- Page 1 USER MANUAL FOR MORE INFORMATION Visit us online at force1rc.com for product information, replacement parts and flight tutorials.
- Page 3 ATTENTION: BEFORE FLYING YOUR DRONE, PLEASE WATCH THIS FLIGHT INSTRUCTION VIDEO. https://youtu.be/tk3qzsUwoWs...
-
Page 4: Table Of Contents
FORCE1 RC CONTENTS Welcome & Safety Precautions ···································· 3 Li-Po Battery Care ························································ 4 Charging Instructions for Drone Battery ······················· 5 Box Contents & Drone Overview ································· 6 Transmitter Overview & Battery Installation ················· 7 Drone Assembly ··························································· 8 Quick Start Guide ······················································· 10 Preflight Checklist ·······················································... -
Page 5: Welcome & Safety Precautions
F100 GHOST User Manual WELCOME! Welcome to the Force1 Team, and thank you for your Force1 drone purchase. Please read this manual carefully before drone operation. (1) This drone is not a toy! It’s a pro-level drone suitable for experienced RC drone users aged 14 years and older. -
Page 6: Li-Po Battery Care
FORCE1 RC LI-PO BATTERY CARE Avoid Overheating Your batteries will sometimes be warm/hot to the touch after use. This is normal, but beware that battery components will fail if not allowed to cool down between uses. Also, do not leave batteries exposed to direct sunlight. -
Page 7: Charging Instructions For Drone Battery
F100 GHOST User Manual CHARGING INSTRUCTIONS FOR DRONE BATTERY 1. Plug in the charger – the charger light will turn green. 2. Connect the charger power line to the battery – red charger indicator turns green when fully charged. LI-PO BATTERY DISPOSAL & RECYCLING Do not put lithium-polymer batteries in household trash. -
Page 8: Box Contents & Drone Overview
FORCE1 RC BOX CONTENTS DRONE TRANSMITTER 2 X 7.4V 1800MAH LI-PO BATTERY PROPELLERS (4) 2 EXTRA COVERS HIGH LANDING GEARS DRONE TOOLS PROPELLER GUARDS (4) ACTION CAMERA CAMERA MOUNT BALANCE CHARGER DRONE OVERVIEW FRONT B PROPELLER A PROPELLER COUNTER-CLOCKWISE CLOCKWISE LEFT RIGHT B PROPELLER... -
Page 9: Transmitter Overview & Battery Installation
F100 GHOST User Manual TRANSMITTER OVERVIEW UNLOCK (SHORT-PRESS) FLIP AND ROLL BUTTON LOCK (LONG-PRESS) PHOTO (SHORT-PRESS)/ VIDEO (LONG-PRESS) LOW/HIGH SPEED SWITCH (SHORT-PRESS) (APPLICABLE WHEN LIGHT SWITCH (LONG-PRESS) CAMERA IS CONNECTED) POWER SWITCH POWER INDICATOR THROTTLE/RUDDER STICK DIRECTION CONTROL STICK TURN LEFT/RIGHT TRIMMER... -
Page 10: Drone Assembly
FORCE1 RC DRONE ASSEMBLY PROPELLERS INSTALLATION/REMOVAL INSTALLATION Install propeller A and B on the corresponding motor shaft and fix them tightly by rotating as per the “lock” direction shown on the propellers. Propellers and drone arms are labeled A or B (Fig. 1). REMOVAL Hold the brushless motor with the rotor blade changing tool;... -
Page 11: Battery Installation
F100 GHOST User Manual HIGH LANDING GEAR INSTALLATION Insert the high-landing gear plug into the socket located at the bottom of the drone, insert and tighten the large headed screws (Fig. 3). Repeat for all high landing gears. FIGURE 3 BATTERY INSTALLATION 1. -
Page 12: Quick Start Guide
FORCE1 RC QUICK START GUIDE Press the red button on top left of the transmitter while turning on the power (Fig. 6). The green light on the transmitter will start flashing. FIGURE 6 Insert the battery into the drone to power it on (Fig. 7). You will hear a long beep and the green light on the transmitter will stop blinking. -
Page 13: Preflight Checklist
F100 GHOST User Manual PREFLIGHT CHECKLIST 1. Fly in an open area and abide by all local and federal guidelines. Check the FAA’s B4UFLY mobile app for up-to-date drone flight info. 2. Make sure your drone and transmitter batteries are fully charged. -
Page 14: Locking/Unlocking
FORCE1 RC CALIBRATION CONTINUED... PAIR TRANSMITTER WITH THE DRONE 1. Press the red button on top left of the transmitter while turning on the power. The transmitter will emit one beep, and the green light will start flashing. This indicates that the transmitter is in connection mode. -
Page 15: Basic Flight Controls
F100 GHOST User Manual BASIC FLIGHT CONTROLS HOVER UP AND DOWN Push the THROTTLE/RUDDER STICK up to fly the drone up, and pull the THROTTLE/RUDDER STICK down to fly the drone down. FLY FORWARD OR BACKWARD Push the DIRECTION CONTROL STICK up to... - Page 16 FORCE1 RC FLIPS AND ROLLS FLIP AND ROLL BUTTON Press and hold the FLIP AND ROLL BUTTON, then use the DIRECTION CONTROL STICK, to choose the direction that you want your drone to roll. Pressing Forward will roll the drone forward, backward to roll back, left or right to roll left or right, respectively.
-
Page 17: Indicator Light Descriptions
F100 GHOST User Manual DRONE INDICATOR LIGHT DESCRIPTION STATUS DESCRIPTION Drone lights flashing Drone gyro is in signal-detection mode quickly FRONT INDICATOR LIGHTS Front lights flash twice Drone not receiving transmitter signal every 2 seconds Front lights flash once Transmitter signal getting lost... -
Page 18: Receiver Pcb Diagram
FORCE1 RC RECEIVER PCB CONNECTING DIAGRAM Make sure your Receiver PCB is properly connected to ensure your drone operates normally. Check the installation direction and connections based on the diagram below if needed. Front motor Rear motor A socket B socket Front side - + + - Rear indicator... -
Page 19: Basic Parts
F100 GHOST User Manual BASIC PARTS Upper Covers Main Frame Propeller Guards Bottom Landing Gear 0001 0002 0003 0004 Propellers A/B High Landing Gear LED Covers Battery Compartment 0005 0006 0007 0008 LED Strips Receiver PCB Clockwise Motor 0009 0010... -
Page 20: Upgrades
FORCE1 RC UPGRADES 360° Panoramic 5.8G FPV Camera Camera TROUBLESHOOTING PROBLEM SOLUTION The drone’s gyro is in signal-detection mode; set the drone on any Lights are flashing quickly flat surface to stabilize before pairing. Adjust all trimmer buttons to the middle value. Drone leans to one side after takeoff Set the drone on a flat surface and repeat calibration instructions. - Page 21 FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide residential protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not Installed and used in accordance with the instructions, may cause harmful interference to radio communications.
