- Page 1 OWNER’S MANUAL & OPERATING INSTRUCTIONS 3,000 lb. WINCH MODEL NUMBER 100124 12039 Smith Ave. SAVE THESE INSTRUCTIONS Santa Fe Springs CA 90670 Important safety instructions MADE IN CHINA USA / 1-877-338-0999 are included in this manual. REV 100124-20160606 www.championpowerequipment.com...
-
Page 2: Visit Our Website
Have questions or need assistance? Do not return this product to the store! WE ARE HERE TO HELP! Visit our website: www.championpowerequipment.com for more info: • Product Info & Updates • Tech Bulletins • Frequently Asked Questions • Product Registration –... -
Page 3: Table Of Contents
100124 3,000 lb. WINCH TAblE Of CONTENTS . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
INTRODUCTION Introduction Congratulations on your purchase of a Champion Power Equipment product . Champion Power Equipment and Champion Engine Technology designs, builds, and supports all of our products to strict specifications and guidelines . With proper product knowledge, safe use, and regular maintenance, this product should bring years of satisfying service . -
Page 5: Manual Conventions
100124 ENGLISH MANUAl CONVENTIONS This manual uses the following symbols to help differentiate between different kinds of information . The safety symbol is used with a key word to alert you to potential hazards in operating and owning power equipment . -
Page 6: Safety Rules
ENGLISH 100124 SAfETy RUlES WARNING WARNING Read this manual thoroughly before operating Do not use the winch to secure or hold a your winch . Failure to follow instructions could vehicle for a long period of time . Do not use result in serious injury or death . - Page 7 100124 ENGLISH SAfETy RUlES WARNING CAUTION When re-spooling the cable, ensure that the Duration of winching pulls should be kept as cable spools in the under-wind position with short as possible . the cable entering the drum from the bottom, If the motor becomes uncomfortably hot to not the top .
-
Page 8: Controls And Features
ENGLISH 100124 CONTROlS AND fEATURES Read this owner’s manual before operating your winch . Familiarize yourself with the location and function of the controls and features . Save this manual for future reference . Winch Motor - 1 .3 HP/1 kW 12V DC motor provides Wire Rope - 3/16 in . -
Page 9: Assembly
100124 ENGLISH ASSEMbly Assembling the Winch Mounting the Winch This winch kit is designed to be used in 2 1 . Insert M10x20 bolts through the mounting different applications: channel holes and attach the roller fairlead to 1)Plate Mount the mounting channel with the M10 lock nuts 2)Mobile provided .(A) -
Page 10: Operation
Self Recovery Locate a suitable anchor such as a strong tree trunk Your 100124 winch is rated at a 3,000 lb . or boulder . Always use a sling as an anchor point . (1,361 kg) capacity in first layer (max) when spooling the first rope layer on the drum . -
Page 11: Winching Techniques A-Z
100124 ENGLISH OPERATION Winching Techniques A-Z Winching Techniques A-Z Cont’d. (a) Take time to assess your situation and plan (p) The vehicle to be winched should be placed your pull . in neutral and the emergency brake released . (b) Put on gloves to protect your hands . -
Page 12: Floating Winching Technique
ENGLISH 100124 OPERATION Operatio “floating” Winch Technique floating Winch Technique Cont’d. Operatio A “Floating” winch technique means that the (5) Follow steps 3-4 for second mounting 4. Now follow steps A-Z on the previous “Floating” Winch Techniques winch and mounting plate are not bolted to the channel hole, D-shackle and rope sling . -
Page 13: Maintenance
100124 ENGLISH MAINTENANCE lubrication The owner/operator is responsible for all periodic maintenance . All moving parts within the electric winch having been lubricated using high temperature lithium WARNING grease at the factory . No internal lubrication is required . Lubricate cable assembly periodically Never operate a damaged or defective winch . -
Page 14: Troubleshooting
ENGLISH 100124 TROUblESHOOTING Problem Cause Solution Loose battery cable connections Tighten nuts on all cable connections Defective switch assembly Replace switch assembly Check for voltage at armature port with switch Motor does not turn on Defective motor pressed . If voltage is present, replace motor Allow to drain and dry . -
Page 15: Specifications
100124 ENGLISH SPECIfICATIONS Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -
Page 16: Parts Diagram
ENGLISH 100124 SPECIfICATIONS Parts Diagram... -
Page 17: Parts List
100124 ENGLISH Parts list Part Number Description Part Number Description 300100-BF Motor - Black Flat Cable Assembly - 300700 4 .8mm(D) x 14m(L) Stationary Gear Housing 300200-BF Assembly - Black Flat C20002 1/4 in . Clevis Hook 300025-N Support Ring... -
Page 18: Other Exclusions
Accessory parts such as starting batteries, and storage Warranty Qualifications covers. Champion Power Equipment (CPE) will register this warranty – Failures due to acts of God and other force majeure upon receipt of your Warranty Registration Card and a copy events beyond the manufacturer’s control.
