Page 2
1. Package Content To check your device and the accessories after unpacking: xCE_E200I Power adaptor & cord Cash Drawer cable 2. Before Starting Open the cable compartment cover behind the stand of terminal and find the power input on the rear side of xCE_E200I (Figure 1, marked by red circle).
Page 3
Input: 100-240Vac 50/60Hz Output: 24V DC, 2.5A (Use only the AC adapter approved and provided by XAC Automation Corporation for use with this device. Use of any other AC adapter may cause a risk of fire or explosion) ■ Operating Temperature: 0 °C to 40 °C ■...
Page 4
3. Powering On Terminal Plug the power adaptor connector into the power jack of E200-I(as shown in Figure 1) and plug the power cord into a surge suppressor (recommended) or a wall socket to boot up the device 4. Using Magnetic Card Reader Secure Magnetic Card Reader is located at the right side of terminal.
Page 5
5. Customer facing display (Optional) xCE_200I provides a 5” shopper display as option for the clients to see the payment amount and the information or the ads at the cashier. (Figure 3) (Figure 3) 6. Fitting the view angle of display The design of xCE_E200I stand is flexible for each user to find his/her best view angle to operate the touch display.
Page 6
7. Guidelines to properly CLEAN your LCD screens Turn your display off and allow it to cool. Make sure your cloth is clean and free of any grit before starting. Spray a liberal amount of the cleaning solution onto one portion of the cloth Using light pressure, wipe the screen to evenly distribute the solution on the screen.
Page 7
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC for Part68: for xCE_E200I models with modem function. xCE_E200I-15YXF, xCE_E200I-15YXX ID NO. US: N7KMM01B200I15YXF; FCC REQUIREMENTS This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA.
Page 8
XAC Automation Corporation. XAC AUTOMATION CORP. shall not be held liable for technical and editorial omissions or errors made herein; nor for incidental or consequential damages resulting from the furnishing, performance or use of his material.
