnet mask is set to the same value as the UHD Player’s IP address. You can change the subnet mask by entering a new one here. DHCP needs to be turned off first.

  • Page 28: Display Configuration

    Typically, the output devices send their EDID to the connected video source via the HDMI cable. By enabling Auto EDID, the UHD Player will automatically attempt to detect the native resolution of the attached output device. If [Auto EDID] is set to “On”, entering any value for [Resolution] will be ignored.
  • Page 29 Alternatively, you may set a fixed dynamic range. To do so, choose between the following options: “SDR”, “HDR10”, “HLG” (Hybrid Log-Gamma). [Pixel Aspect Ratio] The value for [Pixel Aspect ratio] should typically remain set to “Auto”. This means that square pixels are used for the video files (pixel aspect ratio = 1:1), which means that all common video files will be displayed in their correct aspect ratio on the output device.
  • Page 30 Display Configuration in the Initialization File Fig. 19: For more information about how to handle the initialization file, please refer to the Configuration the Initialization File chapter.

  • Page 31: Content

    9. CONTENT THE UHD Player can playback videos, images and audio files in various formats. To be sure to create media files that run with the best playback performance, please see our content guidelines below for video, image and audio files.

  • Page 32: Audio

    PLEASE NOTE: ffmpeg, Handbrake, AnotherGUI or Adobe Media Encoder are not products of AV Stumpfl and, therefore, we cannot support these software solutions. FFMPEG Here is a short guide on how to install ffmpeg on a windows operating system: Download an ffmpeg build from this site: https://ffmpeg.zeranoe.com/builds/.
  • Page 33 Fig. 20: Short instructions on how to define the C:\ffmpeg\bin in your path environmental variable USING FFMPEG VP9: ffmpeg -i input.mp4 -c:v libvpx-vp9 -minrate 30M -maxrate 30M -b:v 30M output.webm h.265: ffmpeg -i input.mp4 -c:v libx265 -minrate 30M -maxrate 30M -b:v 30M output.mp4 Create a video from a set of images (image sequence): ffmpeg -framerate 60 -i input%04d.tif -c:v libx265 -minrate 30M -maxrate 30M -b:v 30M -r 60 output.mp4...

  • Page 34: Muxing Multiple Audio Streams

    It is recommended to use an uncompressed source file for the best output results. 9.5. MUXING MULTIPLE AUDIO STREAMS The UHD Player is able to play videos containing more than one audio stream. Like on a DVD, you can switch between languages without stopping the video playback.
  • Page 35 ffmpeg Calls the program Defines an input file -map 0:v Maps the first video stream of the first input file (in this case, the input.mp4) -map 0:a:0 Maps the first audio stream of the first input file (in this case, the input.mp4) -map 1:a Maps the audio stream of the second input file (in this case, the language1.mp3)

  • Page 36: Media File Playback

    10. MEDIA FILE PLAYBACK As described in the First Steps chapter, the simplest way of playing back media files with the UHD Player in Standalone Mode is as follows: • Save your video, audio and image files to the root folder of the supplied SD Card or any other USB data carrier (e.g.
  • Page 37 PLEASE NOTE: The Play Mode in use will always be overwritten when a playlist is added to the data carrier! To edit the Play Mode via the Web Interface, click on the [BASIC SETTINGS] tab in the Menu Bar and the [Play Mode] function will appear.

  • Page 38: Default Display Time

    Play Mode Options in the Initialization File Fig. 22: For more information about how to handle the initialization file, please refer to Configuration via the Initialization File chapter. 10.2. DEFAULT DISPLAY TIME The duration of video and audio files is defined through their individual file length. Image files do not have a fixed display time, as such.

  • Page 39: Volume

    Default Display Time Setting in the Initialization File Fig. For more information about how to handle the initialization file, please refer to Configuration via the Initialization File chapter. 10.3. VOLUME Basically, there is one volume value (default: 8/approx. 0 dB) set up for all media files containing audio.
  • Page 40 Volume setting in the Initialization File Fig. 26: For more information about how to handle the initialization file, please refer to Configuration via the Initialization File chapter.

  • Page 41: Skipsize

    10.4. SKIPSIZE External Control it is possible to jump within the currently played media file. The number of seconds that can be skipped forward or backward is defined as “Skipsize”. In the Web Interface, click on [ADVANCED SETTINGS] in the menu bar and then on [Skipsize].

  • Page 42: Playlist

    10.5. PLAYLIST The media files on your data carrier can be organized via a playlist. This is a text file named “playlist.txt”, in which a variety of options for each playlist item may be set. A short overview is given below: An individual display time...

  • Page 43: Obligatory Playlist Entries

    File=<filename> Enter the name of the media file you want to allocate to the item. Make sure the Description: name is entered correctly. The UHD Player differentiates between capital and small letters (case sensitive) and reads every space. File=sample.mp4 Example: The media file with the name “sample.mp4”...

  • Page 44: Optional Playlist Entries

    0 (muted) to 10 (100%)—see Volume chapter. No entry means that the default volume of the UHD Player will be applied. Volume=4 The volume of the current media file is set to 40%. The volume of the media file Example: following the current one will remain unchanged and be played with the player’s...
  • Page 45 EXAMPLE Precondition: The player’s default volume is set to “8”. [ITEM 0] File=Sample.jpg Displaytime=-1 [ITEM 1] File=01_nature.mp4 Displaytime=0 Succ=0 Interruptible=FALSE Volume=4 [ITEM 2] File=02_nature.mp4 Loop=3 Displaytime=0 Succ=0 ITEM 0 will be displayed continuously (“Display Time=-1”) until ITEM 1 or ITEM 2 are triggered via external control.
  • Page 46 In the following, all scheduler entries are listed. Please make sure that the date and time of your UHD Player are correctly set! Start Date=<dd.mm.yyyy> This parameter allows the definition of a start date for the item. Before that, the Description: item will be skipped.
  • Page 47 EXAMPLE [ITEM 0] File=logo.jpg Displaytime=30 Start Date=04.08.2017 End Date=31.12.2017 [ITEM 1] File=opened.mp4 Displaytime=0 Start Date=04.08.2017 End Date=31.12.2017 Start Time=10:00:00 End Time=18:00:00 [ITEM 2] File=special.png Displaytime=10 Weekdays=Wed,Thu A museum runs an exhibition from 04.08. to 31.12.2017. ITEM 0, the exhibition’s logo will be displayed while the exhibition is running, but before and after that, it will not be included in the playback.

  • Page 48: Customized Assignments

    10.5.4. CUSTOMIZED ASSIGNMENTS Customized Assignments for external control devices will overwrite the default key assignment. For example, the first GPIO of the remote input port triggers [Item 1] in the playlist by default, no matter which item is currently being played. To assign a different command to this trigger, the new and customized assignment must be entered for every item in the playlist for which it should be valid.
  • Page 49 To call a certain playlist item when the default key assignment is turned off by adding “KeyOff”, use the following syntax: KeyOff <Key Name>=<Item number> … When “KeyOff” is used in a playlist item to disable the default key assignment, <Key Name>=<Item number>...
  • Page 50 EXAMPLE [ITEM 1] File=show1.mp4 KeyOff Key1=1 Key2=2 Key3=1.t Key4=-1.t [ITEM 2] File=show2.mp4 KeyOff Key3=1.t Key4=-1.t Four buttons are connected via the GPIO Input Ports, triggering GPIO1 to GPIO4. Button presses while ITEM 1 is running: When Button1 is pressed, the playback of ITEM 1 starts again. When Button2 is pressed, ITEM 2 starts.

  • Page 51: Media File Management

    11. MEDIA FILE MANAGEMENT The media content that is played by the UHD Player needs to be stored on the player’s SD Card or USB device; there is no internal storage for media files. There are several possibilities to manage the content of the player’s data carrier:...
  • Page 52 [Server address] e.g. ftp.dummy.com [Username] e.g. “User1” [Password] e.g. “secret” [Server folder] e.g. “/UHD Player content” [Start date] & [Start time] Set a [start date] in the format (dd:mm:yyyy) and a [start time] in the format (hh:mm:ss) by choosing the values from the corresponding dropdown menus. This is needed to define the beginning of the External FTP Auto Download.
  • Page 53 [… Interval] When the defined start date and start time is reached, the UHD Player tries to establish a connection to the FTP server and starts the Auto Download process. Based on the initial time, you can define whether this procedure will be repeated hourly, daily, weekly, monthly (every 28 days), or after an individually selected interval (in seconds).
  • Page 54 HOW TO CREATE AND USE A FILE LIST Use a file list (“FileList.txt”) if you want to do one of the following things while executing the External FTP Auto Download: Delete files from the player’s data carrier Copy only certain files from the external FTP server Create a text file using any text editor.
  • Page 55 PLEASE NOTE: As soon as a “FileList.txt” is used, e.g. to delete files from the player, only the files that are specified in this text document will be downloaded from the external FTP server to the player’s data carrier. EXAMPLE 1 – WITHOUT FILE LIST BEFORE Auto Download is started Content on the Player’s SD Card: Content on the External FTP server:...
  • Page 56 AFTER Auto Download is executed Content on the Player’s SD Card: 01.mp4 02.mp4 ByeBye.mp4 Welcome.mp4 As defined in the FileList.txt on the external FTP server, the file “Event.jpg” is first deleted, then only the files Welcome.mp4, ByeBye.mp4 and Playlist.txt are copied from the FTP server to the player’s data carrier.

  • Page 57: Via Local Ftp Server

    11.3. .. VIA LOCAL FTP SERVER The UHD Player hosts a local FTP Server. Using any FTP Client software, you may connect to the UHD Player and delete and/or copy files from/to the player’s SD Card. PLEASE NOTE: If you have changed the contents on the SD Card through FTP access or the file browser in the Web Interface, the UHD Player needs to rescan the sources.
  • Page 58 CONNTECTING TO THE LOCAL FTP SERVER You may use any FTP Client Software to connect to the UHD Player’s Server, e.g. the freeware FileZilla (https://filezilla-project.org/). Within your FTP Client Software, connect to the player’s FTP Server (or host) by entering the player’s IP address (e.g.

  • Page 59: Via The Web Interface

    If you have changed the contents on the SD Card through FTP access or the file browser below, the UHD Player needs to rescan the sources. Please click on the update symbol to start the scan. Click on [SD CARD] or [USB] in the...
  • Page 60 2) MEDIA FILE PREVIEW Click on the name of a video, image, settings or text file. Depending on the browser that is used to view the Web Interface, the file will be displayed directly in your browser, or a dialog box will appear and ask whether the file should be opened with a certain program or saved on your computer.
  • Page 61 5) EDIT INITIALIZATION FILE / PLAYLIST The UHD Player’s initialization file (“UHDPlayerSettings.ini”) and a playlist can be edited within the Web Interface. To do so, click on the Edit Symbol next to the file and it will open in a text editor that is integrated into the Web Interface.
  • Page 62 6) CREATE PLAYLIST A blank playlist can be created by clicking on [New] below the file browser. If there is already a playlist located in the root folder of the player’s data carrier, this one will open in the text editor instead of a blank one.
  • Page 63 If you have changed the contents on the SD Card through FTP access or the file browser below, the UHD Player needs to rescan the sources. Please click on the update symbol to start the scan. n the Web Interface...

  • Page 64: Hdmi Input

    A pop-up dialog will appear, informing you that the playback will be suspended. Confirm this to proceed with the SD Card scan. Fig. 44: Pop-up dialog after [Update Content] button was clicked 12. HDMI INPUT HDMI 2.0 Input port on the rear panel enables you to use an external video/audio source as (live) input.

  • Page 65: Synchronized Playback

    13. SYNCHRONIZED PLAYBACK Multiple UHD Players can be frame synchronized via network to play multi-display presentations. Even if one player goes offline and/or returns to online state at any time, it is automatically resynchronized to the remaining players of the setup. There is no limitation to the number of players that can be synced.
  • Page 66 STEP 2: COPY THE CONTENT ON THE DATA CARRIER Copy the media files for display 1 to the data carrier of player 1, and copy the media files for display 2 to the data carrier of player 2, etc. You do not have to use the same kind of data carriers, e.g. it is possible to use an SD Card for player 1 and a USB stick for player 2.
  • Page 67 SD Card of Player 2 contains: The playlist of Player 2 contains: Video_1B.mp4 [ITEM 1] Video_2B.mp4 File=Welcome_B.jpg Video_3B.mp4 Displaytime=20 Playlist.txt UHDPlayerSetting.ini [ITEM 2] Welcome_B.jpg File=Video_1B.jpg [ITEM 3] File=Video_2B.jpg [ITEM 4] File=Video_3B.jpg […] STEP 4: CONNECT PLAYERS VIA NETWORK It is obligatory that all players are connected to the same network, as the sync control only works over Ethernet.
  • Page 68 [Sync Accuracy] The sync accuracy defines how exact the synced playback will be. “High“: A deviation of < 3 ms is tolerated “Medium”: A deviation of < 16ms is tolerated “Low”: A deviation of < 1000ms is tolerated “Off”: Only the start of a media file is triggered and then the playback is in free-run The option to set the Sync Accuracy to lower values is implemented in case slave players output audio.

  • Page 69: External Control

    14. EXTERNAL CONTROL Fig. 47: Overview of External Control Devices UHD Players can be interactively controlled, e.g. by the Web Interface, proximity sensors, gesture detection or just by push buttons and light barriers. Below is a list of possible control devices: Web Interface Commands sent via UDP or RS232 Avio, which can be used to integrate proximity sensors and gesture detection...

  • Page 70: Rs232 Interface

    Avio. The following are the default serial settings for the UHD Player. The baud rate can be changed but all other parameters are fixed. Baud rate: 9600 Data: 8 bit Parity: none...

  • Page 71: Terminal

    Setting the volume to the value “8” using the command “VOLUME=” Command: VOLUME=8 [CR LF] When the UHD Player receives a command string and determines that it is valid, it performs the command and sends a response to the host device (when using UDP: on the same port). Command: <command>...
  • Page 72 When the UHD Player receives a request string (characterized by an ending with a “?”), it will return the corresponding answer. EXAMPLE: Request: MUTE? [CR LF] Response: MUTE=0 For all available commands, see the RS232/UDP commands chapter in the Appendix.

  • Page 73: Serial Out Via Avio

    14.1.2. SERIAL OUT VIA AVIO When using a UHD Player with an Avio PRO License (you can check the license on the player’s initial Avio Settings screen—see Avio), Avio can be used to send out serial messages via the RS232 interface...

  • Page 74: Udp Control

    Please confirm your changes by pressing [Apply Settings] at the bottom of the page. Now that the UDP port is set up, the UHD Player is ready to receive your command strings. In your control device, start a UDP connection to the UHD Player’s IP address with the corresponding UDP port for incoming and outgoing messages.
  • Page 75 When the UHD Player is unable to perform the command because the command is invalid or contains invalid parameters, the player returns nothing. When the UHD Player receives a request string (characterized by an ending with a “?”), it will return the corresponding answer.

  • Page 76: Usb Devices

    Logitech Presenter Jade Presenter Keyboard Mouse The USB device must be plugged into one of the USB peripheral ports at the UHD Player’s right side. The following sections will give you additional information about how to configure and use these devices.

  • Page 77: Logitech Presenter

    14.3.1. LOGITECH PRESENTER The Logitech Presenter R400 allows you to control the UHD Player via one of the USB peripheral ports. It has eight buttons that have default actions assigned—see image and list below. The Logitech R400 Presenter with default key assignment Fig.

  • Page 78: Jade Presenter

    [CTRL+F5] or [CTRL+S]. 14.3.2. JADE PRESENTER The Jade Presenter allows you to control the UHD Player via one of the USB peripheral ports. It has eight buttons that have default actions assigned—see image and list below.

  • Page 79: Keyboard

    Settings]. PLEASE NOTE: While the UHD Player shows its Web Interface, the presenter’s buttons as mentioned above are without function. In this state, the presenter acts as a mouse device: The pointing stick in the middle moves the mouse pointer and the button on the back-side executes a left-mouse-click.

  • Page 80: Gpios - Remote In

    14.4. GPIOS - REMOTE IN The UHD Player provides 16 GPIOs that can be used to control the playback with various, customized devices, e.g. buttons, switches and any kind of sensor. The GPIO triggers listen for pin state changes and then perform their default action or a customized one.

  • Page 81: Avio

    Avio settings overview in the Web Interface Fig. 60: The location where all the UHD Player’s Avio settings will be saved can be chosen in the Web Interface. Click on [ADVANCED SETTINGS] in the menu bar and then on [AVIO].
  • Page 82 [Avio Settings Location] The player will use the location that is entered here for its Avio settings (save changes and operate). By default, the location of all Avio Settings is the SD Card. You may change this option to operate from a USB data stick or from the player’s internal storage.

  • Page 83: System Settings

    15. SYSTEM SETTINGS 15.1. DATE & TIME By default, the UHD Player’s date and time will automatically be set by an external NTP Server, using the time zone of Europe/Berlin. Network Time Protocol (NTP) is a networking protocol for clock synchronization between computer systems over a network.

  • Page 84: Change Uhd Player Name

    Fig. 64: UHD Player Name setting in the Web Interface To edit the player’s default name, “UHD Player”, click in the text field on the right and enter the new name, consisting of maximum 64 characters. Click on [Set Name] to apply your changes.

  • Page 85: Save & Load Configuration

    [Delete]. 15.5. REBOOT The UHD Player can be rebooted by manually power cycling it or by a trigger via external control. To perform a reboot via the Web Interface, open the player’s web interface in your browser and click...

  • Page 86: Factory Reset

    Click [Reboot] on the right side to reboot the player. 15.6. FACTORY RESET The Web Interface can perform a factory reset on the UHD Player. This will set the player to its factory defaults, including the network settings. To do so, open the player’s Web Interface in your browser and click on [SYSTEM] in the menu bar. In the lower area of this page, you will find the “Factory Reset”...
  • Page 87 System’s page again with all settings. UPDATE VIA MANUAL DOWNLOAD If the player needs to be updated manually, download the latest UHD Player Firmware Version from http://avstumpfl.com/en/service/downloads/. Extract the .zip-file. The extracted folder will contain two files: md5 and UHD_<Firmware-Version-Number>.cfp. Copy these two files to the root folder of an SD Card and plug it in the player’s SD Card slot.

  • Page 88: Backup And Restore

    16. BACKUP AND RESTORE It is very easy to back up a complete UHD Player, as all relevant media and settings files are already bundled on the player’s data carrier. Just remove the player’s SD Card or USB device and copy the entire content to your computer’s hard drive or any other data storage.

  • Page 89: Troubleshooting

    • Set the Avio settings location to “SD” or “USB”, depending on the data carrier that contains the backup. Then the player will read the Avio settings from this location and changes in the Avio configuration will also be stored here. •...

  • Page 90: Appendix

    When the UHD Player is unable to perform the command because the command is invalid or contains invalid parameters, the player returns nothing. When the UHD Player receives a request string (characterized by an ending with a “?”), it will return the corresponding answer.

  • Page 91: Playback

    See below for all remote commands, listed thematically. 18.1.1. PLAYBACK PAUSE Description: Pauses the current playback Example: PAUSE [CR LF] RESUME or PLAY Resumes the playback of a paused media file Description: When the playback is stopped, it starts the playback from the beginning of the playlist (or alphanumeric order when no playlist is used).
  • Page 92 SPEED= It sets the playback speed of the current media file (in %). The playback speed of Description: media files with audio output can only be set to a value between 50% and 120%. SPEED=75 [CR LF] Example: Sets the playback speed to 75% SPEED? Description: Returns the current playback speed (in a common fraction)

  • Page 93: Audio

    TIMETOFINISH? Description: Returns the remaining playback time of the current media file (in seconds) TIMEFOFINISH? [CR LF] Example: Example response: TIMETOFINISH=80 The current media file will end in 80 seconds. 18.1.2. AUDIO VOLUP Description: Increases the volume by 1 step Example: VOLUP [CR LF] VOLDOWN...

  • Page 94: File Organisation

    MUTE? Returns the Mute Mode Description: 0: Player is unmuted 1: Player is muted MUTE? [CR LF] Example: Example response: MUTE=1 AUDIOTRACK= It selects the (stereo) audio track of a video file. If there is only one audio track Description: available, this one will be active, even if another one was chosen.

  • Page 95: System

    18.1.4. SYSTEM DATE= Description: Sets date or date and time. Syntax: <DD.MM.YYYY> <HH:MM:SS> Example: DATE=31.12.2017 23:59:59 [CR LF] SHOWMAININFO It shows the Main Info Page of the player’s Web Interface on the output device. Description: Use the command SHOWPLAYBACK to leave this view again. Example: SHOWMAININFO [CR LF] SHOWPLAYBACK...

  • Page 96: Changelog

    18.2. CHANGELOG UHD Player Firmware Changelog V1.1.2 (Kernel Date: 12.09.2017) - Fixed: Default Displaytime is now interpreted correctly when not using a playlist. V1.1.1 (Kernel Date: 12.09.2017) - Fixed: Apply Settings at the Web Interface did not reload the settings correctly.
