Summary of Contents for Toyota HILUX 2011

  • Page 2 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Air conditioning as well as other interior features for a Interior features comfortable driving experience. Maintenance and Cleaning and protecting your vehicle, performing do-it- care yourself maintenance, and maintenance information.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Index 1-5. Refueling Before driving Opening the fuel tank cap ..74 1-6. Theft deterrent system 1-1. Key information Engine immobilizer Keys........34 system........ 80 1-2. Opening, closing and locking 1-7. Safety information the doors Correct driving posture..82 Wireless remote control ..

  • Page 4: Table Of Contents

    2-4. Using other driving systems When driving Cruise control ..... 167 Four-wheel drive system......171 2-1. Driving procedures Driving assist systems..174 Driving the vehicle ....116 Engine (ignition) switch..131 2-5. Driving information Automatic transmission..135 Cargo and luggage..... 180 Manual transmission...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Index 3-4. Other interior features Interior features Sun visors ......226 Vanity mirror....... 227 Clock ........228 3-1. Using the air conditioning Ashtray ....... 229 system and defogger Cigarette lighter....230 Manual air conditioning Power outlet ....... 231 system ......

  • Page 6: Table Of Contents

    Maintenance and care When trouble arises 4-1. Maintenance and care 5-1. Essential information Cleaning and protecting Emergency flashers ... 328 the vehicle exterior ... 244 If your vehicle needs Cleaning and protecting to be towed ...... 329 the vehicle interior .... 248 If you think something is wrong .......

  • Page 7: Table Of Contents

    TABLE OF CONTENTS Index Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.).... 380 Fuel information ....400 6-2. Initialization Items to initialize ....402 Index Abbreviation list....404 Alphabetical index .... 405 What to do if...... 416...
  • Page 9 Pictorial index Exterior Single-cab models Windshield wipers P. 164 Side turn signal lights P. 143 Outside rear view mirrors P. 66 Hood P. 268 Headlights P. 160 Front turn signal lights P. 143 Front position lights P. 160...
  • Page 10 Stop/tail lights P. 160 ∗ Tailgate P. 42 Side doors P. 38 Rear step bumper P. 43 ∗ Fuel filler door License plate lights P. 74 P. 160 Tires Rear turn signal lights P. 143 ●Rotation P. 287 ●Replacement P. 343 ●Inflation pressure P.
  • Page 11 Pictorial index Exterior Extra-cab models ∗ Windshield wipers P. 164 Side turn signal lights P. 143 Outside rear view mirrors P. 66 Hood P. 268 ∗ Side turn signal lights P. 143 Headlights P. 160 Front turn signal lights P. 143 ∗...
  • Page 12 ∗ Back window P. 73 Stop/tail lights P. 160 ∗ Rear window defogger P. 214 ∗ Tailgate P. 42 Side doors P. 38 Rear step bumper P. 43 ∗ Fuel filler door License plate lights P. 74 P. 160 Tires Rear turn signal lights P.
  • Page 13 Pictorial index Exterior Double-cab models ∗ Windshield wipers P. 164 Side turn signal lights P. 143 Outside rear view mirrors P. 66 Hood P. 268 ∗ Side turn signal lights P. 143 Headlights P. 160 Front turn signal lights P. 143 ∗...
  • Page 14 ∗ Back window P. 73 Stop/tail lights P. 160 ∗ Rear window defogger P. 214 ∗ Tailgate P. 42 Side doors P. 38 Rear step bumper P. 43 ∗ Fuel filler door License plate lights P. 74 P. 160 Tires Rear turn signal lights P.
  • Page 15 Pictorial index Interior Head restraints P. 53 SRS front passenger airbag P. 84 Seat belts P. 56 ∗ Power window switch Cup holder P. 69 P. 220 ∗ Floor mat P. 232 Bottle holder P. 223 ∗ Front seats P. 45 Rear seats P.
  • Page 16 Interior light P. 216 ∗ Personal lights P. 216 ∗ Auxiliary box P. 224 ∗ SRS curtain shield airbags P. 84 Sun visors P. 226 Vanity mirrors P. 227 Anti-glare inside rear view mirror P. 64 ∗ : If equipped...
  • Page 17 Pictorial index Interior Inside lock button P. 39 ∗ Door lock switch P. 39 ∗ Window lock switch P. 70 ∗ Power window switches P. 69 Bottle holder P. 223...
  • Page 18 Vehicles with automatic transmission (2WD models) Shift lever P. 135 Auxiliary box P. 224 Cup holders P. 220 Parking brake lever P. 144 Shift lock override button P. 362 ∗ : If equipped...
  • Page 19 Pictorial index Interior Vehicles with automatic transmission (4WD models) Front drive control lever P. 171 Shift lever P. 135 Cup holder P. 220 Auxiliary box P. 224 Parking brake lever P. 144 Shift lock override button P. 362...
  • Page 20 Vehicles with manual transmission ∗ Front drive control lever P. 171 Auxiliary box P. 224 Shift lever P. 140 Parking brake lever P. 144 Cup holder P. 220 ∗ : If equipped...
  • Page 21 Pictorial index Instrument panel Cup holder P. 220 Headlight switch P. 160 Turn signal lever P. 143 ∗ Fog light switch P. 163 Gauge and meters P. 146 Glove box Tilt steering lock release lever P. 218 P. 63 Windshield wipers and washer switch P.
  • Page 22 Vehicles without automatic air conditioning system Front passenger’s seat belt reminder light P. 341 Clock P. 228 Air conditioning system P. 200 Emergency flasher switch P. 328 ∗ : If equipped...

  • Page 23: Instrument Panel

    Pictorial index Instrument panel Vehicles with automatic air conditioning system Front passenger’s seat belt reminder light P. 341 Multi-information display P. 154 Clock P. 228 Rear window defogger Air conditioning system P. 206 ∗ switch P. 214 Emergency flasher switch P.
  • Page 24 ∗ Ashtray Power heater switch P. 229 P. 213 ∗ Power outlet P. 231 Cigarette lighter P. 230 ∗ ∗ Rear window defogger switch VSC OFF switch P. 175 P. 214 ∗ : If equipped...
  • Page 25 Pictorial index Instrument panel ∗ Cruise control switch P. 167 ∗ ∗ Audio remote control switches “DISP” button P. 155 P. 241 SRS driver airbag P. 84 Horn P. 145 ∗ Telephone switch P. 241 Engine (ignition) switch P. 131...
  • Page 26 ∗ Outside rear view mirror switches P. 66 Security indicator P. 80 Instrument cluster light ∗ control dial P. 148 Hood lock release lever P. 268 ∗ Fuel filler door opener P. 74 ∗ : If equipped...

  • Page 27: For Your Information

    Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and accessories which are not genuine Toyota products may adversely affect the safety of your vehicle, even though these parts may be approved by certain authorities in your country.
  • Page 28 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Scrapping of your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals.
  • Page 29 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 30 Checking your vehicle’s model Check the model code to see what type of model your vehicle is. G G N 1 – T Basic code GGN: Models with 1GR-FE engine TGN: Models with 2TR-FE engine KUN: Models with 1KD-FTV engine Driving system 1: 2WD models 2: 4WD models...
  • Page 31 The label is placed as shown in the following illustrations. The manufacturer’s label is located beside the engine compartment.
  • Page 32 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 34 Before driving 1-1. Key information 1-4. Opening and closing the windows Keys........34 Power windows....69 1-2. Opening, closing and locking Quarter windows (extra-cab models).... 72 the doors Back window (vehicles Wireless remote control ..36 with sliding type) ....73 Side doors ......
  • Page 35 1-1. Key information Keys The following keys are provided with the vehicle. Type A Master keys Valet key Key number plate Type B Master keys (with wireless remote control function) Operating the wireless remote control function (→P. 36) Valet key Key number plate...
  • Page 36 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 363) ■...
  • Page 37 1-2. Opening, closing and locking the doors ∗ Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Unlocks all the doors ∗ : If equipped...
  • Page 38 1-2. Opening, closing and locking the doors ■ Operation signals The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: once; Unlocked: twice) ■ Security feature If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.
  • Page 39 1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the wireless remote control, key or door lock switch. ■ Wireless remote control (if equipped) →P. 36 ■ Turning the key operates the doors as follows: Locks all the doors Unlocks all the doors...
  • Page 40 1-2. Opening, closing and locking the doors ■ Door lock switch Locks all the doors Unlocks all the doors ■ Inside lock buttons Locks the door Unlocks the door The driver’s door can be opened by pulling the inside handle even if the lock button is in the lock position.
  • Page 41 1-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door while pulling the door handle. STEP Rear door child-protector lock (double-cab models only) The door cannot be opened from inside the vehicle when the lock is set.
  • Page 42 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
  • Page 43 1-2. Opening, closing and locking the doors ∗ Tailgate The tailgate can be opened by the following procedures. ■ Opening the tailgate Type A Unlock the latches and open the tailgate slowly. The support cables will hold the tailgate horizontal. After closing the tailgate, try pulling it toward you to make sure it is securely locked.
  • Page 44 1-2. Opening, closing and locking the doors Lowering the tailgate Release the brackets on the sup- port cables from the lugs on both sides as shown in the illustration. Rear step bumper (if equipped) The rear step bumper is for rear end protection and easier step- up loading.
  • Page 45 1-2. Opening, closing and locking the doors CAUTION ■ Caution while driving Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not drive with the tailgate open. ● Do not get on the rear step bumper. NOTICE ■...

  • Page 46: Wheel Front Seats

    1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat (separated type) Seat position adjustment lever Vertical height adjustment dial (driver’s side only) Seatback angle adjustment lever...
  • Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Manual seat (bench type) Seat position adjustment lever (driver’s side only) Seatback angle adjustment lever...
  • Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat (driver’s side only) Seat position adjustment switch Vertical height adjustment switch Seatback angle adjustment switch...
  • Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Moving a front passenger’s seat for rear seat access (extra-cab models only) ■ Getting in the vehicle Pull the seatback angle adjust- ment lever and fold down the seatback. The seat will slide for- ward.
  • Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment ● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.

  • Page 51: Rear Seats

    1-3. Adjustable components (seats, mirrors, steering wheel) ∗ Rear seats Extra-cab models ■ Removing the rear seat cushions Unhook the lock release lever. Pull the seat cushions up and then pull toward the front of vehicle. The seat cushions can be removed separately.
  • Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) Double-cab models ■ Raising the bottom cushion Remove center head STEP restraint. Pull the strap and raise the STEP bottom cushion. The latch under the bottom cushion will release allowing the bottom cushion to be raised.
  • Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Replace center head STEP restraint. CAUTION ■ When removing the rear seat cushions Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not remove the rear seat cushions while driving. ●...

  • Page 54: Head Restraints

    1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Front seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats (if equipped) Pull the head restraints up. Down Push the head restraint down while pressing the lock release...
  • Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Pull the head restraint up while pressing the lock release button. ■ Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position.
  • Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ●...

  • Page 57: Seat Belts

    1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts 3-point type ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Fastening and releasing the seat belt To fasten the seat belt, push the plate into the buckle until a click sound is heard. To release the seat belt, press the release button. Release button ■...
  • Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision or side collision (vehi- cles with SRS side airbags and curtain shield airbags).
  • Page 60 ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation.
  • Page 61 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 62 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ For Australian owners Observe the following additional WARNINGS. WARNING: Seatbelts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;...

  • Page 64: Steering Wheel

    1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel. After adjustment, pull the lever up to secure the steering wheel.

  • Page 65: Inside Rear View Mirror

    1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions: Normal position Anti-glare position Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
  • Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.

  • Page 67: Outside Rear View Mirrors

    1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Manual adjustable type Adjust a mirror. Power adjustable type To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch.
  • Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear. ■ Mirror angle can be adjusted when (power adjustable type) The engine switch is in the “ACC” or “ON” position. CAUTION ■...
  • Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror.

  • Page 70: Windows Power Windows

    1-4. Opening and closing the windows ∗ Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing Opening One-touch opening (driver’s window only) One-touch closing (driver’s window only) : Pushing the switch in the opposite direction will stop win- dow travel partway.
  • Page 71 1-4. Opening and closing the windows Window lock switch Press the switch down to lock the passenger window switches. Use this switch to prevent chil- dren from accidentally opening or closing a passenger window. ■ The power windows can be operated when The engine switch is in the “ON”...
  • Page 72 1-4. Opening and closing the windows CAUTION ■ Closing the windows Observe the following precautions. Failure to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 73 1-4. Opening and closing the windows Quarter windows (extra-cab models) The quarter windows can be opened and closed using the latch han- dle. To open the quarter windows, pull the latch handle toward you and swing it fully out. ■ Closing the quarter windows Make sure that the quarter windows are securely closed after closing them.

  • Page 74: Back Window (Vehicles With Sliding Type)

    1-4. Opening and closing the windows Back window (vehicles with sliding type) The back window can be opened and closed using the lock release lever. To open the back window, push the lock release lever and slide the back window. ■...
  • Page 75 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: ■ Before refueling the vehicle Turn the engine switch off and ensure that all the doors and win- dows are closed. ■ Opening the fuel tank cap Type A Pull up the opener to open the STEP...
  • Page 76 1-5. Refueling Type B To unlock the fuel tank cap, STEP insert the key and turn it coun- terclockwise. Turn the fuel tank cap slowly STEP to open.
  • Page 77 1-5. Refueling Closing the fuel tank cap Type A After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction. Type B Close the fuel tank cap STEP Make sure to put the fuel tank cap with the arrow upward and turn it...
  • Page 78 Use of ethanol blended gasoline in a gasoline engine (1GR-FE engine only) Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
  • Page 79 ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 80 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface.
  • Page 81 1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi-...
  • Page 82 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the grip portion of the key is in contact with a metallic object ●...
  • Page 83 1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 45) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 84 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 85 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 86 1-7. Safety information SRS airbag system components Front airbag sensors Curtain shield airbags equipped) Driver airbag Curtain shield airbag sensors SRS warning light (if equipped) Side and curtain shield airbag Front passenger airbag sensors (if equipped) Airbag sensor assembly Side airbags (if equipped) The main SRS airbag system components are shown above.
  • Page 87 1-7. Safety information ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Vehicles without SRS curtain shield airbags: Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the seats may be hot for several minutes.
  • Page 88 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision (SRS front airbags) The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
  • Page 89 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbags (SRS side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 90 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
  • Page 91 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
  • Page 92 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
  • Page 93 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 94 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad. These items can become projectiles when the SRS driver and front passen- ger airbags deploy.
  • Page 95 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 96 ● For installation details, follow the instructions provided with the child restraint system. General installation instructions are provided in this manual. (→P. 99) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation.
  • Page 97 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Baby seat (infant seat) Child seat (convertible seat) Junior seat (booster seat)
  • Page 98 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 99 1-7. Safety information CAUTION ■ Child restraint precautions ● Vehicles with side airbags and curtain shield airbags: Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
  • Page 100 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt. Attach the top strap when installing a child restraint. 2-point type seat belt equipped) 3-point type seat belts equipped with a child restraint...
  • Page 101 1-7. Safety information Installing child restraints using a seat belt (2-point type seat belt) (if equipped) Forward-facing  Child seat (convertible seat) ■ Place the child restraint system STEP on the rear seat facing the front of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
  • Page 102 1-7. Safety information Installing child restraints using a seat belt (3-point type seat belt) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert...
  • Page 103 1-7. Safety information While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 104 1-7. Safety information Forward-facing  Child seat (convertible seat) ■ Place the child restraint system STEP on the seat facing the front of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
  • Page 105 1-7. Safety information While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 106 1-7. Safety information ■ Junior seat (booster seat) Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
  • Page 107 1-7. Safety information Removing a child restraint installed with a seat belt 2-point type seat belt equipped): Push buckle release button. 3-point type seat belt: Push the buckle release button and fully retract the seat belt.
  • Page 108 1-7. Safety information Child restraint systems with a top strap ■ Installing a child restraint anchor fitting Remove the plug or turn the parts of the floor carpet over as STEP shown in the illustration immediately behind where the child restraint will be positioned on the rear seat.
  • Page 109 1-7. Safety information Bolt (5/16”-18 UNC × 30 mm STEP [1.2 in.]) Lock washer (1.6 mm [0.06 in.] thickness) Anchor fitting (this conforms to ADR34/01.) Front of Spacers (5 mm (0.2 in.) and vehicle 10 mm [0.4 in.]) Install a bolt through the lock washer and anchor fitting, and tighten the bolt securely with the anchor fitting facing the front of...
  • Page 110 1-7. Safety information ■ Installation with a top strap Secure the child restraint system STEP using the seat belt, and move the head restraint in place at the upmost position. Attaching clip STEP Upper anchorage strap Anchor fitting Latch the hook and tighten the top strap.
  • Page 111 You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the fol- lowing item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119-22010) CAUTION ■...
  • Page 112 1-7. Safety information CAUTION ■ When installing a child restraint system ● Only put a forward facing child restraint system on the front seat when unavoid- able. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as pos- sible (if equipped).
  • Page 113 1-7. Safety information CAUTION ■ When installing a child restraint system ● Vehicles with front bench seat: Do not install a child restraint system in the center position. This seat position is not designed to hold a child restraint sys- tem.
  • Page 114 When installing a child restraint system ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system installation. ● When a junior (booster) seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder.
  • Page 115 1-7. Safety information...
  • Page 116 When driving 2-1. Driving procedures 2-2. Instrument cluster Driving the vehicle .... 116 Gauges and meters ..146 Engine (ignition) switch..131 Indicators and warning lights ....... 150 Automatic transmission ..135 Multi-information Manual transmission..140 display ......154 Turn signal lever ....143 Parking brake ....
  • Page 117 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing: ■ Starting the engine →P. 131 ■ Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. STEP (→P. 135) Release the parking brake.
  • Page 118 2-1. Driving procedures ■ Stopping Automatic transmission With the shift lever in D, depress the brake pedal. STEP If necessary, set the parking brake. STEP If the vehicle is to be stopped for an extended period of time, shift the shift lever to P or N. (→P. 135) Manual transmission While depressing the clutch pedal, depress the brake STEP...
  • Page 119 2-1. Driving procedures Manual transmission While depressing the clutch pedal, depress the brake STEP pedal. Set the parking brake. (→P. 144) STEP Shift the shift lever to N. (→P. 140) STEP If parking on a hill, shift the shift lever to 1 or R and block the wheels as needed.
  • Page 120 ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is rec- ommended: ●...
  • Page 121 2-1. Driving procedures ■ Idling time before stopping the engine (diesel engine) To prevent damage to the turbocharger, allow the engine to idle immediately after high-speed driving or driving up a hill. Driving condition Idling time Normal city driving Not necessary Constant speed of approx.
  • Page 122 2-1. Driving procedures CAUTION ■ When starting the vehicle On vehicles with automatic transmission, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■ When driving the vehicle ● Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
  • Page 123 Have the vehicle inspected by your Toyota dealer immediately. ● On vehicles with automatic transmission, do not shift the shift lever to P while the vehicle is moving.
  • Page 124 2-1. Driving procedures CAUTION ● Use engine braking (downshift) to maintain a safe speed when driving down a steep hill. Using the brakes continuously may cause the brakes to overheat and lose effectiveness. (→P. 137) ● Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear view mirrors while driving.
  • Page 125 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
  • Page 126 2-1. Driving procedures CAUTION ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
  • Page 127 The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 128 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly venti- lated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 129 On vehicles with manual transmission, if you cannot accelerate the vehicle even when the clutch is engaged and the accelerator pedal is depressed, this may mean that the clutch is slipping, and the vehicle may be rendered undriveable. Have your Toyota dealer inspect the vehicle as soon as pos- sible.
  • Page 130 2-1. Driving procedures NOTICE ■ When parking the vehicle On vehicles with automatic transmission, always shift the shift lever to P. Failure to do so may cause the vehicle to move or the vehicle may acceler- ate suddenly if the accelerator pedal is accidentally depressed. ■...
  • Page 131 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...

  • Page 132: Engine (Ignition) Switch

    2-1. Driving procedures Engine (ignition) switch ■ Starting the engine Automatic transmission (gasoline engine) Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Firmly depress the brake pedal. STEP Turn the engine switch to the “START” position to start the STEP engine.
  • Page 133 2-1. Driving procedures Manual transmission (diesel engine) Check that the parking brake is set. STEP Check that the shift lever is set in N. STEP Firmly depress the clutch pedal. STEP Turn the engine switch to the “ON” position. STEP indicator turns on.
  • Page 134 2-1. Driving procedures ■ Turning the key from “ACC” to “LOCK” Shift the shift lever to P (automatic transmission) or N (manual STEP transmission). (→P. 135, 140) Push in the key and turn to the “LOCK” STEP position. ■ If the engine does not start The engine immobilizer system may not have been deactivated.
  • Page 135 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
  • Page 136 2-1. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever 4-speed models While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 137 2-1. Driving procedures 5-speed models While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 138 2-1. Driving procedures ■ Shift position purpose Function Shift position 4-speed models 5-speed models Parking the vehicle/starting the engine Reversing Neutral Normal driving Position for engine braking Position for engine braking Position for more powerful engine braking Position for more powerful engine braking Position for maximum engine braking : To improve fuel efficiency and reduce noises, set the shift lever in the D...
  • Page 139 2-1. Driving procedures ■ Downshift restriction The maximum allowable speeds are as follows. 4-speed models Maximum speed km/h (mph) 4WD models Downshifting Front drive Front drive 2WD models control lever in control lever in H2 or H4 D → 3 150 (93) 145 (90) 3 →...
  • Page 140 2-1. Driving procedures ■ AI-SHIFT (if equipped) AI-SHIFT automatically selects the optimal gear according to driver perfor- mance and driving conditions. AI-SHIFT automatically operates when the shift lever is in the D position. The engine speed may remain high after releasing the accelerator pedal. This does not indicate a malfunction.
  • Page 141 2-1. Driving procedures ∗ Manual transmission ■ Shifting the shift lever Fully depress the clutch pedal before operating shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release clutch pedal momentarily,...
  • Page 142 2-1. Driving procedures ■ Maximum downshifting speeds Observe the downshifting speeds in the following table to prevent over-rev- ving the engine. 2WD models Maximum speed km/h (mph) Shift position 1GR-FE engine 2TR-FE engine 1KD-FTV engine 49 (30) 43 (27) 35 (22) 91 (57) 81 (50) 64 (40)
  • Page 143 2-1. Driving procedures 4WD models Maximum speed Front drive km/h (mph) Shift position control lever 1GR-FE engine 1KD-FTV engine 1, 2 1, 2 54 (34) 38 (24) H2, H4 56 (34) 39 (24) 1, 2 21 (13) 15 (9) 22 (14) 1, 2 1, 2 100 (62)
  • Page 144 2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intentions of the driver: Left turn Right turn Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
  • Page 145 2-1. Driving procedures Parking brake To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. At this time, the brake system warning light will come on. release parking brake, slightly raise the lever and lower it in com- pletely while pressing the button.

  • Page 146: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
  • Page 147 2-2. Instrument cluster Gauges and meters Non-Optitron type meters Optitron type meters...
  • Page 148 2-2. Instrument cluster Speedometer Displays the vehicle speed. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel gauge Displays the quantity of fuel remaining in the tank. Odometer/trip meter display change button →P. 148 Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven.
  • Page 149 2-2. Instrument cluster Changing the display Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the button will reset the trip meter. Instrument panel light control (if equipped) The brightness of the instrument panel lights can be adjusted by turn- ing the knob.
  • Page 150 2-2. Instrument cluster ■ The meters and display illuminate when The engine switch is in the “ON” position. ■ The brightness of the instrument panel lights When the headlight switch is turned to on, the brightness will be reduced slightly unless the control dial is turned fully clockwise. ■...

  • Page 151: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicators and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster (non-optitron type) Instrument cluster (optitron type)
  • Page 152 2-2. Instrument cluster Center panel (vehicles without multi-information display) Center panel (vehicles with multi-information display)
  • Page 153 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Four-wheel drive (→P. 143) indicator (→P. 171) (4WD models) Headlight high beam indicator (→P. 160) Tail light indicator Shift position indicators (→P.
  • Page 154 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.

  • Page 155: Multi-Information Display

    2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data including the current outside air temperature. ● Trip information (→P. 156) Displays driving range, fuel consumption and other cruising-related information. ● Clock (→P. 228)
  • Page 156 2-2. Instrument cluster Switch the display “INFO.” or “DISP” button Items displayed can be switched by pressing the “INFO.” button or “DISP” button. “RESET” button...
  • Page 157 2-2. Instrument cluster Display items ■ Outside temperature display Displays the outside temperature. The temperature range that can be displayed is from -40°C (-40°F) to 50°C (122°F). ■ Average fuel consumption Displays the average fuel consumption since the engine switch is turned to the “ON” position. •...
  • Page 158 2-2. Instrument cluster ■ Elapsed time Displays the elapsed time after the engine switch is turned to the “ON” position. • When the engine switch is turned on, time is counted from 0:00. When the time exceeds 19:59, the counter returns to 0:00. •...
  • Page 159 2-2. Instrument cluster Set up display ■ Selecting the units Unit for only the fuel consump- tion rate can be interchanged. Switch to the average fuel consumption or current fuel con- STEP sumption display. Hold down the “INFO.” button until the unit flashes. STEP Push the “RESET”...
  • Page 160 When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) ■ When “--” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ When disconnecting and reconnecting battery terminals The following information data and settings will be reset: ●...

  • Page 161: Wipers Headlight Switch

    2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: The front position, tail, license plate instrument panel lights turn on. The headlights and all lights listed above turn The headlights and all the lights listed above...
  • Page 162 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
  • Page 163 2-3. Operating the lights and wipers NOTICE ■ To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not run- ning.
  • Page 164 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights or front position lights are turned on.

  • Page 165: Windshield Wipers And Washer

    2-3. Operating the lights and wipers Windshield wipers and washer Windshield wipers without intermittent operation The wiper operation is selected by moving the lever as follows. Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer operation...
  • Page 166 2-3. Operating the lights and wipers Intermittent windshield wipers with interval adjuster The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, the wiper interval can be also adjusted. Intermittent windshield wiper operation Low speed windshield wiper operation High...
  • Page 167 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
  • Page 168 2-4. Using other driving systems ∗ Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control. Press the button again to deactivate the cruise control.
  • Page 169 2-4. Using other driving systems ■ Adjusting the set speed Increases the speed Decreases the speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releasing it.
  • Page 170 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
  • Page 171 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
  • Page 172 2-4. Using other driving systems ∗ Four-wheel drive system Use the front drive control lever to select the following transfer modes. H2 (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear. H4 (high speed position, four-wheel drive) Use this for driving only on tracks that permit the tires slide, like off- road, icy or snow-covered roads.
  • Page 173 2-4. Using other driving systems A.D.D. (automatic disconnecting differential) (if equipped) The A.D.D. can be engaged or disengaged by the shifting operations described in the following shifting procedures. Shifting between H2 and H4 Shifting from H2 to H4 Reduce your speed to less than 80 km/h (50 mph). STEP Move the front drive control lever.
  • Page 174 2-4. Using other driving systems ■ Four-wheel drive usage frequency (vehicles with A.D.D.) You should drive in four-wheel drive for at least 16 km (10 miles) each month. This will assure that the front drive components are lubricated. ■ Shifting between H2 and H4 ●...
  • Page 175 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 176 2-4. Using other driving systems When the VSC/TRC systems are operating If the vehicle is in danger of slip- ping or if any of the drive wheels spins, the slip indicator flashes to indicate that the VSC/TRC sys- tems are operating. Disabling the TRC/VSC systems If the vehicle gets stuck in fresh snow or mud, the TRC/VSC systems may reduce power from the engine to the wheels.
  • Page 177 2-4. Using other driving systems ■ Turning off both TRC and VSC systems To turn the TRC and VSC sys- tems off, press and hold the but- ton for more than 3 seconds while the vehicle is stopped. The slip indicator light and VSC OFF indicator light will come on.
  • Page 178 ■ If the VSC OFF indicator light blinks and the slip indicator light comes on... It may indicate a malfunction in the VSC and TRC. Consult your Toyota dealer.
  • Page 179 2-4. Using other driving systems CAUTION ■ The ABS does not operate effectively when ● Tires with inadequate gripping ability are used (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on the wet or slick road.
  • Page 180 The ABS and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
  • Page 181 2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load: ● Stow cargo and luggage in the rear deck whenever possible. ● Be sure all items are secured in place. ● To maintain vehicle balance while driving, position luggage evenly in the rear deck.
  • Page 182 2-5. Driving information CAUTION ■ Things that must not be carried in the rear deck The following things may cause a fire if loaded in the rear deck: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may result in death or serious injury.
  • Page 183 2-5. Driving information CAUTION ■ Load and distribution ● Do not overload your vehicle. ● Do not apply loads unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
  • Page 184 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 185 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 186 2-5. Driving information Selecting tire chains Use the correct tire chain size when mounting the snow chains. Chain size is regulated for each tire size. Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road.
  • Page 187 2-5. Driving information CAUTION ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the specified size. ●...
  • Page 188 For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. For towing purposes, Toyota recommends use of the following parts: ●...
  • Page 189 2-5. Driving information ■ Gross vehicle weight The gross vehicle weight must not exceed the following: 2WD models Single-cab models: 2780 kg (6128 lb.) Extra-cab models: 2740 kg (6040 lb.) Double-cab models: 2710 kg (5974 lb.) 4WD models Single-cab models: 2835 kg (6250 lb.) Extra-cab models: 2710 kg (5974 lb.) Double-cab models: 2780 kg (6128 lb.) [with diesel engine]...
  • Page 190 2-5. Driving information ■ Gross axle weight The load on either the front or rear axle resulting from distribu- tion of the gross vehicle weight on both axles must not exceed the following: 2WD models Single-cab models Front: 1145 kg (2524 lb.) Rear: 1750 kg (3858 lb.) Extra-cab models Front: 1200 kg (2646 lb.)
  • Page 191 Total trailer weight Tongue load Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kits etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer.
  • Page 192 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 800 km (500 miles) of driving.
  • Page 193 2-5. Driving information CAUTION ■ To avoid accident or injury ● The total trailer weight (trailer weight plus the weight of cargo) must not exceed 2250 kg (4960 lb.) [2WD models] or 2500 kg (5511 lb.) [4WD mod- els]. ● The gross combined weight (sum of your vehicle weight plus its load and the total trailer weight) must not exceed the following: 2WD models...
  • Page 194 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
  • Page 195 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: ● Before starting out, check the trailer lights and the vehicle-trailer connections.
  • Page 196 2-5. Driving information ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway. Periodically check the rear to pre- pare for being passed by large trucks or buses, which may cause your vehicle and trailer to sway. If swaying occurs, firmly grip the steering wheel, reduce speed immediately but gradually, and steer straight ahead.
  • Page 197 2-5. Driving information ● Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in P (automatic transmission) or in the 1st or R (manual transmission). Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
  • Page 198 2-5. Driving information CAUTION ■ To avoid an accident ● Observe the legal maximum speeds for trailer towing. ● Slow down and downshift before descending steep or long downhill grades. Do not make sudden downshifts while descending steep or long downhill grades.
  • Page 199 2-5. Driving information...
  • Page 200 Interior features 3-1. Using the air conditioning 3-2. Using the interior lights system and defogger Interior lights list....215 • Personal lights ....216 Manual air conditioning • Interior light..... 216 system ......200 Automatic air conditioning 3-3. Using the storage features system ......
  • Page 201 3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Cooling and dehumidification function on/off button (if equipped) Outside/recirculated air mode lever Air outlet selection dial Temperature control dial Fan speed control dial ∗ : If equipped...
  • Page 202 3-1. Using the air conditioning system and defogger Adjusting the settings To adjust the fan speed, turn the fan speed control dial the STEP clockwise (increase) or the counterclockwise (decrease). Set the dial to “OFF” turns off the fan. To adjust the temperature setting, turn the temperature control STEP dial clockwise (warm) or counterclockwise (cool).
  • Page 203 3-1. Using the air conditioning system and defogger Air outlets and air flow Air flows to the upper body. Air flows to the upper body and feet. Air flows to the feet.
  • Page 204 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. Switching between outside air and recirculated air modes Move the outside/recirculated air mode lever. The mode switches between (introduces air from outside the vehicle) and (recycles air inside the vehicle) each time the lever is moved.
  • Page 205 3-1. Using the air conditioning system and defogger ■ Fogging up of the windows ● The windows will easily fog up when the humidity in the vehicle is high. Turning the “A/C” button on will dehumidify the air from the outlets and defog the windshield effectively.
  • Page 206 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 207 3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air intake display Recirculated air mode button Air outlet display Cooling and dehumidification function on/off button Outside air mode button Automatic Fan speed display...
  • Page 208 3-1. Using the air conditioning system and defogger Using the automatic air conditioning system Press the “AUTO” button. STEP The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Press to increase the temperature and STEP...
  • Page 209 3-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates speed increases. Set the outside/recirculated air mode button to outside air mode if the recirculated air mode is used. (It may switch automati- cally.) To defog the windshield and the side windows early, turn the air flow and temperature up.
  • Page 210 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. Air flows to the feet. Air flows to the feet and the windshield defogger operates.
  • Page 211 3-1. Using the air conditioning system and defogger Switching between outside air and recirculated air modes Press to switch to recirculated air mode and press to switch to outside air mode. Adjusting the position of and opening and closing the air outlets Direct air flow to the left or right, up or down.
  • Page 212 3-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after the “AUTO”...
  • Page 213 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
  • Page 214 3-1. Using the air conditioning system and defogger ∗ Power heater This feature is used to keep the cabin warm in cold conditions. Turns the power heater on/off If you do not turn the switch to off, engine speed increased whenever engine is started.
  • Page 215 3-1. Using the air conditioning system and defogger ∗ Rear window defogger switch Defogger is used to defog the rear window. Vehicles without automatic air conditioning system Turns the defogger on/off Vehicles with automatic air conditioning system Turns the defogger on/off The defogger will automatically turn off after approximately 15 minutes.

  • Page 216: Using The Interior Lights Interior Lights List

    3-2. Using the interior lights Interior lights list Interior light (→P. 216) Personal lights (if equipped) (→P. 216) Engine switch light (if equipped)

  • Page 217: Personal Lights

    3-2. Using the interior lights Personal lights and interior light Personal lights (if equipped) Turns the lights on/off Interior light Turns the light on Turns the light off Turns the door position on ■ Illuminated entry system (if equipped) Type A The lights turn on/off automatically with the opening/closing of the doors.

  • Page 218: Using The Storage Features List Of Storage Features

    3-3. Using the storage features List of storage features Bottle holder (if equipped) Console box (if equipped) Cup holders (if equipped) Auxiliary box (if equipped) Glove box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...

  • Page 219: Glove Box

    3-3. Using the storage features Glove box Glove box The glove box can be opened by pulling the lever, locked and unlocked by using the master key. Open Lock Unlock CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.

  • Page 220: Console Box

    3-3. Using the storage features Console box Console box (if equipped) Lift the lid while pulling up the knob to release the lock. CAUTION ■ Caution while driving Keep the console box closed. In the event of sudden braking or sudden swerving, an accident may occur due to an occupant being struck by the open console box or the items stored inside.

  • Page 221: Cup Holders

    3-3. Using the storage features Cup holders Cup holders Type A (instrument panel) Pull out the cup holder com- pletely. Lift the tray up before returning. Type B (console box) (if equipped) Type C (console box) (if equipped)
  • Page 222 3-3. Using the storage features Cup holders Type D (console box) (if equipped) Type E (rear console box) (if equipped) Pull the lid.
  • Page 223 3-3. Using the storage features Cup holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident, cause injury.

  • Page 224: Bottle Holders

    3-3. Using the storage features Bottle holders Bottle holders For front seats For rear seats (if equipped) ■ When using the holder as a bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. NOTICE ■...

  • Page 225: Auxiliary Boxes

    3-3. Using the storage features Auxiliary boxes Auxiliary boxes Type A (if equipped) Press in the lid. The auxiliary box console is use- ful for temporarily storing sun- glasses and similar small items. Type B (if equipped) Type C (if equipped)
  • Page 226 3-3. Using the storage features Auxiliary boxes Type D (if equipped) CAUTION ■ Caution while driving (type A) Keep the auxiliary boxes closed. In the event of sudden braking or sudden swerving, an accident may occur due to an occupant being struck by an open auxiliary box or the items stored inside.

  • Page 227: Interior Features Sun Visors

    3-4. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side.

  • Page 228: Vanity Mirror

    3-4. Other interior features Vanity mirror Open the cover to use.
  • Page 229 3-4. Other interior features Clock Vehicles without multi-information display Adjusts the hours Adjusts the minutes Rounds nearest hour : e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 Vehicles with multi-information display Adjusts the hours Adjusts the minutes Rounds nearest hour...
  • Page 230 3-4. Other interior features Ashtray Pull the lid. To remove the ashtray, press down on the lock spring plate and pull the lid. CAUTION ■ When not in use Keep the ashtray closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open ashtray or ash flying out.
  • Page 231 3-4. Other interior features Cigarette lighter Push the cigarette lighter. The cigarette lighter will pop up when it is ready for use. ■ The cigarette lighter can be used when The engine switch is in the “ACC” or “ON” position. CAUTION ■...
  • Page 232 3-4. Other interior features ∗ Power outlet The power outlet can be used for 12V accessories that run on less than 10A. Open the cover. ■ The power outlet can be used when The engine switch is in the “ACC” or “ON” position. NOTICE ■...
  • Page 233 3-4. Other interior features Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
  • Page 234 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
  • Page 235 3-4. Other interior features ∗ Compass The compass on the multi-information display indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on, press the “INFO.” or “DISP” button until the compass appears. (→P. 154) “INFO.”...
  • Page 236 3-4. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies depending on the geographic position of the vehicle. If you cross over one of the map boundaries shown in illustration, the compass will deviate.
  • Page 237 3-4. Other interior features ■ Deviation calibration Stop the vehicle. STEP Press and hold the “INFO.” or STEP “DISP” button until a number (1 to 15) appears on the clock. Then press the “H” or “M” button, and referring to the map above, select the number of the zone where you are.
  • Page 238 3-4. Other interior features ■ Circling calibration If the direction display on the compass flashes, circling calibra- tion needs to be performed. Stop the vehicle in a place where it is safe to drive in a circle. STEP Press and hold the “INFO.” or STEP “DISP”...
  • Page 239 3-4. Other interior features ■ Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. ● The vehicle is on an inclined surface. ● The vehicle is in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields (underground car park/parking lot, under a steel tower, between buildings, roof car park/parking lot, near an intersection, near a large vehicle, etc.).
  • Page 240 3-4. Other interior features CAUTION ■ While driving the vehicle Do not adjust the display. Adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Secure a wide space, and watch out for people and vehicles in the vicinity. Do not violate any local traffic rules while performing circling calibration.
  • Page 241 3-4. Other interior features ∗ Deck hooks Raise hooks when needed. The deck hooks are provided for securing loose items. CAUTION ■ When the deck hooks are not in use To avoid injury, always return the deck hooks to their stowed positions. ∗...
  • Page 242 3-4. Other interior features ∗ Using the steering wheel audio switches Some audio features (audio volume control, radio, CD player etc.) can be controlled using the switches on the steering wheel. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel.
  • Page 243 3-4. Other interior features...
  • Page 244 Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..244 Cleaning and protecting the vehicle interior ..248 4-2. Maintenance Maintenance requirements....252 Scheduled maintenance (for Singapore)....255 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 265 Hood .........

  • Page 245: The Vehicle Exterior

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 246 4-1. Maintenance and care ■ High pressure car washes ● Do not allow the nozzles of the car wash to come within close proximity of the windows. ● Before using the car wash, check that the fuel filler door on your vehicle is closed properly.
  • Page 247 4-1. Maintenance and care CAUTION ■ When washing the vehicle Do not apply water to the inside of the engine compartment. Doing so may cause the electrical components etc. to catch fire. ■ Precautions regarding the exhaust pipe Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns.
  • Page 248 4-1. Maintenance and care NOTICE ■ Cleaning the exterior lights ● Wash carefully. Do not use organic substances or scrub with a hard brush. This may damage the surfaces of the lights. ● Do not apply wax to the surfaces of the lights. Wax may cause damage to the lenses.

  • Page 249: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 250 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 251 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
  • Page 252 4-1. Maintenance and care NOTICE ■ Cleaning the inside of the rear window (vehicles with rear window defogger) ● Do not use glass cleaner to clean the rear window, as this may cause damage to the rear window defogger heater wires. Use a cloth dampened with lukewarm water to gently wipe the window clean.

  • Page 253: Maintenance Requirements

    These are best performed by qualified technicians. Even if you are an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your vehicle. This record could be...
  • Page 254 4-2. Maintenance ■ Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for ser- vice. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips, and in-dealership train- ing programs.
  • Page 255 4-2. Maintenance CAUTION ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
  • Page 256 4-2. Maintenance Scheduled maintenance (for Singapore) Perform maintenance by the schedule as follows: Maintenance schedule requirements Your vehicle needs to be serviced according to the normal maintenance schedule. (See “Maintenance schedule” [→P. 256].) If you mainly operate your vehicle under one or more of the spe- cial operating conditions below, some of the maintenance sched- ule items need to be serviced more frequently.
  • Page 257 4-2. Maintenance Maintenance schedule Maintenance operations: = Inspect; R = Replace, change or lubricate; L = Lubricate; SERVICE ODOMETER READING INTERVAL: (Odometer x1000 10 20 30 40 50 60 70 80 reading or MONTHS months, whichever x1000 comes 12 18 24 30 36 42 48 miles first.) BASIC ENGINE COMPONENTS...
  • Page 258 4-2. Maintenance Maintenance operations: = Inspect; R = Replace, change or lubricate; L = Lubricate; SERVICE ODOMETER READING INTERVAL: (Odometer x1000 10 20 30 40 50 60 70 80 reading or MONTHS months, whichever x1000 comes 12 18 24 30 36 42 48 miles first.) IGNITION SYSTEM...
  • Page 259 4-2. Maintenance Maintenance operations: = Inspect; R = Replace, change or lubricate; L = Lubricate; SERVICE ODOMETER READING INTERVAL: (Odometer x1000 10 20 30 40 50 60 70 80 reading or MONTHS months, whichever x1000 comes 12 18 24 30 36 42 48 miles first.) CHASSIS AND BODY...
  • Page 260 4-2. Maintenance Maintenance operations: = Inspect; R = Replace, change or lubricate; L = Lubricate; SERVICE ODOMETER READING INTERVAL: (Odometer x1000 10 20 30 40 50 60 70 80 reading or MONTHS months, whichever x1000 comes 12 18 24 30 36 42 48 miles first.) CHASSIS AND BODY...
  • Page 261 4. First replace at 160000 km (96000 miles) then every 80000 km (48000 miles). 5. Only use “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology. (Coolant with long-life hybrid organic acid technology is a combination of low phosphates and organic acids.)
  • Page 262 4-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe condi- tions. (For outline, see “Maintenance schedule requirements” [→P. 255].) A-1: Operating on rough, muddy or melted snow-covered roads ❏...
  • Page 263 4-2. Maintenance A-2: Operating on dusty roads Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil months Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil filter months I: Every 2500 km (1500 miles) or ❏...
  • Page 264 4-2. Maintenance B-1: Towing a trailer, using a camper or car top carrier Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil months Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil filter months ❏...
  • Page 265 4-2. Maintenance B-2: Repeated short trips less than 8 km (5 miles) and outside tempera- ture remains below freezing Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil months Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil filter months B-3: Extensive idling and/or low speed driving for long distances such as police cars, taxis or door-to-door calls...

  • Page 266: Do-It-Yourself Service Precautions

    Battery condition (→P. 281) • Conventional wrench (for terminal clamp bolts) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (→P.
  • Page 267 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (→P. 273) • Rag or paper towel • Funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (→P. 299) as original •...
  • Page 268 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.

  • Page 269: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the...
  • Page 270 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...

  • Page 271: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment 1GR-FE engine Engine oil level dipstick Fuse box (→P. 299) (→P. 273) Battery (→P. 281) Engine coolant reservoir Washer fluid tank (→P. 285) (→P. 278) Condenser (→P. 280) Engine oil filler cap Radiator (→P. 280) (→P.
  • Page 272 4-3. Do-it-yourself maintenance 2TR-FE engine Engine coolant reservoir Fuse box (→P. 299) (→P. 278) Battery (→P. 281) Engine oil level dipstick Washer fluid tank (→P. 285) (→P. 273) Condenser (→P. 280) Engine oil filler cap Radiator (→P. 280) (→P. 275)
  • Page 273 4-3. Do-it-yourself maintenance 1KD-FTV engine Engine coolant reservoir Fuel filter (→P. 286, 373) (→P. 278) Fuse box (→P. 299) Intercooler (→P. 280) Battery (→P. 281) Engine oil filler cap Washer fluid tank (→P. 285) (→P. 275) Condenser (→P. 280) Engine oil level dipstick Radiator (→P.
  • Page 274 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, STEP wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
  • Page 275 4-3. Do-it-yourself maintenance Wipe the dipstick and reinsert it fully. STEP Type A Full Type B Full Type C Full...
  • Page 276 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 277 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 278 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on a regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, or the engine could be damaged. ●...
  • Page 279 4-3. Do-it-yourself maintenance Engine coolant The coolant level is satisfactory if it is between the upper and lower lines on the reservoir when the engine is cold. Type A Reservoir cap Upper line Lower line If the level is on or below the lower line, add coolant up to the upper line.
  • Page 280 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. CAUTION ■...
  • Page 281 Check the radiator, condenser and intercooler and clear away any foreign objects. If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■ When the engine is hot Do not touch the radiator, condenser or intercooler as they may be hot and cause serious injuries, such as burns.
  • Page 282 4-3. Do-it-yourself maintenance Battery Check the battery as follows: ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Checking battery fluid Check that the level is between the upper and lower lines.
  • Page 283 4-3. Do-it-yourself maintenance ■ Adding distilled water O.K. Remove the vent plug. STEP Add distilled water. STEP If the upper line cannot be seen, check the fluid level by looking directly at the cell. Put the vent plug back on and close it securely. STEP ■...
  • Page 284 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
  • Page 285 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. ■ When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
  • Page 286 4-3. Do-it-yourself maintenance Washer fluid If any washer does not work, the washer tank may be empty. Add washer fluid. CAUTION ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
  • Page 287 4-3. Do-it-yourself maintenance Draining the fuel filter water (diesel engine only) The water in the fuel filter must be drained immediately when the fuel system warning light flashes and buzzer sounds. Place a small tray under the drain plug or drain hose to catch STEP the water.

  • Page 288: Tires

    Vehicles with spare tire of a different wheel type from the installed tires Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that tire rotation is car- Front ried out approximately every 10000 km (6000 miles).
  • Page 289 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Tire life Any tire over 6 years old must be checked by a qualified technician even if it has seldom or never been used or damage is not obvious.
  • Page 290 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).

  • Page 291: Tire Inflation Pressure

    Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 292 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: ● Excessive wear ● Uneven wear ●...

  • Page 293: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
  • Page 294 4-3. Do-it-yourself maintenance CAUTION ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.

  • Page 295: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the engine switch off. STEP Open the glove box. STEP Push in each side of the glove STEP box to disconnect the claws.
  • Page 296 4-3. Do-it-yourself maintenance Remove the filter and replace STEP it with a new one. The “↑UP” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.

  • Page 297: Wireless Remote Control Battery

    4-3. Do-it-yourself maintenance ∗ Wireless remote control battery Replace the battery with a new one if it is depleted. ■ You will need the following items: ● Flathead screwdriver ● Lithium battery CR2016 ■ Replacing the battery Remove the cover. STEP To prevent damage to the key, cover the tip of the screwdriver...
  • Page 298 “+” terminal facing up. ■ Use a CR2016 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 299 4-3. Do-it-yourself maintenance CAUTION ■ Removed battery and other parts Keep away from children. These parts are small and if swallowed by a child, they can cause choking. Failure to do so could result in death or serious injury. NOTICE ■...

  • Page 300: Checking And Replacing Fuses

    Open the fuse box cover. STEP Engine compartment Push the tab in and lift the lid off. Driver’s side instrument panel (front and rear sides) Remove the lower instrument panel. Rear side: Inspection replacement of the fuses, con- tact your Toyota dealer.
  • Page 301 4-3. Do-it-yourself maintenance Passenger’s side instrument panel Open the glove box. Push in each side of the glove box to disconnect the claws. After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 304) for details about which fuse to check. Remove the fuse.
  • Page 302 4-3. Do-it-yourself maintenance Check if the fuse is blown. STEP Type A Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
  • Page 303 Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type D Normal fuse Blown fuse Contact your Toyota dealer. ITY42C014...
  • Page 304 4-3. Do-it-yourself maintenance Type E Normal fuse Blown fuse Contact your Toyota dealer. Type F Normal fuse Blown fuse Contact your Toyota dealer.
  • Page 305 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings The provision of fuses and systems connected to the circuit may dif- fer depending on the model and specification. Engine compartment Fuse Ampere Circuit SPARE 25 A Spare fuse SPARE 15 A Spare fuse SPARE 10 A...
  • Page 306 4-3. Do-it-yourself maintenance Fuse Ampere Circuit PWR SEAT 30 A Power seat PTC NO.2 30 A Power heater RR CLR 40 A No circuit FR HTR 50 A Air conditioning system, A/C fuse ABS NO.2 30 A ABS, TRC and VSC ABS NO.1 40 A ABS, TRC and VSC...
  • Page 307 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Door courtesy switches, power door lock system, wireless remote ECU-B 10 A control system, steering sensor and headlights 15 A Audio system Interior lights, engine switch light, personal light, gauges and meters, DOME 7.5 A clock, multi-information display, wireless remote control system and fog light...
  • Page 308 4-3. Do-it-yourself maintenance Driver’s side instrument panel (front side) Fuse Ampere Circuit PWR OUT 15 A Power outlet Instrument panel light, fog lights, front position lights, tail lights, license plate lights, multiport fuel TAIL 10 A injection system/sequential multi- port fuel injection system, multi- information display and automatic headlight system Stop lights, high mounted stoplight,...
  • Page 309 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Air conditioning system, charging system, ABS, TRC, VSC, emer- gency flashers, turn signal lights, back-up lights, multiport fuel injec- tion system/sequential multiport fuel injection system, shift lock control ECU-IG & 10 A system, rear window defogger, GAUGE headlights, door courtesy switches, power door lock system, wireless...
  • Page 310 4-3. Do-it-yourself maintenance Driver’s side instrument panel (rear side) Fuse Ampere Circuit ABS, TRC, VSC, ACC, CIG, ECU- 40 A IG & GAUGE, and WIP fuses PWR, S-HTR, 4WD, DOOR, DEF 40 A and MIR HTR fuses...
  • Page 311 4-3. Do-it-yourself maintenance Passenger’s side instrument panel ITI43I094 Fuse Ampere Circuit MIR-HTR 15 A No circuit 20 A ABS, TRC and VSC S-HTR 15 A No circuit Rear window defogger and multi- 20 A port fuel injection system/sequential multiport fuel injection system Power door lock system and power DOOR 25 A...
  • Page 312 Never use a fuse of a higher amperage rating than that indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.

  • Page 313: Light Bulbs

    You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. ■ Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
  • Page 314 4-3. Do-it-yourself maintenance ■ Rear bulb locations Stop/tail lights Back-up light License plate Rear turn signal light lights : If equipped Replacing light bulbs ■ Headlight Before replacing the bulbs STEP (right side only [except for the 1GR-FE engine]): Release the clips of the air cleaner filter cover, and remove the cover to allow easy access to the light bulbs.
  • Page 315 4-3. Do-it-yourself maintenance Unplug connector STEP remove the rubber cover. Release bulb retaining STEP spring. Remove the bulb. STEP To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole.
  • Page 316 4-3. Do-it-yourself maintenance ■ Fog lights (if equipped) To allow enough working space, STEP turn the steering wheel to the opposite side of the bulb to be replaced. Remove the bolts and clip. Removing the clip Installing the clip...
  • Page 317 4-3. Do-it-yourself maintenance Partly remove the fender liner STEP and turn the bulb base counter- clockwise. Fender liner Bumper Unplug connector while STEP pressing the lock release. ITO43P165...
  • Page 318 4-3. Do-it-yourself maintenance ■ Front position lights To allow enough working space, STEP turn the steering wheel to the opposite side of the bulb to be replaced. Remove the bolts and clip. Removing the clip Installing the clip...
  • Page 319 4-3. Do-it-yourself maintenance Partly remove the fender liner STEP and turn the bulb base counter- clockwise. Fender liner Bumper Remove the light bulb. STEP...
  • Page 320 4-3. Do-it-yourself maintenance ■ Front turn signal lights To allow enough working space, STEP turn the steering wheel to the opposite side of the bulb to be replaced. Remove the bolts and clip. Removing the clip Installing the clip...
  • Page 321 4-3. Do-it-yourself maintenance Partly remove the fender liner STEP and turn the bulb base counter- clockwise. Fender liner Bumper Remove the light bulb. STEP ITO43P144...
  • Page 322 4-3. Do-it-yourself maintenance ■ Side turn signal lights (fender-mounted type) (if equipped) Remove the unit. STEP Front Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
  • Page 323 4-3. Do-it-yourself maintenance ■ Stop/tail lights, rear turn signal lights and back-up lights Remove the securing bolts and STEP remove the unit. Turn the bulb base counterclock- STEP wise. Stop/tail light Rear turn signal light Back-up light Remove the light bulb. STEP Stop/tail light Rear turn signal light...
  • Page 324 4-3. Do-it-yourself maintenance ■ License plate lights Remove the unit. STEP Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
  • Page 325 LED light bulbs The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations.
  • Page 326 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
  • Page 327 4-3. Do-it-yourself maintenance...
  • Page 328 When trouble arises 5-1. Essential information Emergency flashers ..328 If your vehicle needs to be towed ..... 329 If you think something is wrong......335 Fuel pump shut off system ......336 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ......

  • Page 329: Emergency Flashers

    5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Vehicles without automatic air conditioning system Press the switch to flash all the turn signal lights. To turn them off, press the switch once again.

  • Page 330: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 331 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances at low speeds.
  • Page 332 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage.
  • Page 333 5-1. Essential information Towing with a wheel-lift type truck From the front Vehicles with automatic trans- mission: Use a towing dolly under the rear wheels. Vehicles with manual transmis- sion: We recommend using a towing dolly under the rear wheels. When not using a towing dolly, release the parking brake and shift the shift lever to N.
  • Page 334 5-1. Essential information Using a flatbed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. ■ Before emergency towing Release the parking brake.
  • Page 335 5-1. Essential information NOTICE ■ To prevent causing serious damage to the transmission and transfer (4WD models) when towing using a wheel-lift type truck (vehicles with automatic transmission) 2WD models: Never tow this vehicle from the front with the rear wheels on the ground.

  • Page 336: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle.

  • Page 337: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.

  • Page 338: On Or A Warning Buzzer Sounds

    If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
  • Page 339 Low engine oil pressure warning light Indicates that the engine oil pressure is too low Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
  • Page 340 5-2. Steps to take in an emergency Warning light Warning light/Details SRS warning light Indicates a malfunction in: • The SRS airbag system; or • The seat belt pretensioner system ABS warning light Indicates a malfunction in: • The ABS; or •...
  • Page 341 5-2. Steps to take in an emergency Warning light Warning light/Details Fuel system warning light (diesel engine) (warning buzzer) Indicates: • The amount of accumulated water in the fuel filter has reached the specified level if the light flashes. • Malfunction in the fuel system if the light comes on. : Slow down until the lamp goes off.
  • Page 342 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure Open door warning light Check that all the Indicates that a door is not fully doors are closed.
  • Page 343 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
  • Page 344 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare tire provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
  • Page 345 5-2. Steps to take in an emergency Extra-cab models The jack and tools are stored under the lid. Double-cab models The jack and tools are stored under the bottom cushion.
  • Page 346 5-2. Steps to take in an emergency Taking out the jack and tools Single-cab models Unhook the strap and take out STEP the tool bag. Take out the jack. STEP For loosening For tightening...
  • Page 347 5-2. Steps to take in an emergency Extra-cab models Remove the rear seat cushions. (→P. 50) STEP Pull the tag and open the lid. STEP Unhook the strap and take out STEP the tool bag. Take out the jack. STEP For loosening For tightening...
  • Page 348 5-2. Steps to take in an emergency Double-cab models Tumbling the bottom cushion (→P. 51) STEP Open the lid. STEP Take out the tool bag. STEP Take out the jack. STEP For loosening For tightening...
  • Page 349 5-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. STEP Remove the jack handle end, jack handle extensions and wheel nut wrench from the tool bag and assemble by follow- ing these steps. Loosen the bolts using a screwdriver.
  • Page 350 5-2. Steps to take in an emergency Lower the spare tire completely STEP to the ground. Remove the holding bracket and STEP pull out the spare tire.
  • Page 351 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 352 5-2. Steps to take in an emergency Remove the wheel ornament. STEP Type A Pry off the wheel ornament, using the beveled end of the wheel nut wrench as shown. To protect the wheel ornament, place a rag between the wheel nut wrench and the wheel orna- ment.
  • Page 353 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Assembling the jack handle. (→P. 348) STEP Position the jack at the jack STEP points as shown. Front (2WD models) Under the side rail Front (4WD models) Under the cross member Rear Under the rear axle housing...
  • Page 354 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. When positioning the jack under the rear axle housing, make sure the groove on the top of the jack fits with the rear axle housing. Remove all the wheel nuts and STEP the tire.
  • Page 355 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
  • Page 356 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each wheel nut two or three times in the order STEP shown in the illustration. 2WD models Tightening torque: Aluminum wheels 121 N•m (12.3 kgf•m, 89 ft•lbf) Steel wheels N•m (15.5...
  • Page 357 5-2. Steps to take in an emergency Vehicles with spare tire of the same wheel type as the STEP installed tires: Reinstall the wheel ornament. Type A Type B...
  • Page 358 5-2. Steps to take in an emergency Stowing the flat tire, jack and all tools Lay down the tire with the outer STEP side facing up, and hook the holding bracket as shown in the illustration. Raise the tire. STEP After the tire goes half way up, check that the suspended chain is able to enter the tire hole, for...
  • Page 359 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
  • Page 360 If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. Failure to follow these precautions could cause the wheel nuts to loosen and...
  • Page 361 5-2. Steps to take in an emergency CAUTION ■ When installing the wheel nuts Be sure to install the wheel nuts with the tapered end facing inward. → P. 293) ■ After using the tools and jack Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.

  • Page 362: If The Engine Will Not Start

    One of the following may be the cause of the problem: ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 364) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.

  • Page 363: If The Shift Lever Cannot Be Shifted From P

    (a system to pre- vent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.

  • Page 364: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. Bring a mas- ter key and the key number stamped on the key number plate.

  • Page 365: If The Vehicle Battery Is Discharged

    The following procedures may be used to start the engine if the vehi- cle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
  • Page 366 5-2. Steps to take in an emergency 2TR-FE engine 1KD-FTV engine...
  • Page 367 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order from which they were con- nected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible.
  • Page 368 5-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged (vehicles with auto- matic transmission) The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. ●...
  • Page 369 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
  • Page 370 5-2. Steps to take in an emergency NOTICE ■ When handling jumper cables When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fan or belt.

  • Page 371: If Your Vehicle Overheats

    Wait until the temperature of the engine (shown on the instrument panel) begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your Toyota dealer. After the engine has cooled STEP...
  • Page 372 Water can be used in an emer- gency if engine coolant is unavailable. (→P. 390) Have the vehicle inspected at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating: ●...
  • Page 373 5-2. Steps to take in an emergency CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
  • Page 374 If the engine does not start after the above steps have been per- formed, wait for 10 seconds and try step 2 and 3 again. If the engine still does not start, contact your Toyota dealer. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.

  • Page 375: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift STEP lever to P (automatic transmission) or N (manual transmis- sion).
  • Page 376 5-2. Steps to take in an emergency NOTICE ■ To avoid damage to the transmission and other components ● Avoid spinning the wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.

  • Page 377: If Your Vehicle Has To Be Stopped In An Emergency

    5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
  • Page 378 5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
  • Page 379 5-2. Steps to take in an emergency...
  • Page 380 Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..380 Fuel information ....400 6-2. Initialization Items to initialize ....402...
  • Page 381 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 5135 mm (202.2 in.) Overall length 5260 mm (207.1 in.) 1760 mm (69.3 in.) Overall width 1835 mm (72.2 in.) Single-cab 1680 mm (66.1 in.) models Extra-cab 1720 mm (67.7 in.) models Double-cab 1735 mm (68.3 in.)
  • Page 382 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the rear right frame.
  • Page 383 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 1GR-FE engine 2TR-FE engine 1KD-FTV engine...
  • Page 384 6-1. Specifications Engine 1GR-FE engine Model 1GR-FE Type 6 cylinder V type, 4 cycle, gasoline × × Bore and stroke 94.0 95.0 mm (3.70 3.74 in.) Displacement 3956 cm (241.4 cu.in.) Intake: 0.15  0.25 mm (0.006  0.010 in.) Valve clearance Exhaust: 0.29 ...
  • Page 385 6-1. Specifications 1KD-FTV engine Model 1KD-FTV 4 cylinder in line, 4 cycle, diesel (with turbo- Type charger) × × Bore and stroke 96.0 103.0 mm (3.78 4.06 in.) Displacement 2982 cm (182.0 cu.in.) Intake: 0.20  0.30 mm (0.008  0.012 in.) Valve clearance Exhaust: 0.35 ...
  • Page 386 2TR-FE engine 5.3 L (5.6 qt., 4.7 Imp.qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
  • Page 387 6-1. Specifications Recommended viscosity (SAE): If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 engine oil is recommended. Temperature range anticipated before next oil change. The 10W portion of the oil viscosity rating indicates the characteristic of the oil which allows cold startability.
  • Page 388 6-1. Specifications How to read oil container labels: Either or both API registered marks are added to some oil containers to help you select the proper oil you should use. API Service Symbol Top portion: The oil quality desig- nation by API (American Petro- leum Institute) (SM) Center portion: The SAE viscosity grade (SAE 10W-30)
  • Page 389 6.6 L (7.0 qt., 5.8 Imp.qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: G-DLD-1, API CF-4, CF or ACEA B1 (You may also use API CE or CD.)
  • Page 390 6-1. Specifications DLD logo mark: The Global DLD-1 logo mark, attached on some oil containers to help in selecting the oil you should use, indicates that the oil meets the guidelines recom- mended by the following associ- ations: ● ACEA (Association des Con- structeurs Europeens d’Auto- mobiles) ●...
  • Page 391 With automatic transmission 11.1 L (11.7 qt., 9.8 Imp.qt.) 10.3 L (10.9 qt., 9.1 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
  • Page 392 6-1. Specifications Ignition system Spark plug Make 1GR-FE engine DENSO K20HR-U11 NGK LFR6C11 2TR-FE engine DENSO K20HR-U11 1.1 mm (0.043 in.) Electrical system Battery 1.250  1.290 Fully charged Specific gravity reading 1.160  1.200 Half charged at 20°C (68°F): 1.060 ...
  • Page 393 NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF Type T-IV” (4- speed models) or “Toyota Genuine ATF WS” (5-speed models) may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
  • Page 394 6-1. Specifications Manual transmission 2.6 L (2.7 qt., 2.3 Imp.qt.) models Oil capacity 2.2 L (2.3 qt., 1.9 Imp.qt.) models Oil type Gear oil API GL-4 or GL-5 For Australia and Singapore SAE 75W-90, 80W or 80W-90 Recommended oil viscosity For other countries SAE 75W-90...
  • Page 395 6-1. Specifications Transfer Oil capacity 1.0 L (1.1 qt., 0.9 Imp.qt.) Oil type Gear oil API GL-4 or GL-5 Recommended oil viscosity SAE 75W-90 Differential 2WD models 3.20 L (3.38 qt., 2.82 Imp.qt.) 1.45 L (1.53 qt., 1.28 Imp.qt.) Oil capacity Front 1.65 L (1.74 qt., 1.45 Imp.qt.) 4WD models...
  • Page 396 6-1. Specifications Clutch 5  15 mm (0.2  0.6 in.) Pedal free play Fluid type SAE J1703 or FMVSS No.116 DOT 3 Brakes 2WD models 82 mm (3.2 in.) Pedal Without 89 mm (3.5 in.) clearance models With VSC 83 mm (3.3 in.) 1.0 ...
  • Page 397 6-1. Specifications Chassis lubrication Propeller shafts Spider Lithium base chassis grease, NLGI No.2 Slide yoke Molybdenum-disulfide lithium base chas- sis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 30 mm (1.2 in.) ® Automatic transmission fluid DEXRON Power steering fluid type or III...
  • Page 398 6-1. Specifications Tires and wheels 15 inch tires (2WD models) Tire size 205/70R15C 106/104S Rear wheel Rear wheel Tire inflation pressure Front wheel (unloaded) (loaded) (Recommended cold tire kPa (kgf/cm kPa (kgf/cm kPa (kgf/cm inflation pressure) or bar, psi) or bar, psi) or bar, psi) Single-cab 240 (2.4, 35)
  • Page 399 6-1. Specifications 16 inch tires Tire size 205R16C-8PR 110/108S Rear wheel Rear wheel Front wheel (unloaded) (loaded) Tire inflation pressure kPa (kgf/cm kPa (kgf/cm kPa (kgf/cm (Recommended cold tire or bar, psi) or bar, psi) or bar, psi) inflation pressure) 240 (2.4, 35) 240 (2.4, 35) 320 (3.2, 46)
  • Page 400 6-1. Specifications Light bulbs Light Bulbs Type Headlights 60/55 Fog lights Front position lights Front turn signal lights Exterior Side turn signal lights Rear turn signal lights Back-up lights License plate lights Stop/tail lights 21/5 Interior light Interior Personal lights A: H4 halogen bulbs B: HB4 halogen bulbs C: Wedge base bulbs (clear)

  • Page 401: Fuel Information

    6-1. Specifications Fuel information You must only use unleaded gas- oline in your vehicle. For optimum engine perfor- mance, select premium unleaded gasoline with a Research Octane 1GR-FE engine Number of 95 or higher. If this premium type cannot be obtained, you may temporarily use unleaded gasoline with a Research Octane Number as low...
  • Page 402 ■ If your engine knocks ● Consult your Toyota dealer. ● You may occasionally notice light knocking for a short time while acceler- ating or driving uphill. This is normal and there is no need for concern.

  • Page 403: Initialization Items To Initialize

    6-2. Initialization Items to initialize The following item must be initialized for normal system operation after such cases as the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Power windows After reconnecting or chang- P.

  • Page 404: Index

    Index Abbreviation list ...... 404 Alphabetical index....405 What to do if......416...

  • Page 405: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING 2-Wheel Drive 4-Wheel Drive Air Conditioning Anti-lock Brake System Accessory Automatic Disconnecting Differential Automatic Locking Retractor Auxiliary Child Restraint System DISP Display Emergency Locking Retractor Light Emitting Diode Limited Slip Differential Supplemental Restraint System Traction Control Treadwear indicator Vehicle Identification Number...

  • Page 406: Alphabetical Index

    Alphabetical index Alphabetical index A/C........200, 206 Anti-lock brake system ..174 ABS ........... 174 Ashtray ........229 Air conditioning filter ....294 Automatic air conditioning Air conditioning system system Air conditioning filter ..... 294 Air conditioning filter....294 Automatic Air conditioning air conditioning system..
  • Page 407 Alphabetical index Back window ......73 Care Back-up lights Exterior ......... 244 Replacing light bulbs..... 322 Interior........248 Wattage......... 399 Seat belts......249 Chains........183 Battery Child restraint system Checking ....... 281 Baby seats, definition....95 If the vehicle has discharged battery.........
  • Page 408 Alphabetical index Child-protectors......40 Deck hooks ......240 Cigarette lighter ....... 230 Defogger Cleaning Rear window ......214 Exterior........244 Dimension ........ 380 Display Interior........248 Multi-information Seat belts ......249 display ........ 154 Clock ......... 228 Compass........234 Trip information..... 156 Condenser ........
  • Page 409 Alphabetical index Emergency, in case of Engine If the engine will not start ..361 Compartment ......270 If the shift lever cannot be Engine switch......131 shifted from P ..... 362 Hood ........268 How to start the If the vehicle has discharged engine.........
  • Page 410 Alphabetical index Floor mat ........232 Fuel Fluid Capacity........ 384 Washer........285 Fuel gauge......146 Fog lights Fuel pump shut off system..336 Gas station information..420 Replacing light bulbs..... 315 If you run out of fuel and Switch ........163 the engine stalls ....
  • Page 411 Alphabetical index Identification Keyless entry ......36 Engine........382 Keys Vehicle ........381 Engine switch......131 Ignition switch......131 If you lose your keys ..... 363 Key number ......34 Ignition switch light ....215 Keyless entry ......36 Illuminated entry system..216 Keys........
  • Page 412 Alphabetical index Parking brake......144 Maintenance Do-it-yourself Personal lights maintenance ....... 265 Personal lights ...... 215 Maintenance data ....380 Switch ........216 Wattage ........ 399 Maintenance Power heater ......213 requirements....... 252 Power outlet ......231 Scheduled maintenance ..255 Power windows......
  • Page 413 Alphabetical index Service reminder Seat belts Adjusting the seat belt.....57 indicators ......150 Automatic Locking Shift lever Retractor....... 58 Automatic transmission..135 Front drive control lever ..171 Child restraint system If the shift lever cannot installation......99 be shifted from P ....362 Cleaning and maintaining Manual transmission.....
  • Page 414 Alphabetical index Steering wheel Tachometer ......146 Adjustment ......63 Tailgate ........42 Audio switches ...... 241 Tail lights Stop lights Replacing light bulbs..... 322 Switch ........160 Replacing light bulbs..... 322 Wattage ........ 399 Wattage......... 399 Theft deterrent system Storage feature ......
  • Page 415 Alphabetical index Valet key ........34 Washer Vanity mirrors ......227 Checking....... 285 Vehicle identification Preparing and checking number ........381 before winter....... 183 Switch ........164 Vehicle stability control ..174 Washing and waxing ....244 VSC ........... 174 Wheels ........
  • Page 416 Alphabetical index...
  • Page 417 What to do if... What to do if... If you have a flat tire A tire punctures P. 343 If the engine will not start P. 361 P. 373 If you run out of fuel and the engine stalls The engine does not start P.
  • Page 418 What to do if... ■ Instrument cluster Non-optitron type meters Optitron type meters...
  • Page 419 What to do if... ■ Center panel Vehicles without multi-information display Vehicles with multi-information display...

  • Page 420: Warning Lights

    What to do if... ■Warning lights Automatic transmission Brake system warning fluid temperature warning light P. 337 P. 339 light Charging system Timing belt replacement warning light warning light P. 338 P. 339 Low engine oil pressure Fuel system warning warning light light P.

  • Page 421: Gas Station Information

    GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 74 P. 268 Fuel filler door opener Hood lock release lever Tire inflation pressure P. 74 P. 268 P. 397 Fuel tank capacity (Reference) 76 L (20.1 gal., 16.7 Imp.gal.) Unleaded gasoline with a 1GR-FE engine Research Octane Number of...
