Page 3
• To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user serviceable parts inside. Repair should be done only by authorized Electrolux technicians. • If the power supply cord is damaged, it should be replaced by a qualified technician from Electrolux. • Warning! There may be residual heat after use on heater plate. Do not touch the heater plate immediately after use. • Warning! Do not use the appliance other than intended use, which may cause potential injury. WARNING! DO NOT IMMERSE THE APPLIANCE AND AVOID SPILLAGE ON THE CONNECTOR.
Page 4
SOUP FUNCTION 1. Add the ingredients and appropriate amount of water into the inner pot. 2. Press [MENU] till SOUP function is selected. 3. Press [COOK] to start the cooking cycle. 4. The timing for soup function is THREE hours. 5. With 10 minutes of cooking time to go, the LED panel will display countdown timer and switches to keep warm mode when cooking cycle is completed. www.electrolux.com...
5 hours for the food to be ready. 1. Press [MENU] to select the desired cooking function. 2. Press [TIMER] to activate the delay timer. 3. Press [TIMER] continuously to the desired delay timing. The LED panel will show increment of 1H, up to 12H. 4. Once the timer is set, press [COOK] to start the timer. 5. The LED panel will show hourly count down. 6. With 10 minutes of cooking time to go, the LED panel will display countdown timer and switches to keep warm mode when cooking cycle is completed. Note: Delay timer function is not available for the following: REHEAT, SLOW COOK, CAKE, JAPANESE. www.electrolux.com...
70-80 min 10 cups 75-90 min 2 cups 34-44 min JAPANESE 5 cups 44-50 min 10 cups 45-55 min 1 cup 2 hours PORRIDGE 1.5 cup 2 hours * Please pre-soak the brown rice up to 2 hours before cooking. www.electrolux.com...
The rice cooker does not The master temperature controller automatically switch to keep is defective. Contact authorized service center. warm mode. There is no timer display on The timer battery has run out. Contact authorized service center. the LED panel. www.electrolux.com...
Page 8
Serial Number. The information can be found on the rating plate. Due to the Electrolux policy of continual product development; specifications, colours, and details of our products and those mentioned in this manual are subject to change without notice. www.electrolux.com...
Page 9
• Untuk mengurangi risiko kebakaran atau sengatan listrik, jangan mencoba melepaskan penutup luar perangkat. Tidak ada komponen yang dapat diservis oleh pengguna di bagian dalam perkakas. Perbaikan harus dilakukan hanya oleh teknisi Electrolux resmi. • Jika kabel catu daya rusak, kabel ini harus diganti oleh teknisi yang berkualifikasi dari Electrolux. • Peringatan! Bisa ada sisa panas setelah penggunaan pada permukaan elemen pemanas. Jangan menyentuh permukaan elemen pemanas segera setelah penggunaan. • Peringatan! Jangan menggunakan perangkat selain untuk penggunaan yang dimaksudkan, yang dapat menyebabkan kemungkinan cedera.
Page 10
FUNGSI SOUP (SUP) 1. Masukkan bahan-bahan dan sejumlah air yang sesuai ke dalam panci pemasak. 2. Tekan [MENU] sampai fungsi SOUP terpilih. 3. Tekan [COOK] untuk memulai siklus pemasakan. 4. Waktu untuk fungsi sup adalah TIGA jam. 5. Ketika waktu memasak tersisa 10 menit, panel LED akan menampilkan penghitung waktu mundur dan berpindah ke mode keep warm (menghangatkan) setelah siklus pemasakan selesai. www.electrolux.com...
Page 11
5. Keluarkan kue dari panci pemasak dan biarkan kue mendingin selama 10 menit sebelum disajikan. FUNGSI KEEP WARM (MENGHANGATKAN) Ketika salah satu mode pemasakan (kecuali kue) selesai, penanak nasi secara otomatis berpindah ke mode keep warm (menghangatkan). [OFF/KEEP WARM] akan menyala ketika penanak nasi berada dalam mode keep warm. Panel LED kemudian menunjukkan sudah seberapa lama penanak nasi berada dalam mode keep warm, dengan penambahan satu jam. Setelah 24 jam dalam mode keep warm, penanak nasi akan mati dan memasuki Mode Standby. CATATAN: Fungsi menghangatkan tidak tersedia untuk fungsi CAKE. FUNGSI OFF (MATI) 1. Untuk mematikan penanak nasi ketika berada dalam mode keep warm, tekan [OFF/KEEP WARM] sekali. 2. Matikan sakelar utama dan cabut steker utama dari stopkontak dinding. www.electrolux.com...
Page 12
10 cangkir 75-90 men 2 cangkir 34-44 men JAPANESE 5 cangkir 44-50 men 10 cangkir 45-55 men 1 cangkir 2 jam PORRIDGE 1.5 cangkir 2 jam * Rendamlah dahulu beras pecah kulit/beras merah hingga selama 2 jam sebelum dimasak. www.electrolux.com...
Page 13
Pengatur suhu utama Hubungi pusat servis resmi. rusak. Penanak nasi tidak secara otomatis Pengatur suhu utama beralih ke mode keep warm Hubungi pusat servis resmi. rusak. (menghangatkan). Tidak ada tampilan penga- Baterai pengatur waktu habis. Hubungi pusat servis resmi. tur waktu pada panel LED. www.electrolux.com...
Page 14
Kembalikan produk ke fasilitas daur ulang setempat atau hubungi kantor pemerintah daerah. SERVIS DAN LAYANAN PELANGGAN Ketika menghubungi bagian Servis, pastikan bahwa Anda menyediakan data berikut ini: Model, PNC, Nomor Seri. Informasi dapat ditemukan pada pelat rating. Karena kebijakan pengembangan produk yang terus menerus dari Electrolux, spesifikasi, warna, dan detail produk kami dan yang disebutkan dalam petunjuk ini bisa berubah tanpa pemberitahuan. www.electrolux.com...
Page 21
• Việc sửa chữa chỉ nên do các kỹ thuật viên được ủy quyền của Electrolux thực hiện. • Nếu dây dẫn điện bị hư hại, việc thay thế nên được thực hiện bởi kỹ thuật viên đủ năng lực của Electrolux.
Page 22
4. Thời gian cho chức năng nấu soup là giờ. 5. Màn hình LED sẽ hiển thị hẹn giờ đếm ngược 10 phút trước khi chương trình kết thúc và chuyển sang chế độ giữ ấm khi nấu xong. www.electrolux.com...
Page 23
6. Màn hình LED sẽ hiển thị hẹn giờ đếm ngược 10 phút trước khi chương trình kết thúc và chuyển sang chế độ giữ ấm khi nấu xong. LƯU Ý: Chức năng hẹn giờ nấu không hoạt động ở các chế độ sau: REHEAT (Hâm lại), SLOW COOK (Nấu chậm), CAKE (Nướng bánh), JAPANESE (Gạo Nhật). www.electrolux.com...
Page 25
Liên hệ trung tâm bảo hành được chuyển sang chế độ giữ ấm. bị hỏng. ủy quyền. Không hiển thị hẹn giờ trên Liên hệ trung tâm bảo hành được Hẹn giờ hết pin. màn hình LED. ủy quyền. www.electrolux.com...
Page 26
Có thể tìm thấy thông tin trên nhãn thiết bị. Theo chính sách liên tục phát triển sản phẩm của Electrolux ; thông số kỹ thuật, màu sắc và chi tiết sản phẩm của chúng tôi và những thông tin đề cập trong hướng dẫn sử dụng này có thể thay đổi mà không cần thông báo.
