TABLE OF CONTENTS

Before driving

1

When driving

2

Interior

3

features

Maintenance

4

and care

When trouble

5

arises

Vehicle

6

specifications

For owners

7

Index

Information on the hybrid system and adjusting and op-

erating features such as door locks, mirrors, and steer-

ing column.

Driving, stopping and safe-driving information.

Air conditioning and audio systems, as well as other

interior features for a comfortable driving experience.

Cleaning and protecting your vehicle, performing do-it-

yourself maintenance, and maintenance information.

What to do if the vehicle needs to be towed, gets a flat

tire, or is involved in an accident.

Detailed vehicle information.

Reporting safety defects for U.S. owners, and seat belt

and SRS airbag instructions for Canadian owners

Alphabetical listing of information contained in this

manual.

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Highlander 2011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Highlander 2011

Page 1 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience.
Page 2: For Your Information
A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 3 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 4 In the event of that your vehicle must be disposed of, the hybrid battery must be disposed of your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, they may cause electric shock that can result in death or serious injury.
Page 5 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 7 1-1. Hybrid system Hybrid system Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 8 For this reason, be sure to drive the vehicle at least once every several months for at least 30 minutes or 10 miles (16 km). If the hybrid battery becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Toyota dealer.
Page 9 ■ removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. Sounds and vibrations specific to a hybrid vehicle ■...
Page 10 1-1. Hybrid system High voltage components Air conditioning compressor Service plug Power control unit and DC/ High voltage cables DC converter Front electric motor (traction Hybrid battery (traction bat- motor), transaxle and motor tery) generator Rear electric motor (traction Caution label motor) Take care when handling the hybrid system, as it contains a high volt- age system (about 650 V at maximum) as well as parts that become...
Page 11 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Energy monitor/consumption screen You can view the status of your hybrid system on the multi-infor- mation display (→P.
Page 12: Energy Monitor
1-1. Hybrid system Energy monitor ■ ● How to display on the navigation system screen (if equipped): Press “INFO/PHONE”. STEP Touch “Fuel Consumption” on STEP the “Information” screen. If the “Consumption” screen is displayed, touch ● How to display on the multi-information display: Press the “DISP”...
Page 13 1-1. Hybrid system Multi-information Navigation system screen display When the vehi- cle is powered by both the gas- oline engine and the electric motor (traction motor) When the vehi- cle is powered by the gasoline engine When the vehi- cle is charging the hybrid bat- tery (traction battery)
Page 14 1-1. Hybrid system Consumption screen (navigation system only) ■ Press “INFO/PHONE”. STEP Touch “Fuel Consumption” on STEP the “Information” screen. Regenerated energy in the past 30 minutes One symbol indicates 50 Wh. Up to 4 symbols are shown. Fuel consumption in the past 30 minutes Cruising range Resetting the consumption data...
Page 15 The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. When refueling, the fuel filler door may take a few moments to open ■...
Page 16 1-1. Hybrid system Hybrid battery (traction battery) ■ The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions. CAUTION High voltage precautions ■...
Page 17 1-1. Hybrid system CAUTION Road accident cautions ■ Observe the following precautions to reduce the risk of injury. Pull your vehicle off the road, put the shift lever in P, apply the parking ● brake, and turn the hybrid system off. Do not touch the high voltage parts, cables and connectors.
Page 18 1-1. Hybrid system NOTICE Hybrid battery air vents ■ Do not put foreign objects over the air vents. The hybrid battery (traction ● battery) may overheat and be damaged. Clean the air vents regularly to prevent the hybrid battery (traction battery) ●...
Page 19 1-2. Key information Keys The following keys are provided with the vehicle. Vehicles without smart key system Master keys Valet key Key number plate Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 44) • Operating wireless remote control function (→P.
Page 20 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 538) When riding in an aircraft (vehicles with smart key system) ■...
Page 21 1-3. Opening, closing and locking the doors ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key Electronic key...
Page 22 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
Page 23 1-3. Opening, closing and locking the doors Back door handle Press the button to unlock the door. The door cannot be unlocked for 3 seconds after the door is locked. If you carry the electronic key on your person, the back door can be opened even if it is locked.
Page 24 1-3. Opening, closing and locking the doors Antenna location and effective range Antenna location ■ Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment...
Page 25 1-3. Opening, closing and locking the doors Effective range (areas within which the electronic key is ■ detected) When locking or unlocking the doors This system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles.
Page 26 1-3. Opening, closing and locking the doors Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Conditions affecting operation ■ The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 27 1-3. Opening, closing and locking the doors The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.) Multi-information Unlocking doors Beep display Hold the driver's door han-...
Page 28 1-3. Opening, closing and locking the doors Electronic key battery depletion ■ The standard battery life is 1 to 2 years. (The battery becomes depleted ● even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
Page 29 1-3. Opening, closing and locking the doors The doors may unlock if a large amount of water splashes on the door ● handle, such as in the rain or in a car wash. (The doors will automatically be locked after approximately 60 seconds if the doors are not opened and closed.) Gripping the door handle when wearing a glove may not unlock the door.
Page 30 1-3. Opening, closing and locking the doors When an alarm sounds: ● Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- using the entry function tronic key from the while the electronic key passenger compart- was still inside the passen-...
Page 31 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure Tried to close the driver’s door after carrying the key Shift the shift lever to Interior and exte- outside the vehicle with the P, turn the “POWER” rior alarms sound “POWER”...
Page 32 1-3. Opening, closing and locking the doors Customization that can be configured at Toyota dealer ■ It is possible to deactivate the smart key system etc. (Customizable features →P. 583) Certification for the smart key system ■ For vehicles sold in the U.S.A.
Page 33 (→P. 47) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 34 1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles without smart key system (type A) Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door.
Page 35 1-3. Opening, closing and locking the doors Vehicles without smart key system (type B) Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors. Pushing holding: Sounds alarm Pushing holding:...
Page 36 1-3. Opening, closing and locking the doors Operation signals ■ Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Back door: A buzzer sounds and the emergency flashers flash twice to indicate that the back door has been opened/closed.
Page 37 1-3. Opening, closing and locking the doors Key battery depletion ■ Vehicles without smart key system The standard battery life is 1 to 2 years. (The battery becomes depleted even if the key is not used.) If the wireless remote control function does not operate, the battery may be depleted.
Page 38 ● a personal computer Vehicles with smart key system →P. 49 Customization that can be configured at Toyota dealer ■ Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 583) Reversing the operation of the power back door ■...
Page 39 1-3. Opening, closing and locking the doors Certification for wireless remote control ■ MODEL/FCC IDs: Transmitter: GQ43VT20T Receiver: GQ4-34R IC(Canada)IDs: Transmitter: 1470A-1T Receiver: 1470A-6R MADE IN U.S.A. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Page 40 1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. Entry function (vehicles with smart key system) ■ →P. 44 Wireless remote control ■...
Page 41 1-3. Opening, closing and locking the doors Inside lock button ■ Locks the door Unlocks the door Pulling the door handle can open the front door even if the lock button is in the lock posi- tion. Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set.
Page 42 1-3. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of P locks all door locking function doors. Shift position linked Shifting the shift lever to P unlocks all doors.
Page 43 1-3. Opening, closing and locking the doors Shift the shift lever to P or N, and STEP press and hold the driver's door lock switch approximately 5 seconds and then release it. The shift lever and switch posi- tions corresponding desired function to be set are shown in the following table.
Page 44 Using the mechanical key ■ The doors can also be locked and unlocked with the mechanical key. (→P. 539) Customization that can be configured at Toyota dealer ■ Settings (e.g. door unlocking function) can be changed. (Customizable features →P. 583)
Page 45 1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. Locking and unlocking the back door ■ Door lock switch →P. 63 Entry function (vehicles with smart key system) →P.
Page 46 1-3. Opening, closing and locking the doors Opening the back door from inside the vehicle (vehicles ■ with power back door) Push and hold the switch to open/close. Pushing the switch again while the power back door is operat- ing will cause the operation to reverse.
Page 47 1-3. Opening, closing and locking the doors Canceling the power back door system (vehicles with power back door) Turn the main switch in the glove box off to disable the power back door system. A buzzer sounds twice and the back door can then not be opened with the wireless remote control...
Page 48 1-3. Opening, closing and locking the doors If the back door opener is inoperative ■ The back door can be operated from the inside. Remove the cover. STEP Turn the lever. STEP The power back door can be opened when ■...
Page 49 If excessive force is applied to the back door while it is opening automati- cally, the power back door will stop at that positions, preventing itself from falling down. Customization that can be configured at Toyota dealer ■ Settings (e.g. wireless remote control) can be changed.
Page 50 1-3. Opening, closing and locking the doors CAUTION Operating the back door ■ Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. Remove any heavy loads, such as snow and ice, from the back door ●...
Page 51 1-3. Opening, closing and locking the doors CAUTION Do not attach any accessories other than genuine Toyota parts to the back ● door. Such additional weight on the back door may cause the back door to fall closed again after it is opened.
Page 52 “POWER” switch is turned to ON mode or the hybrid system is started during automatic operation Do not attach any accessories other than genuine Toyota parts to the back ● door. The power back door may not operate, causing itself to malfunction, or the back door may fall closed again after it is opened.
Page 53 Do not touch the damper stay rod with ● gloves or other fabric items. Do not attach any accessories other ● than genuine Toyota parts to the back door. Do not place your hand on the damper ● stay or apply lateral forces to it.
Page 54 1-3. Opening, closing and locking the doors ∗ Glass hatch The glass hatch can be opened using the glass hatch opener. Wireless remote control (vehicles without smart key sys- ■ tem) →P. 57 Entry function (vehicles with smart key system) ■...
Page 55 1-3. Opening, closing and locking the doors CAUTION While driving ■ Keep the glass hatch closed while driving. ● If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 56 Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident. Do not attach any accessories other than genuine Toyota parts to the ● glass hatch. Such additional weight on the glass hatch may cause the glass hatch to fall closed again after it is opened, resulting in death or seri- ous injury.
Page 57 Do not touch the damper stay rod with ● gloves or other fabric items. Do not attach any accessories other ● than genuine Toyota parts to the glass hatch. Do not place your hand or foot on the ● damper stay or apply lateral forces to it.
Page 58 1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat (passenger’s side only) Seat position adjustment lever Seatback angle adjustment lever...
Page 59 1-4. Adjustable components (seats, mirrors, steering wheel) Power seat Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch (driver’s side only) Vertical height adjustment switch (driver’s side only) Driver’s seat leg support adjustment switch (if equipped) Seat lumbar support adjustment switch (driver’s side only) Active head restraints When the occupant’s lower back...
Page 60 1-4. Adjustable components (seats, mirrors, steering wheel) Active head restraints ■ Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may cause the inner struc- ture of the head restraint to appear. This does not indicate a problem. During rear-end collision...
Page 61 1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seats ■ Seat position adjustment lever Seatback angle adjustment lever Pull up the lever until the lock is completely released. Third seats ■ The third seats do not have a seat adjustment function. Moving a second seat for third seat access Getting in the vehicle (right side only) ■...
Page 62 1-4. Adjustable components (seats, mirrors, steering wheel) Getting out of the vehicle (right side only) ■ Lift the lever on the side of the seatback and fold down the seat- back. The seat will slide forward. Move the seat to the front-most position.
Page 63 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the second seats ■ From inside Pull the lever to unlock the seat- back and then fold the seatback down. From outside Pull the lever. L: Left side and center second seats R:Right side second seat After folding down the second seats...
Page 64 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the third seats Before folding down the third seats ■ Stow the third seat belt buckles. STEP Pass the seat belts through the STEP seat belt hangers. This helps to prevent the shoulder belts from being damaged.
Page 65 1-4. Adjustable components (seats, mirrors, steering wheel) Returning the third seats ■ Pull the straps and raise the STEP seatbacks until they lock. Raise the head restraints. STEP Removing the second center seat Before removing the second center seat ■ Take out the side table from the STEP console box.
Page 66 1-4. Adjustable components (seats, mirrors, steering wheel) Removing the second center seat ■ Fold down the second center STEP seatback while pulling the seat- back lock release strap. Pull the lock release lever to STEP remove the second center seat. Stow the second center seat in STEP the console box.
Page 67 1-4. Adjustable components (seats, mirrors, steering wheel) Installing the second center seat Before installing the second center seat ■ Take out the second center seat STEP from the console box. Remove the side table, if used, from the second seat. STEP (→P.
Page 68 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION When adjusting a rear seat or removing the second center seat ■ Be careful that the seat does not hit passengers or luggage. ● Do not recline the seat more than necessary when the vehicle is in motion ●...
Page 69 1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button. Angle adjustment Second seats Pull the head restraints up.
Page 70 1-4. Adjustable components (seats, mirrors, steering wheel) When using the third seat head restraints ■ To use To fold Adjusting the height of the head restraints (except second center seat ■ and third seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 71 1-4. Adjustable components (seats, mirrors, steering wheel) Installing the front and second seat outer head restraints ■ Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
Page 72 1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts ■ ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 73 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front seats) ■ Down Move the height adjuster up and down as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to...
Page 74 1-4. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) ■ The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 75 1-4. Adjustable components (seats, mirrors, steering wheel) When not using the rear seat belts ■ Second seat belts Pass the outer seat belts through the seat belt hangers and secure the seat belt plates to prevent the shoulder belts from being damaged.
Page 76 Each seat belt should be used by one person only. Do not use a seat belt ● for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always ● use a seat belt and/or an appropriate child restraint system.
Page 77 Do not attempt to install, remove, modify, disassemble or dispose of the ● seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
Page 78 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender ■ Do not wear the seat belt extender if you can fasten the seat belt without ● the extender. Do not use the seat belt extender when installing a child restraint system ●...
Page 79 1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 80 1-4. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror ■ Normal position Anti-glare position Auto anti-glare inside rear view mirror ■...
Page 81 1-4. Adjustable components (seats, mirrors, steering wheel) Type B Turns automatic mode on/off The indicator comes on when automatic mode is turned on. Vehicles without smart key system: The mirror will revert to auto- matic mode each time the engine switch is turned to the “ON”...
Page 82 1-4. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error (vehicles with auto anti-glare inside rear view ■ mirror) Type A To ensure that the sensors operate prop- erly, do not touch or cover them. Type B To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 83 1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down Left Folding back the mirrors Push backward to fold the mir- rors.
Page 84 1-4. Adjustable components (seats, mirrors, steering wheel) The outside rear view mirrors can be operated when ■ Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with smart key system The “POWER” switch is in ACCESSORY or ON mode. When the mirrors are fogged up (vehicles with outside rear view mirror ■...
Page 85 1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 86 1-5. Opening and closing the windows and moon roof The power windows can be operated when ■ Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “POWER” switch is in ON mode. Operating the power windows after turning the hybrid system off ■...
Page 87 1-5. Opening and closing the windows and moon roof CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body ●...
Page 88 1-5. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing ■ Open The moon roof stops slightly before the fully opened posi- tion.
Page 89 1-5. Opening and closing the windows and moon roof The moon roof can be operated when ■ Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “POWER” switch is in ON mode. Operating the moon roof after turning the hybrid system off ■...
Page 90 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer.
Page 91 1-5. Opening and closing the windows and moon roof Jam protection function ■ If an object is detected between the moon roof and the frame while closing or tilting down, travel is stopped and the moon roof opens slightly. To reduce wind noise ■...
Page 92 1-5. Opening and closing the windows and moon roof CAUTION Opening the moon roof ■ Observe the following precautions. Failure to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 93 1-6. Refueling Opening the fuel tank cap The fuel tank of your vehicle has a special structure, which requires a reduction in fuel tank pressure before refueling. After the opener switch has been pressed, it will take several seconds until the vehi- cle is ready for refueling.
Page 94 1-6. Refueling Turn the fuel tank cap slowly STEP to open. Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard.
Page 95 10 seconds of the switch being pressed. If the fuel filler door opener is inoperable ■ If the fuel filler door opener switch cannot be operated, contact your Toyota dealer. In the event that urgent refueling is required, follow the procedure below.
Page 96 When replacing the fuel cap ■ Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. When opening the fuel cap ■...
Page 97 1-6. Refueling NOTICE Refueling ■ Finish refueling within 30 minutes. If more than 30 minutes passes, the ● internal valve closes. In this condition, fuel may spill out if you continue to refuel the vehicle. About 5 minutes after the valve is closed, a message “CLOSE FUEL LID”...
Page 98 1-7. Theft deterrent system Immobilizer system The vehicle's keys have built-in transponder chips that prevent the hybrid system from starting if the key has not been previously regis- tered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without navigation system Vehicles without smart key system: The indicator light...
Page 99 1-7. Theft deterrent system Vehicles with navigation system Vehicles without smart key system: The indicator light flashes after the key has been removed from engine switch to indicate that the sys- tem is operating. The indicator light stops flash- ing after the registered key has been inserted into the engine switch to indicate that the system has been can-...
Page 100 1-7. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type immobilizer system. Conditions that may cause the system to malfunction ■ If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system ●...
Page 101 1-7. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes the lights when forcible entry is detected. Triggering of the alarm ■ The alarm is triggered in the following situations when the alarm is set. ● A locked door is unlocked or opened in any way other than using the entry function (vehicles with a smart key system) or wireless remote control or mechanical key.
Page 102 1-7. Theft deterrent system Setting the alarm system ■ Vehicles without navigation system Close the doors, glass hatch and hood, and lock all doors. The system will be set auto- matically after 30 seconds. The indicator light changes from being on to flashing when the system is set.
Page 103 1-7. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. ●...
Page 104 1-7. Theft deterrent system Alarm-operated door lock ■ When the alarm is operating, the doors are locked automatically to pre- ● vent intruders. Do not leave the key inside the vehicle when the alarm is operating, and ● make sure the key is not inside the vehicle when recharging or replacing the 12-volt battery.
Page 105 1-7. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.
Page 106 1-8. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 81) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 107 1-8. Safety information CAUTION While driving ■ Do not adjust the position of the driver's seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...
Page 108 1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 109 1-8. Safety information Airbag system components Curtain shield airbags SRS warning light Side airbags Driver airbag Front passenger airbag Driver’s seat position sen- Side and curtain shield air- bag sensors Driver’s seat belt buckle switch Door sensors Driver knee airbag Front airbag sensors Airbag sensor assembly Front passenger’s seat belt...
Page 110 1-8. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 111 1-8. Safety information SRS airbag deployment conditions (front airbags) ■ The SRS front airbags will deploy in the event of an impact that exceeds ● the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 112 1-8. Safety information Conditions under which the SRS airbags may deploy (inflate), other ■ than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or ●...
Page 113 1-8. Safety information Types of collisions that may not deploy the SRS airbag ■ (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 114 1-8. Safety information When to contact your Toyota dealer ■ In the following cases, contact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 115 1-8. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts ● properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 116 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 117 1-8. Safety information CAUTION SRS airbag precautions ■ Do not sit on the edge of the seat or ● lean against the dashboard. Do not allow a child to stand in front of ● the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 118 1-8. Safety information CAUTION SRS airbag precautions ■ Do not attach anything to or lean any- ● thing against areas such as the dash- board, steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
Page 119 If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. Modification and disposal of SRS airbag system components ■...
Page 120 1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. Vehicles without navigation system Vehicles with navigation system SRS warning light...
Page 121 1-8. Safety information Conditions and operation of the front passenger occupant classification system Adult* ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger's seat belt reminder Flashing* light Front passenger airbag Side airbag on the front passenger seat Devices...
Page 122 1-8. Safety information Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ SRS warning light warning light Front passenger's seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Activated Curtain shield airbag in the front...
Page 123 1-8. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 150) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 124 1-8. Safety information CAUTION Front passenger occupant classification system precautions ■ Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger's seat belt tab has not been left inserted ●...
Page 125 Do not kick the front passenger seat or subject it to severe impact. Other- ● wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the ●...
Page 126 1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 127 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat...
Page 128 In an accident, the child can be crushed against the windshield, or between you and the vehicle's interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 129 1-8. Safety information CAUTION Child restraint precautions ■ Do not use the seat belt extender when installing a child restraint system ● on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 130 1-8. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 131 1-8. Safety information Second seat: Anchor brackets (for top tether strap) Anchor brackets are provided for the second seats.
Page 132 1-8. Safety information Installation with LATCH system Fold the seatback while pulling STEP the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 3rd lock position. (→P. 84) 1st lock position 3rd lock position Type A...
Page 133 1-8. Safety information Type B Latch the buckles onto the STEP LATCH anchors. The bars are installed in the clearance between the seat cush- ion and seatback. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchors.
Page 134 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 135 1-8. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 136 1-8. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 137 1-8. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap (second seat only) Secure the child restraint using STEP the seat belt or lower anchors, and adjust the head restraint to the upmost position.
Page 138 1-8. Safety information Outer seat: Open the anchor STEP bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Center seat: Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 139 1-8. Safety information CAUTION When installing a booster seat ■ Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 97) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 140 1-8. Safety information CAUTION When installing a child restraint system ■ When installing a child restraint system in the rear center seat, adjust both ● seat cushions to the same position and align seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 141 1-8. Safety information...
Page 142 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the hybrid system ■ →P. 177, 182 Driving ■ With the brake pedal depressed, shift the shift lever to D. STEP (→P. 188) Release the parking brake.
Page 143 ■ Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down.
Page 144 2-1. Driving procedures Operating your vehicle in a foreign country ■ Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (→P. 556) For efficient use ■ Put the shift lever into D when driving ●...
Page 145 If they do not work well, depress the brake pedal firmly. If the brake system warning light comes on, immediately stop your vehicle and contact your Toyota dealer. In the following conditions, you may hear a sound in the engine compart- ment.
Page 146 ● check that the back door is closed. Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately.
Page 147 2-1. Driving procedures CAUTION Do not under any circumstances shift the shift lever to P, R or N while the ● vehicle is moving. Doing so can cause significant damage to the transmission system and may result in a loss of vehicle control. Do not shift the shift lever to N while the vehicle is moving.
Page 148 2-1. Driving procedures CAUTION Sudden changes in braking force, such as engine braking and regenera- ● tive braking caused by shifting the shift lever to the B position, may cause the vehicle to skid, resulting in an accident. After driving through a puddle, lightly depress the brake pedal to make ●...
Page 149 2-1. Driving procedures CAUTION When the vehicle is parked ■ Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in ● the vehicle when it is in the sun. Doing so may result in the following. • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
Page 150 ● caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 151 If you hear a squealing or scraping noise (brake pad wear limit indica- ■ tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage can result if the pads are not replaced when needed.
Page 152 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function ● Changes in quantity and quality of oil and fluid used for the engine, hybrid ●...
Page 153 2-1. Driving procedures Power (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. Starting the hybrid system ■ Check that the parking brake is set. STEP Check that the shift lever is set in P.
Page 154 2-1. Driving procedures Changing “POWER” switch modes ■ Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 155 When the “POWER” switch indicator flashes in amber ■ The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. If the “READY” indicator does not come on ■ If the “READY” indicator does not come on when you press the “POWER”...
Page 156 2-1. Driving procedures When the electronic key battery is depleted ■ →P. 477 Conditions affecting operation ■ →P. 49 Note for the entry function ■ →P. 51 CAUTION When starting the hybrid system ■ Always start the hybrid system while sitting in the driver's seat. Do not depress the accelerator pedal while starting the hybrid system under any cir- cumstances.
Page 157 Do not leave the “POWER” switch in ACCESSORY or ON mode for long periods without the hybrid system on. When starting the hybrid system ■ Do not race a cold hybrid system. ● If the hybrid system becomes difficult to start, have the hybrid system ● checked immediately by your Toyota dealer.
Page 158 2-1. Driving procedures Engine (ignition) switch (vehicles without smart key system) Starting the hybrid system ■ Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the STEP...
Page 159 2-1. Driving procedures Changing engine switch position ■ “LOCK” The steering wheel is locked and the key can be removed. (The key can be removed only when the shift lever is in P.) “ACC” Some electrical components such as the audio system can be used.
Page 160 ■ If the “READY” indicator does not come on when you turn the engine switch with the shift lever in P and the brake pedal depressed, contact your Toyota dealer immediately. When the ambient temperature is low, such as during winter driving ■...
Page 161 2-1. Driving procedures CAUTION When starting the hybrid system ■ Always start the hybrid system while sitting in the driver's seat. Do not depress the accelerator while starting the hybrid system under any circum- stances. Doing so may cause an accident resulting in death or serious injury. Caution when driving ■...
Page 162 2-1. Driving procedures EV-Drive Mode In EV-Drive Mode the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. On/off When EV-Drive Mode is turned on, the EV-Drive Mode indica- tor will come on. Pressing the switch when in EV-Drive Mode will return to normal driving (using the gasoline engine and...
Page 163 2-1. Driving procedures Automatic cancelation of EV-Drive Mode ■ When driving in EV-Drive Mode, the gasoline engine may automatically restart in the following situations. When EV-Drive Mode is canceled, a buzzer will sound and the EV-Drive Mode indicator will flash and go off. The hybrid battery (traction battery) becomes low.
Page 164 2-1. Driving procedures Transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever ■ Vehicles without smart key system While the engine switch is in “ON” position, depress the brake pedal and move the shift lever. Vehicles with smart key system While the “POWER”...
Page 165 2-1. Driving procedures Shift position uses ■ Shift position Function Parking the vehicle or starting the hybrid system Reversing Neutral Normal driving Engine braking Selecting Eco drive mode ■ When the vehicle is driven in Eco drive mode, vehicle driving force and operation of the air conditioning system is controlled to improve fuel efficiency.
Page 166 2-1. Driving procedures When in heavy traffic ■ If the shift lever is in N, the hybrid battery (traction battery) will not be charged. To help prevent the battery from discharging, avoid putting the shift lever in N for an extended period of time. Eco drive mode ■...
Page 167 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 168 2-1. Driving procedures Parking brake Sets the parking brake* (Depressing the pedal again U.S.A. Canada releases the parking brake.) *: Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. Usage in winter time ■...
Page 169 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. After adjusting the steering wheel ■ Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 170 2-2. Instrument cluster Gauges and meters Vehicles without smart key system The following gauges and meters illuminate when the engine switch is in the “ON” position. Vehicles with smart key system The following gauges and meters illuminate when the “POWER” switch is in ON mode.
Page 171 2-2. Instrument cluster Odometer/Trip meter Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
Page 172 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel (vehicles without navigation system)
Page 173 2-2. Instrument cluster Center panel (vehicles with navigation system) Indicators ■ The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (→P. 191) (→P. 211) Headlight high beam Tail light indicator indicator (→P.
Page 174 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
Page 175 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
Page 176 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 177 2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the current outside temperature and clock. ● Outside temperature Indicates the outside tempera- ture. The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C).
Page 178: Trip Information
2-2. Instrument cluster ● Warning messages (→P. 521) Automatically displayed when a malfunction occurs in one of the vehicle’s systems. Trip information Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP” button. Energy monitor ■...
Page 179 2-2. Instrument cluster Average fuel consumption ■ Displays the average fuel consumption since the function was reset. This function can be reset by pressing the “DISP” button for longer than one second when the average fuel consumption is displayed. Driving distance ■...
Page 180 2-2. Instrument cluster Setting up the displays Display the set up screen on the STEP multi-information display when the vehicle is stopped. Press and hold the “DISP” button to display the set up screen. Select the desired item on the STEP menu screen.
Page 181 2-2. Instrument cluster Press the “DISP” button to adjust STEP the minutes. After adjusting the minutes, wait 5 seconds to allow the minutes to be automatically input. Setting the display ■ Select “DISPLAY” on the menu screen. Press and hold the STEP “DISP”...
Page 182 2-2. Instrument cluster ● Setting the brightness Select “BRIGHTNESS” on the menu screen. Press and hold STEP the “DISP” button until the display changes. Press the “DISP” button to adjust STEP the brightness. +: Brighter -: Darker After adjusting the brightness, wait 5 seconds to allow the bright- ness to be automatically input.
Page 183 2-2. Instrument cluster Setting the tire inflation pressure information display ■ It is possible to set the tire inflation pressure information display so that it is displayed when the hybrid system is first turned on. Select “TIRE MONITOR INFO.” on the menu screen. Press STEP and hold the “DISP”...
Page 184 2-2. Instrument cluster Setting up the rear view monitor display Display the set up screen on the STEP multi-information display when the vehicle is stopped and the rear view monitor is turned on. Press and hold the “DISP” button to display the set up screen. Select the desired item on the STEP menu screen.
Page 185 2-2. Instrument cluster Setting the contrast ■ Select “CONTRAST” on the menu screen. Press and hold the STEP “DISP” button until the display changes. Press the “DISP” button to adjust STEP the contrast. +: Strengthen -: Weaken After adjusting the contrast, wait 5 seconds to allow the contrast to be automatically input.
Page 186 When stopped, or driving at low speeds (less than 12 mph [20 km/h]), the correct outside temperature may not be displayed, or the display may take longer than normal to change. Customization that can be configured at Toyota dealer ■ Setting of language selection can be changed.
Page 187 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Type A The daytime running lights turn on. The side marker, park- ing, tail, license plate, daytime running lights and instrument panel lights turn on. U.S.A.
Page 188 2-3. Operating the lights and wipers Type B The headlights, park- ing lights and daytime running lights turn on and off automatically. (Vehicles without smart key system: When engine switch is turned to the “ON” position. Vehicles with smart key system: When the “POWER”...
Page 189 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 190 To turn the lights on again, turn the “POWER” switch to ON mode, or turn the light switch off and then back to Customization that can be configured at Toyota dealer ■ Settings (e.g. daytime running light system) can be changed.
Page 191 2-3. Operating the lights and wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on in low beam. Front fog lights on...
Page 192 2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency...
Page 193 2-3. Operating the lights and wipers Wash/wipe operation Wipers operate automatically. The windshield wipers and washer can be operated when ■ Vehicles without smart key system the “ON” position. The engine switch is in Vehicles with smart key system The “POWER” switch is in ON mode. If no windshield washer fluid sprays ■...
Page 194 2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The rear window wiper and washer can be operated when ■ Vehicles without smart key system the “ON”...
Page 195 2-4. Using other driving systems Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch Set the vehicle speed ■ STEP Press the “ON-OFF” button to activate the cruise control. Press the button once more to deactivate the cruise control.
Page 196 2-4. Using other driving systems Adjusting the speed setting ■ Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releasing it.
Page 197 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION To avoid operating the cruise control by mistake ■...
Page 198 2-4. Using other driving systems Rear view monitor system Vehicles with navigation system Refer to the “Navigation System Owner's Manual”. Vehicles without navigation system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
Page 199 2-4. Using other driving systems Displayed area ■ The area covered by the camera is lim- ited. Objects that are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 200 2-4. Using other driving systems Smear effect ■ If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect* char- acteristic to the camera may occur. *: Smear effect: A phenomenon that occurs when a bright light is picked up by the camera;...
Page 201 When washing the vehicle, do not apply intensive bursts of water to the ● camera or camera area. Doing so may result in the camera malfunction- ing. When replacing tires, please consult your Toyota dealer. If you replace the ● tires, the area displayed on the screen may change.
Page 202 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) ■...
Page 203 2-4. Using other driving systems When the VSC/TRAC systems are operating If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or the four wheels spin, the indicator flashes to indicate that the VSC/TRAC systems have been engaged.
Page 204 2-4. Using other driving systems Turning off TRAC and VSC ■ Push and hold the button while the vehicle is stopped to turn off TRAC and VSC. The “TRAC OFF” and VSC off indicator light should come on. Push the button again to turn the system back on.
Page 205 The sys- tem should return to normal within 10 minutes. If the slip indicator comes on... ■ It may indicate a malfunction in the VSC and TRAC. Contact your Toyota dealer. CAUTION The ABS does not operate effectively when ■...
Page 206 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension ■...
Page 207 2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 208 • The brake pedal has been depressed for more than approximately 3 minutes. If the slip indicator comes on... ■ It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION Hill-start assist control ■ Do not overly rely on hill-start assist control. Hill-start assist control may ●...
Page 209 2-5. Driving information Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity. Utility vehicle feature ● Specific design characteristics give it a higher center of gravity than ordinary passenger cars.
Page 210 2-5. Driving information CAUTION Utility vehicle precautions ■ Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die ●...
Page 211 2-5. Driving information Off-road driving Your vehicle is not designed to be driven off-road. However, in the event that off-road driving cannot be avoided, please observe the fol- lowing precautions to help avoid the areas prohibited to vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 212 2-5. Driving information CAUTION Off-road driving precautions ■ Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving ●...
Page 213 2-5. Driving information NOTICE To prevent water damage ■ Take all necessary safety measures to ensure that water damage to the hybrid battery, hybrid system or other components does not occur. Water entering the engine compartment may cause severe damage to the ●...
Page 214 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 215 2-5. Driving information (6)If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb.
Page 216 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compart- ment. Receptacles containing gasoline ● Aerosol cans ● Storage precautions ■ Do not place cargo or luggage in or on the following locations as the ●...
Page 217 ■ To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: Place the cargo so that its weight is ●...
Page 218 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. Total load capacity: 1200 lb. (544 kg) ■ Total load capacity means the combined weight of occupants, cargo and luggage. Seating capacity: 7 occupants (Front 2, Rear 5) ■...
Page 219 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations ■ ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 220 2-5. Driving information When driving the vehicle ■ Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle ■ Park the vehicle and move the shift lever to P without setting the parking brake.
Page 221 2-5. Driving information Tire chains ■ Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. ● Install tire chains on the front tires. ● Install tire chains following the instructions provided in the accompanying ●...
Page 222 NOTICE Repairing or replacing snow tires ■ Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 223 The vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional...
Page 224 2-5. Driving information Weight limits Confirm that the gross trailer weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits. Towing capacity: 3500 lb. (1500 kg) ● The gross trailer weight must never exceed towing capacity described in the table above.
Page 225 2-5. Driving information Towing related term Towing related term Meaning The maximum allowable gross vehicle weight. The gross vehicle weight is the total weight of the vehicle. When towing GVWR (Gross Vehicle a trailer, it is the sum of the vehicle Weight Rating) weight (including the occupants, cargo and any optional equipment installed on...
Page 226 2-5. Driving information Trailer tongue load ● A recommended tongue load varies in accordance with the types of trailers or towing as described below. ● In order to ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. The trailer cargo load should be distributed so that the tongue load is 9 to 11% of the gross trailer weight, not exceeding 350 lb.
Page 227 2-5. Driving information Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be rated for towing a higher weight, the operator must never exceed the maxi- mum weight rating specified for the trailer hitch. Connecting trailer lights Use the wire harness stored in the rear end underbody.
Page 228 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: ● Before starting out, check the trailer lights and the vehicle-trailer connections.
Page 229 2-5. Driving information ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway. Periodically check the rear to prepare for being passed by large trucks or buses, which may cause your vehicle and trailer to sway. If swaying occurs, firmly grip the steering wheel, reduce speed immediately but gradually, and steer straight ahead.
Page 230 Break-in schedule ■ Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
Page 231 2-5. Driving information Maintenance ■ If you tow a trailer, your vehicle will require more frequent maintenance ● due to the additional load. (See “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.) Retighten the fixing bolts of the towing ball and bracket after approxi- ●...
Page 232 2-5. Driving information CAUTION Hitches ■ If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight requirement. ● The towing capacity of 3500 lb. (1500 kg) can only be guaranteed when ●...
Page 233 NOTICE When installing a trailer hitch ■ Use only the position recommended by your Toyota dealer. Do not install ● the trailer hitch on the bumper as this may cause body damage. Do not use axle-mounted hitches, as they can cause damage to the axle ●...
Page 234 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with 4 wheels on the ground.
Page 235 2-5. Driving information...
Page 236 3-1. Using the air conditioning system and defogger ∗ Front manual air conditioning system Temperature control dial Fan speed control dial Outside air or recirculated air mode Air outlet selection dial Rear air conditioning Air conditioning on/off switch on/off switch Adjusting the settings Adjusting the temperature setting ■...
Page 237 3-1. Using the air conditioning system and defogger Adjusting the fan speed ■ Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Turn the dial to “OFF” to turn the fan off. Changing the air outlets ■ Set the air outlet selection dial to an appropriate position.
Page 238 3-1. Using the air conditioning system and defogger Feet Feet and windshield...
Page 239 3-1. Using the air conditioning system and defogger Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time is pressed. Defogging the windshield Set the air outlet selection dial to position.
Page 240 3-1. Using the air conditioning system and defogger Front side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Using the system in recirculated air mode ■ The windows will fog up more easily if the recirculated air mode is used for an extended period.
Page 241 3-1. Using the air conditioning system and defogger When outside air temperature approaches 32°F (0°C) ■ The air conditioning system may not operate even when is pressed. When is selected for the air outlets used ■ For your driving comfort, air flowing to the feet may be warmer than air flow- ing to the upper body depending on the position of the temperature adjust- ment dial.
Page 242 3-1. Using the air conditioning system and defogger ∗ Front automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Control panel Rear air conditioning Temperature control on/off switch for rear passengers Fan speed Windshield defogger Outside air or recirculated...
Page 243 3-1. Using the air conditioning system and defogger Multi-information display Airflow display Fan speed display Driver’s side Front passenger’s side tem- temperature Temperature setting dis- perature setting display setting dis- play for rear passengers play...
Page 244 3-1. Using the air conditioning system and defogger Using the automatic mode Press STEP The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. “AUTO” will be displayed on the multi-information display. Turn the temperature control dial clockwise (warm) or coun- STEP terclockwise (cool).
Page 245 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting ■ Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). The air conditioning system switches between individual and simultaneous modes each time is pressed. Simultaneous mode: Only the driver’s side temperature control dial can be used to adjust the temperature for all seats.
Page 246 3-1. Using the air conditioning system and defogger Changing the air outlets ■ Press The air outlets switch each time either side of is pressed. The air flow shown on the display indicates the following. Upper body Upper body and feet Feet...
Page 247 3-1. Using the air conditioning system and defogger Feet and windshield Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time is pressed.
Page 248 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system oper- ates automatically. Adjusting the position of and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down.
Page 249 3-1. Using the air conditioning system and defogger Using the automatic mode ■ Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. Immediately after the switch is pressed, the fan may stop for a while until ●...
Page 250 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 251 3-1. Using the air conditioning system and defogger ∗ Rear manual air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Changes the air outlets used Fan speed control dial Temperature control dial ∗ : If equipped...
Page 252 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting ■ Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). Changing the air outlets ■ Press the desired Air flows as shown below according to the mode selected. Upper body Upper body and feet...
Page 253 3-1. Using the air conditioning system and defogger Feet Adjusting the fan speed ■ Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Adjusting the position of and opening and closing the air outlets Direct air flow to the left or right, up or down.
Page 254 3-1. Using the air conditioning system and defogger ∗ Rear automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Temperature setting display Temperature Fan speed control dial control dial Changes the air Automatic mode outlets used...
Page 255 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting ■ Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). Changing the air outlets ■ Press The air outlets change as follows each time is pressed.
Page 256 3-1. Using the air conditioning system and defogger Feet Adjusting the fan speed ■ Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Press to turn the fan off. Adjusting the position of and opening and closing the roof side air outlets Direct air flow to the left or right, up or down.
Page 257 3-1. Using the air conditioning system and defogger When driving in Eco drive mode ■ Operation of the air conditioning system is controlled when in Eco drive mode. Turning off Eco drive mode enhances comfort. NOTICE To prevent 12-volt battery from being discharged ■...
Page 258 3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. Vehicles with manual air conditioning system On/off Press the button to turn on the rear window defogger. The indicator light will come on.
Page 259 3-1. Using the air conditioning system and defogger The defogger can be operated when ■ Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “POWER” switch is in ON mode. Outside rear view mirror defoggers (vehicles with outside rear view ■...
Page 260 3-1. Using the air conditioning system and defogger ∗ Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off Press the button to turn on the windshield wiper de-icer. The indicator light will come on.
Page 261 3-1. Using the air conditioning system and defogger ∗ Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Automatic mode Using the automatic mode Press STEP The air conditioning system will operate, and air outlets and fan speed will be set automatically.
Page 262 3-2. Using the audio system Audio system types With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system Type A: CD player and AM/FM radio (with CD changer controller)
Page 263: Table Of Contents
3-2. Using the audio system Type B: CD player with changer and AM/FM radio Title Page Using the radio P. 292 Using the CD player P. 299 Playing back MP3 and WMA discs P. 306 Operating an iPod P. 313 Operating a USB memory P.
Page 264 3-2. Using the audio system Language settings The language used for all voice guidance, voice recognition and mes- sages may be changed. Press STEP Press (MORE). STEP Press (LANG). STEP Press that corresponds to the desired language. STEP For vehicles sold in the U.S.A. “ENG”...
Page 265 3-2. Using the audio system CAUTION For vehicles sold in U.S.A. and Canada ■ Part 15 of the FCC Rules ● FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. Laser products ●...
Page 266: Using The Radio
3-2. Using the audio system Using the radio Adjusting the frequency Power Volume Scanning for (AM, FM mode) or receivable stations channel (SAT mode) Displaying radio Station selector text messages Changing the channel category AM/FM/SAT Seeking a frequency mode button Setting preset buttons Mute ®...
Page 267 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) Scanning the preset radio stations ■ Press and hold until you hear a beep. STEP Preset stations will be played for 5 seconds each. When the desired station is reached, press once again.
Page 268 3-2. Using the audio system ® Satellite Radio ® Receiving XM Satellite Radio ■ Press STEP The display changes as follows each time is pressed. AM → FM → SAT Turn to select the desired channel in all the categories, STEP or press “∧”...
Page 269 3-2. Using the audio system Displaying text information ■ Press Each time is pressed, the display changes in the following order: Title (song/program title) → Name (artist name/feature)/Title (song/pro- gram title). Silencing a sound Press...
Page 270 3-2. Using the audio system Reception sensitivity ■ Cargo loaded on the roof luggage carrier, especially metal objects, may ● ® adversely affect the reception of XM Satellite Radio. Maintaining perfect radio reception at all times is difficult due to the con- ●...
Page 271 ANTENNA securely. CHECK There is a short-circuit in the antenna or the sur- ANTENNA rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
Page 272 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to CHANNEL NOT the previous channel or “CH001”. If it does not AVAILABLE change automatically, select another channel. ®...
Page 273: Using The Cd Player
3-2. Using the audio system Using the CD player Selecting a track Power Volume Searching Displaying text messages playback CD load CD eject Selector buttons (type B only) Selecting a track/ fast-forwarding Playback Playback/pause and rewinding Loading CDs Loading a CD ■...
Page 274 3-2. Using the audio system Loading multiple CDs (type B only) ■ Press and hold until you hear a beep. STEP When the indicator on the slot turns from amber to green, STEP insert a CD. The indicator on the slot turns to amber when the CD is inserted. When the indicator on the slot turns from amber to green STEP again, insert the next CD.
Page 275 3-2. Using the audio system Fast-forwarding and reversing tracks ∧ To fast-forward or reverse, press and hold “ ” or “∨” on Scanning tracks Press STEP The first ten seconds of each track will be played. To cancel, press again. Press again when the desired track is reached.
Page 276: Random Playback
3-2. Using the audio system Random playback Current CD ■ Press (RDM). Songs are played in random order. To cancel, press the button once more (type A without a CD changer), or twice more (type A with a CD changer and type B). All CDs (with a CD changer) ■...
Page 277 “WAIT” or “PLEASE WAIT”: Operation has stopped due to a high tempera- ture inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. Discs that can be used ■...
Page 278 3-2. Using the audio system Lens cleaners ■ Do not use lens cleaners. Doing so may damage the CD player. NOTICE CDs and adapters that cannot be used ■ Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc.
Page 279 3-2. Using the audio system NOTICE CDs with a transparent or translucent ● recording area CDs that have had tape, stickers or CD- ● R labels attached to them, or that have had the label peeled off CD player precautions ■...
Page 280: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Selecting a file Power Volume Displaying text Searching playback messages CD load Selector buttons CD eject (type B only) Selecting a folder and file Selecting a file/ fast-forwarding Playback/pause and rewinding Playback Loading and ejecting MP3 and WMA discs...
Page 281 3-2. Using the audio system Scanning the first file of all the folders ■ Press and hold until you hear a beep. STEP The first ten seconds of the first file in each folder will be played. When the desired folder is reached, press again.
Page 282 3-2. Using the audio system Random playback Playing files from a particular folder in random order ■ Press (RDM). To cancel, press the button once more (type A without a CD changer), or twice more (type A with a CD changer and type B). Playing all of the files on a disc in random order ■...
Page 283 “WAIT” or “PLEASE WAIT”: Operation has stopped due to a high tempera- ture inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played. Discs that can be used ■...
Page 284 3-2. Using the audio system MP3 and WMA files ■ MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. ® WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 285 3-2. Using the audio system Compatible disc formats ● The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 286 3-2. Using the audio system Extensions ● If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 287: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod ■ Open the cover and connect an iPod using an iPod cable. STEP Turn on the power of the iPod if it is not turned on. Vehicles without seat heater Vehicles with seat heater...
Page 288 3-2. Using the audio system Press STEP Control panel ■ Power Volume Selector knob Displaying text messages Selector buttons Selecting a track/ Playback/pause fast-forwarding and rewinding Playback...
Page 289 3-2. Using the audio system Selecting a play mode Press (BROWSE) to select iPod menu mode. STEP Press that corresponds to the desired play mode. STEP Pressing (MORE) to change to the second selection list. Play mode list ■ First Second Third Fourth...
Page 290 3-2. Using the audio system Selecting a list ■ Turn to display the first selection list. STEP Press to select the desired item. STEP Repeat the same procedure to select the desired song name. STEP To return to the previous selection list, press Selecting songs from a song list Press (LIST).
Page 291 3-2. Using the audio system Selecting songs Turn or press “∧” or “∨” on to select the desired song. Playing and pausing songs Press Fast-forwarding and rewinding songs ∧ Press and hold “ ” or “∨” on Shuffle playback Playing songs from one playlist or album in random order ■...
Page 292 3-2. Using the audio system Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time About iPod ■ Apple is not responsible for the operation of this device or its compliance ●...
Page 293 3-2. Using the audio system Compatible models ■ Model Generation Software version iPod 5th generation Ver. 1.2.0 or higher iPod nano 1st generation Ver. 1.3.0 or higher 2nd generation Ver. 1.1.2 or higher 3rd generation Ver. 1.0.0 or higher iPod touch 1st generation Ver.
Page 294: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory ■ Open the cover and connect a USB memory. STEP Turn on the power of the USB memory if it is not turned on. Vehicles without seat heater Vehicles with seat heater...
Page 295 3-2. Using the audio system Press STEP Control panel ■ Power Volume Selector knob Displaying text Searching messages playback Selector buttons Selecting a Selecting a track/ folder and file fast-forwarding Playback/pause and rewinding Playback...
Page 296 3-2. Using the audio system Selecting and scanning a folder Selecting a folder ■ Press “∧” or “∨” on to select the desired folder. Returning to the first file of the first folder ■ Press and hold “∨” on until you hear a beep. Scanning the first file of all the folders ■...
Page 297 3-2. Using the audio system Fast-forwarding and rewinding files ∧ Press and hold “ ” or “∨” on Random playback Playing files from a folder in random order ■ Press (RDM). To cancel, press the button twice. Playing all the files from a USB memory in random order ■...
Page 298 3-2. Using the audio system USB memory functions ■ Depending on the USB memory that is connected to the system, certain functions may not be available. Disconnecting the device and reconnecting it once again may resolve some malfunctions. Error messages ■...
Page 299 3-2. Using the audio system MP3 and WMA files ● MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. ® WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 300 3-2. Using the audio system ID3 and WMA tags ● ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 301 3-2. Using the audio system NOTICE To prevent damage to the USB memory ■ Do not leave the USB memory in the vehicle. The temperature inside may ● become high, resulting in damage to the player. Do not push down on or apply unnecessary pressure to the USB memory ●...
Page 302: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Adjusting the sound quality and ASL Selector buttons Menu button Using the audio control function Changing sound quality modes ■ Press STEP Press that corresponds to the desired mode. STEP “BASS”, “MID”...
Page 303 3-2. Using the audio system Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right BASS Bass* -5 to 5 Mid-range* -5 to 5 High (type B only) TREB Treble* -5 to 5 Front/rear Shifts to FADE volume F7 to R7...
Page 304 3-2. Using the audio system Setting the number of preset pages ■ The number of preset pages desired can be set from 1 to 6. The initial setting is 6 pages. Press STEP Press (MORE). STEP Press (PRESET). STEP Press that corresponds to the desired number of pre- STEP set pages.
Page 305: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect the portable audio device. STEP Vehicles without seat heater Vehicles with seat heater Press STEP...
Page 306 3-2. Using the audio system Operating portable audio devices connected to the audio system ■ The volume can be adjusted using the vehicle's audio controls. All other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet ■...
Page 307: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio mode: Selects radio stations CD mode: Selects tracks, files (MP3 and WMA) and discs (type C only) iPod mode: Selects songs USB memory mode: Selects files and fold-...
Page 308 3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time is pressed. FM→SAT→CD (type A only)→CD changer (with a CD changer) ® →Bluetooth Audio→AUX→USB/iPod→AM Adjusting the volume Press “+”...
Page 309 3-2. Using the audio system Selecting a disc in the CD player (CD player with changer only) Press to select CD mode. STEP Press and hold “∧” or “∨” on until you hear a beep. STEP CAUTION To reduce the risk of an accident ■...
Page 310 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 311 ® 3-3. Using the Bluetooth audio system When transferring ownership of the vehicle ■ Be sure to initialize the system to prevent personal data from being improp- erly accessed. (→P. 376) ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG.
Page 312 ® 3-3. Using the Bluetooth audio system CAUTION FCC WARNING ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
Page 313 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system Audio unit ■ Display Track title, Artist name, Album name, Elapsed time, “Streaming Audio”, etc. is displayed. Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item Bluetooth-Audio...
Page 314 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate Operation procedure when using voice commands ■...
Page 315 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press and hold until “BT AUDIO”...
Page 316: Audio System
® 3-3. Using the Bluetooth audio system Input the passkey into the portable player. STEP Refer to the manual that comes with the portable player for the oper- ation of the portable player. Guidance for registration completion is heard. ® If the portable player has a Bluetooth phone, the phone can be reg- istered at the same time.
Page 317 ® 3-3. Using the Bluetooth audio system When using a voice command ■ For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. Situations that the system may not recognize your voice ■...
Page 318 ® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Selector knob Displaying text messages Fast-forwarding Selecting tracks and reversing Playback/pause Playback Selecting an album Press “∨” or “∧” on Selecting tracks Press “∧” or “∨” on Playing and pausing tracks Press...
Page 319 ® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time Using the steering wheel audio switches →P.
Page 320 ® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: Functions and operation procedures ■...
Page 321 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Players (Pair audio player)” using a voice com- mand or , and perform the procedure for registering a portable player. (→P. 341) Selecting a portable player to be used Select “Select Audio Player”...
Page 322 ® 3-3. Using the Bluetooth audio system Press the talk switch and say “From car” or “From audio”, and STEP select “Confirm” using a voice command or Vehicles with smart key system: If “From car” is selected, the porta- ble player will be automatically connected whenever the “POWER” switch is in either ACCESSORY or ON mode.
Page 323 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players” using a voice command or . The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT Audio Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 324 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player” using a voice command or STEP Select the portable player to be deleted by either of the follow- STEP ing methods and select “Confirm” using a voice command or a.
Page 325 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup System setup items and operation procedures ■ →P. 374...
Page 326 3-4. Using the hands-free phone system (for cellular phone) Hands-free phone system (for cellular phone) features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone. Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”.
Page 327 3-4. Using the hands-free phone system (for cellular phone) Title Page Using the hands-free phone system ■ Operating the system using a voice command ■ Using the hands-free phone system for P. 356 the first time ■ Menu list of the hands-free phone system Making a phone call ■...
Page 328 3-4. Using the hands-free phone system (for cellular phone) Conditions under which the system will not operate ■ ® If using a cellular phone that does not support Bluetooth ● If the cellular phone is switched off ● If you are outside service range ●...
Page 329 3-4. Using the hands-free phone system (for cellular phone) CAUTION FCC WARNING ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
Page 330 3-4. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system Audio unit ■ Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters, such as an umlaut, cannot be dis- played. Selects speed dials Selects items such as menu or number...
Page 331 3-4. Using the hands-free phone system (for cellular phone) Steering wheel telephone switches ■ Volume The voice guidance volume cannot be adjusted by using this switch. On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Off-hook switch Turns the hands-free sys- tem on/starts a call Talk switch...
Page 332 3-4. Using the hands-free phone system (for cellular phone) Operating the system using a voice command By following voice guidance instructions output from the speaker, voice commands enable the operation of the hands-free phone sys- tem without the need to check the display or operate Operation procedure when using a voice command ■...
Page 333 3-4. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 334 3-4. Using the hands-free phone system (for cellular phone) Registration to the hands-free phone system only Select “Phone Only” using a voice command or STEP ® Registration to the hands-free phone system and Bluetooth audio system at the same time Select “Int.
Page 335 3-4. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Normal operation ■ Second First menu Third menu Operation detail menu CallBack Dialing a number stored in (Call the incoming call history back) memory Dialing a number stored in Redial the outgoing call history...
Page 336 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock (Phone book Locking the phone book Security lock) Phonebook Unlock (Phone Unlocking the phone book book unlock) Registering the cellular Pair Phone...
Page 337 3-4. Using the hands-free phone system (for cellular phone) Using a short cut key ■ First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Dial “XXX (number)” Dialing the input numbers Phone book add Adding a new number entry Changing the name of a...
Page 338 3-4. Using the hands-free phone system (for cellular phone) Automatic volume adjustment ■ When vehicle speed reaches 50 mph (80 km/h) or more, the volume auto- matically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command ■...
Page 339 3-4. Using the hands-free phone system (for cellular phone) Making a phone call Making a phone call ■ ● Dialing by inputting a number “Dial by Number” ● Dialing by inputting a name “Dial by Name (Dial by name)” ● Speed dialing ●...
Page 340 3-4. Using the hands-free phone system (for cellular phone) Dial by one of the following methods: STEP a. Press the off-hook switch. b. Press the talk switch and say “Dial”. c. Select “Dial” using Dialing by inputting a name Press the talk switch and say “Dial by name”. STEP Select a registered name to be input by either of the following STEP...
Page 341 3-4. Using the hands-free phone system (for cellular phone) When receiving a phone call Answering a phone call ■ Press the off-hook switch. Refusing a phone call ■ Press the on-hook switch. Transferring a phone call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call.
Page 342 3-4. Using the hands-free phone system (for cellular phone) Select the number by either of the following methods: STEP a. Say “Previous” or “Go back” until the desired number is dis- played. b. Select the desired number using The following operations can be performed: Dialing: Press the off-hook switch or select “Dial”...
Page 343 3-4. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following function can be used for regis- tered cellular phones: Functions and operation procedures ■...
Page 344 3-4. Using the hands-free phone system (for cellular phone) Selecting a cellular phone to be used Select “Select Phone” using a voice command or STEP Pattern A Select a cellular phone to be used by either of the following STEP methods, and select “Confirm”...
Page 345 3-4. Using the hands-free phone system (for cellular phone) Press the talk switch or select “Record Name” using STEP and say a new name. Select “Confirm” using a voice command or STEP Listing the registered cellular phones Selecting “List Phones” using a voice command or causes the list of registered cellular phones to be read aloud.
Page 346 3-4. Using the hands-free phone system (for cellular phone) Deleting a cellular phone Select “Delete Phone” using a voice command or STEP Select a cellular phone to be deleted by either of the following STEP methods and select “Confirm” using a voice command or a.
Page 347 3-4. Using the hands-free phone system (for cellular phone) Turning the hands-free phone automatic connection on/off Turning off the automatic connection ■ Select “Handsfree Power” using a voice command or STEP Select “Turn off” using a voice command or STEP Turning on the automatic connection ■...
Page 348 3-4. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedures ■ ● Setting or changing the PIN (Personal Identification Number) 1.
Page 349 3-4. Using the hands-free phone system (for cellular phone) Changing the PIN ■ Select “Set PIN” using a voice command or STEP Enter the registered PIN using a voice command or STEP Enter a new PIN using a voice command or STEP When using , input the code 1 digit at a time.
Page 350 3-4. Using the hands-free phone system (for cellular phone) Setting voice guidance volume Select “Guidance Volume” using STEP Change the voice guidance volume. STEP To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization Select “Reset Settings” and then “Confirm” using STEP Select “Confirm”...
Page 351 3-4. Using the hands-free phone system (for cellular phone) Initialization ■ The following data in the system can be initialized: ● • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code Once the initialization has been completed, the data cannot be restored ●...
Page 352 3-4. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dials 1.
Page 353 3-4. Using the hands-free phone system (for cellular phone) Use one of the following methods to input a telephone num- STEP ber: Inputting a telephone number using a voice command STEP2-1 Select “By Voice (By voice)” using a voice command STEP2-2 Press the talk switch, say the desired number, and select “Confirm”...
Page 354 3-4. Using the hands-free phone system (for cellular phone) Inputting a phone number using STEP2-1 Select “Manual Input” using STEP2-2 Input a phone number using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
Page 355 3-4. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following STEP methods, and select “Confirm” using a voice command or a. Press the talk switch and say the desired name. b.
Page 356 3-4. Using the hands-free phone system (for cellular phone) Select a desired preset button, and register the data into STEP speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” using a voice command or b.
Page 357 3-4. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” using a voice command or STEP Select data to be deleted by either of the following methods, STEP and select “Confirm” using a voice command or a.
Page 358 3-4. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will be available.
Page 359 3-5. Using the interior lights Interior lights list Your Toyota is equipped with an illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off accord-...
Page 360 3-5. Using the interior lights Personal/interior light main switch and personal/interior lights Personal/interior light main switch “OFF” The personal/interior lights and interior light can be individually turned on or off. Door position The personal/interior lights and interior light come on when a door or the glass hatch (if equipped) is opened.
Page 361: Interior Light
If the lights remain on when the door is not fully closed and the personal/inte- rior light main switch is in the door position, the lights will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer ■ Settings (e.g. The time elapsed before lights turn off) can be changed.
Page 362 3-6. Using the storage features List of storage features Auxiliary boxes Overhead console Glove box Bottle holders Cup holders Side table Console box...
Page 363 3-6. Using the storage features Glove box CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact ●...
Page 364 3-6. Using the storage features Console box Console box Upper Pull up the knob to release the lock. Lift the lid. Lower Push down the lever. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 365: Overhead Console
3-6. Using the storage features Overhead console Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Press in the lid. CAUTION Caution while driving ■ Do not leave the overhead console open while driving. Items stored in it may fall out and cause injury.
Page 366 3-6. Using the storage features Cup holders Cup holders Front (type A) Front (type B) Lift the lid. Console box Pull out the cup holder.
Page 367 3-6. Using the storage features Cup holders Side table Install the side table before using the cup holder. (→P. 399) Removing the adapters changes the size. (→P. 394) Rear Removing the adapters changes the size. (→P. 394)
Page 368 3-6. Using the storage features Cup holders Adjusting size of the cup holders (front [type B], side table and rear) ■ Front (type B) Remove the separator. The separator may be removed for clean- ing. Side table Remove the adapter. Rear Remove the adapter.
Page 369 3-6. Using the storage features Cup holders CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or beverage cans in the cup holders. Even when the lid is closed, items must not be stored in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 370: Bottle Holders
3-6. Using the storage features Bottle holders Bottle holders Front Rear CAUTION Items unsuitable for the bottle holder ■ Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 371: Auxiliary Boxes
3-6. Using the storage features Auxiliary boxes Auxiliary boxes Type A Pull up the lever. Type B (if equipped) Lift the lid.
Page 372 3-6. Using the storage features Auxiliary boxes Type C Lift the lid. Auxiliary box (type C) ■ The side table can be installed. (→P. 399) CAUTION Caution while driving ■ Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking.
Page 373 3-6. Using the storage features Side table Side table Installing the side table ■ Take out the side table from the STEP console box. Remove the second center seat. (→P. 88) STEP Engage the front pins of the STEP side table with the hooks. Push down on the side table to engage the rear pin locks.
Page 374 3-6. Using the storage features Side table Pull the lock release lever to STEP remove the side table. Stow the side table in the con- STEP sole box. Push down on the end to engage STEP the pins in the holes and close the console box door.
Page 375 3-7. Other interior features Sun visors Forward position Flip down. Side position Flip down, unhook, and swing to the side. Side extender Place in side position then slide backwards.
Page 376 3-7. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened. NOTICE To prevent the 12-volt battery from being discharged ■ Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
Page 377 3-7. Other interior features Conversation mirror Press in the lid. Push the lid back up half way. To use the overhead console from the conversation mirror state ■ Fully close the lid, then open it again. (→P. 391)
Page 378 3-7. Other interior features Power outlet The power outlet can be used for the following components. 12 V: Accessories that run on less than 10 A. 120 VAC: Accessories that use less than 100 W. 12 V ■ Type A* Type B*...
Page 379 3-7. Other interior features Type C Type D 120 VAC* ■ : Vehicles with seat heater : Vehicles without seat heater : Vehicles with rear entertainment system...
Page 380 3-7. Other interior features The power outlet can be used when ■ 12 V Vehicles without smart key system: The engine switch is in the “ACC” or “ON” position. Vehicles with smart key system: The “POWER” switch is in ACCESSORY or ON mode. 120 VAC Vehicles without smart key system: The engine switch is in the “ON”...
Page 381 3-7. Other interior features NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent the fuse from being blown ■...
Page 382 3-7. Other interior features ∗ Seat heaters Pops the knob out Driver's seat The indicator light comes on. Adjusts the seat tempera- ture The further you turn the knob Front passenger's seat clockwise, the warmer the seat becomes. The seat heaters can be used when ■...
Page 383 3-7. Other interior features CAUTION Burns ■ Use caution when seating the following persons in a seat with the seat ● heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled •...
Page 384 3-7. Other interior features Armrests Pull the armrest down for use. NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest.
Page 385 ■ Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver's seat. ● Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 386 3-7. Other interior features Luggage compartment features Cargo hooks ■ Cargo hooks are provided for securing loose items. Grocery bag hooks ■ Auxiliary box ■ Lift the center deck board.
Page 387 3-7. Other interior features Separating the luggage compartment ■ The center deck board can be used to separate the luggage compartment. Remove center deck board and insert it upright into the groove. The board cannot be inserted when the luggage cover is stowed.
Page 388 3-7. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 389 3-7. Other interior features Press and hold down one of the STEP ® buttons on the HomeLink the button on the transmitter. When the indicator light on the ® HomeLink changes from a slow to a rapid flash within 20 sec- onds, you can release both but- tons.
Page 390 3-7. Other interior features Programming a Rolling Code system (for U.S.A. owners) ■ If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the learn button on the ceiling mounted garage door STEP opener motor.
Page 391 ® the remaining HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 392 3-7. Other interior features Before programming ■ Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ● ® HomeLink Certification for the garage door opener ■ For vehicles sold in the U.S.A. FCC ID: CB2300NHL3 FCC ID: CB2281AHL4 NOTE:...
Page 393 3-7. Other interior features CAUTION When programming a garage door or other remote control device ■ The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm. Conforming to federal safety standards ■...
Page 394 3-7. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation ■ To turn the compass on or off, press “AUTO”. Displays and directions ■ Display Direction North Northeast East...
Page 395 3-7. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 396 3-7. Other interior features Circling calibration ■ When C appears on the display, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 397 3-7. Other interior features NOTICE To avoid compass malfunctions ■ Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass ■...
Page 398 3-7. Other interior features...
Page 399 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 400 4-1. Maintenance and care Aluminum wheels ■ Remove any dirt immediately by using a neutral detergent. Do not use ● hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. Do not use detergent on the wheels when they are hot, for example after ●...
Page 401 If the windshield washer nozzle become blocked ■ Contact your Toyota dealer. Do not try to clear it with a pin or other object. This may damage the nozzle. Cleaning the exterior lights ■...
Page 402 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: Protecting the vehicle interior ■ Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 403 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 404 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use organic substances such as benzene or gasoline, acidic or ● alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Do not use polish wax or polish cleaner.
Page 405: Scheduled Maintenance
It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 406 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer ■ Toyota technicians are well-trained specialists and are kept up to date ● with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 407 “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 408: Vehicle Interior
4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Transmission “Park” mechanism on an incline with the shift lever in • Moves smoothly? • Does it have appropriate clear- Brake pedal ance and correct amount of free play?
Page 409: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Door • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
Page 410 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test: ■...
Page 411 (→P. 457) • Conventional wrench (for terminal clamp bolts) ⎯ Brake fluid level (→P. 455) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 412 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 480) as original Radiator and condenser ⎯ (→P. 454) • Tire pressure gauge Tire inflation pressure (→P. 469) • Compressed air source • Water washer fluid containing Washer fluid (→P.
Page 413 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment ■ Vehicles without smart key system: Make sure that the engine switch is in ●...
Page 414 4-3. Do-it-yourself maintenance CAUTION Do not touch the engine compartment when the electric cooling fans are ● operating. Vehicles without smart key system: The electric cooling fan may keep rotating for about 3 minutes even after the engine switch is turned to the “LOCK”...
Page 415 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into either of the slots.
Page 416 4-3. Do-it-yourself maintenance CAUTION Pre-driving check ■ Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. After installing the support rod into the slot ■...
Page 417 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front ■ Rear ■...
Page 418 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle ■ Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack ● such as the one shown in the illustra- tion.
Page 419 4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 456) Power control unit coolant reservoir (→P. 452) Brake fluid reservoir (→P. 455) Fuse boxes (→P. 480) Engine oil filler cap Power control unit coolant (→P. 449) radiator (→P. 454) Engine oil level dipstick Electric cooling fans (→P.
Page 420 4-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■...
Page 421 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After turning off the hybrid STEP system, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 422: Adding Engine Oil
4-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 423 ● not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 424 4-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage ■ Check the oil level on a regular basis. When replacing the engine oil ■ Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, or the engine could be damaged. ●...
Page 425 If the coolant level drops within a short time after replenishing ■ Visually check the radiator, hoses, coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection ■...
Page 426 4-3. Do-it-yourself maintenance CAUTION When the hybrid system is hot ■ Do not remove the coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing burns or other injuries. NOTICE When adding coolant ■...
Page 427 Check the radiators and condenser, and clear away any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the hybrid system is hot ■...
Page 428: Brake Fluid
“MAX” and “MIN” lines on the tank. If the level is low, take your vehi- cle to a Toyota dealer as soon as possible. Do not drive your vehi- cle if the red brake system warn- ing light is on. Call a Toyota dealer for assistance.
Page 429: Washer Fluid
4-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations. ● Any washer does not work. ● The warning message appears on the multi-informa- tion display. (→P. 521) CAUTION When adding washer fluid ■ Do not add the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 430 4-3. Do-it-yourself maintenance 12-volt battery Location ■ The 12-volt battery is located on the left-hand side of the luggage compartment. Removing the 12-volt battery cover ■ Remove center deck STEP board. Remove the 12-volt battery STEP cover.
Page 431 With the shift lever in P and the “POWER” switch OFF, open and close ● the driver’s door, then attempt to start the hybrid system. If the system will not start even after multiple attempts at both methods, con- tact your Toyota dealer.
Page 432 4-3. Do-it-yourself maintenance CAUTION Chemicals in the 12-volt battery ■ The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: Do not cause sparks by touching the 12-volt battery terminals with tools.
Page 433 4-3. Do-it-yourself maintenance NOTICE When recharging the 12-volt battery ■ Never recharge the 12-volt battery while the hybrid system is operating. Also, be sure all accessories are turned off.
Page 434 Tire rotation ■ Vehicles without compact spare tire Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota rec- ommends that tire rotation is Front carried out at the same inter- val as tire inspection.
Page 435 The tire pressure warning system ■ Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 515, 521) Vehicles with compact spare tire: The compact spare tire is not equipped with the tire pressure warning valve and transmitters.
Page 436 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 463) Registering ID codes The tire pressure warning valve and transmitter is equipped with a unique ID code.
Page 437 A tire goes flat repeatedly or cannot be properly repaired due to the ● size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 438 4-3. Do-it-yourself maintenance Tire types ■ 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 439 4-3. Do-it-yourself maintenance Tire pressure warning system certification ■ For vehicles sold in the U.S.A. FCC ID: PAXPMV107J FCC ID: HYQ13BCX NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 440 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply ●...
Page 441 When removing or fitting the wheels, tires or the tire pressure warning ● valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
Page 442 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure ■ The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 571) Inspection and adjustment procedure ■ Tire valve Tire pressure gauge Remove the tire valve cap.
Page 443 ● Reduced safety ● Damage to the drive train ● If a tire needs frequent reinflating, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 444 4-3. Do-it-yourself maintenance Always use a tire pressure gauge. ● The appearance of the tire can be misleading. In addition, tire infla- tion pressures that are even just a few pounds off can degrade ride and handling. Do not bleed or reduce tire inflation pressure after driving. It is normal ●...
Page 445 ● Bent wheels that have been straightened Aluminum wheel precautions ■ ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 446 Because tire repair or replacement may affect the tire pressure warn- ● ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 447 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method ■ Vehicles without smart key system: Turn the engine switch STEP OFF. Vehicles with smart key system: Turn the “POWER” switch OFF.
Page 448 4-3. Do-it-yourself maintenance Remove the filter cover. STEP Replacement method ■ Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. Checking interval ■ Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 449 4-3. Do-it-yourself maintenance NOTICE When using the air conditioning system ■ Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system.
Page 450 4-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is discharged. You will need the following items: ■ ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
Page 451 4-3. Do-it-yourself maintenance Replacing the battery (vehicles with smart key system) ■ Take out the mechanical key. STEP Remove the cover. STEP Remove the depleted battery. STEP Insert a new battery with the “+” terminal facing up.
Page 452 Use a CR2032 (vehicles without smart key system) or CR1632 (vehicles ■ with smart key system) lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera ● stores. Replace only with the same or equivalent type recommended by your ●...
Page 453 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Vehicles without smart key system: Turn the engine switch STEP OFF.
Page 454 4-3. Do-it-yourself maintenance Engine compartment (type C) Push the tab in and lift the lid off. Under the instrument panel Remove the lid. Luggage compartment Remove the terminal cover. After a system failure, see “Fuse layout and amperage rat- STEP ings”...
Page 455 4-3. Do-it-yourself maintenance Remove the fuse with the pull- STEP out tool. Check if the fuse has blown. STEP Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
Page 456 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer.
Page 457: Engine Compartment
4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ Type A (fuse block on the back of the cover) Type A (fuse block) Fuse Ampere Circuit SPARE 7.5 A Spare fuse SPARE 15 A Spare fuse SPARE 30 A Spare fuse...
Page 458 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 50 A Air conditioning system FAN No.1 50 A Electric cooling fan FAN No.2 50 A Electric cooling fan ABS NO.1 50 A Brake system RR CLR 40 A Air conditioning system SPARE 40 A Spare fuse RR DEF 30 A...
Page 459 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 10 A Starting system 30 A INJ, GAUGE NO.2, IGN STRG LOCK 20 A Steering lock system RADIO NO.1 20 A Audio system ABS MAIN Electronically controlled brake sys- 15 A NO.3 15 A Audio system 15 A Turn signal lights...
Page 460 4-3. Do-it-yourself maintenance Fuse Ampere Circuit WIP-S 10 A Air conditioning system Multiport fuel injection system/ EFI NO.2 10 A sequential multiport fuel injection system Multiport fuel injection system/ EFI NO.3 10 A sequential multiport fuel injection system F/PMP 15 A Fuel pump Starting system, multiport fuel 15 A...
Page 461 4-3. Do-it-yourself maintenance Type B Fuse Ampere Circuit 15 A Hybrid system IGCT NO.2 10 A Hybrid system IGCT NO.3 10 A Hybrid system INV W/P 10 A Hybrid system Type C Fuse Ampere Circuit ABS MAIN Electronically controlled brake sys- 10 A NO.1 ABS MAIN...
Page 462 4-3. Do-it-yourself maintenance Under the instrument panel ■ Front side of the fuse block Fuse block Fuse Ampere Circuit P/SEAT 30 A Power seat POWER 30 A Power windows RR DOOR RH 25 A Power windows RR DOOR LH 25 A Power windows FR FOG 10 A...
Page 463 4-3. Do-it-yourself maintenance Fuse Ampere Circuit P/SEAT (PS) 30 A Power seat A/C NO.1 10 A Air conditioning system FUEL OPN 7.5 A Fuel filler door opener S/ROOF 20 A Electric moon roof Side marker lights, tail lights, TAIL 15 A license plate lights, fog lights, trailer lights Glove box light, instrument panel...
Page 464: Luggage Compartment
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, steering lock system, 10 A smart key system, SRS airbag sys- tem, hybrid system, electronically controlled brake system Gauges and meters, rear view GAUGE NO.2 7.5 A monitor system Outside rear view mirrors, shift lock...
Page 465 Never use a fuse of a higher amperage rating than indicated, or use any ● other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. ● Never replace a fuse with a wire, even as a temporary fix.
Page 466 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 467 4-3. Do-it-yourself maintenance Rear bulb locations ■ Rear turn signal lights Stop/tail and rear side marker lights License plate lights Back up lights Replacing light bulbs Headlights ■ Unplug connector while STEP depressing the lock release. Low beam (outside) High beam (inside)
Page 468 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. Low beam High beam Fog lights ■ Unplug connector while STEP depressing the lock release. Turn the bulb base counterclock- STEP wise.
Page 469 4-3. Do-it-yourself maintenance Parking, front side marker and front turn signal lights ■ Right side only: Move STEP washer fluid tank opening. Turn the bulb base counterclock- STEP wise.
Page 470 4-3. Do-it-yourself maintenance Remove the light bulb. STEP Back-up lights, stop/tail and rear side marker, and rear turn ■ signal lights Left side Open the back door and remove STEP the cover. To protect the cover, place a rag between the flathead screwdriver and cover as shown in the illus- trations.
Page 471 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. Rear turn signal light Stop/tail and rear side marker light Back-up light Remove the light bulb. STEP Rear turn signal light Stop/tail and rear side marker light Back-up light License plate lights ■...
Page 472 Water has built up inside the headlight. ● LED high mounted stoplight ■ The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 473 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ Turn off the headlights. Do not attempt to replace the bulb immediately ● after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the ●...
Page 474 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Vehicles without navigation system Press the switch to flash all the turn signal lights. To turn them off, press the switch once again.
Page 475 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 476: Emergency Towing
5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances below 18 mph (30 km/h).
Page 477 5-1. Essential information CAUTION Caution while towing ■ Use extreme caution when towing the vehicle. ● Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelet and the cables or chains. Always use caution for the surroundings and other vehicles while towing. If the hybrid system is off, the power assist for the brakes and steering will ●...
Page 478 5-1. Essential information Tighten down the towing eyelet STEP securely using a wheel nut wrench. Location of the emergency towing eyelet ■ →P. 522 CAUTION Installing towing eyelet to the vehicle ■ Make sure that towing eyelet is installed securely. If not securely installed, towing eyelet may come loose during towing.
Page 479 5-1. Essential information NOTICE To prevent body damage ■ Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels. From rear Use a towing dolly under the front wheels.
Page 480 Without adequate clearance, the vehicle could be damaged while being towed. Using a flat bed truck If your Toyota is transported by a flatbed truck, it should be tied down at the locations shown in the illustration.
Page 481 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 482 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 483 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained ●...
Page 484 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light in red (warning buzzer)* •...
Page 485 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 486 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Brake system warning light operation ■...
Page 487 When the light comes on: Adjust the tire inflation Low tire inflation pressure pressure. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system...
Page 488 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Master warning light A buzzer sounds and the warning light comes on →P. 521 and flashes to indicate that the master warning system has detected a malfunc- tion.
Page 489 5-2. Steps to take in an emergency Changing the engine oil (U.S.A. only) ■ Make sure to reset the oil change system. (→P. 450) The tire pressure warning light may turn on due to natural causes ■ The tire pressure warning light may turn on due to natural causes such as natural air leaks or tire inflation pressure changes caused by temper- ature.
Page 490 If there is a lot of snow or ice on the vehicle, in particular around the ● wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota ● wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 491 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, ●...
Page 492 5-2. Steps to take in an emergency CAUTION Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver's responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
Page 493 Warning buzzer ■ A buzzer may sound when a warning message is shown on the multi-information display. If the warning message is shown again after its correction ■ procedure has been performed Contact your Toyota dealer as soon as possible.
Page 494 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle ■ ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 495 5-2. Steps to take in an emergency Taking out the jack Remove the right side deck STEP board. Unhook the tightening strap and STEP remove the pad. After storing the jack, make sure it is securely held by the tightening strap. Loosen STEP Tighten...
Page 496 5-2. Steps to take in an emergency Taking out the spare tire Open the center deck board and STEP remove the cover. Remove the cover. STEP If it is difficult to remove the cover, you can use the key. Attach the adapter socket (for STEP removing a spare tire) to the spare tire clamp bolt.
Page 497 5-2. Steps to take in an emergency Assembling the jack handle. STEP Remove the jack handle and assemble it by following these steps. Loosen the screw. Assemble the jack handle and tighten the screw. Check that the screw is firmly tightened.
Page 498 5-2. Steps to take in an emergency Pull out the spare tire and stand STEP it against the bumper. Remove the holding bracket. STEP...
Page 499 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
Page 500 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
Page 501 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 502 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stowing the flat tire, jack and all tools Remove the center wheel ornament by pushing from the STEP reverse side.
Page 503 5-2. Steps to take in an emergency The compact spare tire ■ The compact spare tire is identified by the label “TEMPORARY USE ● ONLY” on the tire sidewall. Use the compact spare tire temporarily only in an emergency. Make sure to check the tire inflation pressure of the compact spare ●...
Page 504 5-2. Steps to take in an emergency CAUTION Using the tire jack ■ Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or ●...
Page 505 5-2. Steps to take in an emergency CAUTION Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 ● N•m, 10.5 kgf•m) as soon as possible after changing wheels. Failure to follow these precautions could cause the nuts to loosen and the wheel may fall off, which could lead to an accident causing death or serious injury.
Page 506 ■ When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ■...
Page 507 5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: The hybrid system will not start, even though the correct ■...
Page 508 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (→P. 541) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system)
Page 509 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 510 If you lose your keys/wireless remote control transmitter Keys ■ New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate.
Page 511 Changing “POWER” switch modes and starting the hybrid system Shift the shift lever to P and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened and...
Page 512 5 seconds after the buzzer sounds, keeping the brake pedal depressed. In the event that the hybrid system still cannot be operated, contact your Toyota dealer. Stopping the hybrid system ■ Shift the shift lever to P and press the “POWER” switch as you normally do when stopping the hybrid system.
Page 513 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Open the hood.
Page 514 Make sure the “READY” indicator comes on. If the indicator STEP does not comes on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected.
Page 515 5-2. Steps to take in an emergency When the 12-volt battery is removed or discharged ■ The hybrid system may not start. (→P. 458) ● The power back door must be initialized. (→P. 71) ● CAUTION Avoiding 12-volt battery fires or explosions ■...
Page 516 5-2. Steps to take in an emergency NOTICE When handling jumper cables ■ Be careful that the jumper cables do not become tangled in the cooling fans or belt when connecting or disconnecting the cables.
Page 517 Check if the cooling fans are operating. STEP If the fans are operating: Wait until the engine coolant temperature gauge begins to fall and then stop the hybrid system. If the fans are not operating: Stop the hybrid system immediately and call your Toyota dealer.
Page 518 5-2. Steps to take in an emergency After the hybrid system has STEP cooled down, check the engine coolant level and inspect the cooling system for leaks. Engine coolant reservoir Radiator If necessary, add engine coolant STEP up to the “FULL” line. Water can be used in an emer- gency if engine coolant is unavail- able.
Page 519 If necessary, add power control STEP unit coolant up to the “FULL” line. Water can be used in an emer- gency if power control unit cool- ant is unavailable. (→P. 559) Have the vehicle inspected at your nearest Toyota dealer as soon as possible.
Page 520 5-2. Steps to take in an emergency Overheating ■ The following symptoms may occur when your vehicle is overheating: Hybrid system output decreases. ● Steam comes from the engine area. ● CAUTION To prevent an accident or injury when inspecting under the hood of ■...
Page 521 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the hybrid system. Set the parking brake and put the STEP shift lever to P.
Page 522 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
Page 523 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the hybrid system by pressing and holding the “POWER” switch for 3 consec- utive seconds or more. Press and hold for 3 seconds or more Stop the vehicle in a safe place by the road.
Page 524 5-2. Steps to take in an emergency...
Page 525 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 188.8 in. (4795 mm) Overall width 75.2 in. (1910 mm) Overall height 69.3 in. (1760 mm) Wheelbase 109.8 in. (2790 mm) Front tread 64.0 in. (1625 mm) Rear tread 64.0 in.
Page 526 Vehicle identification number ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the right-hand front seat.
Page 527: Engine Number
6-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 2GR-FXE Type 6-cylinder V type, 4-cycle, gasoline 3.70 × 3.27 in. (94.0 × 83.0 mm) Bore and stroke Displacement 210.9 cu.in. (3456 cm Drive belt tension Automatic adjustment Fuel...
Page 528 6-1. Specifications Front electric motor (traction motor) Type Permanent magnet synchronous motor Maximum output 123 kW Maximum torque 247 ft•lbf (335 N•m, 34.2 kgf•m) Rear electric motor (traction motor) Type Permanent magnet synchronous motor Maximum output 50 kW Maximum torque 103 ft•lbf (139 N•m, 14.2 kgf•m) Hybrid battery (traction battery) Type...
Page 529: Lubrication System
6.4 qt. (6.1 L, 5.4 Imp. qt.) Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 530: Cooling System
14.2 qt. (13.5 L, 11.8 Imp. qt.) Power control unit 2.4 qt. (2.3 L, 2.0 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 531: Ignition System
6-1. Specifications Ignition system Spark plug Make DENSO FK20HR11 0.043 in. (1.1 mm) NOTICE Iridium-tipped spark plugs ■ Use only iridium-tipped spark plugs. Do not adjust spark plug gap. Electrical system 12-volt battery 12.6 ⎯ 12.8 V Fully charged 12.2 ⎯ 12.4 V Half charged 11.8 ⎯...
Page 532 *: The fluid capacity is a reference quantity. If replacement is necessary, con- tact your Toyota dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may ulti- mately damage the transmission of your vehicle.
Page 533 6-1. Specifications Brakes Pedal clearance* 3.74 in. (95 mm) Min. 0.04 ⎯ 0.08 in. (1 ⎯ 2 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) 8 ⎯ 10 clicks Parking brake pedal travel* Fluid type SAE J1703 or FMVSS No.116 DOT 3...
Page 534 6-1. Specifications Tires and wheels Type A Tire size P245/65R17 105S Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Spare: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph...
Page 535 6-1. Specifications Type B Tire size P245/55R19 103S Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Spare: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph...
Page 536 6-1. Specifications Type C P245/65R17 105S, T165/90D18 107M Tire size (spare) Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Driving at high speeds above 100 mph Tire inflation pressure (160 km/h) (in countries where such (Recommended cold tire...
Page 537 6-1. Specifications Type D P245/55R19 103S, T165/90D18 107M Tire size (spare) Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Driving at high speeds above 100 mph Tire inflation pressure (160 km/h) (in countries where such (Recommended cold tire...
Page 538: Light Bulbs
6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights High beam 9005 ⎯ Low beam Parking, front side marker and 3457NA 28/8 front turn signal lights ⎯ Fog lights Exterior ⎯ Rear turn signal lights Back-up lights Stop/tail and rear side marker 7443 21/5 lights...
Page 539 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks ■...
Page 540 Toyota allows the use of oxygenate blended gasoline where the oxygen- ● ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no ● lower than 87.
Page 541 6-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used the engine will be ● damaged. Do not use leaded gasoline. ● Leaded gasoline will cause the three-way catalytic converter to lose its effectiveness and the emission control system to function improperly.
Page 542 6-1. Specifications Tire information Typical tire symbols Standard tire Compact spare tire Tire size (→P. 574) DOT and Tire Identification Number (TIN) (→P. 573) Uniform tire quality grading For details, see “Uniform tire quality grading” that follows. Location of treadwear indicators (→P.
Page 543 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked with “RADIAL”...
Page 544 6-1. Specifications Typical DOT and tire identification number (TIN) DOT symbol* Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year *: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 545 6-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 546 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 547 6-1. Specifications Treadwear ■ The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 548 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 549 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 550 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 551 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 552 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 553 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 554 Your vehicle includes a variety of electronic features that can be personalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 555 6-2. Customization Customized Item Function Default setting setting Wireless remote control Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step steps Automatic door lock function to be activated if door is not opened after being unlocked Time elapsed before Wireless...
Page 556 6-2. Customization Customized Item Function Default setting setting Light sensor sensitivity Level 3 Level 1 to 5 Time elapsed before 0 second headlights automati- 60 seconds 30 seconds cally turn off after doors 90 seconds are closed Automatic Ambient light level at light control which instrument illumi- -2(darker) to...
Page 557 6-2. Customization Customized Item Function Default setting setting Operation when you approach the vehicle with the electronic key on your person. Operation when the doors are unlocked using the wireless Outer foot remote control, key or lights entry function (if equipped) Operation when the →...
Page 558 6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the 12-volt battery is reconnected, or mainte- nance is performed on the vehicle. Item When to initialize Reference • After reconnecting or changing the Power back door battery P.
Page 559 6-3. Initialization...
Page 560 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 561 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 562 Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez de l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées. ATTENTION ■ Détérioration et usure des ceintures de sécurité...
Page 563 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. Sacs de sécurité...
Page 564 Sacs de sécurité gonflables latéraux et rideau Sacs de sécurité gonflables latéraux Participent à la protection du thorax des occupants des sièges avant. Sacs de sécurité gonflables rideau Participent principalement à la protection de la tête des occupants assis aux places extérieures.
Page 565 Composition du système de sacs de sécurité gonflables Sacs de sécurité gonflables Témoin d'alerte SRS rideau Sac de sécurité gonflable Sacs de sécurité gonflables conducteur latéraux Capteur de la position du Sac de sécurité gonflable siège conducteur passager avant Contacteur de boucle de Capteurs sacs ceinture...
Page 566 Votre véhicule est équipé de SACS DE SECURITE GONFLABLES INTELLIGENTS (ADVANCED AIRBAGS) conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le système de sacs de sécurité gonflables régule la puissance de déploiement des sacs de sécurité gonflables conducteur et passager avant.
Page 567 ATTENTION ■ Précautions avec les sacs de sécurité gonflables SRS Respectez les précautions suivantes avec les sacs de sécurité gonflables. À défaut, des blessures graves, voire mortelles, pourraient s'ensuivre. Le conducteur et tous les passagers à bord du véhicule doivent porter leur ●...
Page 568 être grièvement blessés ou tués par le déploiement d'un sac de sécurité gonflable. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 569 ATTENTION ■ Précautions avec les sacs de sécurité gonflables SRS ●Ne pas s'asseoir sur le bord du siège et ne pas s'appuyer contre la planche de bord. ●Ne laissez pas un enfant rester debout devant le sac de sécurité gonflable SRS passager avant ou bien s'asseoir sur les genoux du passager avant.
Page 570 ATTENTION ■ Précautions avec les sacs de sécurité gonflables SRS Ne rien fixer ou disposer sur la planche ● de bord, la garniture centrale du moyeu de volant de direction ou la partie inférieure du tableau de bord. Au déploiement des sacs de sécurité gonflables SRS conducteur, passager avant et genoux, tout objet risque de se transformer en projectile.
Page 571 Si les parties renfermant les sacs de sécurité gonflables SRS, telles que la ● garniture du moyeu de volant et les garnitures de montants avant et arrière, apparaissent abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
Page 572 ■ Modification et mise au rebut des éléments du système de sacs de sécurité gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes. Les sacs de sécurité gonflables SRS risquent de ne pas fonctionner correctement ou de se déployer (gonfler) accidentellement, provoquant ainsi...
Page 573 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor Calibration Child Restraint System DISP Display ECON Economy Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Rating GVWR Gross Vehicle Weight Rating Emission Inspection and Maintenance INFO...
Page 574 Abbreviation list ABBREVIATIONS MEANING Vehicle Identification Number Vehicle Stability Control...
Page 575: Gas Station Information
(L, Imp. qt.) (Drain and refill ⎯ Without filter 6.0 (5.7, 5.0) reference) With filter 6.4 (6.1, 5.4) Toyota Genuine Motor Oil or equivalent Oil grade: P. 558 Engine oil type ILSAC multigrade engine oil Recommended oil viscosity: SAE 0W-20...
Page 576 What to do if... What to do if... If you have a flat tire A tire punctures P. 522 If the hybrid system will not start P. 535 The hybrid system does not Immobilizer system P. 121 start If the 12-volt battery is discharged P.
Page 577 What to do if... If a warning light turns on or a A warning light or indicator light P. 512 warning buzzer sounds... comes on ■Warning lights Brake system warning Low fuel level warning light in red light P. 515 Driver’s seat belt reminder light P.
Page 578 What to do if... ABS warning light Tire pressure warning light P. 515 Cruise control indicator light P. 513 P. 513 Electric power steering Slip indicator warning light light P. 513 P. 513 : The light flashes to indicate a malfunction. A warning message is If a warning message is displayed P.
