Epic GZFI8043.1 Owner's Manual

Leg press
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No. GZFI8043.1
Serial No.
Write the serial number in the
space above for future reference.
Serial Number
Decal
(inside tower)
Q
UESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
OWNER'S MANUAL
Visit our website at
www.freemotionfitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GZFI8043.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Epic GZFI8043.1

Summary of Contents for Epic GZFI8043.1

  • Page 1 Model No. GZFI8043.1 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (inside tower) OWNER’S MANUAL UESTIONS? At FreeMotion Fitness, we are committed to providing com- plete customer satisfaction. If you have questions, see HOW...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 WARNING DECAL PLACEMENT .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the strength machine. 1. Read all instructions in this manual before 9. All users of the strength machine should be using the strength machine. Use the strength instructed to report any injury or strength machine only as described in this manual.

  • Page 4: Warning Decal Placement

    WARNING DECAL PLACEMENT The decals shown below have been placed on the strength machine in the indicated locations. If a decal is missing or illegible, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual to order a free replacement decal.

  • Page 5: Before You Begin

    The model innovative features and quality construction provide a number is GZFI8043.1. The serial number can be found reliable product for your club. And the advanced solu- on a decal attached to the strength machine (see the tions to isolating individual muscle groups make the front cover of this manual).

  • Page 6: Adjustments

    ADJUSTMENTS This section explains how to adjust the strength machine. Make sure all parts are properly tightened each time the strength machine is used. Replace any worn parts immediately. ADJUSTING THE RESISTANCE To change the amount of resistance for your workout, insert the weight pin into the desired weight.

  • Page 7: Maintenance

    MAINTENANCE For safe and trouble-free operation of your EPIC STRENGTH strength equipment, it is important to perform preventive maintenance on a regular basis. Make sure that all parts are properly tightened each time the strength machine is used. Replace any worn parts immediately. The strength machine can be cleaned with a cloth damp- ened with water and a mild, non-abrasive soap.
  • Page 8 3. Belts: MONTHLY • Run your fingers along the belt, paying close 1. Grips: attention at the bends and attachment points. • Watch for the following conditions, which may • Check and replace as needed. indicate a worn belt in need of replacement: A.
  • Page 9 CUSHION ATTACHMENT CABLE GUARDS Important: All EPIC STRENGTH cushions are fabri- Check for alignment periodically to ensure that cable cated using dense plywood with tee-nuts installed for guards are not rubbing on the cable and that they are bolting to the machine framework. Because these performing their intended duty.
  • Page 10 CABLE ADJUSTMENTS ADDITIONAL ADJUSTMENT Tower Pulley Adjustment– CAUTION: After making any cable adjustment, pull Tools required: 5/16" Allen wrench/hex key, 9/16" the leg lever using a light load and have someone open end wrench/spanner make sure that the cable is not derailed from a pul- ley or rubbing on a guard (see CABLE GUARDS on 1.
  • Page 11 SERVICING THE WEIGHT STACK 8. Replace the top weight and weight pin on top of the weight stack. 9. Reattach the cable to the top weight coupler. For required parts, see HOW TO CONTACT CUS- 10. Clean and lubricate the guide rods by wiping TOMER CARE on the back cover of this manual.

  • Page 12: Cable Diagram

    CABLE DIAGRAM The diagrams shows the proper route of the belt and cable. Use the diagram to make sure that the belt, the cable, and the cable guards have been assembled correctly. If the belt or cable has not been correctly routed, the strength machine will not function properly and damage may occur.

  • Page 13: Part List

    PART LIST—Model No. GZFI8043.1 R0405A If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual. Key No. Qty. Description Key No. Qty. Description Key No. Qty.

  • Page 14: Exploded Drawing

    EXPLODED DRAWING A—Model No. GZFI8043.1 R0405A...
  • Page 15 EXPLODED DRAWING B—Model No. GZFI8043.1 R0405A...

  • Page 16: How To Contact Customer Care

    Please be prepared to give the following information: • The MODEL NUMBER of the product (GZFI8043.1). • The NAME of the product (EPIC STRENGTH LEG PRESS strength machine). • The SERIAL NUMBER of the product (see the front cover of this manual).
