Page 1: User Manual
User Manual HD Player Pro AV Stumpfl GmbH Mitterweg 46 A-4702 Wallern Tel.: +43-7249-42811 Fax: +43-7249-428114 E-Mail: AVstumpfl@AVstumpfl.com Internet: http://www.AVstumpfl.com... - Page 2 FCC Notices It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
Using the Remote Control when Media File is playing ........22 8.2 MULTIPLE DISPLAY ZONES ..................24 8.4 FTP AUTO DOWNLOAD FUNCTION ................26 8.5 Controlling the HD Player (RS-232/UDP) ..............29 8.6 How to synchronize several HD Player Pro ................ 30... - Page 4 Advance Schedule ..................43 10.2.3 Explanation of the Warning Message ............45 10.3 APPLY THE SCHEDULE ON THE HD Player Pro ............45 11 OPTIONAL AUXILIARY EQUIPMENT ................46 11.1 PLAY-BUTTON BOX (SCV-HDZ-WPBB) ..............46 11.2 IR Cable (SCV-HDZ-IRC) ....................46 11.3 PIR SENSOR (SCV-HDZ-PIR) ..................
-
Page 5: Package Contents
- IP Detect Tool - User Manual 2. INTRODUCTION The new „HD Player“ by AV Stumpfl supports professional High Definition video playback from Compact Flash card. Integrated hardware decode acceleration ensures smooth full HD playback and clear images. Flexible playback, control and configuration options allow the HD Player to be adapted to a variety of different requirements. -
Page 6: Features
Supports Auto Key Lock Function Exports the Configuration Value: You can export the configuration value to the CF card. The configuration value can be modified on your PC, and can be applied to the HD Player Pro or others. Supports FTP Auto Download Function: Connect to Remote FTP server and download data to the CF card automatically. -
Page 7: Hardware Overview
4. HARDWARE OVERVIEW... -
Page 8: Remote Control
“ C F R E A D Y ” L E D : Steady green confirms that the CF card is inserted correctly. CF Card Socket: For CF memory card. “ R E S E T ” B u t t o n : To restart the HD Player Pro. 5. REMOTE CONTROL... -
Page 9: Entering Text Or Ip Address
Status 1: If the “AUTOPLAY (Movie/ Picture/ All Files/ MultiLayer)” function is enabled and there are media files on the CF card or the HD Player Pro is already connected to the display device, the HD Player Pro will auto play media files after power on. -
Page 10: Setting Up
t h e “ E N T E R ” b u t t o n . Y o u w i l l b e ... - Page 11 Assign IP Address: If the HD Player Pro is connected to a network without a DHCP server or you want to use Local FTP Server function, enter the fixed IP address, Mask, Gateway and DNS for the HD Player Pro.
-
Page 12: Setting The Network From The Ip Detect Tool
7.1.2 Setting the Network from the IP Detect Tool With the bundle tool “ IP Detect” , u s e r c o u l d s e a r c h HD Player Pro on the local area network. User could also change the IP setting via this tool. - Page 13 Step3: Double click on the icon to start the tool. Step4: C l i c k o n t h e “ Auto Detect” button, then the tool will show all available HD Player Pro in the local area network.
- Page 14 IP address to HD Player Pro. T h e n e n t e r t h e p r e f e r r e d “ I P ”...
-
Page 15: Ftp Setup
FTP Path: Enter the folder path that you want to share. NTP Server: Enable/ Disable the NTP server function. (if the HD Player Pro i s n ’ t c o n n e c t t o ... - Page 16 functions) NOTE: GMT and applied regions Time Zone Region Time Zone Region (GMT-12:00) Eniwetok, Quazalen (GMT+02:00) Helsinki, Riga, Tallinn (GMT-11:00) Midway, Ireland, Samoa (GMT+03:00) Nairobi Moscow, Saint Petersburg, (GMT-10:00) Hawaii (GMT+03:00) Volgograd (GMT-09:00) Alaska (GMT+03:00) Baghdad Pacific GMT (U.S. & Canada); (GMT-08:00) (GMT+03:00) Kuwait, Raid...
-
Page 17: Video Setup
S e l e c t t h e “ A u t o E D I D ” , t h e HD Player Pro will scan the display device connected and set the... -
Page 18: Other Setup
SlideShow Interval: Set the time each photo is shown to 10, 15, 30 seconds or 1, 10, 15, 30 minutes or 1 hour. . Lock Remote Controller: Enable/ disable the auto key lock function. (The HD Player Pro will auto lock when there is no further input for 1 minute.) Lock Password Setup: P r e s s ... - Page 19 Step1: C o p y t h e f i l e “ H D P l a y e r S e t t i n g . t x t ” o n C F card to your PC. Use “ N o t e p a d + + ” (http://notepad-plus- plus.org/) to open the file, and you can see all the settings of the HD Player Pro. Step2: You can modify directly the configuration value on your PC.
-
Page 20: Other Setup
7.5. OTHER SETUP Multiple Display: Movie: Display stored videos with scrolling text. Movie + PIC (L): Display stored video and pictures with scrolling text, and the pictures are on the left. Movie + PIC (R): Display stored video and pictures with scrolling text, and the pictures are on the right. -
Page 21: Using The Hd Player Pro
PLAY MEDIA FILES FROM THE CF CARD Step 1: Insert the CF card with media files, then turn on the HD Player Pro a n d p r e s s t h e “ E N T E R ” ... -
Page 22: Using The Remote Control When Media File Is Playing
8.1.1 Using the Remote Control when Media File is playing SETUP: Press the button to adjust the brightness, contrast or saturation while the video or picture is playing. With the “+ VOLUME –” button. - First Press: Adjust the brightness. - Second Press: Adjust the contrast. - Page 23 Original Size First Press：ZOOM 01 Second Press：ZOOM 02 Third Press：ZOOM 03...
-
Page 24: Multiple Display Zones
MULTIPLE DISPLAY ZONES Step 1: Put movies, pictures (only supports PNG format/ size: 213x641/ 96DPI) and text file on CF card. Picture Files I f y o u s e l e c t t h e “ By Slide Time” i t e m o f t h e p i c t u r e s l i d e mo d e ; p l e a s e n a me t h e p i c t u r e files 0.png ~ 9.png. -
Page 25: Log Function
LOG FUNCTION Step1. Please turn on the Log Function first. (Refer to 7.4 Other Setup) Step2 .The new log files are automatically generated every day (the log files will be stored in the “syslog” folder on the memory card). Step3. The log file (.txt) can be viewed on your PC using Notepad++ or any other Text editor. -
Page 26: Ftp Auto Download Function
[dlplay] 0: Disable the function (the speed of download will be faster) 1: Enable the function (the speed of download will be slower) Set the time to restart the HD Player Pro after finish downloading (replace the downloaded [time] files). - Page 27 Enter the filename you want to download. [file] 001.mpg Note: The length of file name and extension cannot exceed 20 characters. 002.mpg The file schedule.ini is created by the Schedule Maker software. (refer to section 10) 0.png The file message1.txt is a text file that can change scrolling text settings. U s e t h e “ N o t e p a d ” t o 1.png create the text file on your PC as shown below, and named the file message1.txt (you can schedule.ini...
- Page 28 Example: The MAC address of HD Player Pro is 0013fe098819, and named the file d0013fe098819.txt. NOTE: The MAC address of HD Player Pro will be displayed in the setup menu. Step3: Put all the files (included media files/ command file (ex. d0013fe098819.txt/ schedule.ini/ message1.txt) to the FTP server.
-
Page 29: Controlling The Hd Player (Rs-232/Udp)
2. Make sure the RS232 function is enabled (refer to section 7.5). 3. Use a crossed RS-232 cable to control the HD Player PRO. 4. To control the HD Player PRO via RS232 or UDP the Autoplay function needs to be turned on. Keyboard Layout q：POWER... -
Page 30: How To Synchronize Several Hd Player Pro
How to synchronize several HD Player Pro Step1. Please connect all HD Player Pro via a RJ-45 Cable with an Ethernet Switch Step2. Assign IP Address to HD Player Pro: The Address must be in the same Subnet, Gateway and DNS. - Page 31 Step3. Turn on the Sync-Control on every HD Player: Step4. Set Master/Slave: Set one HD Player Pro to be the Master and the other units (up to 254 units) to be Slaves.
- Page 32 NOTE: HDPlayerSetting.txt-File For easy configuration you are abl e t o e x p o r t t h e “ S e t t i n g s F i l e ” of the HD Player on the CF-Card: Insert the CF-Card with the “...
-
Page 33: Important To Know For Synchronization
The HD Player Sync-Function only works when “Autostart” is activated. (Startup time approximately 90 seconds) · The Repeat settings of the different HD Player Pro must be the same (Repeat Default/All) · The video files on the CF-Card must have the same Length/Bitrate/Framerate on every HD Player PRO. -
Page 34: Http Command Function
Setup” set has been completed (refer to 7.2). Set your router or firewall, and open a port 80 for the HD Player Pro. The following figure is an example, please refer to your user’s manual of router for opening ports. -
Page 35: Control
CONTROL Control: Select one of the control command, and press “Send” to control the HD Player Pro. n Stop: Stop playback n Play: Start playback. n Pause: Pause the playback. n Prev: Play the previous file. n Next: Play the next file. -
Page 36: Network
Enable: Enable or disable the network function. Interface: Select your network connection Ethernet (wired) or Wireless. General Setup Enable DHCP: Enable or disable the DHCP function. IP/ Subnet/ Gateway/ DNS server: Enter the fixed IP address, Subnet, Gateway and DNS for the HD Player Pro. -
Page 37: Server
Password: Enter the password of the HD Player Pro (default password: admin). FTP Server Address: Click on the address to directly connect to the HD Player Pro server. Enter the user name and password (Default User Name: root, Default Password: admin) to log on. After logging on all the media files on the CF card will be listed. -
Page 38: Time
TIME NTP Server Enable: Enable or disable the NTP server function. GMT Server: Enter the NTP server IP address like: 66.187.233.4. Time Zone: Set the time zone of your location. -
Page 39: Features
Port: Enter the port of the HD Player Pro (default port: 80) n User ID: Enter the user name of the HD Player Pro (default ID: root). n Password: Enter the password of the HD Player Pro (default password: admin). -
Page 40: Schedule Function
10 SCHEDULE FUNCTION N O T E : T h e “ N T P S e r v e r ” o r “ L o c a l T i me ” mu s t b e s e t before using the Schedule Function. -
Page 41: Start The Schedule Software
10.2 START THE SCHEDULE SOFTWARE You might double click the “ S c h e d u l e Ma k e r ” i c o n o n y o u r d e s k t o p f o r o p e n i n g t h e “ Schedule G e n e r a t o r ”... - Page 42 n Modify: Click this button to modify the file in the list. n Remove: Click this button to remove the file from the list. n Move Up / Move Down: Click these buttons to change the order that the files are played.
-
Page 43: Advance Schedule
Pr e s s t h e “ SAVE” b u t t o n and a pop-u p w i n d o w w i l l a p p e a r . S e l e c t t h e p a t h , t h e n c l i c k t h e “ SAVE” button to save your setup. NOTE: Do not rename the file (schedule.ini), otherwise the HD Player Pro will not be able to read the file. - Page 44 , t h e n c l i c k t h e “ S A V E ” b u t t o n t o s a v e . NOTE: Do not rename the file (schedule.ini), otherwise the HD Player Pro will not be able to read the...
-
Page 45: Explanation Of The Warning Message
P u t t h e “ schedule. i n i ” f i l e a n d the associated media files on the memory card, and insert the memory card to the HD Player Pro. The HD Player Pro will auto play the files at the designated time. -
Page 46: Optional Auxiliary Equipment
Demo File 4：a01.xxx Demo File 5：b55.xxx Step 2: Insert the CF card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. Step 3: Press one of the buttons 1-5 to play the corresponding demo file. -
Page 47: Pir Sensor (Scv-Hdz-Pir)
Step 1: Set the r e p e a t mo d e t o t h e “ Repeat Default” . Step 2: Insert the CF card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. -
Page 48: Usb Auto-Copy Function
Step2: Put the files that you want to copy and the file “ AUTOCOPY.ini” to the USB flash driver. Step3: Insert the USB flash driver to the HD Player Pro, and it will automatically copy the files from USB flash driver to CF card (it takes about 30sec until the HD Player starts copying the Files). -
Page 49: Troubleshooting
Network Not Working If using wired network, make sure the network cable is plugged in on both the HD Player Pro and your network hub. Make sure to using fast enough CF Cards (Sandisk Extreme III or faster – we recommend using CF cards tested by AV Stumpfl) It is very important to use an audio track in your video content. -
Page 50: Recommended Cf-Cards
Recommended CF-Cards Manifacturer Productname Size [GB] SanDisk SanDisk SanDisk SanDisk Extreme SanDisk Extreme III SanDisk Extreme IV SanDisk Extreme IV Transcend 600x Transcend 400x 15. RECOMMENDED VIDEO FILE FORMATS MPEG-4.10 (H.264) BP@L3 SMPTE 421M (VC-1) MP@HL and AP@L3 WMV9 MP@HL MPEG-2 MP@HL MPEG-4.2 ASP@L5 (720p, 1-point GMC) max.
