Page 1: Quick Reference
YARIS SEDAN 2 0 1 0 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 8/09 Cert no. SGS-COC-005612 I n f o r ma t i o n P r o v i d e d b y : 00505-QRG10-YARS 08-TCS-03084...
Page 2 Tool location of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your Jack handle new Yaris.
Page 3: Table Of Contents
Trunk-Internal release Tire Pressure Monitoring (warning) System Visit your Toyota dealer for information on this and other customizable options. I n f o r ma t i o n P r o v i d e d b y :...
Page 4 OVERVIEW Instrument panel Instrument panel light control Power rearview mirror controls* Headlight, turn signal and front fog light* controls Cruise control Ignition switch Wiper and washer controls Emergency flasher button Front passenger seatbelt reminder light Clock adjust button Odometer/Trip meter switch and trip meter reset button I n f o r ma t i o n P r o v i d e d b y :...
Page 5 “AIR BAG ON” and “AIR BAG OFF” indicator Audio system* Air Conditioning controls AUX adapter* Rear window/Outside rearview mirror defogger switch* Tilt steering lock release lever Hood release * If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 6: Instrument Cluster
If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 7 Malfunction/Check Engine indicator Low engine oil pressure warning Open door warning Airbag SRS warning Low windshield washer fluid level warning Electric power steering system warning Low fuel level warning Engine oil replacement reminder AIR BAG ON indicator AIR BAG OFF indicator Headlight low beam indicator Headlight high beam indicator Front fog light indicator...
Page 8: Fuel Tank Door Release And Cap
OVERVIEW Fuel tank door release and cap Driver seat Hang Pull up Turn NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Keyless entry (if equipped) Locking operation Unlocking operation Push ONCE: Driver door TWICE: All doors...
Page 9: Engine Maintenance
Hood release Pull Pull up latch and raise hood Engine maintenance Windshield washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”...
Page 10: Automatic Transmission
FEATURES/OPERATIONS Automatic Transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The engine switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill.
Page 11: Parking Brake
Parking brake Release Pull (2) Push (1) Pull slightly (3) Lower Windows-Power (if equipped) Driver side Window lock switch Down Window operation Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window at any point, lightly pull the switch up.
Page 12: Seat Adjustments-Rear
FEATURES/OPERATIONS Seat adjustments-Rear (fold-down type) To fold down the rear seatback (1) Slide the seatback security lock to the right unlock position from the trunk room. (2) Lower the seat head restraints. (3) Pull the lock release knob up. (4) Fold the seatback down. Refer to the Owner’s Manual for more details.
Page 13: Lights & Turn Signals
Lights & turn signals Headlights Headlights Parking lights Low beam High beam flasher High beam Daytime Running Light system (DRL)(if equipped) Automatically turns on the headlights at a reduced intensity. Turn signals Right turn Lane change Lane change Left turn Front fog lights (if equipped) Turn Front fog lights turn on only when the headlights are on low beam.
Page 14 FEATURES/OPERATIONS Audio (if equipped) Type 1 Push to turn Push to adjust tone & balance ON/OFF Eject CD Push to skip up Seek station/ /down folder CD track select Mode Mode Station/CD track scan Preset buttons - functions in other View CD text modes indicated beside number.
Page 15: Air Conditioning/Heating
AUX audio jack (if equipped) By inserting a mini plug of a commercially available component into the AUX audio jack, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. ® NOTE: An iPod -dedicated port is standard on all S model sedans.
Page 16: Cruise Control
FEATURES/OPERATIONS Cruise control (if equipped) Turning system ON/OFF System ON/OFF Functions Cancel Resume /Increase speed Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal or the clutch pedal (Manual Transmission). Unless vehicle speed drops below 10 mph, the set speed may be resumed once vehicle exceeds 25 mph.
Page 17: Bottle Holders-Front Seat
Clock Clock adjust button (1) Push and hold the CLOCK button to enter adjustment mode. (2) Press CLOCK button to adjust hours. (3) Wait five seconds to adjust the minutes. (4) Wait another five seconds for process to complete. Cup holders Front Rear Rear seat armrest (if equipped)
Page 18: Door Locks-Power
” indicator will illuminate. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details.
Page 19 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Anti-Lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Ratings GVWR Gross Vehicle Weight Rating Emission inspection and maintenance LATCH Lower Anchors and Tethers for Children Light Emitting Diode...
Page 20: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 21 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 22 CAUTION General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 23 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 24 I n f o r ma t i o n P r o v i d e d b y :...
Page 25 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 26 Pictorial index Exterior Windshield wipers P. 133 Hood P. 231 Outside rear view mirrors P. 53 Front side marker lights P. 130 Headlights (low and high beam) and daytime running lights Front turn signal / P. 130, 131 parking lights P.
Page 27 Fuel filler door P. 58 ∗ Rear window defogger P. 170 Trunk P. 33 Doors P. 28 License plate lights P. 130 Tires Rotation P. 246 Replacement P. 307 Stop/tail and rear side Inflation pressure P. 252 marker lights P. 130 Information P.
Page 28 Pictorial index Interior Head restraints P. 41 Horn P. 120 Seat belts P. 44 SRS driver airbag P. 69 Shift lever P. 114, 116 Power window ∗ Security indicator switches P. 56 P. 62, 64 ∗ Cup holders SRS front P.
Page 29 Vanity mirrors P. 207 Sun visors P. 206 Personal lights P. 199 Interior light P. 199 Anti-glare inside rear view mirror P. 52 ∗ SRS curtain shield airbags P. 69 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 30 Pictorial index Interior ∗ Window lock switch P. 57 Power window Inside door lock button P. 30 ∗ switches P. 56 ∗ Door lock switch P. 30 I n f o r ma t i o n P r o v i d e d b y :...
Page 31 Console box P. 201 Cup holder P. 203 Parking brake lever P. 118 ∗ Power outlet P. 211 ∗ Cigarette lighter P. 210 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 32: Instrument Panel
Pictorial index Instrument panel Windshield wipers and washer switch P. 133 Headlight switch P. 130 Turn signal lever P. 117 ∗ Gauges and meters P. 121 Fog light switch P. 132 Auxiliary box Audio system P. 172 P. 204 Glove box P.
Page 33 Emergency flasher switch P. 286 CLOCK button P. 121, 208 ODO/TRIP button P. 121 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 34 Pictorial index Instrument panel Air conditioning system P. 164 ∗ AUX adapter P. 196 ∗/ Rear window defogger switch Rear window defogger and outside rear ∗ view mirror defogger switch P. 170 I n f o r ma t i o n P r o v i d e d b y :...
Page 35 ∗ Cruise control switch P. 136 Engine (ignition) switch P. 110 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 36 Pictorial index Instrument panel Outside rear view mirror Cup holders P. 202 ∗ switches P. 53 Instrument panel light control dial P. 125 I n f o r ma t i o n P r o v i d e d b y :...
Page 37 VSC OFF switch P. 140 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 38 1-1. Key information Keys The following keys are provided with the vehicle. Vehicles without engine immobilizer system (type A) Master keys (with wireless remote control function) Operating the wireless remote control function (→P. 26) Valet key Key number plate Vehicles without engine immobilizer system (type B) Master keys Valet key Key number plate...
Page 39 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 321)
Page 40 1-2. Opening, closing and locking the doors ∗ Wireless remote control The wireless remote control can be used to lock/unlock the vehicle from outside the vehicle. Locks all doors Sounds alarm (push and hold) Unlocks all doors Pressing the button unlocks the driver’s door.
Page 41 When a wireless key (that emits radio waves) is being used nearby When the wireless key has been left near an electrical appliance such as a personal computer Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features →P. 359) Certification for wireless remote control For vehicles sold in U.S.A.
Page 42 1-2. Opening, closing and locking the doors Doors The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. Wireless remote control (if equipped) →P. 26 Vehicles with power door lock Locks all doors Unlocks all doors Turning the key a single time in the driver’s door unlocks the driver’s door,...
Page 43 1-2. Opening, closing and locking the doors Vehicles without power door lock Locks the door Unlocks the door I n f o r ma t i o n P r o v i d e d b y :...
Page 44 1-2. Opening, closing and locking the doors Door lock switch (if equipped) Driver’s door lock switch Unlocks all doors Locks all doors Passenger’s door lock switch Locks all doors Unlocks all doors Inside door lock button Locks the door Unlocks the door Pulling the inside handle can open the front door even if the lock button is in the lock posi-...
Page 45 A buzzer sounds if the driver’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key. Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed.
Page 46 1-2. Opening, closing and locking the doors CAUTION To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Always use a seat belt.
Page 47 1-2. Opening, closing and locking the doors Trunk The trunk can be opened using the key or trunk opener. Turn the master key clockwise to release the trunk lid. Trunk opener Release the trunk lid. I n f o r ma t i o n P r o v i d e d b y :...
Page 48 1-2. Opening, closing and locking the doors Internal trunk release lever The trunk lid can be opened by pulling up on the glow-in-the-dark lever located on the inside of trunk lid. The lever will continue to glow for some time after the trunk lid is closed. Luggage security system To protect luggage stored in the trunk against theft, do the following procedures.
Page 49 1-2. Opening, closing and locking the doors CAUTION Caution while driving Keep the trunk lid closed while driving. If the trunk lid is left open, it may hit near-by objects while driving or lug- gage in the trunk may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 50 Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) CAUTION Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt.
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats (split rear seats only) The seatbacks of the rear seats can be folded down. Insert the key into the hole on the center seat belt buckle to release tab (with hooked end), and allow the belt to retract.
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Lower each head restraints while pushing the lock release button. Fold seatbacks down while pulling the seatback lock release knobs. Returning rear seatbacks Tilt the rear seatback up until it locks, making sure that you hold the seat belt to prevent it from getting caught between the seatback and the inner side of the vehicle.
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. Make sure that the seatback is securely locked in position by lightly rocking it back and forth.
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraints down while pushing the lock release Lock release button button. Rear seats Vertical adjustment Pull the head restraints up.
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Pull the head restraint up while pushing the lock release button. Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the rear seat head restraints Always raise the head restraint one level from the stowed position when using. CAUTION Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Adjusting the height of the belt (front seats) Down Pull the lock release knob and slide the height adjuster down. Move the height adjuster up as needed until you hear a click.
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) Release method The belt can be completely released when not required, such as when folding down the rear seat. To release the hooked end tab, insert the vehicle’s key into the hole on the buckle. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu-...
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 62 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
Page 63 Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Child restraint lock function belt precaution Do not allow children to play with the child restraint lock function belt. If the belt becomes twisted around a child’s neck, it will not be possible to pull the belt out leading to choking or other serious injuries that could result in death.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Normal position Anti-glare position CAUTION Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch or lever. Power-adjustable type Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Manually adjustable type Adjust the mirror up, down, in or out using the lever.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. Mirror operating conditions (with power-adjustable type only) The engine switch is in the ACC or ON position. CAUTION When driving the vehicle Observe the following precautions while driving.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror. I n f o r ma t i o n P r o v i d e d b y :...
Page 70 1-4. Opening and closing the windows ∗ Power windows The power windows can be opened/closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 71 1-4. Opening and closing the windows Lock switch Press the switch down to lock passenger window switches. Use this switch to prevent chil- dren from accidentally opening or closing a passenger window. The power windows can be operated when The engine switch is in the ON position. Operating the power windows after turning the engine switch off (driver’s window only) The power windows can be operated for approximately 45 seconds even...
Page 72 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the engine switch off and ensure that all the doors and win- dows are closed. Opening the fuel tank cap Open the fuel filler door.
Page 73 1-5. Refueling Hang the fuel tank cap on the back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
Page 74 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 75 1-5. Refueling NOTICE Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. I n f o r ma t i o n P r o v i d e d b y :...
Page 76 1-6. Theft deterrent system ∗ Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi-...
Page 77 1-6. Theft deterrent system Certifications for the engine immobilizer system For vehicles sold in U.S.A. FCC ID: MOZRI-20BTY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 78 1-6. Theft deterrent system Alarm (Puerto Rico) The system sounds the alarm and flashes lights when forcible entry is detected. Triggering of the alarm The alarm is triggered in the following situations. l A locked door or trunk is unlocked or opened in any way other than using the key (vehicles without wireless remote control) or wireless remote control door lock function (vehicles with wireless remote control).
Page 79 1-6. Theft deterrent system System maintenance The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. The windows are closed before the alarm is set.
Page 80 1-6. Theft deterrent system Theft prevention labels (except Canada) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y :...
Page 81 1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 37) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 82 1-7. Safety information CAUTION While driving Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 83 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 84 1-7. Safety information Airbag system components Front passenger airbag Driver’s seat position sen- Curtain shield airbags (if equipped) Driver’s seat belt buckle switch Side airbags (if equipped) AIR BAG ON and AIR BAG SRS warning light OFF indicator lights Curtain shield airbag sen- Front airbag sensors sors (if equipped) Airbag sensor assembly...
Page 85 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys- tem controls airbag deployment power for the driver and front pas- senger. The driver airbag system consists of the driver seat’s position sensor etc.
Page 86 1-7. Safety information If the SRS airbags deploy (inflate) The front windshield may crack. Operating conditions (front airbags) The SRS front airbag will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12-18 mph [20-30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 87 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or hard surface Falling into or jumping over a deep hole...
Page 88 1-7. Safety information Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags [if equipped]) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 89 1-7. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. The front of the vehicle is damaged or deformed, or was involved in an acci- dent that was not severe enough to cause the SRS airbags to inflate.
Page 90 1-7. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
Page 91 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 92 1-7. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. Do not drive the vehicle while the driver or passenger has items resting on their knees.
Page 93 1-7. Safety information CAUTION SRS airbag precautions Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad. These items can become projectiles when SRS driver and front passenger airbags deploy. Vehicles with side airbags and curtain shield airbags: Do not attach anything to areas such as the door, windshield...
Page 94 Vehicles with curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar gar- nishes, are damaged or cracked, have them replaced by your Toyota dealer. Vehicles without curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad are damaged or cracked, have them replaced by your Toyota dealer.
Page 95 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger’s seat belt reminder light AIR BAG ON indicator light...
Page 96 1-7. Safety information Condition and operation in the front passenger occupant classification system Adult AIR BAG ON and AIR BAG OFF indicator AIR BAG ON lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices Activated...
Page 97 1-7. Safety information There is a malfunction in the system AIR BAG ON and AIR BAG OFF indicator AIR BAG lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger Activated...
Page 98 1-7. Safety information CAUTION Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 99 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 100 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 101 1-7. Safety information Forward facing — Convertible seat Booster seat Selecting an appropriate child restraint system Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belts. If a child is too large for a child restraint system, sit the child on a rear seat and use the vehicle’s seat belt.
Page 102 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 103 1-7. Safety information CAUTION Child restraint precautions Make sure you have complied with all installation instructions provided by the child restraint manufacturer and that the system is properly secured. If it is not secured properly, it may cause death or serious injury to the child in the event of emergency braking, sudden swerving or an accident.
Page 104 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 105 1-7. Safety information Installation with LATCH system Remove the head restraint. Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched...
Page 106 1-7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. (→P.
Page 107 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 108 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only.
Page 109 1-7. Safety information Booster seat Place the booster seat on the seat facing the front of the vehi- cle. Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle.
Page 110 1-7. Safety information Child restraint systems with a top tether strap Remove the head restraint. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 111 1-7. Safety information CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 47) In ALR lock mode the belt is locked in that position and cannot be extended, which could cause injury or discomfort to the child seated in the booster seat.
Page 112 1-7. Safety information CAUTION When installing a child restraint system Ensure that the belt and tab are securely locked and the seat belt is not twisted. Push and pull the child restraint system from side to side and forward to be sure it is secure.
Page 113 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the engine (→ P. 110) Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. (→P. 114) Release the parking brake. (→P.
Page 114 2-1. Driving procedures Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake. (→P. 118) Shift the shift lever to P. (→P. 114) When parking on a hill, if necessary, block the wheels. Turn the engine switch off to stop the engine.
Page 115 Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended...
Page 116 Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immedi- ately. On vehicles with an automatic transmission, do not shift the shift lever to P while the vehicle is moving.
Page 117 2-1. Driving procedures CAUTION Do not shift the shift lever to D (vehicles with an automatic transmission) or 1 (vehicles with a manual transmission) while the vehicle is moving back- ward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 118 2-1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. When driving on slippery road surfaces Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
Page 119 2-1. Driving procedures CAUTION Avoid revving or racing the engine. Running the engine at high speed while the vehicle is stopped may cause the exhaust system to overheat, which could result in a fire if combustible material is nearby. When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun.
Page 120 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 121 If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 122 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of engine oil, transaxle fluid, etc.
Page 123 2-1. Driving procedures Engine (ignition) switch Engine switch LOCK The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) Some electrical components such as the audio system can be used.
Page 124 2-1. Driving procedures Manual transmission Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the brake pedal and clutch pedal. Turn the engine switch to the START position and start the engine.
Page 125 2-1. Driving procedures Turning the key from ACC to LOCK Shift the shift lever to P (auto- matic transmission) or N (man- ual transmission). (→P. 114, 116) Push in the key and turn to the LOCK position. Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
Page 126 2-1. Driving procedures CAUTION Caution while driving Do not turn the engine switch to the LOCK position. If in an emergency, you must turn the engine off while the vehicle is moving, turn the engine switch only to the ACC position. NOTICE To prevent battery discharge Do not leave the engine switch in the ACC or ON position for long periods if...
Page 127 2-1. Driving procedures ∗ Automatic Transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever While the engine switch is on, depress the brake pedal and move the shift lever. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 128 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving Position for engine braking Position for more powerful engine braking Position for maximum engine braking : Shifting to the D position allows the system to select a gear suitable for the driving conditions.
Page 129 2-1. Driving procedures ∗ Manual Transmission Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. mph (km/h) Shift position Maximum speed...
Page 130 2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 131 2-1. Driving procedures Parking brake Set the parking brake Fully set the parking brake while depressing the brake pedal. except Canada Canada At this time, the indicator will come on. Release the parking brake Slightly raise the lever Press the button Lower it completely I n f o r ma t i o n P r o v i d e d b y :...
Page 132 2-1. Driving procedures Usage in winter time See “Winter driving tips” for parking brake usage in winter time. (→P. 148) NOTICE Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
Page 133 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 134 2-2. Instrument cluster Gauges and meters Vehicles with Optitron type meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank.
Page 135 2-2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
Page 136 2-2. Instrument cluster Vehicles without Optitron type meters Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Clock Indicates the time. I n f o r ma t i o n P r o v i d e d b y :...
Page 137 2-2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
Page 138 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Brighter Darker With the dial turned fully up, the intensity of the instrument panel lights will not be reduced even when the tail lights/headlights are turned on.
Page 139 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster (vehicles with Optitron type meters) Instrument cluster (vehicles without Optitron type meters) I n f o r ma t i o n P r o v i d e d b y :...
Page 140 2-2. Instrument cluster Center panel I n f o r ma t i o n P r o v i d e d b y :...
Page 141 2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (→P. 117) (→P. 136) (if equipped) Cruise control set indi- Headlight high beam cator (→P. 136) indicator (→P.
Page 142 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 143 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. The daytime running lights turn equipped) side marker, parking, tail, license plate, daytime run- ning lights equipped) and instru- ment panel lights turn Canada except Canada The headlights and all lights listed above turn on.
Page 144 2-3. Operating the lights and wipers Daytime running light system (if equipped) To make your vehicle more visible to other drivers, the headlights turn on automatically (at a reduced intensity) whenever the engine is started and the parking brake is released. Daytime running lights are not designed for use at night.
Page 145 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Front fog light switch Front fog lights ON ∗...
Page 146 2-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper without interval adjuster Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts.
Page 147 2-3. Operating the lights and wipers Intermittent wiper with interval adjuster Wiper intervals can be adjusted for intermittent operation (when selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency...
Page 148 2-3. Operating the lights and wipers Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts. The windshield wiper and washer can be operated when The engine switch must be in the ON position. If no windshield washer fluid sprays Check that the washer nozzles are not blocked and if there is washer fluid in the windshield washer fluid reservoir.
Page 149 2-4. Using other driving systems ∗ Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Cruise control indicator Cruise control set indicator Cruise control switch Set the vehicle speed Press the ON-OFF button to turn the cruise control on.
Page 150 2-4. Using other driving systems Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
Page 151 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION To avoid operating the cruise control by mistake Keep the ON-OFF button off when not in use.
Page 152 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) (if equipped) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface.
Page 153 2-4. Using other driving systems To disable TRAC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRAC or VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. TRAC OFF mode Press the VSC OFF switch briefly.
Page 154 2-4. Using other driving systems VSC OFF mode Stop the vehicle completely, and press the VSC OFF switch for more than 3 seconds. The TRAC OFF and VSC OFF indicators will come on. The system is in TRAC off and VSC off mode.
Page 155 If the TRAC and VSC systems are turned off, the systems will not turn on even when vehicle speed increases. If the slip indicator light up There is a malfunction in the TRAC and VSC systems. Contact your Toyota dealer and have your Toyota inspected. EPS operation sound When the steering wheel operates, a motor sound (whirring sound) may be heard.
Page 156 The ABS and VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 157 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the trunk whenever possible. l Be sure all items are secured in place. l Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 158 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Except Canada: Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb.
Page 159 2-5. Driving information CAUTION Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk. Receptacles containing gasoline Aerosol cans Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury. Do not place cargo or luggage in or on the following locations as the item may get under the clutch, brake or accelerator pedal and prevent the pedals from being depressed properly, block the driver’s vision, or...
Page 160 Towing capacity means the maximum gross trailer weight (trailer weight plus its cargo weight) that your vehicle is able to tow. Towing capacity (except Canada): Toyota does not recommend towing a trailer with your vehicle. Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 161 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 162 2-5. Driving information When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission) or to 1 or R (manual transmission) without setting the parking brake.
Page 163 NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 164 Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 165 For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Weight limits Confirm the total trailer weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits.
Page 166 2-5. Driving information Trailer tongue load The trailer cargo load should be distributed so that the tongue load is 9 to 11% of the total trailer weight, not exceeding the maximum 70 lb. (32 kg) (Tongue load / Total trailer weight × 100 = 9 to 11%) The total trailer weight and tongue load can be measured with platform scales found at a highway weighing station, building...
Page 167 Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bearings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
Page 168 If you wish to install a trailer hitch, your Toyota dealer should be consulted. Use only a hitch that conforms to the total trailer weight requirement.
Page 169 2-5. Driving information NOTICE When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Brakes Toyota recommends trailers with brakes that conform to any applicable fed- eral and state/provincial regulations.
Page 170 2-5. Driving information l Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to the right.
Page 171 2-5. Driving information l In order to maintain engine braking efficiency, do not use the trans- mission in D (automatic transmission) or 5 (manual transmission). l Due to the added load of the trailer, your vehicle’s engine may overheat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade.
Page 172 2-5. Driving information CAUTION To avoid an accident Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.
Page 173 2-5. Driving information Dinghy towing (vehicles with an automatic transmission) Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y :...
Page 174 2-5. Driving information Dinghy towing (vehicles with a manual transmission) Your vehicle can be dinghy towed in a forward direction (with 4 wheels on the ground) behind a motor home. Dinghy towing does not elimi- nate the possibility of damage to your vehicle.
Page 175 2-5. Driving information NOTICE Dinghy towing direction Do not tow the vehicle backwards. Doing so may cause serious damage. To prevent the steering from locking Ensure the engine switch is in the ACC position. I n f o r ma t i o n P r o v i d e d b y :...
Page 176 3-1. Using the air conditioning system and defogger Air conditioning system Air conditioning ON/OFF switch Fan speed control dial Air outlet selection dial Air intake selection dial Temperature control dial Adjusting the settings Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 177 3-1. Using the air conditioning system and defogger Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Set the dial to “0” to turn the fan off. Selecting the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can also be selected for more detailed adjustment.
Page 178 3-1. Using the air conditioning system and defogger When the dial is set to mainly air flows to the feet. : Some models When the dial is set to , air flows to the feet and the wind- shield defogger operates. : Some models When the dial is set to , air...
Page 179 3-1. Using the air conditioning system and defogger Adjusting the position of the air outlets Center outlets Direct air flow to the left or right, up or down. I n f o r ma t i o n P r o v i d e d b y :...
Page 180 3-1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the right and left side outlets Open the vent. Close the vent. I n f o r ma t i o n P r o v i d e d b y :...
Page 181 3-1. Using the air conditioning system and defogger Using the system in recirculated air mode The windows will fog up more easily if the recirculated air mode is used for an extended period. When outside air temperature approaches 32°F (0°C) The air conditioning system may not operate even when is pressed.
Page 182 3-1. Using the air conditioning system and defogger ∗ Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. On/off Press the button to turn on the rear window defogger.
Page 183 3-1. Using the air conditioning system and defogger NOTICE To prevent battery discharge Do not leave the rear window defogger on longer than necessary when the engine is stopped. I n f o r ma t i o n P r o v i d e d b y :...
Page 184 3-2. Using the audio system Audio system types CD player with external CD changer controller and AM/FM radio. Type A Type B I n f o r ma t i o n P r o v i d e d b y :...
Page 185 3-2. Using the audio system Title Page Using the radio P. 175 Using the CD player P. 181 Playing back MP3 and WMA discs P. 187 Optimal use of the audio system P. 194 Using the AUX adapter P. 196 Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is...
Page 186 3-2. Using the audio system NOTICE To prevent battery discharge Do not leave the audio system on longer than necessary with the engine off. To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system. I n f o r ma t i o n P r o v i d e d b y :...
Page 187: Using The Radio
3-2. Using the audio system Using the radio Type A Frequency adjust Power Volume (AM, FM mode) or Station selector channel (SAT mode) Station scan AM·SAT/FM mode but- Text message display Frequency seek (SAT mode) Type B Frequency adjust Power Volume (AM, FM mode) or channel (SAT mode)
Page 188 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning ∧ pressing “ ” or “∨” on Press and hold the button (from ) that the station is to be set to until you hear a beep. ®...
Page 189 3-2. Using the audio system Turn to select the desired channel in the all ∧ categories or press “ ” or “∨” on select the desired channel in the current category. ® Setting XM Satellite Radio channel presets Select the desired channel. Press and hold the button (from ) that the channel is to be set to until you hear a beep.
Page 190 ® : Use of XM Satellite Radio requires XM tuner and service. Contact your Toyota dealer. When the battery is disconnected Stations presets are erased. Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 191 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
Page 192 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877-438-9677 (Canada).
Page 193: Using The Cd Player
3-2. Using the audio system Using the CD player Type A Power Volume CD selection (with external CD changer only) CD eject Playback Repeat play Random playback Text message display Track selection Search playback Reverse Fast-forward Type B CD selection Power Volume (with external CD changer only)
Page 194 3-2. Using the audio system Loading a CD Insert a CD. Ejecting a CD Press and remove the CD. Selecting and scanning a track Selecting a track ∧ Press “ ” to move up or “∨” to move down using until the desired track number is displayed.
Page 195 3-2. Using the audio system The first 10 seconds of the first track on each CD will be played. Press the switch again when the desired CD is reached. Repeat play Repeating a track Press (RPT) or (RPT). Repeating all of the tracks on a CD (with external CD changer only) Press and hold (RPT) or...
Page 196 3-2. Using the audio system Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 charac- ters.
Page 197 3-2. Using the audio system NOTICE CDs and adapters that cannot be used Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the CD player and/or the CD insert/eject function. CDs that have a diameter that is not 4.7 in.
Page 198 3-2. Using the audio system NOTICE CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. Do not apply oil to the CD player. Store CDs away from direct sunlight.
Page 199: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Type A Power Volume File selection Folder selection Playback Repeat play Disc eject File selection Reverse Fast-forward Search playback Random playback Text message display Type B Power Volume File selection Disc eject Fast-forward Folder selection...
Page 200 3-2. Using the audio system Loading MP3 and WMA disc Insert a disc. Ejecting MP3 and WMA disc Press and remove the disc. Selecting a folder Selecting folders one at a time To select the desired folder, press “∧” or “∨” on Selecting the desired folder by cueing the first file of each folder Press and hold...
Page 201 3-2. Using the audio system Scanning the desired file by cueing the files in the folder Press The first 10 seconds of all files in the folder will be played. When the desired file is reached, press the switch once again. Fast-forwarding and reversing files To fast-forward or reverse.
Page 202 3-2. Using the audio system Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 charac- ters.
Page 203 3-2. Using the audio system Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
Page 204 3-2. Using the audio system Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 205 3-2. Using the audio system Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 206: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Type A Displays the current mode Changes the following set- ting Sound quality and volume balance (→P. 195) The sound quality and bal- ance setting can be changed to produce the best sound. Type B Using the AUDIO CONTROL function Changing sound quality modes...
Page 207 3-2. Using the audio system Adjusting sound quality Turning adjusts the level. Sound qual- Mode Turn to the Turn to the Level ity mode displayed left right Bass -5 to 5 High Treble -5 to 5 Front/rear Shifts to volume R7 to F7 Shifts to rear front...
Page 208: Using The Aux Adapter
3-2. Using the audio system ∗ Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable audio device. Type A Press Type B Press ∗...
Page 209 3-2. Using the audio system Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet or cigarette lighter Noise may occur during playback.
Page 210 DOOR position, the light will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 359)
Page 211 3-3. Using the interior lights Interior light and personal lights Interior light DOOR position Personal lights On/off I n f o r ma t i o n P r o v i d e d b y :...
Page 212 3-4. Using the storage features List of storage features Cup holders Glove box Bottle holders Console box Auxiliary box CAUTION Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 213 3-4. Using the storage features Glove box and console box Glove box Pull up the lever. CAUTION Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Console box Lift the lid while pulling the lever. I n f o r ma t i o n P r o v i d e d b y :...
Page 214 3-4. Using the storage features Console box and cup holders CAUTION Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Cup holders (front) Push on the lid. CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.
Page 215 3-4. Using the storage features Cup holders Cup holders (rear) Type A Pull the lid down. Type B (if equipped) Pull the armrest down. CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 216 3-4. Using the storage features Bottle holders and auxiliary box Bottle holders Bottle holders Depending on their size or shape, some bottles may not fit in the holders. NOTICE Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
Page 217 3-4. Using the storage features Auxiliary box CAUTION Caution while driving Keep the auxiliary box closed. Injuries may result in the event of an accident or sudden braking. When use the auxiliary box Do not use the auxiliary box as an ashtray. I n f o r ma t i o n P r o v i d e d b y :...
Page 218 3-5. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. I n f o r ma t i o n P r o v i d e d b y :...
Page 219 3-5. Other interior features Vanity mirrors Slide the cover. I n f o r ma t i o n P r o v i d e d b y :...
Page 220 3-5. Other interior features Clock Press and hold the CLOCK button to enter the adjustment mode for the clock. Press the CLOCK button to adjust the hours. After adjusting the hours, wait 5 seconds to allow the hours to be automatically input.
Page 221 3-5. Other interior features ∗ Portable ashtray The ashtray can be installed in a cup holder. (→P. 202) CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of emergency braking, sudden swerving or an accident. To prevent fire Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
Page 222 3-5. Other interior features ∗ Cigarette lighter Push cigarette lighter down. The cigarette lighter will pop up when it is ready for use. The cigarette lighter can be used when The engine switch is in the ACC or ON position. CAUTION To avoid burns or fires Do not touch the metal parts of the cigarette lighter.
Page 223 3-5. Other interior features ∗ Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. The power outlet can be used when The engine switch is in the ACC or ON position. NOTICE To avoid damaging the power outlet Close the power outlet lid when the power outlet is not in use.
Page 224 3-5. Other interior features ∗ Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest Do not place too much strain on the armrest. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 225 When installing the driver’s floor mat Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver’s seat. Always install the floor mat securely using the retaining hooks (clips) pro- vided.
Page 226 3-5. Other interior features CAUTION Before driving Check that the floor mat is securely fixed in the right place with all the pro- vided retaining hooks (clips). Be espe- cially careful to perform this check after cleaning the floor. With the engine stopped and the shift lever in P (automatic transmission) or N (manual transmission), fully depress each pedal to the floor to make sure it...
Page 227 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 228 4-1. Maintenance and care CAUTION Caution about the exhaust pipe Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns. NOTICE To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.)
Page 229 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 230 4-1. Maintenance and care Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 231 4-1. Maintenance and care NOTICE Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Do not use polish wax or polish cleaner.
Page 232 Warranty Information Booklet”, “Owner’s Manual Supplement”. Repair and replacement It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 233 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 234 “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 235 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 236 4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Doors/trunk • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? •...
Page 237 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...
Page 238 • FMVSS No.116 DOT 3 or SAE Brake fluid level (→P. 240) J1703 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 239 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- Light bulbs (→P. 274) age rating as original • Flathead screw driver Radiator and condenser ⎯ (→P. 240) • Tire pressure gauge Tire inflation pressure (→P. 252) •...
Page 240 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 241 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. If the brake fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 242 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. Hold the hood open by insert- ing the supporting rod into the slot.
Page 243 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear I n f o r ma t i o n P r o v i d e d b y :...
Page 244 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 245 4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 244) Fuse box (→P. 263) Engine oil filler cap Condenser (→P. 240) (→P. 235) Electric cooling fan Engine oil level dipstick Engine coolant reservoir (→P. 235) (→P. 239) Radiator cap Radiator (→P.
Page 246 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
Page 247 4-3. Do-it-yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 248 1000 km) If you consume more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles (1000 km), contact your Toyota dealer. After changing the engine oil (except Canada) The oil change system should be reset. Perform the following procedures: Turn the engine switch off with the Trip A reading shown.(→P.
Page 249 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 250 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
Page 251 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser as they may be hot and may cause burns.
Page 252 4-3. Do-it-yourself maintenance Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency.
Page 253 4-3. Do-it-yourself maintenance Battery Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 254 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: Do not cause sparks by touching the battery terminals with tools.
Page 255 4-3. Do-it-yourself maintenance NOTICE When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the low washer fluid warning light comes on (if equipped), the washer tank may be empty.
Page 256 4-3. Do-it-yourself maintenance CAUTION When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 257 The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise.
Page 258 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 259 4-3. Do-it-yourself maintenance If the tread wears down below 0.16 in. (4 mm) on snow tires The effectiveness of snow tires is lost. Maximum load of tire Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater.
Page 260 4-3. Do-it-yourself maintenance Routine tire inflation pressure checks The tire pressure warning system does not replace routine tire inflation pressure checks. Make sure to check tire inflation pressure as part of your routine of daily vehicle checks. Tire pressure warning system certification MODEL/FCC IDs: Transmitter: PAXPMV107J Receiver: HYQ13BCG...
Page 261 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 262 When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
Page 263 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 346) I n f o r ma t i o n P r o v i d e d b y :...
Page 264 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the graduations of the gauge. If the tire inflation pressure is not within the recommended levels, adjust inflate the tire.
Page 265 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 266 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling Possibility of blowouts resulting from overheated tires Poor sealing of the tire bead Wheel deformation and/or tire separation A greater possibility of tire damage from road hazards...
Page 267 Used wheels l Bent wheels that have been straightened Aluminum wheel precautions (if equipped) l Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 268 4-3. Do-it-yourself maintenance When replacing wheels The wheels of your Toyota, except for the compact spare tire, are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be installed.
Page 269 4-3. Do-it-yourself maintenance ∗ Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the claws.
Page 270 4-3. Do-it-yourself maintenance Pinch the latches. Remove the filter cover. Pull out the filter. Rotate the filter to remove it. Installing method Set a new filter. The “↑UP” marks shown on the filter should be pointing up. Rotate the filter. Push in the filter.
Page 271 4-3. Do-it-yourself maintenance Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.) If air flow from the vents decreases dramatically The filter may be clogged.
Page 272 4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. You will need the following items: l Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with plastic tape.) l Lithium battery CR2016 Replacing the battery Remove the cover.
Page 273 The wireless remote control will not function properly. The operational range is reduced. Use a CR2016 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 274 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 275 4-3. Do-it-yourself maintenance Under the instrument panel Type A 1. Open the auxiliary box. 2. Pull up the box and disen- gage the claws. Remove the stoppers from the cut- outs and remove the box. Type B Remove the lid. I n f o r ma t i o n P r o v i d e d b y :...
Page 276 4-3. Do-it-yourself maintenance After a system failure, see “Fuse layout and amperage ratings” (→P. 267) for details about which fuse to check. Remove the fuse with the pull- out tool. Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 277 The amperage rating can be found on the fuse box lid Type C Normal fuse Blown fuse Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 278 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment (type A) Fuse Ampere Circuit Charging system, HTR SUB2, EPS, ABS1/VSC1, HTR, ABS2/ 120 A VSC2, HTR SUB1,RDI, DEF, FR FOG, OBD2, D/L, POWER, RR DOOR, RL DOOR, STOP and AM1 EFI, HORN, AM2, ALT-S, DOME, ST, ECU-B, ETCS, HAZ, H-LP LH/ MAIN...
Page 279 4-3. Do-it-yourself maintenance Engine compartment (type B) Fuse Ampere Circuit Starting system, multiport fuel 15 A injection system/sequential multi- port fuel injection system HORN 10 A Horn Multiport fuel injection system/ 20 A sequential multiport fuel injection system SPARE 30 A Spare fuse SPARE 10 A...
Page 280 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Daytime running light system, front passenger occupant classification system, power windows, door lock ECU-B 7.5 A system, theft deterrent system, meter and gauge, traction control system, vehicle stability control system ALT-S 7.5 A Charging system Multiport fuel injection system/ sequential multiport fuel injection ETCS...
Page 281 4-3. Do-it-yourself maintenance Under the instrument panel (type A) Fuse Ampere Circuit ACC2 7.5 A Shift lock system 40 A Rear window defogger POWER 30 A Power windows I n f o r ma t i o n P r o v i d e d b y :...
Page 282 4-3. Do-it-yourself maintenance Under the instrument panel (type B) Fuse Ampere Circuit Side marker lights, parking lights, tail lights, license plate lights, multi- TAIL 10 A port fuel injection system/sequen- tial multiport fuel injection system Illuminations, instrument panel light PANEL 1 7.5 A control, meter and gauge Rear window defogger, air condi-...
Page 283 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection ID/UP/MIR HTR 10 A system, outside rear view mirror control, outside rear view mirror heaters Multiport fuel injection system/ sequential multiport fuel injection 7.5 A system, SRS airbag system, front passenger occupant classification system 7.5 A...
Page 284 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.
Page 285 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 286 4-3. Do-it-yourself maintenance Rear bulb locations Stop/tail and rear High mounted stoplight side marker lights (vehicles without the rear spoiler) License Rear turn signal lights plate lights Back-up lights Replacing light bulbs Headlights and daytime running lights (if equipped) Unplug the connector. Remove the rubber cover.
Page 287 4-3. Do-it-yourself maintenance Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole. Front fog lights (if equipped) Remove the bolts and clips. Partly remove the fender liner. I n f o r ma t i o n P r o v i d e d b y :...
Page 288 4-3. Do-it-yourself maintenance Unplug connector while depressing the lock release. Turn the bulb counterclockwise. Front side marker lights Remove the bolts and clips. Partly remove the fender liner. I n f o r ma t i o n P r o v i d e d b y :...
Page 289 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Remove the light bulb. Front turn signal/parking lights Remove the bolts and clips. Partly remove the fender liner. I n f o r ma t i o n P r o v i d e d b y :...
Page 290 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Remove the light bulb. Back-up lights, stop/tail and rear side marker lights and rear turn signal lights Open the trunk lid and remove the clip. I n f o r ma t i o n P r o v i d e d b y :...
Page 291 4-3. Do-it-yourself maintenance Partly remove the cover and turn the bulb bases counterclock- wise. Stop/tail and rear side marker lights Rear turn signal light Back-up light Remove the light bulb. Stop/tail and rear side marker lights Rear turn signal light Back-up light High mounted stoplight (vehicles without the rear spoiler) Disengage the claws.
Page 292 4-3. Do-it-yourself maintenance Unplug the connector. Turn the bulb base counterclock- wise. Remove the light bulb. License plate lights Open the trunk lid. If equipped: Remove the clips and partly remove the cover. I n f o r ma t i o n P r o v i d e d b y :...
Page 293 The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. I n f o r ma t i o n P r o v i d e d b y :...
Page 294 4-3. Do-it-yourself maintenance Installing the clips Insert the clips. CAUTION Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. To prevent damage or fire Make sure bulbs are fully seated and locked.
Page 295 4-3. Do-it-yourself maintenance I n f o r ma t i o n P r o v i d e d b y :...
Page 296 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 297 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 298 5-1. Essential information Emergency towing procedure Release the parking brake. Put the transmission in N. Turn the engine switch to the ACC (engine off) or ON (engine run- ning) position. CAUTION Caution while towing Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelet and the cables or chains.
Page 299 5-1. Essential information Installing towing eyelet Remove the eyelet cover using a flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. Insert the towing eyelet into the hole and tighten partially by hand.
Page 300 5-1. Essential information CAUTION Installing towing eyelet to the vehicle Make sure that towing eyelet is installed securely. If not securely installed, towing eyelet may come loose during towing. This may lead to accidents that cause serious injury or even death. Towing with a sling-type truck NOTICE To prevent body damage...
Page 301 5-1. Essential information NOTICE To prevent damaging the vehicle When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed. Towing with a wheel lift-type truck from the rear Vehicles with an automatic trans- mission: Use a towing dolly under the front wheels.
Page 302 5-1. Essential information Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in Front the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 303 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 304 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 305 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 306 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained...
Page 307 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* •...
Page 308 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp...
Page 309 5-2. Steps to take in an emergency Warning light Warning light/Details SRS warning light Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; • The seat belt pretensioner system. ABS warning light (if equipped) (except Canada) Indicates a malfunction in: •...
Page 310 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light Check that all doors Indicates that a door is are closed.
Page 311 (except Canada) • When the light comes on Have the system after blinking for 1 checked by your minute: Malfunction in Toyota dealer. the tire pressure warning system. Low washer fluid warn- ing light Fill the tank. (if equipped)
Page 312 5-2. Steps to take in an emergency : Driver’s seat belt reminder: The driver’s seat belt reminder sounds to alert the driver that his or her seat belt is not fastened. Once the engine switch is turned to the ON or START position, the buzzer sounds for 6 seconds.
Page 313 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Front passenger detection sensor and passenger seat belt reminder If luggage or other load is placed on the front passenger seat, depending on its weight, the reminder light to flash and buzzer to sound.
Page 314 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 315 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 316 5-2. Steps to take in an emergency CAUTION Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
Page 317 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to P (automatic transmission) or R (manual transmission).
Page 318 5-2. Steps to take in an emergency Taking out the jack Move the driver seat to the front-most position. Remove the cover. Tighten Loosen Taking out the spare tire Loosen the center fastener that secures the spare tire. I n f o r ma t i o n P r o v i d e d b y :...
Page 319 5-2. Steps to take in an emergency Compact spare tire The compact spare tire saves space in your luggage compartment, and its lighter weight helps to enhance fuel economy and permits easier installation in case of a flat tire. compact spare tire designed for temporary emer-...
Page 320 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left- the front...
Page 321 5-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Turn the jack portion “A” by hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is slightly raised off the ground.
Page 322 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 323 5-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 76 ft·lbf (103 N·m, 10.5 kgf·m) Vehicles with aluminum wheels, remove the center wheel ornament by pushing from the reverse side.
Page 324 5-2. Steps to take in an emergency If you have a flat front tire on a road covered with snow or ice Install the compact spare tire on the rear of the vehicle. Perform the fol- lowing steps and fit tire chains to the front tires. Replace a rear tire with the compact spare tire.
Page 325 5-2. Steps to take in an emergency CAUTION Using the jack Improper use of the jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 326 5-2. Steps to take in an emergency CAUTION When using the compact spare tire Remember that your compact spare tire is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. Do not use two compact spare tires simultaneously. Replace the compact spare tire with a standard tire as soon as possi- ble.
Page 327 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
Page 328 5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 110) or releasing the steering lock (→P. 110), confirm the following points. The engine will not start even when the starter motor oper- ates normally.
Page 329 One or both of the battery terminals may be disconnected. l The battery may be discharged. (→P. 322) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. I n f o r ma t i o n P r o v i d e d b y :...
Page 330 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 331 5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the key number stamped on your key number plate. Vehicles with engine immobilizer system, the dealer will also need the master key.
Page 332 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connecting the jumper cables...
Page 333 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting.
Page 334 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions Do not smoke, use matches, cigarette lighters or allow open flame near the battery. Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery.
Page 335 If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 336 (→P. 337) Have the vehicle checked at your nearest Toyota dealer as soon as possible. I n f o r ma t i o n P r o v i d e d b y :...
Page 337 5-2. Steps to take in an emergency Overheating If you observe the following, your vehicle may be overheating. The high engine coolant temperature warning light flashes or comes on or a loss of power is experienced. Steam is coming from under the hood. CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle...
Page 338 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P (vehicles with an automatic transmission) or N (vehicles with a manual transmission).
Page 339 5-2. Steps to take in an emergency CAUTION When attempting to free a stuck vehicle If you choose to rock the vehicle back and forth to free it, make sure the sur- rounding area is clear, to avoid striking other vehicles, objects or persons. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 340 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 341 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 169.3 in. (4300 mm) Overall width 66.5 in. (1690 mm) Overall height 57.5 in. (1460 mm) Wheelbase 100.4 in. (2550 mm) 58.3 in. (1480 mm) Front 57.9 in. (1470 mm) Tread 57.9 in.
Page 342 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 343 6-1. Specifications This number is also on the Certi- fication Label. Engine number The engine number is stamped on the engine block as shown. I n f o r ma t i o n P r o v i d e d b y :...
Page 344 6-1. Specifications Engine Model 1NZ-FE Type 4-cylinder in line, 4-cycle, gasoline 2.95 × 3.33 in. (75.0 × 84.7 mm) Bore and stroke Displacement 91.3 cu.in. (1497 cm 68 — 90 lbf (300 — 400 N, 31 — 41 kgf) Generator Water pump Drive belt tension Crankshaft...
Page 345 Without filter 3.6 qt. (3.4 L, 3.0 Imp.qt.) Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toy- ota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 346 Capacity Vehicles with a manual transmission 5.1 qt. (4.8 L, 4.2 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 347 6-1. Specifications Ignition system Spark plug Make DENSO SK16R11 IFR5A11 0.043 in. (1.1 mm) NOTICE Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine. Electrical system Battery 12.6 ⎯ 12.8 V Fully charged Open voltage at 12.2 ⎯...
Page 348 If replacement is necessary, contact your Toyota dealer. NOTICE Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
Page 349 6-1. Specifications Brakes Pedal clearance Vehicle without the VSC Without the ABS 2.8 in. (70 mm) Min. With the ABS 2.9 in. (73 mm) Min. Vehicle with the VSC 3.0 in. (76 mm) Min. 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm) Pedal free play Brake pad wear limit 0.04 in.
Page 350 6-1. Specifications Tires and wheels Tire size P175/65R14 81S, P185/60R15 84T Driving under normal conditions Front tires: 32 psi (220 kPa, 2.2 kgf/cm or bar) Rear tires: 32 psi (220 kPa, 2.2 kgf/cm or bar) Tire inflation pressure Driving at high speeds above 100 mph (Recommended cold tire (160 km/h) (in countries where such inflation pressure)
Page 351 6-1. Specifications Light bulbs Light Bulbs Bulb No Type Headlights — 60/55 Front fog lights — (if equipped) Front side marker — lights Front turn signal/park- — 21/5 ing lights Exterior Rear turn signal lights — Stop/tail and rear side —...
Page 352 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
Page 353 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
Page 354 6-1. Specifications NOTICE Notice on fuel quality Do not use improper fuels. If improper fuels are used the engine will be damaged. Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction. Do not use gasohol other than that stated here.
Page 355 6-1. Specifications Tire information Typical tire symbols Standard tire Tire size (→P. 350) DOT and Tire Identification Number (TIN) (→P. 349) Location of treadwear indicators (→P. 351) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 356 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (→P. 351) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
Page 357 6-1. Specifications Compact spare tire TEMPORARY USE ONLY (→P. 309) A compact spare tire is identified by the phrase TEMPORARY USE ONLY molded into its sidewall. This tire is designed for temporary emergency use only. Tire size (→P. 350) DOT and Tire Identification Number (TIN) (→P.
Page 358 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Typical DOT and tire identification number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire...
Page 359 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 360 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 361 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 362 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 363 6-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb...
Page 364 6-1. Specifications Tire related term Meaning The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles...
Page 365 6-1. Specifications Tire related term Meaning (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall (b)The outward facing sidewall of asymmetrical tire that has a particular side that must...
Page 366 6-1. Specifications Tire related term Meaning A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that...
Page 367 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indica- designed to give a visual indication of the...
Page 368 Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
Page 369 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation after the Illumination engine switch is turned → P. 198) to the LOCK position Operation when the doors are unlocked Seat Belt Vehicle speed linked Reminder...
Page 370 6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Engine oil maintenance After changing engine oil P.
Page 371 6-2. Customization I n f o r ma t i o n P r o v i d e d b y :...
Page 372 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 373 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. I n f o r ma t i o n P r o v i d e d b y :...
Page 374 I n f o r ma t i o n P r o v i d e d b y :...
Page 375 Alphabetical index Alphabetical index A/C ..........164 Optimal use ......194 Portable music player....196 ABS ........139 Radio........175 Warning light ......298 Type ........172 Air conditioning filter....258 Automatic transmission Air conditioning system Automatic transmission ..114 Air conditioning filter ..... 258 Fluid ........339 Air conditioning system ..
Page 376 Alphabetical index Child restraint system Console box ......201 Booster seats, definition..86 CRS ..........86 Booster seats, installation ..90 Cruise control Convertible seats, definition ..86 Cruise control......136 Convertible seats, Indicator ........ 136 installation......90 Cup holders......202 Front passenger occupant Curtain shield airbags ....69 classification system .....81 Customizable features ....
Page 377 Alphabetical index If the warning buzzer Warning light ......298 sounds ....... 297 Engine switch......110 If the warning light turns on .. 297 Engine oil maintenance If you have a flat tire .... 307 data .........237 If you lose your keys..... 321 If you think something is EPS ........139 wrong .........
Page 378 Alphabetical index Gas station information ..380 Inside rear view mirror ....52 Gauge ........121 Interior light Information ......343 Switch ........199 Refueling .........58 Wattage......... 342 Type ........335 Warning light ......300 Jack Fuel door........58 Positioning a floor jack ..232 Fuel filler door ......58 Vehicle-equipped jack...
Page 379 Alphabetical index Tail lights switch ....130 Outside rear view mirrors Turn signal lights switch ..117 Adjusting .........53 Load capacity ......147 Defogger .......170 Lock steering column ..... 112 Folding ........54 Overheating, Engine ....325 Maintenance Do-it-yourself Parking brake ......118 maintenance ......
Page 380 Alphabetical index Seat belts Switch ........130 Adjustment ......45 Wattage......... 342 ALR .........47 Side mirror Automatic Locking Retractor ...47 Adjusting .........53 Child restraint system Defogger ....... 170 installation.......86, 90 Folding ........54 Cleaning and maintaining..219 Spare tire ELR .........47 Identification number..... 346 Emergency Locking Inflation pressure ..
Page 381 Alphabetical index Ignition switch....... 110 Tire pressure warning Hazard lights switch ..... 286 system ......246, 300 Headlights switch ....130 Warning light ......300 Light switch......130 Tools .........307 Power door lock switch... 28 Total load capacity....147 Power window switch ..... 56 Towing Turn signal lights ....
Page 382 Alphabetical index Front passenger occupant Wireless remote control key classification system ...298 Replacing the key battery ..261 Front passenger’s seat belt...300 Wireless remote control ..26 High engine coolant WMA disc........187 temperature ......298 Low brake fluid ......297 Low engine oil pressure ..298 Low fuel level ......300 Low tire inflation pressure ..300 Low washer fluid ....300...
Page 383 What to do if... What to do if... A tire punctures If you have a flat tire P. 307 P. 318 If the engine will not start The engine does not start P. 62 Engine immobilizer system P. 322 If the vehicle battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 384 What to do if... The warning light or indicator If a warning light turns on P. 297 light comes on Instrument cluster Vehicles with Optitron type meters Vehicles without Optitron type meters Center panel I n f o r ma t i o n P r o v i d e d b y :...
Page 385 What to do if... nWarning lights Brake system warning Engine oil replacement light reminder light P. 301 SRS warning light P. 297 P. 299 Charging system warning Electric power steering light warning light P. 298 P. 299 Open door warning light Low engine oil pressure warning light P.
Page 386: Gas Station Information
With filter 3.9 (3.7, 3.3) (Drain and refill) Without filter 3.6 (3.4, 3.0) Toyota Genuine Motor Oil or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil. P. 336 Recommended oil viscosity: SAE 5W-30 I n f o r ma t i o n P r o v i d e d b y :...

This manual is also suitable for:

2011 yaris

Toyota 2010 YARIS SEDAN Quick Reference Manual

Quick Links

QUICK REFERENCE

Related Manuals for Toyota 2010 YARIS SEDAN

Summary of Contents for Toyota 2010 YARIS SEDAN

This manual is also suitable for:

Table of Contents
